Tenda 3G186R Manuel utilisateur

All For Better Networking

Mobile WiFi always with you

It's a 3G modem, also is a wifi n router

3G186R is a mobile wireless modem router designed for

business professionals and people who travel often. It's

developed based on WCDMA and IEEE802.11n

technologies. Just put a 3G-enabled sim card on it and it

becomes a 3G modem that provides up to speeds of

7.2Mbps downlink and 5.76Mbps uplink. It also acts as a

wireless n router, which allows you to share 3G

connection with up to 5 users. The unit gives you a true

freedom of connectivity with battery-powered, so you

can access to internet anywhere anytime.

One 3G connection, shared by multiple users

Just insert a SIM card to the 3G186R, it turns 3G connection into a

WiFi hotspot for sharing. It's very convenient if you're on the road

with your colleagues doing some projects. You won't be needing

5 different 3G modems.

Sleek and pocket design

The 3G186R is sleek with its size. It's so pocketable — it can easily fit in your jeans' pocket. It is

half the size of a regular phone. Also the unit is unlocked so you can use it with any WCDMA

network, so you can take it with you while travelling in any corner of the world.

Sleek and pocket design

The 3G186R is powered by a lithium ion battery, which enables you to do things like browsing

web, emailing and chatting for 3-4 hours. If you connect the unit to a laptop, it will be charging

and can still be used as a wifi router at the same time. When disconnecting from internet

connection, it enters standby mode to conserve battery life for 5-6 hours.

3G ModelNo 3G186R

Operating Enviroment

Operating Temperature 0? ~ 40?

Storage Temperature -30oC ~ 70oC

Operating Humidity 10% ~ 90% RH Non-condensing

Storage Humidity 10% ~ 90% RH Non-condensing

Minimum System Requirement

Computer with:

Internet Explorer 5.5 or Firefox 1.0 later

CD drive

Network Adapter

All For Better Networking

Product Features:

Tri-band 900/1800/2100MHZ

Supports IEEE 802.11n、IEEE 802.11g、

IEEE 802.11b

Supports WCDMA ,downlink 7.2Mbps,

uplink 5.76Mbps

Delivers wireless speeds of up to 150Mbps

Supports WPA-PSK、WPA2-PSK、

WPA&WPA2-PSK security encryptions

Supports up to 5 users

Provides customized traffic and time limit

to save your 3G service billing

Supports UPnP

Provides firewall to against malicious

attacks.

Provides syslog Tri-band

900/1800/2100MHZ

Supports IEEE 802.11n、IEEE 802.11g、

IEEE 802.11b

Supports WCDMA ,downlink 7.2Mbps,

uplink 5.76Mbps

Delivers wireless speeds of up to 150Mbps

Supports WPA-PSK、WPA2-PSK、

WPA&WPA2-PSK security encryptions

3G ModelNo 3G186R

Standards

802.11n, 802.11g, 802.11b,

WCDMA/GSM/HSPUA/HSPA

Band

900/1800/2100MHZ

Wireless Rate 150Mbps

Interface

1 Micro USB 2.0 interface for power charging

Button Power, Reset

LED

POWER/3G/WIFI/BATTERY

Antenna Internal 1T1R

Power

170-240 V

5V==1.2A

3G186R

Power Adapter

Quick Installation Guide

Lithium Battery

CD-ROM

Y-shaped USB Cable (Power over USB )

Package Contents

3 7V

BP-4L
