1201-N+
79033-N+ User Manual
1201-N+ Seamless Presentation Switcher
All Rights Reserved
Version: 79033-N+_2020V1.0
www.tekvox.com
1201-N+
79033-N+ User Manual
Preface
Read this user manual carefully before using the product. Pictures shown in this manual are for
reference only. Different product model specifications may vary.
This manual is only for operation instruction, please contact the local distributor for maintenance
assistance. The functions described in this version were updated October, 2018. In order to continue
improving the product, we reserve the right to make function or parameter changes without notice or
obligation. Please refer to the dealers for the latest details.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. It has
been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a commercial installation.
Operation of this equipment in a residential area is likely to cause interference, in which case the user
at their own expense will be required to take whatever measures may be necessary to correct the
interference.
Any changes or modifications not expressly approved by the manufacture would void the user’s
authority to operate the equipment.
www.tekvox.com
1201-N+
79033-N+ User Manual
Safety Precautions
To ensure the best performance from the product, please read all instructions carefully before using
the device. Save this manual for further reference.
Unpack the equipment carefully, and save the original box and packing material for possible
future shipment
Follow basic safety precautions to reduce the risk of fire, electrical shock, and injury to persons
Do not dismantle the housing or modify the module (electrical shock or burn hazard)
Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration, or malfunction
Refer all servicing to qualified service personnel
To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this product
near water
Do not put any heavy items on the product’s power cable
Do not remove the housing of the device as opening or removing housing may expose you to
dangerous voltage or other hazards
Install the device in a place with sufficient ventilation to avoid damage caused by overheating
Keep the module away from liquids
Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object
or liquid falls or spills on to the housing, unplug the module immediately.
Do not twist or pull by force ends of the optical cable as it may cause malfunction.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug power to the device before
cleaning.
Unplug the power cord when left unused for a long period of time
Information on disposal for scrapped devices: do not burn or mix with general household waste.
Treat them as normal electrical waste
www.tekvox.com
1201-N+
79033-N+ User Manual
Table of Contents
1. Product Introduction .................................................................................................................... 6
1.1 Features ............................................................................................................................................... 6
1.2 Package List ........................................................................................................................................ 7
2. Specifications .............................................................................................................................. 8
3. Product Appearance ..................................................................................................................... 9
3.1 1201-N+ Presentation Switcher Panels ............................................................................................ 9
3.1.1 1201-N+ Front Panel .................................................................................................................. 9
3.1.2 1201-N+ Rear Panel ................................................................................................................. 10
3.2 TPUH411RA HDBaseT Receiver Panels ......................................................................................... 11
3.2.1 TPUH411RA Front Panel ......................................................................................................... 11
3.2.2 TPUH411RA Rear Panel .......................................................................................................... 12
4. System Connection .................................................................................................................... 13
4.1 Installation Precautions.................................................................................................................... 13
4.2 System Diagram ................................................................................................................................ 13
4.3 Connection Procedure Steps ........................................................................................................... 14
4.4 Connection of Microphone Mixer .................................................................................................... 14
4.5 Application ......................................................................................................................................... 14
5. Front Panel Control .................................................................................................................... 15
5.1 Manual-Switching ............................................................................................................................. 15
5.2 Auto-Switching .................................................................................................................................. 15
5.3 Volume Adjustment .......................................................................................................................... 15
5.4 Operations of IR ................................................................................................................................ 16
5.4.1 IR Remote ................................................................................................................................. 16
5.4.2 Control of Far-End IR Device from Local ................................................................................ 17
5.4.3 Control Local Device from Remote ........................................................................................ 17
5.5 Operation of CEC Functions ............................................................................................................. 18
5.6 RS232 Control ................................................................................................................................... 18
5.6.1 RS232 Communication Protocol ............................................................................................ 19
www.tekvox.com
1201-N+
79033-N+ User Manual
5.6.2 RS232 Control Modes .............................................................................................................. 27
5.6.3 Control TEK-1201-N+ AND Display from Local RS232 Port ................................................. 27
5.6.4 Control TEK 1201-N+ from Local and Remote ...................................................................... 28
5.7 Operations in OSD Menu .................................................................................................................. 29
5.7.1 Options ...................................................................................................................................... 29
5.7.2 Instructions for VGA Converting Cable .................................................................................. 30
5.7.3 Picture ....................................................................................................................................... 32
5.7.4 Setup ......................................................................................................................................... 33
5.8 GUI Control ........................................................................................................................................ 33
5.8.1 Control Menu ............................................................................................................................ 34
5.8.2 Configuration Menu ................................................................................................................. 35
5.8.3 RS232 Control Menu ................................................................................................................ 36
5.8.4 Password Menu ....................................................................................................................... 37
5.8.5 GUI Update ................................................................................................................................ 37
6. Panel Drawing ............................................................................................................................ 38
7. Troubleshooting & Maintenance ................................................................................................. 39
8. After-Sales Service .................................................................................................................... 40
www.tekvox.com
1201-N+
79033-N+ User Manual
1. Product Introduction
The TEK 1201-N+ is a next generation, compact seamless presentation switcher/scaler that can be
used on a wall, rack-mounted in a podium, teacher’s desk, or under a conference table. The switcher
includes the following:
Six input seamless Auto-Switcher Scaler
Inputs - 5 HDMI, 1 Multi-format (VGA, YUV, or Video)
Outputs – Mirrored HDMI and HDBaseT Lite
Balanced stereo audio output
RS232 control from unit or receiver
TCP/IP control
Stereo Mix Input
Separate Program and Mix volume control
Operates with TEKVOX Drop-In commands
Hands-Free operation with automatic switching and power control of a display using CEC
IR remote control from receiver
IR pass through to receiver
IR from receiver to sources
On Screen Menu Controls for easy setup
Control of HDMI sources with CEC or IR
Control of display with CEC, IR, or RS232
Allows RS232 pass through for display control
Rack and wall mounting kit included
1.1 Features
HDMI 1.4a and HDCP 2.2 Compliant
Supports CEC transport commands for each HDMI input
Supports CEC Display On/Off commands
Supports video auto-switching with automatic TV power control
Bi-directional IR and RS232 control. Including TEKVOX Macro commands
Selectable output resolutions: 1920x1200, 1920x1080, 1600x1200, 1600x900, 1360x768,
1280x800, 1280x720, 1024x768
www.tekvox.com
1201-N+
79033-N+ User Manual
1.2 Package List
1 x TEK 1201-N+
2 x Wall Mounting ears
2 x Rack Mounting ears
1 x Inline Power Adapter (24VDC, 2.71A)
1 x IR remote
1 x IR receiver
1 x IR emitters
1 x RS232 cable (3-Pin phoenix connector to DB9)
1 x VGA converting cables (male VGA to female YPbPr)
2 x 3-Pin phoenix connectors
1 x 5-Pin phoenix connector
6 x Screws (black color)
4 x Plastic cushions
1 x TEK TPUH411RA HDBaseT Receiver
1 x User Manual
Note: Please contact your distributor immediately if any damage or defect in the components is found.
www.tekvox.com
1201-N+
79033-N+ User Manual
2. Specifications
Input 5 HDMI (Female), 1 VGA (Female, 15-pin)
Video Signal HDMI, YPbPr, C-video, VGA
Output 1 HDMI (Female)
1 HDBaseT (Female RJ-45)
IR Input 1 IR In, 3.5mm mini jack
IR Output 1 IR Out, 3.5mm mini jack
Resolution Range 1024×768, 1280×720, 1280×800, 1920×1080, 1600×1200,
1600×900, 1920×1200
Bandwidth
HDMI: 4.95 Gbps (1.65 Gbps per color)
C-video: 150 MHz
YPbPr: 170 MHz
VGA: 375 MHz
Transmission Distance 325 ft. (100m)
HDCP Compliant w/ DVI & HDMI 1.4, HDCP 2.2
Audio Input
1 Stereo Audio for VGA (3.5mm jack)
1 Stereo Line Level (3 Pin Phoenix)
2 Stereo Audio Input (3.5mm jack)
Audio Output 1 Balanced Stereo (5 Pin Phoenix)
Frequency Response 20Hz~20KHz
Control
IR Remote
Front Panel Buttons
RS-232
TCP/IP
Power Supply Input: 100VAC ~ 240VAC, 50/60Hz
Output: DC 24V, 2.71A
Power Consumption 28W
Temperature 14 ~ 104°F (-10 ~ 40°C)
Humidity 10% ~ 90%
Case Dimension 8.7″(221mm) x 1.73″(44mm) x 9.25″(235mm)
1U Rack Mountable
Product Weight 2.1 lbs. (0.95kg)
www.tekvox.com
1201-N+
79033-N+ User Manual
3. Product Appearance
3.1 1201-N+ Presentation Switcher Panels
3.1.1 1201-N+ Front Panel
1) Built-in IR Receiver
2) Power Indicator - RED when the device is in standby, GREEN when device is powered on and no
indicator when there is no power to device.
3) 1-HDMI/MHL input selector and activity LED/Left key for OSD.
4) 2-HDMI input selector and activity LED/Right key for OSD.
5) 3-HDMI input selector and activity LED/Up key for OSD.
6) 4-HDMI input selector and activity LED/Down key for OSD.
7) 5-HDMI input selector and activity LED/ENTER key for OSD.
8) 6-VGA input selector and activity LED/OSD menu button.
9) Auto-switching selector and activity LED.
Press this to enter or exit auto-switching mode
Long-press this button 3 seconds or more to reset output resolution to 720p or to activate
HDMI and HDBT outputs if they have been turned off.
Note: When you set any VGA port to C-video or YPbPr in Manual-switching mode, the
system will not be able to enter Auto-switching mode.
10) Volume knob for variable audio control - Push knob in to toggle between ‘MIX’ and ‘Source’
control.
VO LUME
IR
SO URCE
MIX
1-HDMI/MH L 6-VG A
5-HDMI3- HDMI 4-HD MI2-HDM I AUTO
RES RES ET/3sMENU/3 sENTER
TEK 1201-N
1
2
3
4
5
6
7
8
9
10
www.tekvox.com
1201-N+
79033-N+ User Manual
3.1.2 1201-N+ Rear Panel
1) INPUTS
Video input ports: 1 HDMI/MHL, 4 HDMI inputs, and 1 VGA.
Audio input ports: 1 VGA auxiliary audio input.
2) OUTPUTS
HDMI output: HDMI video output port.
HDBaseT output: Support PoH. Connect with a compatible HDBaseT Receiver to transmit AV
signal, IR, or RS232 control signal.
3) AUDIO IN
MIX: 3-Pin phoenix connector for line audio input.
1-AUDIO: 3.5mm mini jack, embedded audio input for 1-HDMI.
2-AUDIO: 3.5mm mini jack, embedded audio input for 2-HDMI.
4) CONTROL
IR IN & IR OUT: Connect with IR Receiver and Emitter to control devices via IR.
IR EYE: Connect with the IR Receiver (with carrier wave only) to control this SC61TS via the
including IR Remote.
FIRMWARE: Type-A USB port for updating system firmware or loading customized EDID data.
RS232: Serial port, 3-pin phoenix connector - connect with a control device (such as a PC) to
control SC61TS or other devices connected with HDBaseT Receiver.
TCP/IP: Ethernet port - connect with PC to control SC61TS via GUI.
5) AUDIO OUT - Stereo balanced L/R audio output.
6) DC 24V - Locking power port, connect 24V DC power adapter.
Table des matières
Autres manuels Tekvox Changer
Tekvox
Tekvox TEKMV41-HD Manuel utilisateur
Tekvox
Tekvox SCU21T-KVM Manuel utilisateur
Tekvox
Tekvox 71028-DI Manuel utilisateur
Tekvox
Tekvox TEK 1 Manuel utilisateur
Tekvox
Tekvox MV41 Manuel utilisateur
Tekvox
Tekvox TEK MV71-4K 79065 Manuel utilisateur
Tekvox
Tekvox MV41 Plus Manuel utilisateur
Tekvox
Tekvox TEK 1201-HD Manuel utilisateur
Tekvox
Tekvox TEK 1201-MV Manuel utilisateur
Tekvox
Tekvox TEK 51T-HD Manuel utilisateur
