OPERATOR’S

MANUAL

DCA² MC 2500 - DCA² MC 5500DCA² MC 2500 - DCA² MC 5500

DCA² MC 7500 - DCA² MC 10500DCA² MC 7500 - DCA² MC 10500

Dealer:

Owner:

Firm / Farm:

City: State:

No. of the Certificate of Guarantee:

Serial / No.:

Date: Invoice No.:

Product:

Notes:

IDENTIFICATION

Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. DCA² MC 2500, 5500, 7500 & 10500

Introduction

The DCA² MC models perform an uniform distribution of dry and

humid limestone, granulated or powdered fertilizer, gypsum,

seeds and other products.

DCA² MC 2500, DCA² MC 5500, DCA² MC 7500 and DCA²

MC 10500 models have cardan shafts and belt transmission to

activate the conveyor and the rotating discs.

The DCA² MC 2500 feature a fixed wheelset with 2tires.

The wheelset tandem type (DCA² MC 5500, DCA² MC 7500 and

DCA² MC 10500) have four tires that precisely follow the soil

profile.

The conveyor is made of carbon steel and has tighteners to

adjust the tension.

The opening of the dosing gate features a graduated scale and

easy adjustment to distribute several quantities.

The fins are adjustable on the discs, performing an adequate

distribution of different products.

This operator's manual contains the necessary information for the

best performance of this spreader. The operator must carefully

read the entire manual before working with the equipment. Also,

read and understand the safety recommendations.

For any further clarification or in the event of technical problems

that may arise during the service, consult your dealer and the

Technical Support department of the factory. They can ensure

the fully functioning of your TATU spreader.

Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

2DCA² MC 2500, 5500, 7500 & 10500

Table of contents

1. To the owner 3

2. To the operator 4 to 12

3. Data sheet 13 to 15

4. Components 16 to 21

5. Assembly 22 to 24

6. Set-up instructions 25 to 33

Preparing the tractor / Preparing the equipment 25

Hitching to the tractor 26 & 27

Coupling the cardan shaft to the PTO 28

Reducing the cardan shaft length 29

Cardan shaft assembly / Cardan working angle 30

Jack position for working or transportation 31

Equipment leveling / Deflector use / Tractor speed 32

PTO rotation / Final inspection 33

7. Adjustments and operations 34 to 49

Speed of the rotating discs / Conveyor speed (cardan shaft) 34

Speed of the rotating discs / Conveyor speed (hydraulic motor) 35

Sprockets change (cardan shaft) 36

Sprockets change (hydraulic motor) 37

Fins position on the discs 38

Distance between distribution bands / Flow divider adjustment 39

Gate opening 40

Application tables 41

Dry limestone / Granulated fertilizer distribution tables 42 & 43

Calculation for different distributions 44

Conveyor tension adjustment 45

Belt tension adjustment 46

Changing the belt of the rotating discs 47

Operations - Important points 48

Troubleshooting guide 49

8. Optional 50 & 51

Directioner 50

Damper 51

9. Maintenance 52 to 62

Lubrication / Lubricate every 24 hours of service 52 & 53

Filtering element replacement indicator / Replacing the filtering element 54 & 55

Belt replacement 56

Rotating discs maintenance 57

Periodic maintenance 58

Tires replacement 59

Spreader storage 60

Tires inflation 61

Hydraulic safety 62

10. Important data 63

11. Important 64

Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. DCA² MC 2500, 5500, 7500 & 10500

General information

Important

To the owner

The acquisition of any Tatu product assures to the original purchaser the following

rights:

• Warranty certificate;

• Operator's manual;

• Technical assistance by the dealer on equipment delivery.

However, the owner must check the condition of the equipment on delivery, as well

as knowing the warranty terms.

Special attention should be given to the safety recommendations, operation precautions

and maintenance of the equipment.

The instructions in this manual indicates how to get the best performance and allow

the operator to get maximum income, increasing the equipment lifetime.

This manual should be read by operators and maintenance staff.

• Only people who own a full knowledge of the tractor and equipment

must transport, operate and carry out any maintenance on them;

• Marchesan is not responsible for any damage caused by accident

on transporting, incorrect utilization or inadequate storage, either

by negligence and/or lack of experience from any person;

• Marchesan is not responsible for any damage caused by unpredictable

situations or the incorrect use of the equipment.

The warranty shall not be applied to any equipment or any part thereof which

has been altered elsewhere than at the place of manufacture or which the

original purchaser thereof at retail has used or allowed to be used parts, not

made or supplied by Marchesan.

NOTE

Right and left hand side indication are made observing the equipment from the rear.

To order any parts or request technical assistance services, it is required to provide

the data contained on the nameplate, which is located on the equipment frame.

Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

4DCA² MC 2500, 5500, 7500 & 10500

To the operator

Working safely

Be careful with the environment

Dear operator!

Respect the ecology. Do not throw trash away. This gesture of

goodwill helps to protect our environment.

Products such as oil, fuel, filters, batteries and others are

spilt over the soil and can penetrate to the underground layers,

compromising nature. Ecological and conscious disposal of them

should be done.

This equipment is simple to operate, requiring however the basic

and essential cautions to its handling.

Always keep in mind that safety requires constant attention,

observation and prudence during work, transportation, maintenance

and storage.

• Security aspects must be carefully observed, to avoid

accidents.

• This symbol is a warning used to prevent accidents.

• The instructions under this symbol refers to the safety of the

operator, mechanician or third parties, therefore they should

be carefully read and observed. If the safety instructions are

not being followed, a serious accident or even death may

occur.

Read and understand the information before making any

adjustment or maintenance.

Have extreme caution when operating with the power take-off

(PTO), which you should not get closer during operation.

When hitching the equipment to the tractor, use a chain to

lock the equipment drawbar to the tractor hitch bar. This procedure

will prevent a possible rupture of any hydraulic hose or breaks on

the hitching system, what would make the equipment tilt up.

Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. DCA² MC 2500, 5500, 7500 & 10500

To the operator

Never use your bare hands to check hydraulic leaks, the high

pressure can cause injuries.

Never attempt to change the adjustments, clean or lubricate the

equipment when the same is switched on or in movement.

Be careful while driving on slopes. Risk of overturn.

Prevent that chemical products (i.e.: fertilizers, treated seeds)

make any contact with your skin or clothes.

Keep access and work places clean or free from oil and grease.

Risk of accidents.

Never transport the equipment on highways or paved roads.

Avoid that the tractor wheels touch the drawbar in sharp turns.

The presence of any other people on the tractor or equipment

is stricly forbidden.

Have extreme caution when driving under electrical power lines.

Any contact may result in severe shocks, injuries or death.

For your protection and safety, always wear adequate clothes

and footwear while operating the equipment.

Always use the safety locks to carry out any maintenance or to

transport the equipment.

Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

6DCA² MC 2500, 5500, 7500 & 10500

To the operator

• Only trained and qualified personnel are allowed to operate the equipment.

• While working or during transportation, only the presence of the operator is

allowed in the tractor.

• Do not allow children to play or to get over the equipment while it is operating,

during transportation or storage.

• When setting the equipment to transport position, check if there are no people

or animals close or under it.

• Use personal protective equipment (PPE).

• Wear appropriate clothes and footwear. Avoid clothes that are either loose or

hanging from the body, which may become entangled in moving parts.

• Wear protective gloves to work near the cutting parts.

• Never operate the equipment without its protective devices.

• Have full knowledge of the soil before starting to work. Use the speed which is

suitable to the conditions of the ground or pathways to be covered. Provide the

delineation of obstacles or hazardous locations.

• Carefully check the transport width on narrow locations.

• Be careful while hitching the equipment to the tractor.

• Only pull the equipment using a tractor with appropriate power.

• Do not drive the equipment under the influence of alcohol or any soothing/

stimulating medicine, as it may result in a serious accident.

• In case of a fire outbreak or any possible hazard, the operator must leave the

area as fast as possible and look for a safe place. Always have emergency

numbers in hands.

• In case of emergency, know how to stop the tractor and equipment quickly.

• Always shut down the engine, remove the key and use the handbrake before

leaving the tractor seat.

• Never attempt to change the adjustments, clean or lubricate the equipment while

it is moving.

• Whenever you unhitch the equipment, either in the field or shed, do it on a

flat and firm surface and use jacks. Make sure that the equipment is properly

supported.

• We suggest that you carefully read the manual, as it will be a guide for periodic

verifications that need to be done and will allow that you assure the maintenance

of your equipment.

• If there is any doubt after reading it, ask your dealer. For more complicated

operations, there will be the right person to help you there.

• Please check the general safety instructions on the back cover of this manual.

Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. DCA² MC 2500, 5500, 7500 & 10500

Transportation over truck or trailer

To the operator

Marchesan does not advise the equipment traffic on highways, because this

practice involves serious security risks in addition to being prohibited by the

current existing traffic law. The transportation for long distances should be done

on truck, trailer or others by following these safety guidelines:

• Use adequate ramps to load or unload the equipment. Do not make the loading

on ditch banks, it can cause a serious accident.

• When lifting with a hoist, use the appropriate points to lift.

• Underpin the equipment wheels appropriately.

• Use chock blocks and safety chains to secure the equipment to the truck or

trailer during the transport.

• Make sure the SMV (Slow Moving Vehicle) sign, and all the lights and reflectors

that are required by the local highway and transport autorithies are in place, are

clean and can be seen clearly by all overtaking and oncoming traffic.

• After 8 to 10 km transporting, please inspect the load condition. Repeat this

procedure every 80 to 100 km. Give more attention when transporting the

equipment on rough roads, slopes and other adverse conditions.

• Always be careful with the load height, especially when passing under electrical

power lines, bridges and others.

• Check all laws and regulations regarding the height limits and load width while

transporting the equipment on truck or trailer. If necessary use banners, lights

and other devices in order to give adequate warning to the other drivers.

Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.

8DCA² MC 2500, 5500, 7500 & 10500

To the operator

Working safety standards

It is important to have knowledge not only about the functioning, operation of the

equipment and its technology, but also about the working legal aspects when using the

equipment, such as safety standards, operator's manual and working safety.

The equipment and tools used on the rural area must be properly handled, otherwise

health and safety of involved personnel may be compromised.

The operator must be capable and authorized to operate the tractor, meaning that the

person must comprehend the functioning instructions of the tractor and know about the

safety standards related to the job that will be performed.

The Ministry of Labor and Employment created safety standards that aim to decrease

the risk of accidents that may occur to the rural worker. Related to the subject of agicultural

machines and equipments, we specifically mention the NR 06, NR 12 and NR 31 standards.

Regulatory Standard - NR 06:

• For purposes of applying this Regulatory Standard, Personal Protective Equipment

(PPE) is considered any device or product that is worn by an individual worker for protection

against risks that could threaten safety and health at work.

Regulatory Standard - NR 12:

• This Regulatory Standard and its annexes provide technical references, basic

principles and protective measures to ensure the health and physical integrity of workers,

and establishes minimum requirements for the prevention of accidents and occupational

diseases in the design stages and use of machinery and equipment of all kinds, and also to

its manufacture, importation, trading, exhibition and cession in any way. It is understood to

be used to the construction, transportation, assembly, installation, adjustment, operation,

cleaning, maintenance, inspection, disabling and dismantling of machinery or equipment.

Regulatory Standard - NR 31:

• This Regulatory Standard has the purpose to establish the precept to be applied on

the organization and on the working environment, in order to make compatible the planning

and development of agriculture, livestock, forestry, forest exploration and aquaculture with

safety in the working environment.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Tatu Marchesan Épandeur

Tatu Marchesan

Tatu Marchesan DCA 1200 Manuel utilisateur

Manuels Épandeur populaires d'autres marques

PEQUEA

PEQUEA GT-100 Manuel utilisateur

Herculano

Herculano H2RS9 Manuel utilisateur

Epoke

Epoke SKE8 Manuel utilisateur

GEA

GEA EL44 Fiche technique

Boss Snowplow

Boss Snowplow TGS 800 Manuel utilisateur

Fisher

Fisher EMERSON 168 Series Manuel utilisateur

Fisher

Fisher POLY-CASTER 78601 Manuel utilisateur

TurfEx

TurfEx RS7200 Manuel du propriétaire

Ferris

Ferris Pathfinder Series Manuel utilisateur

Fayat Group

Fayat Group DYNAPAC S100 Guide de dépannage

Art's-Way Manufacturing

Art's-Way Manufacturing X700 Manuel d'installation et d'exploitation

EASTMAN

EASTMAN CR 500 Manuel utilisateur

Nogueira

Nogueira RoyalFlow-600 Manuel utilisateur

Buyers

Buyers TGS05B Manuel utilisateur

Magnum

Magnum V-BOX PV Series Supplément

Meyer's

Meyer's VB280 Manuel utilisateur

SnowEx

SnowEx VX-4210 Manuel utilisateur

Kramer

Kramer VM-400HDCP Manuel utilisateur
