TBK vision RYK413F Manuel utilisateur

Box Camera

Instruction Manual

VER.:1.0, NO.:040125A

Thank you very much for purchasing our product. Before operating this

product, please read this instruction manual carefully to ensure proper use.

1. Safety Precautious

CAUTION

RISK OF ELECTRIC

SHOCK. DO NOT OPEN!

CAUTION : TO REDUCE THE RISK OF ELECTRIC

L SHOCK, DO NOT OPEN CO

ERS.

NO USER SER

ICE

BLE P

RTS INSIDE. REFER SER

ICING TO QU

LIFIED

SER

ICE PERSONNEL.

Disposal of Old Electrical & Electronic Equipment (Applicable in

the European Union and other European countries with separate

collection systems).

Please do not directly touch the sensor element. If necessary, use

a soft cloth moistened with alcohol to wipe off any dust.

Please be extra careful not to shake the camera

Please avoid places where there is direct sunlight

When using this camera in places where the lighting differs greatly,

please use the auto iris lens with ND filter.

Please avoid places where temperatures exceed 50℃or more,

high humidity or where direct rain drops hit, frequent vibrations, or

shocks occur.

During the night, if a minimum brightness of 0.1 Lux can not be

achieved, install appropriate light fixtures.

When the camera is not used, keep the lens or the lens cap

attached to protect the sensor.

2. Description

The camera uses SONY high sensitive super HAD interline transfer

image sensor, and employs digital signal processor (DSP) chip-set for

image control, and all integrated state circuitry which provide

extremely long life and high reliability. This camera offers excellent

image quality with low lag and high burn resistance, and is not subject

to distortions from magnetic fields.

Highly resistance to shock and vibration, easy to install, this

camera is a very good choice for your color CCTV system.

3. Feature

Camera with SONY Super HAD CCD sensor in metal case.

Employs Digital Signal Processor (DSP) chip-set for image control.

Pixel number: NTSC=380K/ PAL=440K (EIA=380K/ CCIR=440K) for

high resolution models, and NTSC=270K/ PAL=320K (EIA=270K/

CCIR=320K) for normal resolution models.

High sensitivity, low smear, high anti-blooming, and high S/N ratio.

Powerful functions: Auto Electronic Shutter (AES), Auto Iris (AI),

Auto Gain Control (AGC), Auto White Balance (AWB), and Back

Light Compensation (BLC).

Supports Auto Iris Lens: both Video-Drive & DC-Drive lens.

Supports both C and CS mount lens.

Optional Audio function ("S" model).

4. Contents

Item Name of Part Quantity

1 Camera 1

2 Appurtenance Bag 1

3 L-Wrench 1

4 Connector 4 Pins for Auto Iris Lens 1

5 Instruction Manual 1

6 Screws (optional) 2

7 Mounting Block (optional) 1

5. Name of Each Part

Fig. 1

Fig. 2

6. Installation & Operation

Please refer to Fig. 1 or Fig. 2 (P3) and setup guide below:

1. Remove the cap cover from the top of the lens mount.

2. Screw the lens into the lens mount.

3. Connect the video output (11) to the monitor or other video device

through a 75 Ohms type coaxial cable.

4. Connect the power source (8), AC with the power cord, or DC by

using the DC Jack (+12V DC is in the center of the jack plug),

then the LED indicator will lit.

5. Once the picture appears on the monitor, adjust the focus and iris of

the lens to obtain the best picture.

6. When the subject is not in focus after adjusting the focus of the lens,

adjust the back focus as follows:

•Set the lens focus ring to infinity (∞).

•Take picture of the subject at a distance more than 20M away.

•Loosen the screw securing the lens mount (use L-wrench).

•Turn the lens and secure it to the lens mount so that the subject

is in focus and the picture is clear.

•Tighten the screw securing the lens mount (2).

7. Mount the mounting bracket to hole (1) on the top or bottom of the

camera, using the enclosed 8mm mounting block with 2 screws

furnished.

8. Auto Iris Function

•When using an auto iris lens, SW1 (10) should be in the “AI/ MI”

position to disable AES function. Before plugging the enclosed

miniature 4 pins to the auto iris connector (4), please check the

type of auto iris lens used, and also the compatibility on the

polarities.

•When using DC Drive auto iris lens is used (or Direct Drive), the

switch (5) should be in the “DC Drive” position. Adjust VR (6) to

the proper level.

•When Video Drive auto iris lens is used, the switch (5) should be

in the “Video DR” position.

•When using manual iris lens, the switch SW1 (10) is

select-able depending on the application environment.

9. When using the BLC (Back Light Compensation) function, the

switch SW2 (4) should be in position with "BLC".

10. Auto Iris Control

Pin VIDEO DRIVER DC DRIVER

(Direct DRIVE)

VDC OUT

IRIS OUT

N.C.

GND

DAMP-

DAMP+

DRIVE+

DRIVE-

uto Iris Lens Connector

7. Specification

According to the camera purchased, select and refer to the appropriate specification below:

Color Camera

Image Device 1/3“ Color SONY

Super HAD

1/3“ Color SONY

Hi-Res. Super HAD

1/3“ Color SONY Ultra

Hi-Res. Super HAD

1/4” Color SONY

Super HAD

Picture Elements NTSC: 510 x 492

PAL: 500 x 582

NTSC: 768 x 494

PAL: 752 x 582

NTSC: 510 x 492

PAL: 500 x 582

Resolution 380 TVL 470 TVL 550 TVL 330 TVL

Min. Illumination 0.1Lux/ F1.2 0.2Lux/ F1.2 0.2Lux/ F1.2

S/N Ratio More than 48 dB

Electronic Shutter NTSC:1/60~1/100,000, PAL:1/50~1/110,000

Auto-Iris Support Video-Drive Lens & DC-Drive Lens

Gamma 0.45

Lens Mount C or CS mount (adjustable).

Gain Control Auto

White Balance Auto

Back Light Comp. On/ Off

Sync. System Internal.

Video Output 1 Vp-p/ 75 Ohms.

Audio Output 2Vp-p/ 50 Ohms. (optional)

Power Supply DC12V±10%, AC24V, AC110V, AC100~240V, DC12V/ AC24V Dual (optional)

Power

Consumption

DC/ 125mA max.

AC/ 3.2W max.

DC/ 110mA max.

AC/ 3.0W max.

DC/ 175mA max.

AC/ 3.5W max.

DC/ 130mA max.

AC/ 2.3W max.

Operating Temp. -10℃to 50℃

B/W Camera

Image Device 1/3” B/W SONY Super HAD 1/3” B/W SONY Hi-Res.

Super HAD 1/3” B/W CCD

Picture Elements EIA: 510 x 492

CCIR: 500 x 582

EIA: 768 x 494

CCIR: 752 x 582

EIA: 510 x 492

CCIR: 500 x 582

Resolution 420 TVL 510 TVL 600 TVL 710 TVL 400 TVL

Min. Illumination 0.05 Lux/ F1.2 0.02 Lux/ F2.0 0.1 Lux/ F1.2 0.03 Lux/ F2.0 0.2 Lux/ F1.2

S/N Ratio More than 48 dB

Electronic Shutter EIA: 1/60~1/120,000, CCIR: 1/50~1/120,000

Auto Iris Support Video-Drive Lens & DC-Drive Lens

Gamma 0.45

Lens Mount C or CS mount (adjustable).

Gain Control Auto

Back Light Comp. On/ Off

Sync. System Internal, Native Sync.

Video Output 1 Vp-p/ 75 Ohms.

Audio Output 2Vp-p/ 50 Ohms. (optional)

Power Supply DC12V±10%, AC24V, AC110V, AC100~240V, DC12V/ AC24V Dual (optional)

Power

Consumption DC/ 139mA max.

AC/ 2.8W max.

DC/ 109mA max.

AC/ 2.8W max.

DC/ 137mA max.

AC/ 2.8W max.

DC/ 115mA max.

AC/ 2.8W max.

DC/ 137mA max.

AC/ 2.8W max.

Operating Temp. -10℃to 50℃

Note: Design and specifications are subject to change without prior notice.
