Technics SL-HD560E Manuel utilisateur

ORDERNo.AD0203063C2

Compact Disc Player

SL-HD560E

Traverse Deck:RAE0152ZMechanismSeries

Colour

(N)...........GoldType

System

SC-HD560:

Tuner;ST-HD560, Amplifier;SE-HD560,

CD Player;SL-HD560, Cassette Deck;RS-HD560,

Speakers;SB-HD560 (MadeinSpain.)

SPECIFICATIONS

Specifications

1

Digital outputterminal: Optical ×1

Audio section

DA converter: 1bit2DACMASH

Format

Sampling frequency: 44.1kHz

Pickup

Wavelength: 780 nm

General

Dimensions(W×H×D): 210×76.3×246 mm

Mass: 1.3kg

Notes:

Specificationsaresubjecttochangewithoutnotice.

Mass and dimensionsareapproximate.

*Noteon CD-R and CD-RW

Thisunitmay notbeabletoplay someCD-R dueto

thecondition ofrecording.

Itcannotplay CD-RW.

1. Note

1. Because touniqueinterconnecting cables, whenacomponent

requires service, send orbring intheentiresystem.

2. Refertotheservice manual forModel No. SE-HD560 (OrderNo.

AD0203061C2) forinformation on Accessories and Packaging.

2. BeforeRepair

Thisequipment(SL-HD560), whichisacomponentofthesystem, issuppliedwithpowerfrom

theAmplifier(SE-HD560)through theTuner(ST-HD560). Whenrepairing thisequipmentor

checking operation ofthesystem, besuretoconnecttoothersystemcomponentswithit.

Powersupplyand operation checks inthestateofitas asingleequipmentisimpracticable.

2

3. Handling Precautions forTraverse Deck

Thelaserdiodeinthetraverse deck (optical pickup)may break downduetopotential difference

causedbystaticelectricityofclothes or humanbody.

Sobecareful ofelectrostaticbreakdownduring repairofthetraverse deck (optical pickup).

3.1. Handling oftraverse deck (optical pickup)

1. Donotsubject thetraverse deck (optical pickup)tostatic

electricityas itisextremelysensitivetoelectrical shock.

2. To protect thelaserdiodeagainst electrostaticbreakdown, short

theflexibleboard(FFCboard)withacliporsimilarobject. Referto

Fig. 3-1.

3. Take carenottoapplyexcessivestress totheflexibleboard(FFC

board).

4. Donotturnthevariableresistor(laserpoweradjustment). Ithas

alreadybeenadjusted. Referto Fig. 3-1.

Fig. 3-1.

3.2. Grounding forelectrostaticbreakdownprevention

3.2.1. Humanbodygrounding

Use theanti-staticwriststraptodischargethestaticelectricityfrom your body. Referto Fig. 3-2.

Fig. 3-2.

3

3.2.2. Worktablegrounding

Putaconductive material (sheet) or steel sheeton thearea wherethetraverse deck (optical

pickup)isplaced, and ground thesheet. Referto Fig. 3-3.

Fig. 3-3.

Caution:

Thestaticelectricityofyourclothes will notbegroundedthrough

thewrist strap.

Sotake carenottolet yourclothes touchthetraverse deck (optical

pickup).

4. Precaution of LaserDiode

5. Location of Controls

6. Operation Checks and Component Replacement

Procedures

4

-Thissection describes procedures forchecking theoperation of

themajorprintedcircuitboardsand replacing themain

components.

-Forreassemblyafteroperation checks orreplacement, reverse the

respectiveprocedures. Special reassemblyprocedures are

describedonlywhenrequired.

6.1. Checking forthemainP.C.B.

-Check themainP.C.B. as shownbelow.

6.2. Checking fortheCD servoP.C.B.

-Follow the(Step1) -(Step3) ofitem6.1.

5

-Check theCD servoP.C.B. as shownbelow.

6

6.3. Replacementforthetraverse deck ass’y

-Follow the(Step1) -(Step3) ofitem6.1.

-Follow the(Step1) -(Step5) ofitem6.2.

7

8

9

10
