Technetix AIMA-RFSW Manuel d'exploitation

AIMA-RFSW

RF A/B

PROTECTION

SWITCH

Online

Email: customer.service.[email protected]

Website: technetix.com

2018-08/EN V1

Technetix Group Limited

Product user manual

2018-08/EN V1

Product user manual

AIMA-RFSW

Technetix Group Limited

Contents

1 About this manual .....................................................................................................................................................1

1.1 Related documentation ..............................................................................................................................................................................1

1.2 Technical support........................................................................................................................................................................................1

2 Precautions.................................................................................................................................................................2

3 Overview.....................................................................................................................................................................3

3.1 Product description ....................................................................................................................................................................................3

3.2 Product key features.................................................................................................................................................................................3

3.3 Speciﬁcations..............................................................................................................................................................................................4

3.3.1 Block diagram ...........................................................................................................................................................................................5

3.4 Order details................................................................................................................................................................................................5

4 Module characteristics .............................................................................................................................................6

4.1 Module appearance and port layout ....................................................................................................................................................6

4.1.1 Overview......................................................................................................................................................................................................6

4.1.2 Front panel layout....................................................................................................................................................................................7

4.1.3 Rear panel layout.....................................................................................................................................................................................8

5 Installation ..................................................................................................................................................................9

5.1 Preparatory work for installation ............................................................................................................................................................9

5.2 Unpacking....................................................................................................................................................................................................9

5.3 Module installation ....................................................................................................................................................................................10

5.4 Check module LEDs .................................................................................................................................................................................11

5.5 Test the RF input signal............................................................................................................................................................................11

6 Module conﬁguration & alarm setup .....................................................................................................................12

6.1 Port conﬁguration screen .........................................................................................................................................................................12

6.2 Restoring factory default .........................................................................................................................................................................14

6.3 Reboot...........................................................................................................................................................................................................15

6.4 Alarms monitoring......................................................................................................................................................................................17

6.4.1 Alarm status pages..................................................................................................................................................................................17

2018-08/EN V1

Product user manual

AIMA-RFSW

Technetix Group Limited

6.4.2 Module operating voltage and temperature alarm.....................................................................................................................18

6.4.3 Module port alarms................................................................................................................................................................................19

6.5 Alarm monitoring conﬁguration.............................................................................................................................................................20

6.5.1 Monitoring function ON/OFF ...............................................................................................................................................................20

6.5.2 Temperature, +12V/+5V voltage alarm level management ......................................................................................................21

6.5.3 Input/Output status monitoring..........................................................................................................................................................22

6.6 Logs management ....................................................................................................................................................................................24

6.7 Device uprade.............................................................................................................................................................................................25

7 Troubleshooting.........................................................................................................................................................26

Appendix A: Default alarm limit settings......................................................................................................................27

12018-08/EN V1 Technetix Group Limited

Product user manual

AIMA-RFSW

1 About this manual

1.1 Related documentation

The following documents may be used in conjunction with this manual:

• AIMA3000 - Product User Manual

• AIMA ASMM - Product User Manual

• AIMA3000 NMS Web Management System Product User Manual

• NMS3-EPSM - Basic Inventory Management

• NMS3-EPSM - Basic Alarm Management

• NMS3-EPSM - Basic System Management

• NMS3-EPSM - Basic Template Management

1.2 Technical Support

If you need help in the process of setting up and maintaining RFSW, please contact Technetix customer service:

Europe:

Technetix BV

Kazemat 5

NL-3905 NR Veenendaal

P.O. Box 385

NL-3900 AJ Veenendaal

The Netherlands

Phone: +31 318 58 59 59

Email: customer.service.[email protected]

22018-08/EN V1 Technetix Group Limited

Product user manual

AIMA-RFSW

2 Precautions

WARNING!

This equipment is intended for indoor applications. To prevent ﬁre or electrical shock, or

damage to the equipment, do not expose units to water or moisture.

■You should carefully read and thoroughly understand the contents of the manual before installing

and using this equipment.

■At any time, there may be dangerous voltage inside the device.

■DO NOT power up before the cover and the panels of the equipment are installed and the

enclosure is closed.

Cleaning

Only use a damp cloth to clean the front panel. Use a soft dry cloth to clean the top of the unit.

DO NOT use any spray cleaners or chemicals of any kind.

Outage or overload requiring service and repairs

Unplug the unit and refer the servicing to Technetix qualiﬁed service personnel only.

Servicing and repairs

DO NOT attempt to service this unit yourself. Refer all servicing needs to Technetix qualiﬁed service

personnel only.

32018-08/EN V1 Technetix Group Limited

Product user manual

AIMA-RFSW

3 Overview

3.1 About the Product

The RF A/B Protection Switch (RFSW) is designed to plug into the latest generation Advanced Intelligent Multi-services

Access platform - the AIMA3000.

Providing reliable radio signal stability, the RFSW is an RF-based switching device designed for automatic or manual

switching of radio signals. It maintains the RF output in the event of a loss or degraded signal of one of the two signals

connected to its inputs.

Engineered for high-isolation, the impedance-matched RF switch relay, is controlled by microcontroller-based logic circuits.

This intelligent microcontroller manages the switch based on the detection of RF input signal levels. In addition, the switch

can operate based on user-deﬁned minimum and maximum RF threshold levels. The RFSW switching module provides

self-monitoring and communicates with the ASMM (AIMA3000 System Management Module) within the AIMA3000 chassis.

The switching action may be set to by automatic or manual operation. When in manual mode, the switch can be controlled

through the ASMM’s Web Interface, the AIMA hand-held controller, or through the NMSE. The module’s microcontroller

determines when to switch signals based on total RF power as commonly used in forward transmission, or based on pilot

tone detection of a single frequency as speciﬁed by the customer.

3.2 Product Key Features

■Plug-and-play AIMA3000 platform module

■Forward-path version (5 MHz to 1218 MHz) suits CENELEC and NTSC up to 158 channels (both analog and digital)

■Highly reliable, compact design

■Operates in AUTO or MANUAL mode

■Operator deﬁned adjustable thresholds for both inputs with the maximum and minimum signal parameters

■Comprehensive remote monitoring

■Conﬁgurable alarm threshold levels

■Remote ﬁrmware upgrade and auto upload/download of conﬁguration ﬁles through ASMM webinterface or

using the NMSE

■Bulk ﬁrmware updates through the NMSE

■FCC, CE and RCM(1) compliant

(1) See Declaration of Conformity for current status.

42018-08/EN V1 Technetix Group Limited

Product user manual

AIMA-RFSW

3.3 Speciﬁcations

RF performance

RF bandwidth 5 - 1218 MHz

RF ﬂatness ± 0.5 dB

Insertion loss 3 dB maximum

Isolation < 65 dB (5 to 1000 MHz)

< 60 dB (1000 to 1218 MHz)

RF impedance 75 Ω

RF return loss > 16 dB

RF test point relative to RF output port -20 ± 1 dB

RF connectors 3 x GSK-type female

RF test points 3 x Mini-SMB

Switching time < 15 ms

Alarms and status Front-panel LEDS and SNMP traps

General

Power supply Powered via AIMA3000 backplane

Power consumption < 0.5 W

Operating temperature -5 - 55°C

Operating humidity Maximum 90 % (Non-condensing)

Storage temperature -25 - 70°C

Storage humidity 90% (non-condensing)

Dimensions (W*D*H) 24.6 * 410 * 152.5 mm

Weight 0.88 kg

Supported network management options The NMSE or through ASMM’s Web Interface

52018-08/EN V1 Technetix Group Limited

Product user manual

AIMA-RFSW

3.3.1 Block Diagram

Figure 3-1 RFSW block diagram

3.4 Order Details

A-RFSW-[Z] RF A/B protection switch

Options:

Z Bandwidth

1G 45 - 1000 MHz (Standard)

12 5 - 1218MHz

62018-08/EN V1 Technetix Group Limited

Product user manual

AIMA-RFSW

4 Module Characteristics

4.1 Module Appearance and Port Layout

4.1.1 Overview

Figure 4-1 Module appearance

72018-08/EN V1 Technetix Group Limited

Product user manual

AIMA-RFSW

4.1.2 Front panel view

Figure 4-2 FPAS Front panel layout

Table 4-1 FPAS Front Panel Functions

Item Number Item Description

1 MODE Module working mode indicator Manual: Green Light Blinking, 1 time per second Automatic: Green

2 STAT Module working status indicator Normal: Green Minor Alarm: Orange Major Alarm: Red

3 RF 1 IN LED Input A working mode indicator (Select input A, light blinking), 1 time per second Normal: Green

Minor Alarm: Orange Major Alarm: Red

4 RF 1 IN TP Input A testing point

5 RF 2 IN LED Input B working mode indicator (Select input B, light blinking), 1 time per second Normal: Green

Minor Alarm: Orange Major Alarm: Red

6 RF 2 IN TP Input B testing point

7 RF OUT LED RF working mode indicator Normal: Green Major Alarm: Red Minor Alarm: Orange

8 RF OUT TP RF output testing point

9 Tab-retaining clip Plug and ﬁx the module. The tab-retaining clip will pop-up after pressing the

release and plug module.

10 Front screw Fix RFSW Module
