QUICK GUIDE TO THE

ENGLISH - GERMAN - SPANISH - ITALIAN - FRENCH - JAPANESE

For complete manuals in German, Spanish, Italian and French please refer to our website at:

www.tcelectronic.com

QUICK GUIDE

% rel.rel.

MIX EFFECT BAL.IN LEVEL

LEVELS MULTI SPECTRAL LCD DISPLAY

POWER 0

INPUT

-dB

44.1KHz

48KHz

Digital IN PARALLEL

LOCK

DUAL SEND/RET

STEREO LINKED

DUAL MONO

SERIAL

ANALOG

DIGITAL

EDITED FACTORY USER MIDI IN

The M-ONE Hall

DUAL EFFECTS PROCESSOR

POWER button

Power on/off.

IN LEVEL nob

Adjusts the Input level.

MIX nob

Adjusts the lobal mix between

dry and wet si nal.

Fully clockwise is 100% effect.

EFFECT BAL nob

Adjusts the balance between the

two En ines.

INPUT Meters

The Peak meter shows the Input

level of left/ri ht channels.

The meter ran e is:

0, -3, -6 ,-12, -18, -24, -40.

OVERLOAD LEDs

The OVERLOAD LEDs indicate

one of two situations:

- The Input level is too hot and

therefore overloadin .

- There is an internal DSP

overflow.

The Overload LED is lit when

1 sample is @ 0dBFS.

ANALOG/DIGITAL LED

ANALOG/DIGITAL indicator

states the selected Input.

Input type is selected in the

"I/O Setup" menu.

SAMPLE RATE indicator

The SAMPLE RATE indica-

tor shows the clock source

and the incomin master

clock. The icon Di ital In

will be blinkin if no clock or

unacceptable clock is found.

ROUTING indicator

Indication of what Routin

mode the MONE currently is

usin .

ALGO Indicator

Shows the currently used

al orithms in each of the two

En ines.

DYNAMIC meters 1+2

These two meters show the

ain reduction when an

En ine is runnin Dynamic

al orithms.

The Dynamic al orithms are:

Compressor, Limiter, Gate,

Expander and De-esser.

DISPLAY

Displays the preset number

and the preset type:

Factory or User.

EDITED icon

This icon will be lit as soon as

the current recalled preset

has been modified.

FACTORY/USER icon

Shows whether you are

operatin in the Factory or

the User bank.

MIDI IN icon

Shows any incomin

MIDI information.

Revision 1 - SW 1.01

Prod. No: E60500201

QUICK GUIDE

I/O RECALL

BYPASS 2

TAP UTILITY STORE EXIT

EFFECTS PROGRAMSETUP CONTROL

ENTER

BYPASS 1

ROUTING ALGO |EDIT ALGO |EDIT

ROUTING ey

Press the ROUTING key to set

the En ine Routin .

The options are: Dual Send /Ret,

Parallel, Parallel/Serial, Serial,

Stereo, Dual Mono.

I/O SETUP

Basic parameters are set here.

- Input source - Analo /Di ital.

- Sample Rate - 44.1/48kHz/DI.

- Bypass Mode - See Bypass

keys 1 and 2.

- Global Output level.

- Input level sensitivity:

Consumer (-10dBu) or

professional (+4 dBu).

- Dither 16, 20 or 24(off).

TAP ey

Tap this key to enter lobal Tap

tempo and to enter the Tap menu.

Subdivision of the tapped tempo

is setup in this menu. The tapped

tempo can be used for Delay

time, Chorus rate etc.

UTILITY

MIDI, SysEx-ID, Routin -lock,

Bypass mode and Pedal function.

STORE ey

Selects the Store menu. Presets

can be stored in the User bank

only. Location is selected usin

the CONTROL wheel. Operation

is confirmed usin ENTER.

CURSOR UP/DOWN

Use the cursors to move around

in the display.

ENTER ey

Confirms operations. The ENTER

key LED will indicate when this

key can be used.

EXIT ey

Is used to exit a menu or to

disapprove an action.

CONTROL wheel

Is used to chan e values.

ALGO/EDIT 1+2

Press this key to enter the Edit

display and the Al orithm Chan e

display of the currently selected

En ine.

BYPASS eys 1 and 2

The Bypass mode is set up in

Utility. There are three different

Bypass modes:

1 0% Mix:

The Input si nal is passed

directly to the Output.

2 Fx Input:

Cuts only the En ine Input in

order to let the effect "rin out",

but will still leave the same

amount of dry si nal comin

throu h.

3 Fx Output:

Cuts only the En ine Output in

order to kill the Fx instanta-

neously, but leaves the same

amount of dry si nal comin

throu h.

RECALL ey

Selects the Recall menu.

Select a desired preset usin the

CONTROL wheel and press the

ENTER key to enter/load the

selected preset.

QUICK GUIDE

Setting up the MONE

This explains a couple of the most commonly used setups:

M•ONE

MIXER

1R2

RETURNSSENDS

DUALEFFECTS PROCESSOR

MIX

FX BAL

ENG1

ENG2

MIX

FX BAL

ENG 1 ENG 2

MIX

FX BAL

ENG1

ENG2

MIXER

RETURNSSENDS

M•ONE

DUALEFFECTS PROCESSOR

MIXER

INSERTS

M•ONE

DUALEFFECTS PROCESSOR

With this setup the two En ines are

used as separate stereo effects

with a common 2 channel Output.

Example: Feed the two MONE

en ines with si nal from e. . two

separate Aux-sends from your

mixer. Connect the MONE L/R

Output to a stereo L/R return on

your mixer.

In Serial mode En ine 1 is

always routed before En ine 2.

The Output of En ine 1 is routed

directly to the Input of En ine 2.

Example: Use a De-esser in

En ine 1 and a Reverb in

En ine 2.

In this mode the MONE works as

two completely independent mono

units. This would be a typical setup

when usin the MONE as two

Compressors, Limiters, De-esser or

basically any combination of two

non stereo Effects

Dual Input Mode Serial Mode Dual Mono Mode

Dual Input Routing Serial Routing Dual Mono Routing

How to change algorithms:

- Press the ALGO/EDIT 1 or 2 dependin on which En ines al orithm you wish chan e.

- Select al orithm usin the CONTROL wheel.

- Press ENTER to confirm.

- Connect the MONE as illustrated below, usin balanced 1/4 jack cables.

- Press the ROUTING key to enter the Routin display.

- Use the CONTROL wheel to select Routin . The ENTER key is now blinkin .

- Press ENTER to activate the selected Routin .
