Teltonika TFT100 Guide d'installation

Quick Manual

E-Forklift Tracker

TFT100


2
TFT100 | Wiki
Table of Contents
Table of Contents..................................................................................2
Know your device..................................................................................3
Pinout ........................................................................................................................ 4
Set up your device.................................................................................5
How to insert Micro-SIM card and connect the battery......................... 5
How to install USB drivers (Windows) ........................................................... 6
PC Connection (Windows) ................................................................................. 6
Configuration (Windows) ................................................................................... 6
Quick SMS configuration.................................................................................... 8
Mounting recommendations...............................................................9
LED indications ....................................................................................10
Characteristics .....................................................................................10
Basic characteristics............................................................................................10
Electrical characteristics ....................................................................................11
Safety information..............................................................................12
Certification and Approvals ...............................................................13


TFT100 | Wiki

Know your device

Figure 1 TFT100 device view

TFT100 | Wiki

Pinout

Table 1 TFT100 pinout

Pin color

CAN Pin

name

CAN Description

RS232 Pin

name

RS232 Description

RS485 Pin

name

RS485

Description

UART Pin

name

UART Description

Red

VCC (10-97) V

DC (+)

Power supply

(+10…+97 V DC)

VCC (10-97) V

DC (+)

Power supply

(+10…+97 V DC)

VCC (10-97)

V DC (+)

Power supply

(+10…+97 V DC)

VCC (10-97) V

DC (+)

Power supply

(+10…+97 V DC)

Black

GND (-)

Ground

GND (-)

Ground

GND (-)

Ground

GND (-)

Ground

Yellow

1-Wire Power

+3,8 V output for

1-Wire devices

1-Wire Power

+3,8 V output for

1-Wire devices

1-Wire

Power

+3,8 V output for

1-Wire devices

1-Wire Power

+3,8 V output for

1-Wire devices

White/Green

CAN-H

CAN interface High

RS232-IN

Input wire for RS232

RS485-B

Signal Wire B for

RS485

UART-RX

Input for data

reception through

UART

White

CAN-L

Can interface Low

RS232-OUT

Output wire for

RS232

RS485-A

Signal wire A for

RS485

UART-TX

Output for data

transmission through

UART

Grey

AIN2/DIN2

Analog input,

channel 2 / Digital

output, channel 2

AIN2/DIN2

Analog input,

channel 2 / Digital

output, channel 2

AIN2/DIN2

Analog input,

channel 2 / Digital

output, channel 2

AIN2/DIN2

Analog input, channel

2 / Digital output,

channel 2

White/Orange

DOUT1/DIN3

Digital output,

channel 1 / Digital

input, channel 3

DOUT1/DIN3

Digital output,

channel 1 / Digital

input, channel 3

DOUT1/DIN3

Digital output,

channel 1 / Digital

input, channel 3

DOUT1/DIN3

Digital output,

channel 1 / Digital

input, channel 3

Violet

DOUT2/DIN4

Digital output,

channel 2 / Digital

input, channel 4

DOUT2/DIN4

Digital output,

channel 2 / Digital

input, channel 4

DOUT2/DIN4

Digital output,

channel 2 / Digital

input, channel 4

DOUT2/DIN4

Digital output,

channel 2 / Digital

input, channel 4

Green

AIN1/DIN1

Analog input,

channel 1 / Digital

input, channel 1

AIN1/DIN1

Analog input,

channel 1 / Digital

input, channel 1

AIN1/DIN1

Analog input,

channel 1 / Digital

input, channel 1

AIN1/DIN1

Analog input, channel

1 / Digital input,

channel 1

Blue

1-Wire Data

Data channel for 1-

Wire devices

1-Wire Data

Data channel for 1-

Wire devices

1-Wire Data

Data channel for 1-

Wire devices

1-Wire Data

Data channel for 1-

Wire devices

TFT100 | Wiki

Set up your device

How to insert Micro-SIM card and

connect the battery

1. Unscrew 6 screws counter-clockwise that are located on the

bottom of the device.

2. Remove the cover.

3. Insert Micro-SIM card as shown with PIN request disabled or

read Security info how to enter it later in Configurator. Make sure

that Micro-SIM card cut-off corner is pointing forward to slot.

4. Connect battery as shown to device.

5. After configuration, see “PC Connection (Windows)”, attach device

cover back and screw in all screws.

6. Device is ready to be connected.

Figure 4 Unscrew screws

Figure 5 Cover removal

Figure 3 Micro-SIM card insert

Figure 2 Battery connection

Figure 6 Attaching cover back

Figure 7 Device is ready

TFT100 | Wiki

How to install USB drivers

(Windows)

1. Please download COM port drivers from here.

2. Extract and run TeltonikaCOMDriver.exe.

3. Click Next in driver installation window.

4. In the following window click Install button.

Setup will continue installing the driver and eventually the

confirmation window will appear. Click Finish to complete the setup.

PC Connection (Windows)

1. Power-up TFT100 with DC voltage (10 –97 V) power supply using

power cable. LED’s should start blinking, see “LED indications”.

2. Connect device to computer using Micro-USB cable or Bluetooth

connection:

•Using Micro-USB cable

▬You will need to install USB drivers, see “How to install USB

drivers (Windows)”

•Using Bluetooth

▬TFT100 Bluetooth is enabled by default. Turn on Bluetooth

on your PC, then select Add Bluetooth or other device >

Bluetooth. Choose your device named –

“TFT100_last_7_imei_digits”, without LE in the end. Enter

default password 5555, press Connect and then select

Done.

3. You are now ready to use the device on your computer.

Configuration (Windows)

At first TFT100 device will have default factory settings set. These

settings should be changed according to the user's needs. Main

configuration can be performed via Teltonika Configurator software.

Get the latest Configurator version from here.Configurator operates

on Microsoft Windows OS and uses prerequisite MS .NET Framework.

Make sure you have the correct version installed.

Table 2 MS .NET requirements

MS .NET requirements

Operating

system

MS .NET Framework

version

Version

Links

Windows Vista

Windows 7

Windows 8.1

Windows 10

MS .NET Framework

4.6.2

32 and 64 bit

www.microsoft.com

Downloaded Configurator will be in compressed archive. Extract it

and launch Configurator.exe. After launch software language can be

changed by clicking in the right bottom corner (Figure 8 Language

selection).

TFT100 | Wiki

Configuration process begins by pressing on connected device (Figure

9 Device connected via USB).

After connection to Configurator Status window will be displayed

(Figure 10 Configurator Status window).

Various Status window tabs display information about GNSS,GSM,

I/O, Maintenance and etc. TFT100 has one user editable profile, which

can be loaded and saved to the device. After any modification of

configuration the changes need to be saved to device using Save to

device button. Main buttons offer following functionality:

1. Load from device –loads configuration from device.

2. Save to device –saves configuration to device.

3. Load from file –loads configuration from file.

4. Save to file –saves configuration to file.

5. Update firmware –updates firmware on device.

6. Read records –reads records from the device.

7. Reboot device –restarts device.

8. Reset configuration –sets device configuration to default.

Most important configurator section is GPRS –where all your server

and GPRS settings can be configured and Data Acquisition –where

data acquiring parameters can be configured.

More details about TFT100 configuration using Configurator can be

found in our Wiki.

Figure 8 Language selection

Figure 10 Configurator Status window

Figure 9 Device connected via USB

TFT100 | Wiki

Quick SMS configuration

Default configuration has optimal parameters present to ensure best

performance of track quality and data usage.

Quickly set up your device by sending this SMS command to it:

Note: Before SMS text, two space symbols should be inserted.

GPRS settings:

•

2001

–APN

•

2002

–APN username (if there

are no APN username, empty

field should be left)

•

2003

–APN password (if there

are no APN password, empty

field should be left)

Server settings:

•

2004

–Domain

•

2005

–Port

•

2006

–Data sending protocol (0

–TCP, 1 –UDP)

Default configuration settings

Movement and ignition detection:

Vehicle movement will

be detected by

accelerometer

Ignition will be detected

by vehicle power voltage

between 10 –97 V or

CAN

Device makes a record On Moving if one of these events happen:

300 seconds passes

Vehicle turns 10 degrees

Vehicle drives 100

meters

Speed difference between

last coordinate and

current position is greater

than 10 km/h

Device makes a record On Stop if:

1 hour passes while

vehicle is stationary and

ignition is off

Records sending to server:

If device has made a

record it is sent to the

server every 120

seconds

After successful SMS configuration, TFT100 device will synchronize

time and update records to configured server. Time intervals and

default I/O elements can be changed by using Teltonika

Configurator or SMS parameters.

" setparam

2001

:APN;

2002

:APN_username;

2003

:APN_password;

2004

:Domain;

2005

:Port;

2006

;0"

TFT100 | Wiki

Mounting recommendations

•Connecting wires

▬Wires should be fastened to stable wires or other non-moving

parts. Any heat emitting and/or moving objects should be kept

away from the wires.

▬There should be no exposed wires. If factory isolation was

removed while connecting the wires, the isolation material

should be applied.

▬If the wires are placed in the exterior or in places where they

can be damaged or exposed to heat, humidity, dirt, etc.,

additional isolation should be applied and the wires should not

be loose.

▬Wires cannot be connected to the board computers or control

units.

•Connecting power source

▬Be sure that after the car computer goes to sleep mode, power

might be still available on the power wires. Depending on the

car model, this may happen in 5 to 30 minutes period.

▬When the module is connected, measure the voltage again to

make sure it did not decrease.

▬It is recommended to connect to the main power cable in the

fuse box.

•Connecting ground wire

▬Ground wire is connected to the vehicle frame or metal parts

that are fixed to the frame.

▬If the wire is fixed with the bolt, the loop must be connected to

the end of the wire.

▬For better contact scrub paint from the spot where loop is

going to be connected.

PAY ATTENTION! Connecting the power supply must be

carried out in a very low impedance point of on-board vehicle

network. Connecting the GND at an arbitrary point to the

mass of the car is unacceptable, as static and dynamic

potentials on the line GND will be unpredictable, which can

lead to unstable TFT100 operation and even its failure.

TFT100 | Wiki

LED indications

Table 3 Navigation LED indications

Table 4 Status LED indications

Behaviour

Meaning

Blinking every second

Normal mode

Blinking every two seconds

Sleep mode

Blinking fast for a short time

Modem activity

Off

Device is not working or device is in

boot mode

Characteristics

Basic characteristics

Table 5 Basic characteristics

Module

Name

TM2500

Technology

GSM, GPRS, GNSS, BLUETOOTH 4.0 +

GNSS

GPS, GLONASS, GALILEO, BEIDOU,

SBAS, QZSS, DGPS, AGPS

Receiver

33 channel

Tracking sensitivity

-165 dBM

Accuracy

< 3 m

Hot start

< 1 s

Warm start

< 25 s

Cold start

< 35 s

Cellular

Technology

GSM

2G bands

Quad-band 850 / 900 / 1800 / 1900

MHz

Data transfer

GPRS Multi-Slot Class 12 (up to 240

kbps), GPRS Mobile Station Class B

Data support

SMS (text/data)

Behaviour

Meaning

Permanently switched on

GNSS signal is not received

Blinking every second

Normal mode, GNSS is working

Off

GNSS is turned off because: device is

not working or device is in sleep mode

Blinkling fast constantly

Device firmware is being flashed

Autres manuels pour TFT100

Table des matières

Autres manuels Teltonika GPS

Teltonika

Teltonika Telematics FMC150 Manuel utilisateur

Teltonika

Teltonika TAT140 Guide d'installation

Teltonika

Teltonika FMC230 Guide d'installation

Teltonika

Teltonika FMB920 Manuel utilisateur

Teltonika

Teltonika FMM80A Guide d'installation

Teltonika

Teltonika TFT100 Guide d'installation

Teltonika

Teltonika Telematics FTC881 Manuel utilisateur

Teltonika

Teltonika Telematics FTC921 Manuel utilisateur

Teltonika

Teltonika Telematics FMB150 Manuel utilisateur

Teltonika

Teltonika FMB208 Guide d'installation

Teltonika

Teltonika GH5200 Guide d'installation et d'utilisation

Teltonika

Teltonika FMA120 Manuel utilisateur

Teltonika

Teltonika FMB002 Manuel utilisateur

Teltonika

Teltonika GH3000 Manuel utilisateur

Teltonika

Teltonika TST100 Manuel utilisateur

Teltonika

Teltonika FMM880 Manuel utilisateur

Teltonika

Teltonika FM1100 Manuel utilisateur

Teltonika

Teltonika GH4000 Instructions de montage

Teltonika

Teltonika FMU130 Manuel utilisateur

Teltonika

Teltonika T-Box/GPS-800 Manuel utilisateur

Teltonika

Teltonika FMB125 Manuel utilisateur

Teltonika

Teltonika FMT100 Guide d'installation

Teltonika

Teltonika FMB640 Manuel utilisateur

Teltonika

Teltonika Telematics FTC921 Guide d'installation

Manuels GPS populaires d'autres marques

Raven

Raven Cruizer II Manuel

Hama

Hama 53118 Manuel utilisateur

Garmin

Garmin SOUNDER 125 Manuel utilisateur

Garmin

Garmin DEZL 580 Manuel utilisateur

Jigabot

Jigabot EX Manuel utilisateur

Pointer

Pointer Cellocator CelloTrack XT LTE Guide d'installation

Queclink

Queclink GV55LITE Manuel utilisateur

Voxson

Voxson Voxtrack GPS500 Manuel d'instructions

Garmin

Garmin ECHOMAP PLUS Manuel utilisateur

Starcom Systems

Starcom Systems Kylos Compact Manuel utilisateur

Garmin

Garmin 15 H Series Manuel utilisateur

Cobra

Cobra Marine MC 600Ci Manuel utilisateur

Cellocator

Cellocator CelloTrack T Manuel utilisateur

Enfora

Enfora Mini-MT GSM2228UG001 Manuel utilisateur

Magellan

Magellan eXplorist 100 Manuel utilisateur

LTE

LTE G50B Manuel utilisateur

Garmin

Garmin DEZL OTR500 Manuel utilisateur

SkyGolf

SkyGolf SkyCaddie SG1 Manuel utilisateur
