TCT Mobile A556C Manuel utilisateur

English - CJA60A1KFAGA

A556C User Manual

Table of contents

Basics.................................................................................................................................6

InBox............................................................................................................................................................6

Phone Overview .......................................................................................................................................6

Proper Holding Position .........................................................................................................................7

Battery ....................................................................................................................................................... 8

microSDTM Card........................................................................................................................................9

Turning Phone On or Off.................................................................................................................... 10

Phone options......................................................................................................................................... 10

Finger Gestures...................................................................................................................................... 11

Keyboard.........................................................................................................................12

Using the QWERTY Keyboard ......................................................................................................... 12

Using the Onscreen Keyboard........................................................................................................... 13

Text editing.............................................................................................................................................. 13

Getting Started..............................................................................................................15

Google Account ..................................................................................................................................... 15

Getting to Know the Home Screen................................................................................................. 16

Customizing the Home Screen.......................................................................................................... 17

Essential Display Icons.......................................................................................................................... 19

Notifications Panel................................................................................................................................. 21

Opening and Switching Between Applications............................................................................... 21

Sleep Mode.............................................................................................................................................. 23

Adjusting Volume.................................................................................................................................... 24

Searching Your Phone and the Web.................................................................................................. 24

Connecting Your Phone to a Computer ......................................................................................... 26

Phone Calls.....................................................................................................................27

Making Calls ............................................................................................................................................ 27

Answering or Rejecting Calls............................................................................................................. 29

Using In-Call Options........................................................................................................................... 30

Using Call Log......................................................................................................................................... 31

Listening to Your Voicemail.................................................................................................................. 32

Using Voice Dialer.................................................................................................................................. 33

Conventions used in this guide

In this user guide, we use the following symbols to indicate useful and important information:

NOTE NOTE Notes, usage tips, or additional information

Warning Situations that could cause injury to yourself or others

Caution Situations that could cause damage to your device or other

equipment

2 3

Contacts..........................................................................................................................34

About Contacts...................................................................................................................................... 34

Opening Your Contacts........................................................................................................................ 34

Getting Started....................................................................................................................................... 34

Editing/ Deleting Contacts .................................................................................................................. 37

Communicating ...................................................................................................................................... 39

Account Setting...................................................................................................................................... 40

Messaging........................................................................................................................41

About Messaging.................................................................................................................................... 41

Sending Messages................................................................................................................................... 41

Reading Messages .................................................................................................................................. 43

Receiving CMAS Alerts Messages ..................................................................................................... 44

Changing Messaging Settings............................................................................................................... 45

Google.............................................................................................................................47

GmailTM ......................................................................................................................................................47

Google TalkTM .......................................................................................................................................... 51

Maps...........................................................................................................................................................54

Places..........................................................................................................................................................57

Navigation.................................................................................................................................................58

Latitude......................................................................................................................................................60

Calendar....................................................................................................................................................63

Market........................................................................................................................................................66

Books.........................................................................................................................................................69

Web ................................................................................................................................ 72

Email...........................................................................................................................................................72

Browser.....................................................................................................................................................76

YouTubeTM .................................................................................................................................................81

FacebookTM ...............................................................................................................................................84

Wi-Fi®........................................................................................................................................................84

Downloads................................................................................................................................................85

Bluetooth®......................................................................................................................87

Using Bluetooth®................................................................................................................................... 87

Disconnecting or Unpairing from a Bluetooth®Device............................................................. 88

Connecting to a Bluetooth®Headset.............................................................................................. 88

Sending and Receiving Information Using Bluetooth®................................................................. 89

Entertainment................................................................................................................91

Camera/Camcorder.............................................................................................................................. 91

Gallery .......................................................................................................................................................94

Videos........................................................................................................................................................96

Sound Recorder..................................................................................................................................... 97

Music..........................................................................................................................................................97

Tools ............................................................................................................................. 101

Clock........................................................................................................................................................101

Calculator...............................................................................................................................................102

Memo.......................................................................................................................................................103

MyFiles.....................................................................................................................................................103

Settings ........................................................................................................................ 105

Settings on Your Phone ......................................................................................................................105

Safety and use ............................................................................................................. 111

Please read before proceeding......................................................................................................... 111

Limitation of damages.........................................................................................................................111

Important health information and safety precautions...............................................................112

Regulatory agency identifications ....................................................................................................120

4 5

Specifications

Display

r 2.8 inches QVGA, IPS full-angle viewing,TFT 262k colors

r Multitouch capacitive touch screen

Camera

r 2Mp FF with LED flash

Dimensions and Weight

r Dimensions: 4.7 x 2.4 x 0.5 inch (121.2 x 63 x 14.45mm)

r Weight: 4.7oz (133g)

Memory

r 512MB (ROM)/512MB (RAM)

r External memory: microSDTM support up to 32GB

Operating Frequencies

r Networks: CDMA 1900(BC1) - 1XEV-DO rA Wi-Fi®(802.11 b/g/n) (802.11n 2.4GHz only)

r Data speed: Up To HSDPA 7.2Mbps

Operating System

r AndroidTM 2.3.5 (Gingerbread)

Connectivity

r BT 3.0 (HSP/HFP/A2DP/OPP),Wi-Fi®802.11 b/g/n

Sensors

r Accelerometer, E-compass, Proximity Sensor

LBS

r A-GPS

Power Management (Performance)

Battery Type Capacity Standby Time Talk Time

Lithium-Ion(Li-ion) 1300 mAh 270 hours (Slot Index 2) 4.2 hours (CDG89)

6 7

Basics

In Box

The A556C comes with the following items included in the box:

A556C Mobile Phone Battery Micro USB cable USB Power adapter

Battery cover Quick start guide 2GB microSDTM card (mounted in the device)

Phone Overview

Headset connector

Power key

Back key

Touchscreen

Search key

Menu key

Home key

Back cover lock

Loudspeaker

Camera

LED flash

Earpiece

Micro-USB

connector

Volume up

Volume down

QWERTY Keyboard Overview

Caps/Shift key

Function key

Space bar

A-Z

Delete key

Enter key

Symbol key

Smiley key

Your phone has a QWERTY keyboard which provides a superior typing experience for easy

and comfortable texting.

Proper Holding Position

NOTE The A556C is equipped with an antenna located in the base of the unit. For

optimum call quality, hold the phone along the sides and avoid touching the top

and bottom of the phone while in a call.

8 9

Battery

Note that browsing the web frequently, extended data usage, being in a poor signal area, or

subjecting the device to extreme temperatures will cause the battery to discharge quickly.

To increase battery life, limit your data usage, or turn off Wi-Fi®, GPS, and Bluetooth®when

not required.

Installing the battery

Please use only the original batteries and accessories you received with your phone or

your carrier recommended replacements.

1. Remove the battery cover from the unit.

2.Align the battery’s exposed gold contacts with the battery connectors inside the battery

compartment.

3. Insert the contact side of the battery first and then gently push the battery into place.

4. Replace the battery cover over the battery compartment and press down until you hear

a click.

Removing the battery

1. Make sure that your device is turned off, and then remove the battery cover.

2. Push the bottom of the battery to upwards and remove the battery.

Charging your battery

Before you turn on your device and start using it, it is recommended that you charge the

battery.

1. Plug the USB cable into the USB power adapter.

2. Plug the power adapter into a standard outlet.

3. Locate the USB port located on the left side of your device.

4. Plug the other end of the USB cable into the phone’s micro USB port.

5.The USB icon on the cable should always face up when connecting the cable to your device

as shown.

NOTE r*UJTNPSFFGGJDJFOUUPDIBSHFUIFCBUUFSZXJUIZPVSEFWJDFQPXFSFEPGG

r#BUUFSZPQFSBUJOHUJNFHSBEVBMMZEFDSFBTFTPWFSUJNF

r*GUIFCBUUFSZGBJMTUPQFSGPSNOPSNBMMZZPVNBZOFFEUPSFQMBDFUIFCBUUFSZ

r5IFCBUUFSZNVTUCFJOTUBMMFEGPSUIFQIPOFUPXPSLQSPQFSMZ

microSDTM Card

Use the microSDTM card to store your photos, videos, music and some memory card enabled

AndroidTM applications.You can also move and copy files to your computer from your device.

Inserting the microSDTM card

1. Remove the battery cover.

2. Locate the microSDTM card slot.

3. Insert the microSDTM card into the slot with its gold contacts facing down until it clicks

into the place.

4. Replace the battery cover.

Removing the microSDTM card

1. Make sure that your device is turned off, and then remove the battery cover.

2. Press the microSDTM card to eject it from the slot, then slide it out the rest of the way.

10 11

Removing the microSDTM card while the phone is on

If you need to remove the microSDTM card while the phone is on, unmount the microSDTM

card first to prevent corrupting or damaging the files in the microSDTM card.

1. From the Home screen, tap Apps > Settings. Or press Menu key > Settings.

2.Tap Storage > Unmount SD card.

3. Remove the microSDTM card by following the steps in “Removing the microSDTM card”.

Turning Phone On or Off

Turning your phone on

1. Press and hold Power/Lock key.

NOTE The first time you use your phone you’ll need to set it up. See the Getting Started

chapter for details.

Turning your phone off

1. If the display is off, press Power/Lock key to turn it back on.

2. Press and hold Power/Lock key for a few seconds.

3.When Phone options menu appears, tap Power off > OK.

Phone options

Silent mode

1. Press and hold Power/Lock key.

2.Tap Silent mode.

r When you select Silent mode, or (1) is displayed in the Status bar. Ringtones, alerts,

and all audible sounds except media and alarms are silenced.

NOTE To turn silent mode off, press and hold Power/Lock key and then tap Silent

mode again.

Airplane mode

1. Press and hold Power/Lock key.

2.Tap Airplane mode.

r When you set Airplane mode, is displayed in the Status bar.WiFi, Bluetooth®, and mobile

network functions are all disabled.

NOTE To turn airplane mode off, press and hold Power/Lock key and then tap

Airplane mode again.

Finger Gestures

Ta p To select onscreen items such as application and settings icons or press

onscreen buttons, simply touch them with your finger.

Tap and hold To open available options for the item, simply touch and hold your finger

on the screen over the item.

Swipe or slide Quickly drag your finger vertically or horizontally across the screen.

Drag Tap and hold your finger before you start to drag.While dragging, do not

release your finger until the item reaches your desired location.

Flick Flicking the screen is similar to swiping, but you only need to swipe

your finger in lighter and quicker strokes. This finger gesture is always

in a vertical direction, such as flicking through the contacts or the

message lists.

Rotate For most screens, you can automatically change the screen orientation

from portrait to landscape by turning the phone sideways.When entering

text, you can turn the phone sideways to bring up a bigger on-screen

keyboard.

(1) The phone setting will vary depending on the changes made to the default settings in

Settings\Sound\Vibrate.

12 13

Keyboard

Using the QWERTY Keyboard

Your device has a specially designed QWERTY keyboard that provides a superior, easy, and

comfortable typing experience.

1. Caps/Shift key To type a single uppercase letter. To continuously type letters,

press Caps/Shift key twice to lock it. Press Caps/Shift key

again to unlock.

2. Fn (Function key) To type the number or symbol printed on the keys in gray, hold

down the Fn key and press one or more letter keys.To return to

typing letters, release the Fn key.

To continuously type numbers and symbols, press Fn key twice to

lock it. Press Fn key again to unlock.

3. @To type “@”.

4. Space bar To type a blank space.

5.A-Z

(alphanumeric keys)

To enter numbers, letters or special characters. Go to the Google

Search screen if pressed on the Home screen.

6. Delete (Delete key) To delete a character. Press and hold to rapidly delete the entire

entry.

7. Enter (Enter key) To begin a new line or to select an item.

8. Sym (Symbol key) Pressing the Sym key opens a pop up menu of additional symbols.

9. Smiley key To type Smiley icons. (Emoticons)

NOTE For better performance in low-light environments, your handset includes a

backlight feature which illuminates the QWERTY keyboard so you can type with

ease.

Using the Onscreen Keyboard

In addition to the QWERTY keyboard you can also enter text using the onscreen keyboard.

Some applications open the keyboard automatically. In others, tap anywhere in a text field to

open the keyboard.You can choose between two included on-screen keyboards to select the

one that best fits your typing preferences.

NOTE To use the onscreen keyboard, from the Home screen, tap Apps > Settings >

Language & keyboard > Soft keyboard switch > Select Landscape mode

or Portrait mode or both.

r Tap Landscape mode to use the onscreen keyboard in landscape orientation on your

screen.

r Tap Portrait mode to use the onscreen keyboard in portrait orientation on your screen.

r If you want to change the on-screen keyboard type:Tap and hold the text input field > Tap

Input method > Select AndroidTM keyboard.

r Remember, the A556C has a built-in QWERTY keyboard, which you can use for all phone

functions.

NOTE You can change all keyboard settings including User dictionary through the settings

menu. From the Home screen, tap Apps > Settings > Language & keyboard.

Or press Menu key > Settings > Language & keyboard.

Text editing

You can edit the text you have entered.

r Touch and hold text you have entered

r Options list pops up

r Select the operation you need (Select word, Select all, Cut, Copy, etc.)

14 15

TouchPal Input

Touch to enter edit panel.

Touch to enter Voice input mode.

Touch to enter text or

numbers.Touch & hold

to select input method.

Touch to hide keyboard.

Long press to enter multiple

choices mode.

Touch to enter numbers,

symbols, etc.

Touch to switch back to last chosen one.

Touch and hold to change input language.

Touch to activate

Word prediction.

Touch for TouchPal

settings and additional

information

Touch to switch "abc/

Abc/ABC" input mode

AndroidTM keyboard

Touch to switch "abc/

Abc/ABC" input mode

Touch to switch to symbol

and numeric keyboard

Touch to enter Voice input.

Touch and hold, then select to

enter symbol/emotion.

Touch and hold to enter an

accent of the letter.

Touch to enter text or numbers.

Touch and hold to select input

method.

Touch to enter the symbol

Touch to enter Input options.

Getting Started

Google Account

You must sign in to a Google account to use GmailTM, Google CalendarTM, and other Google

applications; to download applications from Android Market; to back up your settings to

Google servers; and to take advantage of other Google services on your phone.

Registering a Google account

GmailTM, Android Marketplace, and some other applications require a valid Google account

for use.

1.Tap Sign in to register your Google account.

r If you don’t have a Google account, tap Create instead. See the next section for more

details.

2. Enter your Google account Username and Password > Tap Sign in.

Creating a new Google account

1.Tap Create > Enter First name, Last name and Username > Tap Next.

2. Enter a password in to the Type a password, Confirm password fields, then tap Next.

r Password tip:Your password must be a minimum of 8 characters in length.

3. Select Security question and enter the Answer, which will be needed if you forget your

password and then enter a Secondary Email > Create.

4. Read through Google Terms of Service > Tap I agree,Next.

5. Enter the letters shown on the screen > Tap Next > Tap Finish.

Adding a Google account

1. From the Home screen, tap Apps > Settings.

2.Tap Accounts & sync > Add account.

3.Tap Google > Tap Next.

4.Tap Sign in to register your Google account.

16 17

5. Enter your Google account Username and Password > Tap Sign in > Finish.

r The A556C supports multiple Google accounts.

r If you have the same contact across multiple Google accounts, you can merge duplicates into a

single item in the contact list.

Removing a Google account

1. From the Home screen, tap Apps > Settings.

2.Tap Accounts & sync.

3. Select the account to be deleted > Tap Remove account > Remove account.

r All information associated with that account will be deleted.This includes contacts, emails,

messages, calendar events, etc. At least one Google account is required for normal phone

operation.

NOTE The phone must be reset to remove a solitary Google account.

Getting to Know the Home Screen

The Home screen is displayed when the device is in idle mode.You can add your favorite apps,

shortcuts, folders and widgets to the Home screen so they’re only a tap away.

The Home screen is actually five separate screens. Slide your finger the left or right and you’ll

discover more space to add icons, widgets, and more. Press Home key to return to the

center Home screen.

Previewing the Home screens

1. From any Home screen, tap and hold Apps.

2.When you choose a desired Home screen, the display shifts to the selected Home screen.

Customizing the Home Screen

The Home screens and display wallpaper are extensively customizable.

Home screen customization options

1. Open the Home screen you want to customize.

2. Press Menu key > Add. Or just tap and hold an empty area on the Home screen.

3. On the menu that appears, select from the following choices.

Shortcuts Shortcuts can cover such functions asApplications, Bookmark, Contact, Direct

dial, Direct message, Directions & Navigation, Music playlist and Settings.

Widgets Widgets are mini-applications for functions as Analogue clock, Calendar,

Digital Clock, FacebookTM, Google Search, Google+TM, Home screen tips,

Latitude, Market, Music, Picture frame, Power Control, Traffic, WorldClock

and YouTubeTM.

Folders If you create a new folder, you can drag icons into the folder to organize them.

You can also select All contacts, Bluetooth®received, Contacts with phone

numbers or Starred contacts.

Wallpapers You can choose from your Gallery photos, Live wallpaper or Wallpaper to

change the display background.

Table des matières

Autres manuels TCT Mobile Téléphone portable

TCT Mobile

TCT Mobile U10C Manuel utilisateur

TCT Mobile

TCT Mobile Vodafone 575 Manuel utilisateur

TCT Mobile

TCT Mobile Smart III Manuel utilisateur

TCT Mobile

TCT Mobile Smart Kicka Manuel utilisateur

TCT Mobile

TCT Mobile MTAG 351 Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
