TEINNOVA covix mo3 Manuel utilisateur
Ozone quantity meter
mo3
user manual
ENG
This instruction manual is protected by copyright. We reserve all rights,
especially the rights to produce, translate and prepare it using electronic systems.
©
introduction
Training service
Technical service
Thank you for placing your trust in a quality product from TEINNOVA.
This product has been made using modern manufacturing techniques and
thorough quality assurance measures.
We strive to do everything we can to make sure you are satisfied with this
product and can operate it without any issues.
Should you have any questions about this product, please contact either your
stockist or us directly.
Before use, carefully read the operating instructions for your equipment.
Treat this manual as part of the product and always keep it nearby for future
reference.
We offer companies optional training that is specific to our products and
also teaches their operators how to provide the best service and thus con-
tribute to the success of their end customers. Aspects such as knowing how
to prepare a fair and objective quote, to respond to specific problems that
may arise, or to offer a more professional and efficient service.
Because we manufacture our own cleaning equipment we can constantly
control the quality and performance of each product we manufacture. This
is what has allowed us to maintain low-cost service rates which have always
been settled by quickly our own Technical Support Service who are mana-
ged by the same team as our factory.
We have all kinds of spare parts for your equipment, as well as related ac-
cessories.
Dear Customer,
1
7
8
4
10
2-3
9
6
5-6
11
table of measurements
table of contents
symbols used
know your equipment
troubleshooting guide
safety warnings
technical specifications
guarantee conditions
operating instructions
maintenance and care
declaration of conformity
1
symbols used
DANGER!
WARNING!
ATTENTION!
IMPORTANT!
All the symbols used in this manual, as well as those on the equipment itself, are explained in this section. It is
important to read the text associated with these symbols carefully, since it is about personal safety and equip-
ment safety.
This symbol warns of a potentially dangerous situation that could result in se-
rious injury or even death if the given instructions are not followed appropria-
tely. Make sure you read all the instructions in the “Safety Information” section.
This symbol warns of a potentially dangerous situation that could result in
minor or moderate injury, or damage to property resulting in injury to people
if the given instructions are not followed appropriately.
This symbol warns you of a situation that may cause damage to property,
without causing injury, if the given instructions are not followed appropriately.
This symbol highlights information relating to the best way to use the equip-
ment while avoiding any possible improper operation.
2
know your equipment
DESCRIPTION AND CONTENTDESCRIPTION AND CONTENT
The pump type gas detector is safety equipment that can be used continuously to detect
the concentration of filtered gas.
The calculation speed is fast and the test data is accurate and stable.
The detector uses a 2.4 inch high definition color LCD display, through an interface and
messages in English. USB charging, built-in 2900ma high-capacity lithium battery and hi-
gh-end vacuum suction pump, high-quality gas sensor, with excellent sensitivity and exce-
llent repeatability.
It has a built-in water and dust filter to prevent damage to sensors and instruments due to
water vapour and dust.
APPLICATIONS
Disinfection
of spaces
Disinfection
of air ducts
Vehicles of
all kinds
3
Gas sensing hole
Alarm indicator
TFT Color LCD
Selection and air
pump key
Up arrow
key
Return function
keys
USB Recharge
Confirm function key►
Long press switch
know your equipment
EQUIPMENT PARTS AND CONTENTSEQUIPMENT PARTS AND CONTENTS
4
>Sudden changes in air pressure can affect the sensor reading of oxygen.
>During use, keep the sensor air inlet clean. A lock on the inlet air pressure may cause the detec-
tor reading to be low.
>Operators must be sufficiently prepared. And they must wear the corresponding protection
equipment.
>Properly store your equipment for transport. Do not store the detector in a static high tempera-
ture or humid environment.
>Regularly check your equipment to verify its condition and that there is no breakage.
>Maintenance or replacement of parts without the manufacturer’s permission is prohibited.
>Installation, depuration, configuration and other operations must be carried out by professionals.
>The meter should avoid contact with organic solvents, alcohol, coating, oil and high concentra-
tion gas, including silica gel and other adhesives.
>It must not be stored or used in an environment containing corrosive gases (such as concen-
trated chlorine, etc.), or in other hostile environments (including high and low temperature), high
humidity, electromagnetic field and intense sunlight).
> In the event of a fault, please contact TEINNOVA Technical Assistance Service on
+34 941 44 50 56.
safety warnings
5
operating instructions
Powered up:
Press and hold“ ”key for 3 seconds, the backlight of the instrument will be on, and the voice
prompt “welcome to use the intelligent voice gas detector, please wait while starting”.
Turned off:
Long press“ ”key for 3 second.
During use:
After turning on the machine, first enter the heating interface. The warm-up time is 60 seconds.
In the warm-up state, you can also press the Enter key to skip the warm-up interface, but it is not
recommended because the value read may be unstable or inaccurate. After warming-up, some
warning messages may appear and then enter the measurement status.
Load mode:Load mode:
When the USB charging cable is inserted in the off state, the current power will be displayed
on the screen. When the power is only 10%, there will be a voice message “power is insuffi-
cient, charge”. If the power is lower than 5%, the detector will automatically shut down to avoid
data loss inside the detector and unexpected damage to sensitive components inside the
instrument due to lack of voltage.
Note: make sure that the meter is fully charged before use.
Air pump switch:
Briefly press the key to turn the air pump on and off.
The gas concentration curve will be drawn only when the air pump is on at the curve interface.
Change of unit:
On the gas detection screen, briefly press the start button to change the current gas unit.
Currently, ppm and Mg / m3 are supported for switching.
Alarm configuration:
The user can set the alarm threshold (high/low) and the alarm mode of the target gas through
this option. When the gas concentration is higher than the minimum alarm threshold set by the
system, the detector will give a voice message and then simulate the alarm signal by sounding
the rma all the time; the alarm light on the detector and
the internal vibration motor will start at the same time. When the gas concentration detected
by the detector returns to the normal value, the alarm will be activated.
For the oxygen sensor, when the oxygen concentration value is below the threshold minimum
system threshold or higher than the maximum system threshold, the detector will give an
alarm.
Alarm Threshold: when in the alarm threshold configuration interface, move the focus to select
6
troubleshooting guide
The ozone meter cannot be turned on.
The meter cannot be charged.
No response to the test value of the gas
on the meter.
The concentration value of the instrument in
clean air is unstable.
The battery is exhausted. Restart the meter
after charging. If it cannot be started, contact
SAT.
Measure if the charger output voltage is
4.75 - 5.5v. If the output voltage is abnormal,
replace the charger.
- The oxygen content of the introduced gas
is too low: <5%.
- The life of the sensor has ended.
Place the instrument in a clean place
without interfering gas, and the instrument
value will fall to the normal value.
problem solution
the high alarm value or the low alarm value to be modified. The user can press the “OK” key to
operate the value, change the cursor to select a value through the keys “◄” y “►”, add or sub-
tract the value through “▲” and “▼”,
press the “OK” key to confirm when the value is set, move the highlight to the storage by pres-
sing the “◄” and “►” keys, and press it again to save.
At this point, the system indicates that the save is successful and the voice mentions “Save suc-
cessful”. Press “▼” to return to the menu.
There are three detector alarm modes: sound, vibration and
light. When our company’s gas detector leaves the factory,
the alarm modes are activated by default and can be adjusted
by the user according to actual needs.
System configuration:
User can move the cursor to the “system setting” icon and
press “OK” key to enter the system setting selection interface.
Year, month, day and time setting: You can set the time with “◄” and “►”, to finish press OK. Press
the “▼” key during setting to return to the menu.
Communication settings: you can set the direction and speed of transmission
of the instrument. When importing data to the computer,
Password setting: Default is “1111”. If you change it and forget it, you can only contact the company
staff to send it back to the factory for recovery.
Air pump settings: Set the air pump to close
automatically at a fixed time, with a fixed maximum time of 999 seconds. If not required
time, change the time to 000 seconds and the air pump will be normally open.
