11N Wireless USB Adapter User Guide
-- 1 --
11N Wireless USB Adapter User Guide
Copyright Statement
is the registered trademark of
Shenzhen Tenda Technology Co., Ltd. All the products
and product names mentioned herein are the
trademarks or registered trademarks of their
respective holders. Copyright of the whole product as
integration, including its accessories and software,
belongs to Shenzhen Tenda Technology Co., Ltd.
Without the permission of Shenzhen Tenda Technology
Co., Ltd, any individual or party is not allowed to copy,
plagiarize, imitate or translate it into other languages.
All the photos and product specifications mentioned in
this guide are for references only. As the upgrade of
software and hardware, there will be changes. And if
there are changes, Tenda is not responsible for
informing in advance. If you want to know more about
our product information, please visit our website at
www.tenda.cn.
-- 1 --
11N Wireless USB Adapter User Guide
-- 2 --
Table of Content
Chapter 1 Introduction........................................3
1.1 Product Feature .......................................4
1.2 Product Deployment .................................5
1.3 Indicator Description ................................6
1.4 Package Contents.....................................6
Chapter 2 Installation Guide.................................7
Chapter 3 Client Utility Interface.........................12
3.1 Station Mode.........................................13
3.1.1 Station Mode Topology......................13
3.1.2 Status ............................................14
3.1.3 Site Survey .....................................15
3.1.4 Profile Management..........................16
3.1.5 Statistics.........................................18
3.1.6 WPS Setting ....................................18
3.2 AP Mode ...............................................20
3.2.1 AP Mode Topology ............................20
3.2.2 Basic Setting ...................................21
3.2.3 Security Setting...............................22
3.2.4 Access Control.................................23
3.2.5 About.............................................25
Appendix One: Acronyms and Terms ...................26
Appendix Two: Product Specification....................29
Appendix Three: How to connect with PSP............30
11N Wireless USB Adapter User Guide
Chapter 1 Introduction
W322U utilizes the latest wireless networking
technology, IEEE802.11n (Draft 2.0), and can be
greatly compatible backwards with 802.11b/g
standards, Provides 300Mbps receiving rate and
300Mbps sending rate, which multiples wireless
transmission range and reduces “dead spots” in the
wireless coverage area.
Soft AP supported by W322U can help you establish
wireless LAN networking fastly. Besides, WPS (Wi-Fi
Protected Setup) encryption methods can free you
from remembering the long passwords. Moreover,
complete WMM support makes your voice and video
more smooth. Especially supporting PSP, NDS and WII
connections with Xlink Kai will be your best choice to
enjoy on-line gaming.
All in all, W322U is a cost-effective Wireless-N USB
Adapter with high-performance and further wireless
coverage.
-3-
11N Wireless USB Adapter User Guide
1.1 Product Feature
Complies with IEEE 802.11n (Draft 2.0), IEEE
802.11g and IEEE 802.11b standards
Provides USB2.0 port
Provides 300Mbps receiving rate and 300Mbps
sending rate
Supports 20MHz/40MHz frequency width
Auto-detects and changes the network
transmissionrate
Provides two work modes: Infrastructure and
Ad-Hoc
Supports Soft AP to establish your wireless
LAN networking
supports PSP, WII and NDS connecting with
InternetandXlinkKaitoenjoyon-linegaming
Supports 64/128-bit WEP, WPA, WPA2
encryption methods and 802.1x security
authentication standard
Supports WPS (Wi-Fi Protected Setup)
encryption method to free you from
remembering long passwords
-4-
11N Wireless USB Adapter User Guide
Supports WMM to make your voice and video
more smooth
Easy-to-install, plug and play
1.2 Product Deployment
W322U Wireless USB Adapter offers fast,
reliable and cost- effective solution for
wireless access. Deployment as follows;
For staff who requires higher mobility in the
office, they want to have access to traditional
wired or wireless network in any place of the
company;
Enterprise or individual who requires often
changes in lay out of network cables;
Companies or places which are not suitable for
LAN cable laying out because of budget or
objective building, including places of great
interests, rent places or places for short-term
-5-
11N Wireless USB Adapter User Guide
usage;
Company or individual who avoids using
expensive cables, renting cables or renting
rights for access.
1.3 Indicator Description
In the front panel of W3111U, there is a LED indicator
blinking when data communication is going on.
1.4 Package Contents
Unpack the packets, and please find the following
items:
One W322U 11N Wireless USB Adapter
One CD-ROM
One Quick Installation Guide
-6-
11N Wireless USB Adapter User Guide
Chapter 2 Installation Guide
This chapter is to assist you how to use the included
CD-ROM which comprises the Setup Wizard and the
Client Utility Interface.
The following steps on Setup Wizard are taken the
Windows XP as example.
1. Please insert the Wireless USB Adapter into the
USB port of your computer.
2. “Found New Hardware” system dialogue appears,
and selects “Cancel” to use the included Setup
Wizard for fast installation; of course, you also can
select “Next” to install by manual.
-7-
11N Wireless USB Adapter User Guide
3. Inert the included CD-ROM into the CD-ROM
drive of your computer, and the Welcome screen
appears. (If not appear, double click the
“Setup.exe” icon.)
-8-
11N Wireless USB Adapter User Guide
4. Click “Enter”.
5. Click “Next” to start installing.
-9-
