Techlogix TL-TP70-HDC Manuel utilisateur
User Manual
TL-TP70-HDC
70m Twisted Pair Extender Set for HDMI, RS232 &
IR
All Rights Reserved
Version: TL-TP70-HDC _180619
TL-TP70-HDC User Manual
www.tlnetworx.com
Preface
Read this user manual carefully before using this product. Pictures shown in this manual
are for reference only; the actual product may vary.
This manual is only for operation instruction only and not for any maintenance or
repair.
Trademarks
Product model and logo are trademarked. Any other trademarks mentioned in this
manual are acknowledged as the properties of the trademark owner. No part of this
publication may be copied or reproduced without prior written consent.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a commercial installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference.
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.
TL-TP70-HDC User Manual
www.tlnetworx.com
SAFETY PRECAUTIONS
To insure proper operation, please read all instructions carefully before using the
device. Save this manual for further reference.
⚫Unpack the equipment carefully and save the original box and packing material for
possible future shipment
⚫Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
⚫Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
⚫Using supplies or parts not meeting the products’ specifications may cause damage,
deterioration or malfunction.
⚫Refer all servicing to qualified service personnel.
⚫To prevent fire or shock hazard, do not expose the unit to rain, moisture or install
this product near water.
⚫Do not remove the housing of the device, as opening or removing housing may
expose you to dangerous voltage or other hazards.
⚫Install the device in a place with adequate ventilation to avoid damage caused by
overheating.
⚫Keep the device away from liquids.
⚫Spillage into the housing may result in fire, electrical shock, or equipment damage.
If an object or liquid falls or spills on to the housing, unplug the device immediately.
⚫Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
⚫Unplug the power cord when left unused for a long period of time.
⚫If disposing of the unit, do not burn or mix with general household waste. The
device must be disposed of per local regulations for electronic recycling.
www.tlnetworx.com
TL-TP70-HDC User Manual
Table of Contents
1. Introduction ..............................................................................................................................................1
1.1 Introduction to TL-TP70-HDC.................................................................................................1
1.2 Features ..........................................................................................................................................1
1.3 Package Contents........................................................................................................................1
2. Panel Description....................................................................................................................................2
2.1 Transmitter.....................................................................................................................................2
2.2 Receiver ..........................................................................................................................................3
3. System Connection ................................................................................................................................5
3.1 Usage Precautions.......................................................................................................................5
3.2 System Diagram...........................................................................................................................5
3.3 Connection Procedure...............................................................................................................5
3.4 Twisted Pair Cable Connection...............................................................................................6
4. Specification .............................................................................................................................................7
4.1 Supported Resolution................................................................................................................8
5. Panel Drawing ..........................................................................................................................................9
6. Troubleshooting & Maintenance ...................................................................................................10
7. After-sales Service ...............................................................................................................................10
1
www.tlnetworx.com
TL-TP70-HDC User Manual
1. Introduction
1.1 Introduction to TL-TP70-HDC
The TL-TP70-HDC is an ultra-thin extender set consisting of a transmitter (TL-TP70-
HDC-T) and a receiver (TL-TP70-HDC-R). The set transmits an HDMI signal to the
receiver up to 70m distance via a Cat5e/Cat6A cable. Featuring bi-directional IR and
RS232, you can control your display or source using included accessories. With bi-
directional PoE power, you only need to connect the power supply on one end.
1.2 Features
•EDID pass through
•HDCP 2.2 compliant
•4K over Cat 5e/6 up to 40m
•1080p over Cat 5e/6 up to 70m
•Bi-directional IR, RS232
Note: Shielded twisted pair cable with shielded connectors are recommended.
1.3 Package Contents
➢1 x Transmitter (TX)
➢1 x Receiver (RX)
➢4 x Mounting ears
➢8 x Screws
➢8 x Plastic cushions
➢1 x Power adapter (DC 24V 1.25A)
➢2 x RS232 cables
➢1 x User manual
2
www.tlnetworx.com
TL-TP70-HDC User Manual
2. Panel Description
2.1 Transmitter
No.
Name
Description
①
LINK
TP link status indicator
➢OFF: no link
➢GREEN: link successful
➢Blinking GREEN: link abnormal
②
HDCP
HDCP compliant indicator
➢OFF: no HDMI traffic (no picture)
➢GREEN: traffic with HDCP
➢Blinking GREEN: traffic without HDCP
③
Power
OFF: No power
RED: DC power present
④
RS232
RS232 control connector
⑤
IR IN
Connects to a 5V IR receiver (with carrier); signals tranmitted to the
remote receiver
⑥
IR OUT
Connects to a 5V IR emitter (with carrier); signals tranmitted from
the remote receiver
HDCPLINK
TX
RXTX
TP OUT
TP OUT
3
www.tlnetworx.com
TL-TP70-HDC User Manual
⑦
HDMI IN
Connect to an HDMI source
⑧
TP OUT
Connect to the TP IN socket on the receiver via a twisted pair
cable; supports bi-directional PoC
⑨
DC 24V
Connect to the power supply (Note: power is only required on the
transmitter or receiver)
Pictures shown in this manual are only for reference.
2.2 Receiver
No.
Name
Description
①
LINK
Twisted pair link status indicator
➢OFF: no link
➢GREEN: link successful
➢Blinking GREEN: link abnormal
②
HDCP
HDCP compliant indicator
➢OFF: no HDMI traffic (no picture)
➢GREEN: traffic with HDCP
➢Blinking GREEN: traffic without HDCP
HDCPLINK
RX
RXTX
TP IN
4
www.tlnetworx.com
TL-TP70-HDC User Manual
③
Power
OFF: No power
RED: DC power present
④
RS232
RS232 control connector
⑤
IR IN
Connects to a 5V IR receiver (with carrier); signals tranmitted to the
remote transmitter
⑥
IR OUT
Connects to a 5V IR emitter (with carrier); signals tranmitted from
the remote transmitter
⑦
HDMI OUT
Connect to an HDMI display
⑧
TP IN
Connect to the TP OUT socket on the transmitter via a twisted pair
cable; supports bi-directional PoC
⑨
DC 24V
Connect to the power supply (Note: power is only required on the
transmitter or receiver)
Pictures shown in this manual are only for reference.
5
www.tlnetworx.com
TL-TP70-HDC User Manual
3. System Connection
3.1 Usage Precautions
1) System should be installed in a clean environment that has a proper temperature
and humidity.
2) All of the power switches, plugs, sockets and power cords should be installed
properly.
3) All devices should be connected before powering on the devices.
4) The twisted pair terminations for the devices should be a straight-thru conforming
to the TIA/EIA T568B standard.
3.2 System Diagram
3.3 Connection Procedure
Step1. Connect an HDMI source (such as a set top box) to the HDMI IN port of the
transmitter with an HDMI cable.
Step2. Connect TP OUT port of the transmitter to TP IN port of the receiver using a
twisted pair cable.
Step3. Connect an HDMI display to HDMI OUT port of the receiver with an HDMI
cable.
Step4. If IR control is required, perform the following:
a) Connect the IR emitter to the IR OUT port on either the transmitter or
DVD
HDMI
HDMI
INPUT
RS232
Controlpanel
Projector
IR Remote
Receiver
Transmitter
CAT5e
6
www.tlnetworx.com
TL-TP70-HDC User Manual
receiver.
b) Connect the IR receiver to the IR IN port on either the transmitter or
receiver.
Step5. If RS232 control is required, connect the RS232 port of the devices to be
controlled to the receiver or the transmitter.
Step6. Connect the DC24V power adaptor to either the transmitter or receiver. Power
will be transmitter to the remote extender via the twisted pair cable.
3.4 Twisted Pair Cable Connection
The Cat5e/Cat6 terminations for twisted pair devices should be a straight thru
connection conforming to the TIA/EIAT568B standard. The TIA/EIA T568A standard is
NOT recommended.
Note: For best operation, the
twisted pair cable should be
shielded and the cable
connectors should be metallic.
The shielded layer of cable
MUST be connected to the
connector’s metal shell.
TIA/EIA T568A
TIA/EIA T568B
Pin
Cable color
Pin
Cable color
1
green white
1
orange white
2
green
2
orange
3
orange white
3
green white
4
blue
4
blue
5
blue white
5
blue white
6
orange
6
green
7
brown white
7
brown white
8
brown
8
brown
1st
Ground
4--5
1st
Ground
4--5
2nd
Ground
3--6
2nd
Ground
1--2
3rd
Group
1--2
3rd
Group
3--6
4th
Group
7--8
4th
Group
7--8
