Teltonika Telematics FTC921 Guide d'installation

FTC921

Small and smart tracker

Quick Manual v1.5

Quick Manual v1.5 // FTC921 2

CONTENT

Know your device................................................................................................................................................................................................3

Pinout ...................................................................................................................................................................................................................4

Wiring scheme.....................................................................................................................................................................................................5

Set up your device ..............................................................................................................................................................................................6

How to install USB drivers (Windows) ..............................................................................................................................................................7

PC Connection (Windows)..................................................................................................................................................................................7

Conguration (Windows) ...................................................................................................................................................................................8

Quick SMS conguration....................................................................................................................................................................................9

Mounting recommendations.......................................................................................................................................................................... 10

Basic characteristics ........................................................................................................................................................................................ 11

LED indications................................................................................................................................................................................................. 11

Safety information .......................................................................................................................................................................................... 14

Certication and Approvals ............................................................................................................................................................................ 15

Warranty ........................................................................................................................................................................................................... 17

Warranty disclaimer......................................................................................................................................................................................... 17

Quick Manual v1.5 // FTC921 3

KNOW YOUR DEVICE

1X5

SOCKET

STATUS

LED

NAVIGATE

LED

SIM

SLOT

BATTERY

SOCKET

GNSS

ANTENA

TOP VIEW TOP VIEW (WITHOUT COVER)BOTTOM VIEW (WITHOUT COVER)

Quick Manual v1.5 // FTC921 4

PIN NUMBER PIN NAME DESCRIPTION

1 VCC (10-90) VDC (+) (Red) Power supply

(+10-90 V DC)

2 GND (-) (Black) Ground

3 DIN1

(Yellow) Digital input,

channel 1. DEDICATED

FOR IGNITION INPUT

4AIN1

(Grey) Analog input,

channel 1. Input range:

0-90 V DC

5DOUT1

(White) Digital output.

Open collector output.

Max. 0,5 A DC

PINOUT

+10...90 V DC

GND

AIN1

DOUT1

DIN1

FTC921 pinout

Quick Manual v1.5 // FTC921 5

WIRING SCHEME

BUZZER

8586

87a

IGNITION

DETECTION

FUEL GAUGE

STARTER

ANALOG

LLS SENSOR

ALARM BUTTON

DOOR SENSOR

POWER SUPPLY

10 - 30V DC

WIRING SCHEMEFMM920

+10...90 V DC

GND

AIN1

DIN1

DOUT1

Quick Manual v1.5 // FTC921 6

SET UP YOUR DEVICE

HOW TO INSERT MICRO-SIM CARD AND CONNECT THE BATTERY

COVER REMOVAL

BATTERY CONNECTION

3SIM CARD INSERT

COVER REMOVAL

DEVICE IS READY

You will receive your device fully closed.

Connect battery by pressing connector

rmly to socket, ensure that both sides

of connector locks properly.

Gently remove side cover.

Device is ready to be mounted.

Insert SIM card as shown. Make sure

Nano-SIM card cut-o corner is pointing

towards SIM slot.

Quick Manual v1.5 // FTC921 7

PC CONNECTION

(WINDOWS)

HOW TO INSTALL USB

DRIVERS (WINDOWS)

1. Please download COM port drivers from here1.

2. Extract and run TeltonikaCOMDriver.exe.

3. Click Next in driver installation window.

4. In the following window click Install button.

5. Setup will continue installing the driver and eventually the

conrmation window will appear. Click Finish to complete

the setup.

1 wiki.teltonika-gps.com/images/d/d0/TeltonikaCOMDriver.zip

1. Power-up FTC921 with DC voltage (10-90V) power supply

using power wires. LEDs should start blinking.

2. Connect device to computer using Micro-USB cable

and install USB driver, see “How to install USB drivers

(Windows)1”

1 Page 6, "How to install USB drivers"

Quick Manual v1.5 // FTC921 8

After connection Device status window will be loaded with

device, GNSS and Cellular information.

Most important congurator section is GPRS – where all

your server and GPRS settings can be congured and Data

Acquisition – where data collecting parameters can be setu p.

More details about FTC921 conguration using TCT can be fnd

on our Wiki1.

1 wiki.teltonika-gps.com/view/FTC921_Conguration

Save to device – saves conguration to device.

Upload le – loads conguration from le.

Save to le – saves conguration to le.

Update – update device rmware.

Reset conguration – sets device conguration

to default.

MS .NET

REQUIREMENTS

Operating

system

MS .NET

Framework

version

Version Links

Windows

Vista

Windows 7

Windows 8.1

Windows 10

MS .NET

Framework

4.6.2

32 and 64 bit www.microsoft.com1

1 dotnet.microsoft.com/en-us/download/dotnet-framework/net462

At rst FTC921 device will have default factory settings set.

These settings should be changed according to the user's

needs. Main conguration can be performed via Teltonika

Congurator tool1 (TCT).

1/wiki.teltonika-gps.com/view/FTC921

CONFIGURATION

(WINDOWS)

Downloaded Telematics Conguration Tool (TCT) setup

le will be in compressed archive, extract it and launch

TelematicsCongurationTool.Setup.exe

Once TCT is installed, launch it and you will see connected

devices, press congure.

Quick Manual v1.5 // FTC921 9

QUICK SMS CONFIGURATION

Default conguration has optimal parameters present to ensure best performance of track quality and data usage.

Quickly set up your device by sending this SMS command to it:

Note: Before SMS text, one space symbols should be inserted.

GPRS SETTINGS:

 2001 – APN

 2002 – APN username (if there are no APN username,

empty eld should be left)

 2003 – APN password (if there are no APN password,

empty eld should be left)

SERVER SETTINGS:

 2004 – Domain

 2005 – Port

 2006 – Data sending protocol (0 – TCP, 1 – UDP)

« setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0»

1 2 3 4 5 6

Quick Manual v1.5 // FTC921 10

MOUNTING RECOMMENDATIONS

CONNECTING WIRES

• Wires should be fastened to stable wires or other non-

moving parts. Any heat emitting and/or moving objects

should be kept away from the wires.

• There should be no exposed wires. If factory isolation was

removed while connecting wires, the isolation material

should be applied.

• If the wires are placed in the exterior or in places where

they can be damaged or exposed to heat, humidity, dirt,

etc., additional isolation should be applied and the wires

should not be loose.

• Wires cannot be connected to the board computers or

control units.

CONNECTING POWER SOURCE

• Be sure that after the car computer goes to sleep mode,

power might be still available on the power wires.

Depending on car, this may happen in 5 to 30 minutes

period.

• When module is connected, measure voltage again to

make sure it did not decrease.

• It is recommended to connect to the main power cable in

the fuse box.

• 3 A, 125 V external fuse shall be used.

CONNECTING IGNITION WIRE

• Be sure to check if it is a real ignition wire i. e. power does

not disappear after starting the engine.

• Check if this is not an ACC wire (when key is in the rst

position, most of the vehicle electronics are available).

• Check if power is still available when you turn o any of

vehicles devices.

• Ignition is connected to the ignition relay output. As

alternative, any other relay, which has power output when

ignition is on, may be chosen.

CONNECTING GROUND WIRE

• Ground wire is connected to the vehicle frame or metal

parts that are xed to the frame.

• If the wire is xed with the bolt, the loop must be connected

to the end of the wire.

• For better contact scrub paint from the spot where loop is

going to be connected.

CAUTION! Caution statements are a

description of situations where a non-

immediate or potential hazard presents

a lesser threat of injury that could result

in minor or moderate injuries to workers

and/or the general public.
