Detailed Installation Instructions

TECUMSEH EUROPE Sales and Logistics

2, avenue Blaise Pascal, 38090 Vaulx-Milieu, France

Tel.: +33 (0)4 74 82 24 00

[email protected] - www.tecumseh.com

FH2Long Notice

03/2020

Please read this notice in full.

The implementation, operation, maintenance and end-of-life management of products involves following strict rules in accordance

with existing standards and best practices. Current standards and legislation should be respected in the country where the

compressor is installed, and the rules of good refrigeration and electrical installation practice should be applied.

These instructions cover the main points of the ISO Standards. The EN guidelines and standards described below prevail in the

European Union.

1. Statements of compliance and incorporation

These refrigeration compressors are designed to be incorporated into machines in accordance with the Machinery Directive

2006/42/EC. They comply with the Low voltage Directive 2014/35/EU and the PED Directive 2014/68/EU.

Their commissioning is only permitted if they have been assembled in accordance with the following instructions, and if the machines

comply with existing regulations.

In case of the use of A2L-classified refrigerants following ISO 817, follow the safety rules specific to flammable fluids. The compressors

will be installed, maintained in accordance with ISO 5149 or EN 378 or EN60335-2 safety standards. FH2 compressors with A2L

refrigerants requiring above compliance are with designation FH****N for R1234yf, FH**** P for R454C and R455A.

2. Safety and risks associated with the implementation and use of flammable refrigerants, classified as Category A2L

2.1. Flammable refrigerants:

R1234yf is a pure hydrofluoro olefin (HFO) fluid.

R455A is a non-azeotropic mixture of hydrofluoro olefin (HFO), hydrofluorocarbon (HFC) and natural fluid composed of R1234yf

(75.5%), R32 (21.5%) and R744 (3%)

R454C is a non-azeotropic mixture of hydrofluoro olefin (HFO) and hydrofluorocarbon (HFC) composed of R1234yf (78.5%) and R32

(21.5%)

R1234yf, R455A, and R454C fluids are heavier than air so they will naturally accumulate at the floor or bottom of the installation in

the absence of ventilation .

Their main features are:

Refrigerant R1234yf R455A R454C

Security class A2L A2L A2L

Lower flammability limit under

normal conditions in volume/volume

according to ISO 817

6.2% 11.8% 6.2%

Lower flammability limit under

normal conditions 0.289 kg/m30.431 kg/m3

0.293 kg/m3

Practical limit

20% LFL 57.8 g/m386 g/m3

59 g/m3

Self-inflammation temperature

(following ISO 817) 405°C ND (473°C supplier

data)

ND (> 400°C supplier

data)

FH2Long Notice

03/2020

Never use the product without referring to the Safety Data Sheet (S.D.S.) provided by refrigerant supplier/manufacturer.

2.2. Scope of application of standards for refrigeration systems using flammable fluids

Where authorised by local regulations and provided that the location is suitable, the maximum Refrigerant charge quantity for

hermetically sealed compressors running on R1234yf, R455A, R454C are defined in the table below:

Refrigerant

following EN 60335-2

series standards

(except EN 60335-2-40)

following

CEI 60335-2-89

standards

following

EN 378-1: 2017*

R1234yf 150g 1200g 1700g

R455A 150g 1200g 2500g

R454C 150g 1200g 1600g

*For higher refrigerant charge Quantities, please refer to the requirements of Standard EN 378-1

2.3. Preventing the formation of potentially explosive zones

The use of flammable fluids may present a risk of ignition in the event of a leak. It is therefore important to ensure that the refrigeration

system design and adequate compressor ventilation to avoid risk of formation of an explosive zone.

2.4. Staff Qualification

It is essential that Standard EN 378-3 is observed during installation and Standard EN 378-4 during maintenance works.

To maintain and repair the installations, staff must be authorised to handle refrigerants and correctly trained in the handling of

flammable refrigerants in order to avoid the risk of the formation of an explosive atmosphere.

Consequently, staff must know the tools, the transportation procedure for the compressor and refrigerant, and the safety precautions

and regulations that apply to maintenance and repair work. Do-not use ignition sources while handling flammable refrigerants.

2.5. Protection of the compressor's electric terminal

The disintegration of the insulation (glass bead) on a compressor electrical terminal due to physical shock or over heating can result

in terminal venting . Oil and refrigerant can spray out of the compressor if one of the terminal pins is ejected from the hermetic

terminal, this mixture can be ignited by electricity/ spark and produce flames that can lead to serious burns or death. Any accidental

damage to the electrical terminal during compressor’s installation or operation must be scrapped.

To reduce the risk of electrocution or serious burns or death from terminal venting with ignition never energize the system unless

the compressor’s protective terminal cover is securely fastened and the compressor is properly connected to ground.

Also, especially when using flammable refrigerants, Tecumseh advocates the use of a security system to protect users, installers and

installation. The system will be able to detect a spike in intensity that could melt the insulation (the phenomenon of "terminal

venting"), and will thereby cut off the compressor's power supply.

Since the compressor is not equipped with protection in the case of an external fire, it is appropriate for the equipment manufacturer

to secure the installation to prevent a fire. Adequate means of purging and protection against exceeding permissible limits (see

conditions on the PED label) must be provided. Compressors should not be installed in a corrosive or dusty environment.

FH2Long Notice

03/2020

3. Specifications - Marking compressors in the FH2range

3.1. Identification label and designation:

FH****N, FH****P compressors are CATEGORY II certified under the 2014/68/EU PED Pressure Equipment Directive.

(Reference free internal volume: 6.16L)

Labels contain the following information:

Information in agreement with EN 378-2:

Ref. Designation

a Voltage

b Frequency

c Number of phases

d Bill of Material

e Refrigerant

f Model Number

g Serial number

h Maximum allowable pressure (*)

i Min/max temperature (*)

j 1.1 * PS (*)

k Registration number of the notified body (*)

l Manufacturing and testing date (*)

m Free volume

FH****P compressors are qualified for R455A and R454C

FH **** N compressors are qualified for R134a and R1234yf.

The Identification label of these compressors has a yellow Flammable

warning logo as shown opposite:

In the case of multi-fluid compressors, the Printed PS pressure = at the pressure of the fluid + binding to TS maxi

Fluids PS (b) PED category

R-404A

20.1

R-452A

R-449A

20.4

R-448A

20.4

R-455A

21.5

R-454C

18.4

R-1234yf

10.8

R-513A

11.5

R-134a

10.9

FH2Long Notice

03/2020

3.2. Specifications

The housing of the compressors in the ‘FH2’ family is subject to the low pressure of the refrigeration system.

In line with the PED and in order to ensure the best level of quality of its products at all times, Tecumseh tests each compressor on an

assembly line at a pneumatic pressure which is greater than or equal to the requirement 1.1 x PS as per Annex C 1.3.2 of standard NF

EN 14276-1, irrespective of the refrigerant indicated on the identification label and based on the calculation of the most Critical

refrigerant,

For information: 1.1 * PS (46°C sat) = 24 bar rel for R455A.

Additional burst tests are also performed periodically.

4. Transport - handling:

The compressor is charged with oil and nitrogen (0.3 to 0.5 bar) at the final stage of assembly inside the factory. The compressors are

delivered with out refrigerant charged .

For information about compressor delivery, refer to your terms of sale. Check the condition of the equipment compressor at its

reception. (Good exterior appearance, no shock or deformation) especially on the connection terminal.

Do not hold or lift the compressor by the tubes, use its lifting ring intended for this purpose. Refer to our technical documentation to

find out which storage and transport positions are allowed.

The recommendations for transporting refrigeration systems/ appliances loaded with refrigerants are the responsibility of the

respective manufacturer of these refrigeration systems / appliances.

5. Recommendations related to the use and assembly of the compressor in a refrigeration system:

In the case of operating with flammable refrigerants, installation must be designed on the basis of a risk analysis to avoid refrigerant

accumulation in the event of leakage in areas that are potential ignition sources.

-It is recommended to provide a device capable of detecting current taken by compressor in order to prevent sudden surge

in currents that could melt the insulation (“pin venting” phenomenon) on electrical terminal pin of the compressor.

-Provide appropriate protections in line with local regulations to prevent the public, user or anyone with access to the

application from degrading the product.

-Also provide adequate signage for flammable refrigerants on the complete installation, so that the user or anyone with

access to the application is aware of the risks associated with their presence (putting in place standard pictograms preventing

the risk of flammability).

-Establish an appropriate way to alert the user that they need to call on a professional to manipulate the application.

5.1. Maximum allowable pressure

Tecumseh compressors are designed to operate at a maximum ambient temperature of +46°C. Observe and comply with the specific

regulations to optimise the quantity of refrigerant in the installation and never exceed the maximum discharge pressure corresponding

to the maximum condensation temperature of the compressor's operation. The compressor housing should not be subjected to a

temperature below -35°C; the materials used would not guarantee sufficient mechanical characteristics.

FH2Long Notice

03/2020

5.2. Expansion element

Tecumseh recommends the use of thermostatic expansion valves.

5.3. Installation for the first commissioning

Tecumseh cannot be held responsible if the installation and maintenance do not comply with the instructions provided in this manual.

Current guidelines and regulations in force in the country where the compressor is installed, and the rules of the art for refrigeration

and electrical connections, must be complied with.

5.4. Location of the compressor and definition of refrigerant charge

5.4.1. Defining the refrigerant charge

The refrigerant charge should not exceed the amount that can be stored under high pressure. To prevent migration of refrigerant

in to the compressor housing during the compressor’s off period/ thermal cycling, or when the refrigerant charge quantity is

greater than 1.5 Kg, Tecumseh recommends the use of a crank case Heater and/or an non-return valve (NRV)on the discharge

pipe line connected to condenser inlet( Scope of supply of NRV lies with the Refrigeration system/ appliance manufacturer) .

The return of liquid during transitional periods will be prevented by Accumulator.

The maximum charge quantity of flammable refrigerants is defined in Annex C of EN 378-1 based on the volume in which the

refrigeration system is installed, its location and its type of occupancy (non-exhaustive).

5.4.2. Location of electrical components that create sparks in the case of the use of A2L flammable fluids

They must be located in a non flammable area. Tecumseh recommends installing them high up, and in a adequately ventilated

area.

5.4.3. Replacing the compressor

Ensure that the compressor should not block the movement of people or opening of doors and shutters.

Ensure that the compressor is mounted on a base or structure that has enough strength to support it’s safe operation. Check that

the compressor level is horizontal and ensure silent blocks are assembled to the mounting leg . Be careful not to block the flow of

air around the electrical components and compressor, to ensure its cooling.

5.5. Brazing, refrigeration connections

As a reminder, Brazing can only be carried out on installations not loaded with refrigerants.

To keep the installation running smoothly, it is advisable to:

- Braze using dry nitrogen and keep any flames away from electrical equipment.

- Insulate the suction line up to the compressor entrance, to avoid condensation.

Cut and shape the tubes carefully, to prevent dust and metal particles from entering the system. Never use a saw. Use a bending tool

adapted to the diameter of the tube to avoid excessive restrictions.

Tecumseh recommends brazed connections instead of Flare and Nut fittings to limit the likelihood of leakage over time. Screwed

fittings on a flat surface using a gasket are acceptable. A leakage check is mandatory before commissioning.

FH2Long Notice

03/2020

5.6. Suction and Discharge valve tightening torques

1- SAE tips 1/4'': 7 to 11 Nm

A – Process connection

B – Pressure gauge connection

2- setting needle square 1/4’’ : 6 à 13 Nm

setting needle square 5/16’’ : 30 à 34,5 Nm

3- packing gland nut: 5 à 13 Nm

4- Rotalock connection 1’’1/4- 12UNF : 114 Nm à 126 Nm.

Rotalock connection 1’’-14 UNS : 70 Nm à 85 Nm

Unlock the packing nut before handling the float valve. Then tighten the

packing nut.

5.7. Suspensions

An external suspension set including Silent blocks (Grommets) and spacers (sleeves) come as standard with all Tecumseh compressors.

The role of these silent blocks is to reduce the transmission of vibrations generated by the compressor to the base on which it is

mounted. In order to ensure this function properly, silent blocks should not be constrained. For this, the washer pressing on the spacer

must leave a clearance of 1 to 4 mm from the top of the silent block. In order to not distort the spacer, apply a tightening torque of

between 8 to 13 Nm for the M8 screws.

5.8. Electrical connections

Electrical connections will be made before the refrigeration system is charged with refrigerant.

To preserve the quality of the Tecumseh compressor and the safety of the installation and ensure their proper operation, it is

imperative to:

- Always wire the compressor when it is switched off.

- Validate the compatibility of the installation's power voltage with that of the compressor (see the nameplate).

- Validate the compatibility of the compressor's electrical drawing with that of the installation.

- Size the connecting cables (power, control) according to the characteristics of the installed compressor (see nameplate).

- Protect the power line and install a grounding line.

- Make electrical connections in accordance with the country's current regulations.

- Use the electrical components that come with the compressor, even if others seem acceptable.

FH2Long Notice

03/2020

The electric box must always be fixed vertically.

Dimensions

JUNIOR box

SENIOR box

125

180

206

232

130

154

Assembly drawing for Protective cover for FH2Compressors

5.9. Circuit sealing

Before Charging with refrigerant, systematically search for leaks on all fittings, and seal them if necessary.

5.10. Evacuation

FH2Long Notice

03/2020

Evacuate the installation to reach a residual pressure of about 200 micrometres of mercury (0.27 mbar), guaranteeing a good quality

of vacuum. It is advisable to drain the HP and BP circuits simultaneously in order to reduce the operation time and ensure an identical

level of vacuum throughout the circuit.

6. Refrigerant charge, powering up and maintenance:

If the following manipulations are performed in potentially explosive atmospheres, Tecumseh recommends referring to Standard EN

378. Part 4 prescribes the general safety guidelines, Annex E provides guidelines for interventions in equipment using flammable

refrigerants.

General recommendations:

The electrical boxes will be properly installed and closed before charging the refrigerant and switching on installation.

HFO levels in the air will be monitored throughout the whole refrigerant charge and maintenance period.

Leak detection equipment will be calibrated to 20% of the LFL of the refrigerant in accordance with the EN 378-4 standard.

The work area will be ventilated throughout the procedure.

6.1. Coolant charge

The provisions in Parts 2, 3 and 4 of EN 378 must apply to prevent the risk of refrigerant emission during refrigeration system filling

and emptying operations.

Limit the refrigerant load so that the pressures are in the operating window defined by Tecumseh.

Never start the compressor if the vacuum is not broken in HP and BP.

The components will be grounded before starting the refrigerant charge.

Load the installation only with the refrigerant or one of the refrigerants for which the compressor was designed (see nameplate).

The refrigerant charge will always be in liquid form, to keep the mixture in the right place.

- Do not add any additives or dyes.

6.2. Risk of refrigerant Over Charge

If the main parts of the compressor are submerged due to excess refrigerant charge, this can cause the compressor housing to burst.

Immersion of the crank case, connecting rod, piston and cylinder in the liquid creates a hydraulic blockage preventing the compressor

from starting: this is therefore a blocked rotor situation. If, for some reason, the compressor protector does not intervene quickly

enough, a high current in the motor winding will create a rapid rise in temperature. This will cause the liquid to vaporise and the

pressure in the compressor housing to increase rapidly.

As an example of what not to do when charging a system with refrigerant, never leave the charging cylinder connected to the system,

even if the valve of the cylinder or that of the "manifold" is closed. If one of these valves leaks slightly, the system will be Over Charged

with the risks mentioned above.

6.3. Checks when commissioning

- Calibrate electrical protective devices, adjust the set/cut points of the regulatory and safety devices.

- Fully open the service valves.

- Check the operation of the oil heater, if present.

Tecumseh compressors are protected by an external or internal over load protector , the principle of which is based on a

temperature/current combination. Like any protective device, it is normal for the compressor to trip on overload protector when it is

operating outside the Tecumseh’s recommended application window.

FH2Long Notice

03/2020

When operating conditions are stabilised, do the following checks:

-Tension(Voltage) and intensity ( Current) absorbed by the compressor;

-HP and BP pressures from the installation;

-Overheating, undercooling, return gas temperature, discharge temperature;

-Search for leaks;

-Carry out a general inspection of the installation (cleanliness of installation, abnormal noise, etc.). Visually inspect the

refrigeration system (for example, according to the list listed in Annex G of EN378-2).

For installations operating with a flammable refrigerant, check if the leak detection equipment is working properly.

Do not add oil unless the pipes exceed 20 m; in this case, use the oil recommended by Tecumseh.

6.4. Maintenance

Tecumseh recommends securing the maintenance area in accordance with EN 378 Part 4

Below is a non-exhaustive list of recommendations:

-Obtain a permit for high-temperature work (if necessary);

-Ensure that no flammable material is stored in the work area and that there are no sparks in the work area;

-Switch off electrical appliances;

-Keep heat sources away to avoid explosions;

-If a heat source is present in the workplace, make sure a fire extinguisher is available;

-Ensure that the work area is properly ventilated, before intervening on the refrigeration system or before welding or tender

brazing work;

-Mark the work area to prevent entry of unqualified people;

-Ensure that the leak detection system used is spark-proof, secured appropriately or inherently safe

-Ensure that all maintenance personnel have been trained.

Wherever possible, the refrigeration system operating with a refrigerant classified as an A2L category will be transported to a

workshop authorized and compliant to do its maintenance.

Check that the pressure of the refrigeration system will not be a danger factor during the intervention (projection of parts, refrigerant

etc.). The compressor can reach temperatures above 120°C in operation. Do not intervene in the compressor without protection.

IMPORTANT : If the detection system preventing sudden surge in current that could melt the insulation (pin venting) has tripped,

do not reset it. Replace the compressor following installation and commissioning recommendations (see Section 5).

6.4.1. Recovery of flammable refrigerants

-Use a recovery plant suitable for flammable refrigerants

-Identify the refrigerant in the cylinder and affix the flammability logo

-Do not mix refrigerants together.

6.4.2. Inerting the refrigeration system and precautions before soldering

-Ensure that a fire extinguisher is present nearby,

-Inert the system with nitrogen without oxygen (or air),

-The flow will be ventilated preferably outdoors.

6.4.3. Opening of the refrigeration system and replacement of components

IMPORTANT : Soldering operation is prohibited on installations / refrigeration system charged with a flammable refrigerant .

More generally, it is imperative to prohibit any source of ignition (sparks, flames, hot springs) near the circuit.

Autres manuels pour FH2

Autres manuels Tecumseh Compresseur

Tecumseh

Tecumseh AEA4440YXA Guide produit

Manuels Compresseur populaires d'autres marques

Panasonic

Panasonic Matsushita QA91K22CAU6 Manuel utilisateur

EKOM

EKOM DK50 B Manuel utilisateur

Challenge Xtreme

Challenge Xtreme CX 1500/1 Manuel utilisateur

Conrad

Conrad 1719346 Manuel utilisateur

Hanbell

Hanbell RC2-AV Series Manuel utilisateur

PLASMATECH

PLASMATECH SHARK 25 Manuel utilisateur

Emerson

Emerson Copeland Scroll Digital HLR Series Mode d’emploi

Drawmer

Drawmer 1968 MKII Manuel utilisateur

Badger Air-Brush

Badger Air-Brush X-Air 80-8 Mode d’emploi

Omnitronic

Omnitronic CL-166 Manuel utilisateur

Scheppach

Scheppach HC24V Instructions de montage

Ingersoll-Rand

Ingersoll-Rand centac C950 Manuel technique

LG GVH282PAB Manuel utilisateur

Kooper

Kooper 2196438 Manuel utilisateur

American Eagle

American Eagle SHD-66DD Manuel utilisateur

Frick

Frick 1510 Manuel utilisateur

Sierra

Sierra Eagle 12 VX Manuel

EUFAB

EUFAB 21083 Manuel utilisateur
