Teltonika MSP500 Guide d'installation

Quick Manual

v1.0

Tracker for speed limiting

MSP500

MSP500 |

Wiki

Table of Contents

Know your device .......................................................................... 3

Pinout................................................................................................. 4

Wiring scheme................................................................................... 5

Set up your device......................................................................... 6

How to insert Micro-SIM card and connect the battery................ 6

PC Connection (Windows)................................................................ 7

How to install USB drivers (Windows)............................................. 7

Configuration (Windows) ................................................................. 7

Quick SMS configuration.................................................................. 9

Mounting recommendations ..................................................... 10

LED behaviour.............................................................................. 11

Characteristics............................................................................. 11

Basic characteristics ....................................................................... 11

Electrical characteristics................................................................. 13

Safety information ...................................................................... 14

Warranty ...................................................................................... 15

Warranty Disclaimer........................................................................15

MSP500 |

Wiki

Know your device

Figure 1 MSP500 device view

MSP500 |

Wiki

Pinout

Table 1 MSP500 pinout

PIN NUMBER PIN NAME DESCRIPTION

1 VCC (10-32)V Power supply (10-32) V DC (+)

2 RS232 GND RS232 Ground pin

3 RS232-TX Output for data transmit through

RS232

4 USB DATA + Differential serial data +

5 USB DATA- Differential serial data -

6 GND Ground pin. (10-32)V DC

7 AIN1 Analog input, channel 1. Input range: 0-

30 V DC.

8 RS232-RX Input for data receive through RS232

9 USB GND Ground PIN for USB

10 USB +5V Power supply for USB

Figure 2 MSP500 socket pinout

MSP500 |

Wiki

Figure 3 MSP500 Wiring scheme

Wiring scheme

MSP500 |

Wiki

Set up your device

How to insert Micro-SIM card and

connect the battery

1. Gently remove MSP500 cover using plastic pry tool from both

sides.

2. Insert Micro-SIM card as shown with PIN request disabled or

read our Wiki how to enter it later in Teltonika Configurator.

Make sure that Micro-SIM card cut-off corner is pointing

forward to slot.

3. Connect battery as shown to device. Position the battery in

place where it does not obstruct other components.

4. After configuration, see “PC Connection (Windows)”, attach

device cover back.

Figure 4 Cover removal Figure 5 Micro-SIM card insert Figure 6 Battery connection Figure 7 Attaching cover back

MSP500 |

Wiki

PC Connection (Windows)

1. Power-up MSP500 with DC voltage (10 – 32 V) power supply

using power cable. LED’s should start blinking, see “LED

behaviour ”.

2. Connect device to computer using USB Type-B cable.

How to install USB drivers

(Windows)

1. Please download COM port drivers from here.

2. Extract and run TeltonikaCOMDriver.exe.

3. Click Next in driver installation window.

4. In the following window click Install button.

Setup will continue installing the driver and eventually the

confirmation window will appear. Click Finish to complete the

setup.

Configuration (Windows)

At first MSP500 device will have default factory settings set. These

settings should be changed according to the user's needs. Main

configuration can be performed via Teltonika configurator

software. Configurator operates on Microsoft Windows OS and

uses prerequisite MS .NET Framework. Make sure you have the

correct version installed.

Table 2 MS .NET requirements

MS .NET REQUIREMENTS

Operating

system

MS .NET Framework

version Version Links

Windows Vista

Windows 7

Windows 8.1

Windows 10

MS .NET Framework

4.6.2 32 and 64 bit www.microsoft.com

Downloaded Configurator will be in compressed archive. Extract it

and launch Configurator.exe. After launch software language can

be changed by clicking in the right bottom corner (Figure 8

Language selection).

MSP500 |

Wiki

Configuration process begins by pressing on connected device

(Figure 9 Device connected via USB).

After connection to Configurator Status window will be displayed

(Figure 10 Configurator Status window).

Various Status window tabs display information about GNSS,

GSM,I/O, Maintenance and etc. MSP500 has one user editable

profile, which can be loaded and saved to the device. After any

modification of configuration the changes need to be saved to

device using Save to device button. Main buttons offer following

functionality:

1. Load from device – loads configuration from device.

2. Save to device – saves configuration to device.

3. Load from file – loads configuration from file.

4. Save to file – saves configuration to file.

5. Update firmware – updates firmware on device.

6. Reboot device – restarts device.

7. Reset configuration – sets device configuration to

default.

Most important configurator section is GPRS – where all your

server and GPRS settings can be configured and Data Acquisition

–where data acquiring parameters can be configured.

More details about MSP500 configuration using Configurator can

be found in our Wiki.

Figure 9 Device connected via USB

Figure 8 Language selection

Figure 10 Configurator Status window

MSP500 |

Wiki

Quick SMS configuration

Default configuration has optimal parameters present to ensure

best performance of track quality and data usage.

Quickly set up your device by sending this SMS command to it:

Note: Before SMS text, two space symbols should be inserted.

GPRS settings:

•2001 – APN

•2002 – APN username (if there

are no APN username, empty

field should be left)

•2003 – APN password (if there

are no APN password, empty

field should be left)

Server settings:

•2004 – Domain

•2005 – Port

•2006 – Data sending protocol

(0 – TCP, 1 – UDP)

Default configuration settings

Movement and ignition detection:

Vehicle movement will

be detected by

accelerometer

Ignition will be detected

by vehicle power voltage

between 13,2

– 32 V

Device makes a record

On Moving if one of these events happen:

300 seconds passes

Vehicle turns 10 degrees

Vehicle drives 100

meters

Speed difference

between last coordinate

and current position is

greater than 10 km/h

Device makes a record

On Stop if:

1 hour passes while

vehicle is stationary

and ignition is off

Records sending to server:

If device has made a

record it is

sent to the

server every 120

seconds

After successful SMS configuration, MSP500 device will

synchronize time and update records to configured server.

Time intervals and default I/O elements can be changed by using

Teltonika Configurator or SMS parameters.

" setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0"

MSP500 |

Wiki

Mounting recommendations

•Connecting wires

▬Wires should be fastened to stable wires or other non-

moving parts. Any heat emitting and/or moving objects

should be kept away from the wires.

▬There should be no exposed wires. If factory isolation was

removed while connecting the wires, the isolation material

should be applied.

▬If the wires are placed in the exterior or in places where they

can be damaged or exposed to heat, humidity, dirt, etc.,

additional isolation should be applied and the wires should

not be loose.

▬Wires cannot be connected to the board computers or

control units.

•Connecting power source

▬Be sure that after the car computer goes to sleep mode,

power might be still available on the power wires.

Depending on the car model, this may happen in 5 to 30

minutes period.

▬When the module is connected, measure the voltage again

to make sure it did not decrease.

▬It is recommended to connect to the main power cable in

the fuse box.

▬3 A, 125 V external fuse shall be used.

•Connecting ground wire

▬Ground wire is connected to the vehicle frame or metal

parts that are fixed to the frame.

▬If the wire is fixed with the bolt, the loop must be connected

to the end of the wire.

▬For better contact scrub paint from the spot where loop is

going to be connected.

PAY ATTENTION! Connecting the power supply must be

carried out in a very low impedance point of on-board

vehicle network. Connecting the GND at an arbitrary

point to the mass of the car is unacceptable, as static

and dynamic potentials on the line GND will be

unpredictable, which can lead to unstable MSP500

operation and even its failure.
