BT1212 User Manual

(HTT06681172)

This document will provide a quick guide

to the operation of the Techno BT1212

CNC Router equipped with a NCstudio

Controller.

The BT1212 CNC Router is powered by high

precision stepper motors and controlled by

a hand-held NCstudio controller.

NCstudio Controller

2Call: 1-631-648-7481 or Visit: support.technocnc.com

BT1212 User Manual

(HTT06681172)

TABLE OF CONTENTS

I Safety Instructions ............................................................... Page 3

Colleting Guidelines ............................................................... Page 4

II NCStudio Controller Functionality

Functions of the Keys ..................................... Page 5

Shift Commands / Combination Keys ..................................... Page 6

III Operating Tutorials

3.0- Switching Movement to Step or Jog ........................ Page 7

3.1- Jogging the Machine and

Changing from High/Low Jog Speed ........................ Page 7

3.2- Stepping the machine ........................ Page 7

3.3- Modifying the Jog Speed and Step Size

3.4- Feedrate Override ........................ Page 8

3.5- Adjusting the XYZ Position/WCS/User Origin ........... Page 9

 3.6-LoadingaG-codele ..................................................Page10

3.7- Running a G-code File .................................................. Page 11

IV Advanced Tutorials

4.1- Alternating between Override and Programmed Feedrates .. Page 12

 4.2-SettingOverridespeedforaG-codele .........................Page13

4.3- Setting the Table Size ......................... Page 14

Changing to Different Offset (a new XY Zero location) ............ Page 15

Pulse Equiv (scale factors) ......................... Page 16

  NotesontheG-codele  .........................Page16

Acceleration Set ......................... Page 16

V Appendix

Using the 4th Axis on a BT1212 Machine Page 17

Warranty Page 18

Call: 1-631-648-7481 or Visit: support.technocnc.com 3

BT1212 User Manual

(HTT06681172)

WARNING: IMPROPER OR UNSAFE OPERATION OF THE MACHINE WILL

RESULT IN PERSONAL INJURY AND/OR DAMAGE TO THE EQUIPMENT.

READ THESE INSTRUCTIONS THOROUGHLY BEFORE OPERATING MACHINE. DO NOT OPERATE

MACHINE IF YOU ARE UNFAMILIAR WITH THESE SAFE OPERATING INSTRUCTIONS. DO NOT

OPERATE MACHINE WITHOUT KNOWING WHERE THE EMERGENCY STOP SWITCH IS LOCATED.

PREVENT FIRE HAZARDS by using the proper feeds, speeds, and tooling while operating your

Techno machine. For example, setting feeds and speeds too low and/or using dull tool bits creates

friction at the material. The friction generates heat which can result in a re that can be drawn

through the vacuum table or dust collector without warning. Fire hazard from friction heating

caused by dull tools is possible when cutting certain materials, especially composite material

Safety Instructions

1. Keepngers,hands,andallotherobjectsawayfrom

machine while power is on.

2. Disconnect power to all system components when

not in use, when changing accessories, and before

servicing.

3. Do not loosen, remove, or adjust machine parts or

cables while power is on.

4. Exercise care with machine controls and around

keyboard to avoid unintentional starting.

5. Make sure voltage supplied is appropriate to

specicationsofcomponents.

6. Machines must be plugged into three-pronged

grounded outlets. Do not remove the grounding plug

or connect into an ungrounded extension cord.

7. Keep cables and cords away from heat, oil, and

sharp edges. Do not overstretch or run them under

other objects or over work surfaces.

8. Useproperxturesandclampstosecurework.Never

use hands to secure work.

9. Do not attempt to exceed limits of machine.

10. Do not attempt to use machine for purposes other

than what is intended.

11. Use machine only in clean, well-lit areas free from

ammableliquidsandexcessivemoisture.

12. Stay alert at all times when operating the machine.

13. Always wear safety goggles.

14. Donotwearloose-ttingclothingwhenoperating

machine. Long hair should be protected.

15. Always maintain proper balance and footing when

working around the machine.

16. Maintain equipment with care. Keep cutting tools

clean and sharp. Lubricate and change accessories

when necessary. Cables and cords should be

inspected regularly. Keep controls clean and dry.

17. Before using, check for damaged parts. An

authorized service center should perform all repairs.

Only identical or authorized replacement parts should

be used.

18. Remove any adjusting keys and wrenches before

turning machine on.

19. Do not operate the machine unattended.

20. Follow all safety instructions and processing

instructions in the MSDS for the material being

processed.

21. Use proper precautions with dust collection systems

topreventsparksandrehazards.

22. Makesuretohaveproperreextinguishing

equipment on hand at all times.

4Call: 1-631-648-7481 or Visit: support.technocnc.com

BT1212 User Manual

(HTT06681172)

Colleting Guidelines

Call: 1-631-648-7481 or Visit: support.technocnc.com 5

BT1212 User Manual

(HTT06681172)

Single Keystroke Functions on the Handheld Pendant

Positive Feedrate

Override

(Input the number 7)

X- Movement

(Input the number 4)

Jog Speed Select

(Input the number 0)

Enter Manual

Parameters Screen

Change high/low

speed and XYZ step

increment

Z+ Movement

(Input the number 9)

X+ Movement

(Input the number 6)

Z- Movement

(Input the number 3)

Menu Screen

(Input a decimal point)

Shift Key

Switch

between Jog

and Step

modes

Down

Directional

Key

Set XY Zero Position

(Input a minus sign)

Stop

Cancel

Escape

Directional

Key

Pause

Start key

Spindle On/Off

(Input the number 5)

Negative Feedrate

Override

(Input the number 1)

Y+ Movement

(Input the number 8)

Y- Movement

(Input the number 2)

Select

Bold Indicates Primary Function

(Parenthesis Indicates Secondary Function)

Yellow Keys represent movement

related keys

Blue Keys represent speed and

feed related keys

6Call: 1-631-648-7481 or Visit: support.technocnc.com

BT1212 User Manual

(HTT06681172)

Shift Commands / Combination Keystrokes

To use the shift commands, you must press and hold the shift key and then select

a second key to use the Shift Command function.

Go to current work (relative) origin

Switch between work (relative) and machine (absolute)

Go to XYZ home (mechanical origin)

Resume from breakpoint M0 command

Open help screen

Set Z zero position manually not using Touch-Off pad

Call: 1-631-648-7481 or Visit: support.technocnc.com 7

BT1212 User Manual

(HTT06681172)

Select between high and

low Jog speeds

3.1- Jogging the machine and changing from High/Low Jog Speed.

To Jog the machine, hold down one of the Yellow directional keys on the keypad

while in Jog mode. The keypad has X+,X-,Y+,Y-,Z+,Z- printed on the keys to

indicate direction.

The machine has two speeds, High and Low.

When the machine starts it will be in the Low speed.

To toggle between low and high speed press the Jog Speed Select Button. You can

only toggle speed when in Jog Mode.

The LCD will display High or Low on the right of the screen.

Press ‘OK’ to change high and low speeds, see section 3.3.

III Operating Tutorials.

3.0- Switching Movement to Step or Jog.

There are two modes that allow the user to control the movement of the

machine: Jog and Step. To switch between these modes press the “Shift” button.

The mode will be displayed on the bottom left of the screen.

Jog- Also known as continuous mode. When a directional arrow is pressed, the

machine will move in that direction until the button is released.

Stepping- Also known as step mode. When a directional arrow is pressed, the

machine will move an exact amount, as dictated by the manual parameters

page. To move again, you must release the button and press it again.

3.2- Stepping the machine.

To move the machine in increments, press down one of the Yellow directional keys on the

keypad while in Stepping mode. The keypad has X+,X-,Y+,Y-,Z+,Z- printed on the keys to

indicate direction.

This will move the machine in predetermined increments in the axis selected.

By default, the X and Y axes will move in .005 inches and the Z axis will move in .001

inches.

Press ‘OK’ to change step size, see section 3.3

8Call: 1-631-648-7481 or Visit: support.technocnc.com

BT1212 User Manual

(HTT06681172)

Decrease

Feedrate

Increase

Feedrate OR

3.3- Modifying the Jog Speed and Step Size

The machine can be jogged at two speeds, low and high. You can also change the

increments in which the machine will move in Step mode. These speeds are set in

the Manual Parameters page.

To access the Manual Parameters page press OK from the Main Screen

Set the High and Low speed to a suitable value.

Adjust the Step value as needed.

To Exit out of this screen and return to the main menu press ESC.

Warning: Adjust the step size carefully. If you set the step size to an excessive value, the

machine will move by that value and could damage the machine.

When inputting a decimal increment, you must enter the value as 0.###

Zero+decimal+(your increment)

Low Speed

High Speed

XY Step Size

To move the cursor, use the Up and Down directional

arrows.

Enter a new value.

Press OK to accept that value.

3.4- Feedrate Override.

While running a G-Code le, the user can manually override the feedrate or

cutting speed of the program. The range of the override goes from 10% to 120%

of the original feedrate.

The user can override the feedrate using the following keys:

Call: 1-631-648-7481 or Visit: support.technocnc.com 9

BT1212 User Manual

(HTT06681172)

3.5- Adjusting the XYZ Zero position/WCS/User Origin.

XYZ zero position, Working Coordinate System (WCS), and

User Origin are all the same thing.

Different CAM systems and users just name the concept

differently. For convenience XYZ zero position will be used in

the rest of this manual.

XYZ zero position is the location point on a drawing in a

CAD/CAM package where X,Y and Z all equal zero.

Generally, XY zero is on the bottom left corner and Z zero

is the top of the part. In g 3.3a the letters are located

away from the XY zero, all points representing positive

integers.

In Fig 3.3b the object represents the material the letters will

be cut from. The machine should be jogged to the corner of

the material by using the directional arrows on the keypad.

Once the machine is in location press to set XY zero. The

coordinates on the controller will change to 0,0.XY zero is

now set.

Fig.3.3b

Fig. 3.3a

There are two methods for setting the Z-axis zero position:

1. Manual Method: Use the Z-axis directional arrows on the

keypad to move the router to the top of the material. Switch

to Step Mode to slowly move the machine into position.

When the router bit is in position press shift/aux and the

Z=0 button as shown.

2. Tool Calibration Block: Place the touch off block on top

of the material and under the cutter. Press shift/aux and 0

simultaneously. The spindle will slowly move down until it

touches the touchpad. The Z axis will now be set to the top

of the material.

The Z coordinate will now read ‘Z 0.000’

Zero Z-axis

Activate Z-Touch off procedure.

10 Call: 1-631-648-7481 or Visit: support.technocnc.com

BT1212 User Manual

(HTT06681172)

3.6- Loading a G-code

File.

Press the Menu button.

Select “2.USB les” to access the ash drive.

Only a G-code le with an “nc” extension with show.

Scroll through the les with and

Select le by pressing OK.

Then load the le by pressing 1.

Note:

Files can be copied from this USB to the controller using the “2” button

Local disk space is limited!

Once a le is copied locally, it can also be selected from the jog speed /step size screen

Autres manuels pour BT1212

Table des matières

Autres manuels Techno CNC Systems Système de contrôle

Techno CNC Systems

Techno CNC Systems Titan Series Manuel utilisateur

Techno CNC Systems

Techno CNC Systems HD series Manuel utilisateur

Techno CNC Systems

Techno CNC Systems WinCNC Manuel utilisateur

Techno CNC Systems

Techno CNC Systems Venture Series Manuel utilisateur

Manuels Système de contrôle populaires d'autres marques

Pentair Pool Products

Pentair Pool Products Compool Manuel utilisateur

ComfortNET

ComfortNET CTK04 Manuel utilisateur

Fireye

Fireye InSight II 95DSS3 Manuel utilisateur

CAME

CAME G3000 Manuel utilisateur

Idemia

Idemia MorphoAccess VP MD Manuel utilisateur

Axis

Axis P1445-LE-3 Manuel utilisateur

HEIDENHAIN

HEIDENHAIN TNC 150 B Manuel utilisateur

CNC-Step

CNC-Step High-Z T-Series Manuel utilisateur

Doosan

Doosan DVF Series Manuel utilisateur

Honeywell

Honeywell KAP 140 Manuel utilisateur

Honeywell

Honeywell vk41 series Manuel utilisateur

AirBench

AirBench FPW Guide d'installation

Cypress

Cypress HHR-3160 Manuel utilisateur

CAME

CAME GLT40AOS Manuel utilisateur

Zonex

Zonex GEN II -VVT Guide de l'utilisateur

Altronics

Altronics K 9650 Manuel utilisateur

micro-trak

micro-trak RoadMaster Manuel utilisateur

micro-trak

micro-trak Calc-An-Acre II Manuel utilisateur
