Tellabs 8600 Manuel utilisateur
Tellabs ®8600 Managed Edge System
Tellabs ®8609 Access Switch FP1.0
Tellabs®8611 Access Switch FP1.1
Interface Configuration Guide
76.8610-50149A
18.08.2011
Document Information
Revision History
Document No. Date Description of Changes
76.8610-50149A 18.08.2011 First introduction.
© 2011 Tellabs. All rights reserved.
This Tellabs manual is owned by Tellabs or its licensors and protected by U.S. and international copyright laws, conventions and
treaties. Your right to use this manual is subject to limitations and restrictions imposed by applicable licenses and copyright laws.
Unauthorized reproduction, modification, distribution, display or other use of this manual may result in criminal and civil penalties.
The following trademarks and service marks are owned by Tellabs Operations, Inc. or its affiliates in the United States and/or
other countries: TELLABS®, TELLABS®logo, TELLABS and T symbol®, and T symbol®.
Any other company or product names may be trademarks of their respective companies.
The specifications and information regarding the products in this manual are subject to change without notice. All statements,
information, and recommendations in this manual are believed to be accurate but are presented without warranty of any kind,
express or implied. Users must take full responsibility for their application of any products.
Adobe®Reader®are registered trademarks of Adobe Systems Incorporated in the United States and/or other countries.
Tellabs®8600 Managed Edge System 76.8610-50149A
Tellabs®8609 Access Switch FP1.0 Tellabs®8611 Access Switch FP1.1 Interface Configuration Guide © 2011 Tellabs.
2
Document Information
Terms and Abbreviations
Term Explanation
AAL ATM Adaptation Layer
ACFC Address and Control Field Compression
AIS Alarm Indication Signal
ATM Asynchronous Transfer Mode
BE Best Effort
BER Bit Error Ratio
BFD Bidirectional Forwarding Detection
CAC Connection Admission Control
CBR Constant Bit Rate
CESoPSN Circuit Emulation Service over Packet Switched Network
CLI Command Line Interface
CRC Cyclic Redundancy Check
DEG Degraded
ESF Extended Super Frame
FCS Frame Check Sequence
FE Fast Ethernet
GE Gigabit Ethernet
HDLC High-Level Data Link Control
HM High speed Module
IEEE Institute of Electrical and Electronics Engineers
IETF Internet Engineering Task Force
IMA Inverse Multiplexing for ATM
IP Internet Protocol
IPCP IP Network Control Protocol of the PPP
IS-IS Intermediate System to Intermediate System (Interior Gateway Protocol)
LAN Local Area Network
LCP Link Control Protocol
LLC Logical Link Control
LM Line Module
LOF Loss Of Frame
MAC Media Access Control
MC-MLPPP Multiclass MLPPP
MGE Management GE
76.8610-50149A Tellabs®8600 Managed Edge System
© 2011 Tellabs. Tellabs®8609 Access Switch FP1.0 Tellabs®8611 Access Switch FP1.1 Interface Configuration Guide
3
Document Information
MLPPP Multilink PPP
MPLS Multiprotocol Label Switching. A switching method that forwards IP trafficusinga
label.
MPLSCP MPLS Network Control Protocol of the PPP
MRU Maximum Receive Unit
MRRU Maximum Received Reconstructed Unit
MTU Maximum Transmission Unit
MuxCP Multiplexed Control Protocol
NCP Network Control Protocol
NE Network Element
NLPID Network Layer Protocol Identifier
NNI Network-to-Network Interface
NRT Non-Real Time
NTP Network Time Protocol
OAM Operations, Administration and Maintenance
OSINLCP OSI Network Layer Control Protocol
P12s Framed 2.048 kbps according to G.704 and G.706
P12x Unframed 2.048 kbps according to G.703
PDH Plesiochronous Digital Hierarchy
PFC Protocol Field Compression
PFF Protocol Field Flag
PID Protocol ID
PLM Physical Line Module
PMD Physical Medium Dependent
PPP Point-to-Point Protocol
PPPMux PPP Multiplexing
PPPMuxCP PPP Multiplexed Control Protocol
PTM Packet Transfer Mode
PWE3 Pseudowire Emulation Edge to Edge
QoS Quality of Service
RAI Remote Alarm Indicator
RDI Remote Defect Indicator
RT Real Time
RTC Real Time Clock
RTT Round Trip Time
SAToP Structure-Agnostic Time Division Multiplexing over Packet
SF Super Frame
Tellabs®8600 Managed Edge System 76.8610-50149A
Tellabs®8609 Access Switch FP1.0 Tellabs®8611 Access Switch FP1.1 Interface Configuration Guide © 2011 Tellabs.
4
Document Information
SFP Small Form-factor Pluggable
SNAP Subnetwork Access Protocol
SRA Seamless Rate Adaptation
SSD Server Signal Degraded
SSF Server Signal Fail
TC Transmission Convergence layer
TDM Time Division Multiplexing
TLP Transmission Layer Port
UBR Unspecified Bit Rate
UDP User Datagram Protocol
UNI User Network Interface
VBR Variable Bit Rate
VC ATM Virtual Channel
VCC Virtual Channel Connection
VCCV Virtual Circuit Connectivity Verification
VCI Virtual Channel Identifier
VCL Virtual Channel Link
VLAN Virtual LAN
VP Virtual Path
VPC Virtual Path Connection
VPI Virtual Path Identifier
VPL Virtual Path Link
Vo I P Vo i c e o v e r I P
XC Cross-Connection
76.8610-50149A Tellabs®8600 Managed Edge System
© 2011 Tellabs. Tellabs®8609 Access Switch FP1.0 Tellabs®8611 Access Switch FP1.1 Interface Configuration Guide
5
Tellabs®8600 Managed Edge System 76.8610-50149A
Tellabs®8609 Access Switch FP1.0 Tellabs®8611 Access Switch FP1.1 Interface Configuration Guide © 2011 Tellabs.
6
Table of Contents
Table of Contents
About This Manual ............................................................................................................ 10
Objectives....................................................................................................................................................................... 10
Audience......................................................................................................................................................................... 10
Related Documentation .................................................................................................................................................. 10
Interface Numbering Conventions ................................................................................................................................. 11
Document Conventions .................................................................................................................................................. 12
Documentation Feedback ............................................................................................................................................... 12
1 Overview ......................................................................................................................13
1.1 ETSI and ANSI Mode ......................................................................................................................................... 13
2 Network Element Interfaces ....................................................................................... 14
2.1 Tellabs 8609 Access Switch ............................................................................................................................... 14
2.1.1 Overview ............................................................................................................................................. 14
2.1.2 Fixed Interfaces ................................................................................................................................... 14
2.1.3 Supported Line Modules ..................................................................................................................... 15
2.2 Tellabs 8611 Access Switch ............................................................................................................................... 15
2.2.1 Overview ............................................................................................................................................. 15
2.2.2 PLM Combination Rules ..................................................................................................................... 16
3 Physical Line Modules................................................................................................ 18
3.1 Line Modules....................................................................................................................................................... 18
3.1.1 8xchE1/chT1 LM................................................................................................................................. 18
3.1.2 8x10/100BASE-TX LM ...................................................................................................................... 21
3.2 High Speed Modules ........................................................................................................................................... 22
3.2.1 4x100/1000BASE-X HM .................................................................................................................... 22
3.2.2 4x10/100/1000BASE-TX HM............................................................................................................. 23
4 Management Port (MGMT)..........................................................................................25
5 Fault Management Operation and Configuration..................................................... 26
76.8610-50149A Tellabs®8600 Managed Edge System
© 2011 Tellabs. Tellabs®8609 Access Switch FP1.0 Tellabs®8611 Access Switch FP1.1 Interface Configuration Guide
7
Table of Contents
5.1 TDM Fault Management ..................................................................................................................................... 26
5.1.1 Principles ............................................................................................................................................. 26
5.1.2 Fault Suppression ................................................................................................................................ 27
6 Performance Monitoring............................................................................................. 28
6.1 TDM Performance Monitoring............................................................................................................................ 28
6.1.1 G.826 Performance Monitoring........................................................................................................... 28
6.1.2 GR-253/GR-820 Performance Monitoring.......................................................................................... 29
7 ANSI Loopback Operations........................................................................................ 30
7.1 DS1 Loopback ..................................................................................................................................................... 30
7.1.1 Loopback Operation ........................................................................................................................... 30
7.1.2 Equipment Loopback Operation.......................................................................................................... 30
7.1.3 Invoking a Remote Loopback.............................................................................................................. 30
7.1.4 Remote Loopback Methods................................................................................................................. 31
7.1.5 Loopback Example in SAToP Application..........................................................................................31
7.1.6 Loopback Example in CESoPSN, and Multiservice Applications...................................................... 32
8 References ................................................................................................................... 34
9 Interface Configuration Examples ............................................................................. 36
9.1 All Interfaces ....................................................................................................................................................... 36
9.1.1 Basic Configuration ............................................................................................................................. 37
9.1.2 Checking Interface Configuration Status and Basic Troubleshooting................................................. 38
9.2 Ethernet Basic Configuration............................................................................................................................... 41
9.3 Selecting Operation Mode ................................................................................................................................... 42
9.4 VLAN Management ............................................................................................................................................ 43
9.4.1 Acceptable Frame Filter ...................................................................................................................... 43
9.4.2 Create VLAN....................................................................................................................................... 43
9.4.3 Delete VLAN....................................................................................................................................... 43
9.5 8xchE1/chT1 LM................................................................................................................................................. 43
9.5.1 Starting Configuration ......................................................................................................................... 44
9.5.2 Configuring E1/T1 Physical Layer Interface....................................................................................... 45
9.5.3 Configuring P12s Layer for ATM........................................................................................................ 45
9.5.4 Configuring DS1 Layer for ATM ........................................................................................................ 46
9.5.5 Configuring P12s/DS1 for HDLC ....................................................................................................... 46
9.5.6 Configuring P12s/DS1 for PPP and MLPPP ....................................................................................... 47
9.5.7 Configuring ANSI Remote Loopbacks ............................................................................................... 52
9.5.8 Configuring Fault Monitoring and Reporting...................................................................................... 52
9.6 Management Port of SCM ................................................................................................................................... 54
9.6.1 External Switch Operations ................................................................................................................. 54
9.6.2 Investigating MGMT Protection Status............................................................................................... 54
Tellabs®8600 Managed Edge System 76.8610-50149A
Tellabs®8609 Access Switch FP1.0 Tellabs®8611 Access Switch FP1.1 Interface Configuration Guide © 2011 Tellabs.
8
Table of Contents
Layer Descriptions............................................................................................................ 55
PDH Layers .................................................................................................................................................................... 55
Ethernet Layers .............................................................................................................................................................. 58
Port Protocols ................................................................................................................................................................. 59
Fault Management.......................................................................................................................................................... 74
76.8610-50149A Tellabs®8600 Managed Edge System
© 2011 Tellabs. Tellabs®8609 Access Switch FP1.0 Tellabs®8611 Access Switch FP1.1 Interface Configuration Guide
9
About This Manual
About This Manual
This chapter discusses the objectives and intended audience of this manual, Tellab s ®8600
Managed Edge System Tellabs®8609 Access Switch and Tellabs®8611 Access Switch Interface
Configuration Guide and consists of the following sections:
• Objectives
• Audience
• Related Documentation
• Conventions
• Documentation Feedback
Objectives
This manual provides an overview of the Tellabs 8609 access switch and Tellabs 8611 access switch
interface functions and instructions on how to configure them using Command-Line Interface (CLI)
and ASCII textual commands with a router’s console or remote terminal (Telnet).
Audience
This manual is designed for administration personnel for configuring the Tellabs 8609 access switch
and Tellabs 8611 access switch interface functions with CLI. On the other hand, Tellabs®8000
Intelligent Network Manager provides access to equal functionality for administration personnel
with a graphical user interface.
It is assumed that you have a basic understanding of networks and network interfaces of different
technologies (ATM, PDH, PPP, Ethernet).
Related Documentation
The document numbering scheme consists of the document ID, indicated by numbers, and the
document revision, indicated by a letter. The references in the Related Documentation table below
are generic and include only the document ID. To make sure the references point to the latest
available document versions, please refer to the relevant product document program on the Tellabs
Portal by navigating to www.portal.tellabs.com > Product Documentation > Data Networking >
Tellabs 8600 Managed Edge System > Technical Documentation.
Tellabs ®8600 Managed Edge System
Hardware Installation Guide (76.8600-40039)
Provides guidance on mechanical installation,
grounding, powering, cabling and maintenance.
Tellabs ®8600 Managed Edge System FP1.0
Tellabs ®8609 Access Switch Reference
Manual (76.8610-40086)
Describes network element features: enclosure,
baseboard, interfaces and power supply modules.
Tellabs®8600 Managed Edge System 76.8610-50149A
Tellabs®8609 Access Switch FP1.0 Tellabs®8611 Access Switch FP1.1 Interface Configuration Guide © 2011 Tellabs.
10
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels Tellabs Routeur réseau
Manuels Routeur réseau populaires d'autres marques
NETGEAR
NETGEAR FS526T - Switch Manuel utilisateur
Korenix
Korenix JetNet 5710G Series Manuel utilisateur
Automated Logic
Automated Logic ZN551 Manuel du propriétaire
Cisco
Cisco ASR 1000 Series Manuel de l'opérateur
EnGenius
EnGenius ESR-9710 Manuel utilisateur
Cisco
Cisco 805 Series Instructions d'utilisation et de sécurité
