Telos XP50 Manuel utilisateur
Telos
Manual
Content
Specifications
About the device
Description
Package Contents
Components and Controls
Features
Power supply
Precautions
Recommendations for Battery Use
Battery Charging
Battery Installation
External Power Supply
Getting Started
Powering on and Image Settings
Button Operation
Interface
Status Bar
Quick Menu
Main Menu
Enter the Main Menu
Amplification Level
Colour Modes
Smoothing Filter
User Mode
Icon Brightness
PiP Mode
Wi-Fi Activation
Wi-Fi Settings
Microphone
Calibration Mode
General Settings
Defective Pixel Repair
Defective Pixel Repair
Restore Default Pixel Map
Device Information
Functions
Video Recording and Photography
Digital Zoom
PiP Function
Display-Off Function
Wi-Fi Function
Stadiametric Rangefinder
Installing the Device on a Tripod
USB Connection
Software
Stream Vision 2
Firmware Update
Maintenance
Technical Inspection
Technical Maintenance and Storage
Troubleshooting
Legal Compliances and Disclaimers
Specifications
You can learn more about the main parameters here.
XP50
Model XP50
SKU 77493
Microbolometer
Type uncooled
Resolution, Pixels 640x480
Pixel Pitch, µm 17
NETD, mK < 18
Frame Rate, Hz 50
Optical
Characteristics
Magnification, x 2.5
Smooth Digital
Zoom, x 2.5-10
Digital Zoom, x x1 - x4
Lens Focus, mm 50
Relative Aperture,
D/f' 1.0
Minimum Focus
Distance, m/y 5 / 5.5
Exit Pupil
Diameter,
mm/inch 4 / 0.16
Angular Field of
View (Horizontal x
Vertical), degree 12.4х9.3
Linear Field of
View, m at 100 m 21.8
Eyepiece Focus
Range, Dioptre +4 / -5
Detection
Distance for Deer-
Sized Objects, m/y 1800 / 1969
Display
Type AMOLED
Resolution, Pixels 1024x768
Operational
Characteristics
Power Supply, V 3 - 4.2
Battery
Type/Capacity/Nominal
Output Voltage
LPS7i Li-ion Battery Pack / 6400 mAh / DC
3.7 V
External Power
Supply 5 V, 9 V (USB Type-C)
Battery Run Time
at t=22°C, hours* 8.5
Degree of
Protection, IP
Code (IEC60529) IPX7
Operating
Temperature
Range, °C / °F -25 … +40 / -13 – +104
Dimensions,
mm/inch 238x72x62 / 9.37x2.83x2.44
Weight (with
battery), kg/oz 0.67 / 23.6
Video Recorder
Photo/Video
Resolution, Pixels 1024x768
Video/Photo
Format .mp4 / .jpg
Built-in Memory 64 GB
Wi-Fi Channel**
Frequency 2.4/5 GHz
Standard IEEE 802.11 b/g/n/ac
* Actual battery life may vary depending on the use of Wi-Fi and the built-in
video recorder.
** Reception range may vary depending on various factors: obstacles, other
Wi-Fi networks.
Description
Telosthermal imaging monoculars are designed for use both at night-time
and during the day and provide exceptional image quality even in adverse
weather conditions (fog, smog, rain) and beyond obstacles like branches,
tall grass, dense foliage, etc. known to hinder target detection.
Unlike night-vision devices based on electron-optical converters, thermal
imaging devices do not need an external light source and are resistant to
bright light.
Telosthermal imagers are designed for various applications including
hunting, observation, security, terrain orientation, search and rescue
operations, etc.
To get started, see the sections:
Battery Charging
Battery Installation
Powering on and Image Settings
Stream Vision 2
Package Contents
Telos thermal imager
LPS7i battery pack with protective cover
Spare battery compartment cover
Power adapter
USB Type-C cable with USB Type-A adapter
Case
Hand strap
Quick start guide
Lens cloth
Warranty card
Components and Controls
