Tempmate C1 Manuel utilisateur

empower your supply chain.

V1.0-08/2023-EN · Technical Changes and Errors excepted 3

1. Intended Use ...........................................................................................................................................................................................3

2. Device Description ................................................................................................................................................................................4

3. Display ...................................................................................................................................................................................................... 5

4. Operation and Use ................................................................................................................................................................................6

 Conguration................................................................................................................................................................................6

 Startlogger..................................................................................................................................................................................6

Set mark .................. .....................................................................................................................................................................7

 Temporaryevaluation...............................................................................................................................................................8

 Stoplogger....................................................................................................................................................................................8

 Evaluation......................................................................................................................................................................................8

5. Important Notes ....................................................................................................................................................................................9

6.MainTechnicalSpecicationstempmate.®-C1.....................................................................................................................10

7. Contact Information...........................................................................................................................................................................12

Contents

1. Intended Use

Thetempmate.®-C1isasingle-usetemperaturedata

loggerspecicallydesignedtomonitortemperaturedu-

ringtransportationofproductsthatmustbestoredat

extremelylowtemperatures.Anyuseoroperationthat

requiresspecicrequirementsandstandardsnotspe-

cicallymentionedinthedatasheetmustbevalidated

andtestedatthecustomer‘sownresponsibility.

empower your supply chain.

V1.0-08/2023-EN · Technical Changes and Errors excepted 5

1RecordingStatus

2Mark

3Battery Level

4AlarmLevel

5Password Protection

6MeasurementValue

7TemperatureUnit,TimeUnit

8Max.Value,Min.Value,AverageValue

9AlarmStatus

10 Start Delay

11 Reuse–canbeusedforseveralcampaigns

12StopButtonInvalid

2. Device Description 3. Display

USB Port

StartButton

StopButton

- Toscrollthroughthemenu,pressthegreenstartbuttonseveraltimesinquicksuccession.

- Thedisplaychangesfromthecurrenttemperaturedisplayrsttothemaximumrecorded

 temperaturevalue,thentotheminimumandnallytotheaveragevalueofthecurrentrecording.

- Pressingthebuttonagaintakesyoubacktothecurrenttemperaturedisplay.

- Todisplaytheremainingusagetimeofthedevice,presstheredstopbutton.Theeffective

 recordingtimedependsontheselectedmeasuringinterval.

Important:Thetotalrunningtimeof90dayswith24hourseachwillbedeductedperhourafterthestart

Menunavigation

empower your supply chain.

V1.0-08/2023-EN · Technical Changes and Errors excepted 7

4. Operation and Use

STEP1Conguration*optional

Thisstepisonlynecessaryifyouwanttoadjustthepre-installedcongurationtoyourapplication.

- Downloadthefreetempbase.-Cryosoftware.

https://www.tempmate.com/de/download/

- Installthetempbase.-CryosoftwareonyourPC.

- RemovethecapandconnecttheunbootedloggertoyourPC.

- Openthetempbase.-Cryosoftware.Thecongurationscreenisdisplayeddirectly.

- Makethedesiredsettingsandsavethemviathemenuitem„SaveParameter“(1) ontoyourdevice.

- RemovetheloggerfromyourPCandreplacethecapsecurely.

STEP2Startlogger(manually)

- Pressandholdthegreenstartbuttonfor5seconds.

- Asuccessfulstartisindicatedby

bEGn

onyourdevicedisplay.

Important:Ifadifferentsignalornosignalappears,donotusetheloggerandcontactoursupportvia

suppor[email protected].Thedevicedisplayisdisableduntilthedevicehasbeensuccessfullystarted.

Alternativestartmodes

Startviasoftware(optional)

 o Thissettingcanbemadeinthetempbase.-Cryosoftware.

  (seeSTEP1)

 o ThestartistriggeredautomaticallyassoonasthedeviceisdisconnectedfromthePC.

Important:Amanualstartisnotpossiblewiththisconguration.

Timedstart:(optional)

o Thissettingcanbemadeinthetempbase.-Cryosoftware.

  (seeSTEP1)

 o Thedevicewillstartaccordingtothetimesetinthecongurationsoftware.

Important:Amanualstartisnotpossibleinthisconguration.

Important:Whensettingastartdelay,thedisplayshowsacountdownoftheselectedtimeperiod.

STEP 3 Set mark

- Pressthegreenstartbuttontwiceinquicksuccession.

- Assoonasthedevicerecordsthemarking,thesymbolappears..

- Oncethesymboldisappears,themarkingprocessiscompleted.

Important:Onlyonemarkispossiblepermeasuringinterval.

*Example

empower your supply chain.

V1.0-08/2023-EN · Technical Changes and Errors excepted 9

STEP6Evaluation

- ConnectthestoppedloggertoyourPC.

- Thedisplaywillshow

PdF

and/or

CSu

toindicatethattherespectivereportsarebeinggenerated.

- Oncethereportisgenerated,thedisplaywillshow

USb

- TheloggercannowbedisconnectedfromthePC.

Important:Alwaysmakesurethatthisstepisperformedbeforerestartingthedevice.Ifthedeviceisrestarted,

allolddatawillbeoverwritten.

STEP4TemporaryEvaluation

- ConnectyourstartedorpauseddevicetoyourPC.

- Atemporaryreportwillbegeneratedautomatically.

- SaveyourreportandremovetheloggerfromyourPCagain.

Important: IfyouconnecttheloggertoyourPCinthestartedmode,therecordingwillcontinuealsointhis

moment.Inordertobeabletoassignanyuctuationsinyourmeasurementresults,weadviseyoutoseta

markbeforeandafterthetemporaryreadout(seeSTEP3).

STEP 5 StopLogger(manual)

- Pressandholdtheredstopbuttonfor5seconds.

- Thedisplayswitchesoffafterasuccessfulstop.

Important: Inthestoppedstate,ashortpressofanykeyissucienttoviewthemax.,min.andaveragevalue

ofthelastrecording.

Important:Thedevicestopsautomaticallywhenthememoryisfull.

Alternativestopmodes

StopbySoftware(optional)

o Openthetempbase.-Cryosoftwareandconnectyourunstoppedtempmate.®-C1toyourPC.

 (seeSTEP1)

o Selectthe„Stoprecording“menuitemtostopthedevice.

5. Important Notes

- Iftheiconisdisplayedonthescreen,theloggerneedstoberecongured

- Whenisdisplayedonthescreen,itmeansthatthebatteryleveloftheloggeristoolowtorecord

 formorethananother10days.

- Iftheiconisdisplayed,thelogger‘sbatteryistoolowtorecord.

- Thecongurationofyourdevicecannotbechangedduringrecording.

- Alwaysdisposeofbatteriesaccordingtoyourcountry‘sregulations.

- Donotplacethedeviceincorrosiveliquidsorexposeittodirectheat.

empower your supply chain.

V1.0-08/2023-EN · Technical Changes and Errors excepted 11

MainTechnicalSpecicationstempmate.®-C1

Model DryIce/LowTemperatureDataLogger

PartNumber TC1-000

Usage Single-Use/MultiStart/Stopwithin90dayspossible

TemperatureRange -90°Cto+70°C

Accuracy ±0.5°C(-30°Cto+70°C)±1.0°C(others)

Resolution 0.1°C

Memory Capacity 20.000ReadingsusingPDF&CSV(default)

35.000ReadingsusingPDFonly(optional)

Connection USB

Indication LCD

Battery 3.6VLithiumBattery

Runtime Max.90days

Dimensions 96mm(L)*44mm(W)*15mm(H)

IP Protection IP65

Mark Max. 9 points

Alarm Max. 6 points

LoggingInterval 1minute-24hours

Start Delay 1minute-24hours

ReportFormat PDF/CSV

Software Freetempbase-CryoSoftwareforWindowssystems

Certications CE,RoHs,EN12830,RTC-DO160

Shelf-Life 2 Years

empower your supply chain.

V1.0-08/2023-EN · Technical Changes and Errors excepted 13

Doyouhaveanyquestions?Pleasecontactus-our

experiencedteamwillbehappytosupportyou.

[email protected]

+49713163540

Contact Information

tempmateGmbH

Wannenäckerstr. 41

74078Heilbronn,Germany

Tel.+49-7131-6354-0

[email protected]

www.tempmate.com
