Telematrix 3300TRM Manuel utilisateur

Copyright TeleMatrix Inc.2008

3300TRM

1 LINE TRIMLINE

USERS GUIDE

TELEPHONE SET

INTRODUCTION

Congratulations on the purchase of

your

TeleMatrix Trimline telephone. This

telephone is a precision electronic device

designed and manufactured with the highest

quality components and workmanship that

requires minimum maintenance. Please be sure

to read the contents in this user’s guide

to become familiar with its features and

functionality.

CONTENTS

Table Of Contents

Introduction

Features

Controls

Definition Of Controls

Installation

Parts Checklist

Wall Mounting

Switch Setting

Care & Maintenance

Service

Warranty

































FEATURES

Single Line Operation

Tone Dialing

Message Waiting Lamp

Convenient Data Port

Handset Volume Control

Flash Function (100mS/300mS and 600mS)

Dial In Handset

Last Number Redial

Hi/Low Ringer Volume Control

Desk or Wall Mountable

Fully Modular

Hearing Aid Compatible

CONTROLS

DEFINITION OF CONTROLS

1. Data Port

Used for plugging in a laptop, modem, fax, etc.

Redial Key

Used to automatically redial the last number dial.

3. Flash Key

Provides a 100mS/300mS or 600mS time line break.

4. Handset Volume Control

Amplifies the volume of the receiver.

5. Dial Pad

Large keys used for outbound dialing.

Line Reset Key

Used to reset the line to place another call.

7. Ringer Volume Control

Switch to adjust the loudness ofthe ringer.

8. Message Waiting Lamp

Visual indicator to tell you that a message is waiting,

or that the line is ringing.

INSTALLATION

Caution





Never install telephone wiring during a lightning

storm.













Never install telephone jacks in wet location

unless the jack is specifically designed for wet

locations.

Never touch none insulated telephone wires or

terminal unless the telephone line has been

disconnected at the network interface.

Use caution when installing or modifying

telephone lines.

1. 15’/4.5mlinecordsoldseperately

2. RJ11C/WLineCord-3.5/.09m

3. HandsetCoilCord-10’/3.05m

INSTALLATION

Connecting The Line Cord

Plug the end of the 15-foot modular telephone

line cord into the jack on the top of the base

unit. Plug the remaining end of the line cord

into a standard telephone outlet.

INSTALLATION

Connecting The Handset Cord

Plug one end of the modular coiled handset

cord into the receptacle located on the left

side of the base unit. Plug the remaining end

into the receptacle on the handset.
