WVR720UP, WVR820UP, and WVR830UP Upgrades

for the WVR7200, WVR8200, and WVR8300

Waveform Rasterizers

ZZZ

Instructions

Warning

The servicing instructions are for use by qualiﬁed personnel

only. To avoid personal injury, do not perform any servicing

unless you are qualiﬁed to do so. Refer to all safety summaries

prior to performing service.

www.tektronix.com

*P075101603*

075-1016-03

or suppliers, and are protected by national copyright laws and international treaty provisions.

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication

supersedes that in all previously published material. Speciﬁcations and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc.

14150 SW Karl Braun Drive

P.O. Box 500

Beaverton, OR 97077

USA

For product information, sales, service, and technical support:

In North America, call 1-800-833-9200.

Worldwide, visit www.tektronix.com to ﬁnd contacts in your area.

Table of Contents

Important safety information...................................................................................... 1

General safety summary ...................................................................................... 1

Service safety summary....................................................................................... 3

Terms in this manual .......................................................................................... 4

Symbols and terms on the product........................................................................... 4

Kit description ...................................................................................................... 5

Products......................................................................................................... 7

Required tools.................................................................................................. 7

Kit parts lists ................................................................................................... 8

Upgrade installation............................................................................................... 12

Verify the currently installed options....................................................................... 12

How to prevent electrostatic discharge..................................................................... 13

Install software upgrade...................................................................................... 14

Install the option hardware................................................................................... 18

Install the option software key .............................................................................. 35

Ver i fy the upgrade................................................................................................. 36

Quick veriﬁcation............................................................................................. 36

Detailed veriﬁcation.......................................................................................... 36

WVR720UP, WVR820UP, and WVR830UP Upgrades i

Table of Contents

ii WVR720UP, WVR820UP, and WVR830UP Upgrades

Important safety information

This manual contains information and warnings that must be followed by the user

for safe operation and to keep the product in a safe condition.

To safely perform service on this product, additional information is provided at

the end of this section. (See page 3, Service safety summary.)

General safety summary

Use the product only as speciﬁed. Review the following safety precautions to

avoid injury and prevent damage to this product or any products connected to it.

Carefully read all instructions. Retain these instructions for future reference.

Comply with local and national safety codes.

For correct and safe operation of the product, it is essential that you follow

generally accepted safety procedures in addition to the safety precautions speciﬁed

in this manual.

The product is designed to be used by trained personnel only.

Only qualiﬁed personnel who are aware of the hazards involved should remove

the cover for repair, maintenance, or adjustment.

Before use, always check the product with a known source to be sure it is

operating correctly.

This product is not intended for detection of hazardous voltages.

Use personal protective equipment to prevent shock and arc blast injury where

hazardous live conductors are exposed.

While using this product, you may need to access other parts of a larger system.

Read the safety sections of the other component manuals for warnings and

cautions related to operating the system.

When incorporating this equipment into a system, the safety of that system is the

responsibility of the assembler of the system.

WVR720UP, WVR820UP, and WVR830UP Upgrades 1

Important safety information

To avoid ﬁre or personal

injury

Use proper power cord. Use only the power cord speciﬁed for this product and

certiﬁed for the country of use.

Do not use the provided power cord for other products.

Ground the product. This product is grounded through the grounding conductor

of the power cord. To avoid electric shock, the grounding conductor must be

connected to earth ground. Before making connections to the input or output

terminals of the product, make sure that the product is properly grounded.

Power disconnect. The power cord disconnects the product from the power

source. See instructions for the location. Do not position the equipment so that

it is difﬁcult to operate the power cord; it must remain accessible to the user at

all times to allow for quick disconnection if needed.

Observe all terminal ratings. To avoid ﬁre or shock hazard, observe all ratings

and markings on the product. Consult the product manual for further ratings

information before making connections to the product.

Do not apply a potential to any terminal, including the common terminal, that

exceeds the maximum rating of that terminal.

Do not operate without covers. Do not operate this product with covers or panels

removed, or with the case open. Hazardous voltage exposure is possible.

Avoid exposed circuitry. Do not touch exposed connections and components

when power is present.

Do not operate with suspected failures. If you suspect that there is damage to this

product, have it inspected by qualiﬁed service personnel.

Disable the product if it is damaged. Do not use the product if it is damaged

or operates incorrectly. If in doubt about safety of the product, turn it off and

disconnect the power cord. Clearly mark the product to prevent its further

operation.

Before use, inspect voltage probes, test leads, and accessories for mechanical

damage and replace when damaged. Do not use probes or test leads if they are

damaged, if there is exposed metal, or if a wear indicator shows.

Examine the exterior of the product before you use it. Look for cracks or missing

pieces.

Use only speciﬁed replacement parts.

Do not operate in wet/damp conditions. Be aware that condensation may occur if

a unit is moved from a cold to a warm environment.

Do not operate in an explosive atmosphere.

Keep product surfaces clean and dry. Remove the input signals before you clean

the product.

2 WVR720UP, WVR820UP, and WVR830UP Upgrades

Important safety information

Provide proper ventilation. Refer to the installation instructions in the manual for

details on installing the product so it has proper ventilation.

Slots and openings are provided for ventilation and should never be covered or

otherwise obstructed. Do not push objects into any of the openings.

Provide a safe working environment. Always place the product in a location

convenient for viewing the display and indicators.

Avoid improper or prolonged use of keyboards, pointers, and button pads.

Be sure your work area meets applicable ergonomic standards. Consult with an

ergonomics professional to avoid stress injuries.

Use care when lifting and carrying the product.

Use only the Tektronix rackmount hardware speciﬁed for this product.

Servicesafetysummary

The Service safety summary section contains additional information required to

safely perform service on the product. Only qualiﬁed personnel should perform

service procedures. Read this Service safety summary and the General safety

summary before performing any service procedures.

To avoid electric shock. Do not touch exposed connections.

Do not service alone. Do not perform internal service or adjustments of this

product unless another person capable of rendering ﬁrst aid and resuscitation is

present.

Disconnect power. To avoid electric shock, switch off the product power and

disconnect the power cord from the mains power before removing any covers or

panels, or opening the case for servicing.

Use care when servicing with power on. Dangerous voltages or currents may exist

in this product. Disconnect power, remove battery (if applicable), and disconnect

test leads before removing protective panels, soldering, or replacing components.

Verify safety after repair. Always recheck ground continuity and mains dielectric

strength after performing a repair.

WVR720UP, WVR820UP, and WVR830UP Upgrades 3

Important safety information

Termsinthismanual

These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result

in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in

damage to this product or other property.

Symbols and terms on the product

These terms may appear on the product:

DANGER indicates an injury hazard immediately accessible as you read

the marking.

WARNING indicates an injury hazard not immediately accessible as you

read the marking.

CAUTION indicates a hazard to property including the product.

When this symbol is marked on the product, be sure to consult the manual

to ﬁnd out the nature of the potential hazards and any actions which have to

betakentoavoidthem. (Thissymbolmayalsobeusedtorefertheuserto

ratings in the manual.)

The following symbol(s) may appear on the product:

4 WVR720UP, WVR820UP, and WVR830UP Upgrades

Kit description

This document provides instructions for installing the video, audio, and analysis

upgrades listed in the following tables into an existing Tektronix WVR7200,

WVR8200, or WVR8300 waveform rasterizer.

Table 1: Supported video upgrades

Video

upgrades WVR820UP WVR830UP WVR720UP Description

Option 2SDI Adds a second SDI input module, adding 2 additional SDI

inputs that support 3G-SDI, HD-SDI, and SD-SDI. (Option

3G is required for 3G-SDI support).

Option 3G Adds support for 3G-SDI signal formats.

Option 4K Adds support for UHDTV1/4K signal formats.

(requires Options 3G and 2SDI)

Option CPS Adds support for Composite Analog Video Monitoring;

2 composite Analog inputs; passive loop-through. This

option not compatible with Option 2SDI.

Option 3D Adds Stereoscopic 3-D Video Monitoring Capabilities

(including Simultaneous Input Monitoring (SIM) of dual

SDI inputs and synchronized left eye and right eye signals

monitoring (SyncVu™)).

Option S3D Adds Stereoscopic 3-D Video Monitoring Capabilities

(including Simultaneous Input Monitoring (SIM) of dual

SDI inputs and synchronized left eye and right eye signals

monitoring (SyncVu™)).

Option GEN Adds color bar and pathological signal generator for

SD/HD SDI. Option 3G required for 3G-SDI support.

Option AVD Add support for out-of-service audio/video delay

measurement; requires Option AD or DPE.

Option SIM Adds simultaneous monitoring of 2 HD/SD-SDI inputs

or one HD/SD-SDI input and one CPS input; Option 3G

required for 3G-SDI formats support.

WVR720UP, WVR820UP, and WVR830UP Upgrades 5

Kit description

Table 2: Supported audio upgrades

Audio

upgrades WVR820UP WVR830UP WVR720UP Description

Option AD Adds Analog Audio Monitoring (2 sets of 6 channel Analog

Audio inputs and 8 channels of Analog Audio outputs); 16

channels Embedded and AES/EBU Digital Audio support

(8 channels at a time).

Option DPE Adds Option AD capabilities (Analog and Digital Audio,

Embedded or External AES), plus support for decoding

and monitoring Dolby E, Dolby D, and Dolby Digital Plus

Audio. (Audio cable available separately).

Table 3: Supported analysis upgrades

Analysis

upgrades WVR820UP WVR830UP WVR720UP Description

Option EYE Adds Eye Pattern Display and Jitter Measurement

Package (includes 3G-SDI, HD-SDI, and SD-SDI

Eye pattern and Jitter waveform displays; automated

measurements of Eye pattern paramenters,Jitter, and

cable parameters; color bar and pathological signal

generation); Option 3G required for 3G-SDI support.

Option PHY Adds Physical Layer Measurement Package (includes

3G-SDI, HD-SDI, and SD-SDI Eye pattern and jitter

waveform displays; automated measurements of Eye

pattern parameters, jitter, and cable parameters; color bar

and pathological signal generation); Option 3G required

for 3G-SDI support.

Option PHY3 Adds Physical Layer Measurement Package (includes

3G-SDI, HD-SDI, and SD-SDI Eye pattern and jitter

waveform displays; automated measurements of Eye

pattern parameters, jitter, and cable parameters; Option

3G required for 3G-SDI support.

Option PROD Adds Advanced Gamut Monitoring Package (Spearhead

Display and Luma Qualiﬁed Vector Display).

Option DAT Adds data analysis capabilities. Allows for logic-level view

of video and embedded audio data stream and ANC data

extraction.

6 WVR720UP, WVR820UP, and WVR830UP Upgrades

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Tektronix Instrument de mesure

Tektronix

Tektronix RSA5103B Manuel

Tektronix

Tektronix RSA6100A Series Manuel d'utilisation et d'entretien

Tektronix

Tektronix 492P Manuel d'utilisation et d'entretien

Tektronix

Tektronix SDA601 Manuel utilisateur

Tektronix

Tektronix S-1 Manuel utilisateur

Tektronix

Tektronix RSA3408B Manuel utilisateur

Tektronix

Tektronix 7L5 Manuel utilisateur

Tektronix

Tektronix CSA8000B Series Manuel utilisateur

Tektronix

Tektronix TLA 700 Series Manuel utilisateur

Tektronix

Tektronix VM700T Manuel utilisateur

Tektronix

Tektronix KEITHLEY 2600B Series Manuel utilisateur

Tektronix

Tektronix 067 -0794-00 Manuel utilisateur

Tektronix

Tektronix 492, 492P Manuel utilisateur

Tektronix

Tektronix TLA7000 Series Manuel utilisateur

Tektronix

Tektronix WFM5200 series Manuel d'utilisation et d'entretien

Tektronix

Tektronix WVR7200 Manuel d'utilisation et d'entretien

Tektronix

Tektronix WCA2UP-03 Manuel utilisateur

Tektronix

Tektronix VM700A VMTB Manuel utilisateur

Tektronix

Tektronix PRISM MPI Manuel utilisateur

Tektronix

Tektronix 3177 Manuel utilisateur

Tektronix

Tektronix 7L12 Manuel utilisateur

Tektronix

Tektronix AWG70001B Manuel

Tektronix

Tektronix RSA306 Manuel d'utilisation et d'entretien

Tektronix

Tektronix P6241 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
