Teka DE 90.2 Guide de l'utilisateur
43
Code Nº: PRM-00-0001
Revised / Date: 2006
INSTALLER’S MANUAL
Page Nº: 43 of 95
5 DECORATIVE HOODS
When fitting a decorative hood, there are a number of important factors to bear in mind. These
include:
Before installing the hood, check that there are is no aesthetic damage, such as scratches
or dents before you procede.
Check that all the technical information appearing on the specification plate corresponds to
the characteristics of the mains electrical supply in question (voltage and frequency).
Respect at all times the local regulations referring to electrical installation and evacuation of
gases.
The appliance should be connected to the mains supply via a suitable omnipolar switch
with a 3 mm miminum gap between contacts.
Do not connect the appliance to ducts used for the evacuation of gases of a non-electrical
nature, such as boilers, chimneys etc.
Do not start up the appliance if the mains cable or control panel appear to be damaged in
any way.
Once the apparatus has been fitted, ensure that the mains cable does not come into
contact with sharp metal edges.
Minimum distances between the hob and hood should be strictly observed: 60cm for
electric hobs 70 cm for gas and mixed hobs.
For optimum performance, theexit duct should not exceed 4 metres in length, nor have
more than two 90ºbends, and its diameter should be at least 120 mm.
44
Code Nº: PRM-00-0001
Revised / Date: 2006
INSTALLER’S MANUAL
Page Nº: 44 of 95
Model Dimensions
ISLA
ND ALADA ISLA
DS ISLA
45
Code Nº: PRM-00-0001
Revised / Date: 2006
INSTALLER’S MANUAL
Page Nº: 45 of 95
Model Dimensions
CL 90
DX 90
ASYMETRIC DA 90
46
Code Nº: PRM-00-0001
Revised / Date: 2006
INSTALLER’S MANUAL
Page Nº: 46 of 95
Model Dimensions
DS 60.1/70/90
DI 70/90/110
DM 60/70/90
47
Code Nº: PRM-00-0001
Revised / Date: 2006
INSTALLER’S MANUAL
Page Nº: 47 of 95
Model Dimensions
DE 60.2 / 70.2/ 90.2
ND ALADA 70 / 90
CONICAL DC 60/70/90
48
Code Nº: PRM-00-0001
Revised / Date: 2006
INSTALLER’S MANUAL
Page Nº: 48 of 95
Model Dimensions
RUSTIC DR 90
Model Dimensions
DF 90
49
Code Nº: PRM-00-0001
Revised / Date: 2006
INSTALLER’S MANUAL
Page Nº: 49 of 95
DP DH DAL
Accessories supplied with decorative hoods:
150/125 mm adaptor
Anti-return valve
Support for tube cover
Support for wall mounting
Screws
Rawlplugs
Washers
50
Code Nº: PRM-00-0001
Revised / Date: 2006
INSTALLER’S MANUAL
Page Nº: 50 of 95
5.1 INSTALLATION OF DECORATIVE HOOD
DX ISLA
This hood should be fitted in the following way:
1) Using the support (O), mark and make a small hole for the screws (S) (8x45) in the ceiling.
2) Secure the support with the corresponding screws (S).
3) Place the upper part of the internal structure (A6) on the support (O), with screws (Q)
(M6x16).
4) Adjust the decorative supplementary piece (U), carefully securing it with the screws (V) (M4)
supplied with the piece.
5) Insert piece (B) if the interior tube (not supplied) has a diametre of 120 mm.
6) Secure the interior tube with a jubilee clip (not supplied) to (B), or on the exit section of the
motor, as appropriate.
7) Insert the upper tube cover (A8) inside the lower tube cover (A9).
51
Code Nº: PRM-00-0001
Revised / Date: 2006
INSTALLER’S MANUAL
Page Nº: 51 of 95
8) Adapt the combination of the lower tube cover (A9) and the upper tube cover (A8) to the
lower part of the of the internal structure (A7) and the decorative extra piece (U).
9) Fit the whole of the combined lower piece to the upper piece and mount on the ceiling with
the screws provided (A10) (M4 x 12), to the desired height.
10) Connect the upper part of the inner tube (not included) to the exit.
11) Lift the upper tube cover (A8) and secure it to the upper part with the supplied screws (G)
(M4 x 12), with a conical head.
12) Adjust the decorative supplementary piece (U), securing it to the hood with the screws (V)
(M4) supplied with the piece.
52
Code Nº: PRM-00-0001
Revised / Date: 2006
INSTALLER’S MANUAL
Page Nº: 52 of 95
ND ALADA ISLA
DS ISLA
DX 90
Ce manuel convient aux modèles suivants
14
Autres manuels Teka hotte de ventilation
Teka
Teka ND ISLA Vr. 03 Manuel utilisateur
