TECOR TR-D465E Manuel utilisateur
TECOR TR-D465E
Desktop Thermal Printer
User Guide
1. Introduction
TR-D465E is a small, highly efficient desktop printer with a 300dpi direct thermal head
with the capability of handling 108mm (4.25") wide media. The default speed is set to
152 mm/s with a smart media size detection feature, so you don’t need to manually set
the media size when you loading a different media.
1.1. Printer Accessories
After unpacking, please check the accessories that come with the package.
●Barcode Printer
●Power Adapter with Cord
●Printer Cable (USB)
●CD
●Quick Start Guide with Warranty Card
1.2. General Specifications
Printer Model
TR-D465E
Printing Features
Resolution
300 DPI
Printing method
Direct Thermal
Max.print speed
152 mm (6") / s
Max.print width
108mm (4.25")
Max.print length
1778 mm (70")
Media
Media type
Continuous, gap, black mark, fan-fold and punched hole
Media width
25.4 mm ~ 116 mm
Media thickness
0.06 mm ~0.20 mm
Label length
10 ~ 1778 mm (0.39 " ~ 70 ")
Label roll capacity
External paper roll holder
Performance Features
Processor
32-bit CPU
Memory
8MB Flash Memory/8MB SDRAM
Interface
USB
Sensors
Gap sensor, Cover opening sensor, Black mark sensor, Paper exit
sensor
Fonts/Graphics/Symbologies
Internal fonts
8 alpha-numeric bitmap fonts, Windows fonts are downloadable
from software.
1D barcode
Code 39, Code 93, Code 128UCC, Code 128 ，subsets A, B, C,
Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E,
EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China
POST
2D barcode
PDF-417, Maxicode, DataMatrix, QR code
Rotation
0°、90°、180°、270°
Emulaion
TSPL、EPL、ZPL、DPL
Physical Features
Dimension
185 mm (W) x 85 mm (H) x85 mm (D)
Weight
0.722kg
Printer Model
TR-D465E
Printing Features
Resolution
300 DPI
Printing method
Direct Thermal
Max.print speed
152 mm (6") / s
Reliability
Print head life
30 km
Software
Driver
Windows/Linux/Mac
SDK
Windows/Linux/iOS
Power supply
Input：AC 100-240V,1.8A, 50-60Hz
Output：DC 24V, 2.5A, 60W
Environmental Conditions
Operation
5 ~ 40°C（41~104°F），Humidity: 25 ~ 85% non-condensing
Storage
environment
-40 ~ 60°C（-40~140°F），Humidity:10 ~ 90% non-condensing
2. Installation
2.1 Printer Setup
1. Please ensure the printer is on a flat surface and the power switch is off.
2. Plug the power cord into the ower jack connector at the rear of the printer then plus the
power plug into an outlet.
2.2 Loading Label
1. Press the opening button located on the side of the printer, then pull the top cover up.
2. Load the label through the label guide, adjusting width if necessary.
3. Close the cover.
2.3 Single label loading
In ready status, put a single label into the inlet (back of the printer), the label will then
auto-load.
3. LED and FEED key
3.1 LED status indicator light
Color
Description
Blue
Ready for printing
Flickering Blue
Downloading data or printing paused.
Purple
Cleaning data
Red
Cover is opened
Flickering Red
Error. no paper, jam or other errors.
3.2 Functions of the FEED key
1. Feeding paper
To press the FEED key when the printer is ready(LED color is blue), the printer will load
the next label.
2. Pause the print job
To press the FEED key when the printer is printing(LED light is flickering blue), the print
job will be suspended. Press FEED again, the print job will resume.
Note: please do NOT turn off the power when the print job is suspended, or the data will
be lost.
3.3 Boot options
There are four boot options while turning on the printer.
Light color
Function
Red
Blue
Purple
flickering
Red
flickering
Purple
flickering
Blue
Blue
1. Run gap detection
Keep pressing FEED
key while turning on
the power
release
2. Run gap detection
then print self test
and go to dump mode
Keep pressing FEED key while
turning on the power
release
3. Revert to default
setting
Keep pressing FEED key while turning on the
power
release
4. Skip to load
AUTO.BAS Program
Keep pressing FEED key while turning on the power
release
3.3.1 Label gap detection
When loading a different label, or to recover the default setting of the printer, we need to
run the paper gap detection for register the size of the new label. Some models have the
ability to auto-detect paper gap, so it doesn’t need to be done manually.
Follow the steps below to run paper gap detection.
1. Turn off the printer.
2. Load the labels into the printer.
3. Press down the FEED key (don’t release) then turn on the printer.
4. Release the button while the light colour is flickering Red.
3.3.2 Self-testing and dump mode.
Self-testing is used for verifying the print quality and settings.
Dump mode
After the self-test is printed, the printer system enters the debugging mode. In the
debugging mode, all the volume labels will be printed as machine code. The ASCII strings
on the left are the data received by the system. The data on the right are printed from the
strings on the left, in hexadecimal values. This function is provided for users or engineers
to debug programs. You only need to restart the printer to leave the debugging mode and
return to the normal printing mode.
3.3.3 Initialise the printer.
Initialise will recover the default settings and remove user files in DRAM. Please run it
carefully.
Default settings in the below table
Setting
Default value
Speed
152.0 mm/sec (6 ips) (203DPI)
Density
8
Paper Width
3” (76 mm)
Paper High
5.11” (130 mm)
Sensor Kind
Gap sensor
Gap
0.16” (4.0 mm)
Direction
0
Start Point
0,0 (upper left corner)
Offset
0
Tear-Off Mode
On
Character Set
850
Country Code
001
Clean Flash
No
3.3.4 Skip to load AUTO.BAS
When turning on the printer, the AUTO.BAS file in the flash will be loaded and the
commands in this file will be automatically executed. To skip this process, please keep
pressing down the FEED key until the LED light become blue while turning on the printer.
