MANUAL: DECON/pak Portable

Decontamination System

INSTRUCTIONS FOR SAFE OPERATION AND MAINTENANCE

WARNING

Read instruction manual before use. Operation of this device without understanding the manual

and receiving proper training is a misuse of this equipment. Users who have not read and

understood all operating and safety instructions are not qualied to operate this portable agent

system. This instruction manual is intended to familiarize reghters and maintenance personnel

with the operation, servicing, and safety procedures associated with the DECON/pak Portable

Decontamination System. This manual should be kept available to all operating and maintenance

personnel.

WARNING

Improper use of agent can result in injury or damage to the environment. Follow the agent

concentrate manufacturer’s instructions and re service training to avoid using the wrong type of

agent for decontamination purposes.

WARNING

There is a wide variety of agent concentrates. Each user is responsible for verifying that any agent

concentrate chosen to be used with this unit has been tested to assure that the agent obtained is

suitable for the purpose intended.

DECON/pak

PATENTED

UL502-D

PORTABLE DECONTAMINATION SYSTEM

Valparaiso, IN 46383-9327

+1 219 462-6161 • 800 348-2686 • MADE IN U.S.A.

www.tft.com

TASK FORCE TIPS

UL521

Read manual before use.

WARNING

Pat# 5,810,089

RATED FLOW

12 GPM at 100 PSI

45 L/MIN at 6.8 BAR

Minimum Operating Condition

7 GPM at 40 PSI

30 L/MIN at 3 BAR

Maximum Operating Condition

27 GPM at 500 PSI

100 L/MIN at 40 BAR

TASK FORCE TIPS, INC.

MADE IN USA • www.tft.com

3701 Innovation Way, Valparaiso, IN 46383-9327 USA

800-348-2686 • 219- 462-6161 • Fax 219-464-7155

©Copyright Task Force Tips, Inc. 2017 LIU-050 December 4, 2017 Rev00

DANGER

PERSONAL RESPONSIBILITY CODE

The member companies of FEMSA that provide emergency response

equipment and services want responders to know and understand the

following:

1. Fireghting and Emergency Response are inherently dangerous activities

requiring proper training in their hazards and the use of extreme caution

at all times.

2. It is your responsibility to read and understand any user’s instructions,

including purpose and limitations, provided with any piece of equipment

you may be called upon to use.

3. It is your responsibility to know that you have been properly trained in

Fireghting and /or Emergency Response and in the use, precautions, and

care of any equipment you may be called upon to use.

4. It is your responsibility to be in proper physical condition and to maintain

the personal skill level required to operate any equipment you may be

called upon to use.

5. It is your responsibility to know that your equipment is in operable

condition and has been maintained in accordance with the manufacturer’s

instructions.

6. Failure to follow these guidelines may result in death, burns or other

severe injury.

FEMSA

Fire and Emergency Manufacturers and Service Association

P.O. Box 147, Lynneld, MA 01940 • www.FEMSA.org

©Copyright Task Force Tips, Inc. 2017 LIU-050 December 4, 2017 Rev00

Table Of Contents

1.0 MEANING OF SIGNAL WORDS

2.0 SAFETY

3.0 GENERAL INFORMATION

3.1 PART IDENTIFICATION

3.2 LEFT or RIGHT HAND OPERATION

4.0 AGENT SELECTION

4.1 AGENT COMPATIBILITY

5.0 OPERATION

5.1 HOSE CONNECTION

5.2 FILLING TANK

5.3 CONNECT DISCHARGE HOSE AND NOZZLE

5.4 SETTING AGENT CONCENTRATION

5.5 CONTROLLING FLOW

5.6 AGENT QUALITY

5.7 SHUT DOWN AFTER USE (FLUSHING)

5.8 STORAGE

6.0 TROUBLE-SHOOTING

7.0 CLEAN UP AND MAINTENANCE

7.1 DRAIN HOLE

8.0 SPECIFICATIONS

9.0 DRAWINGS AND PARTS LIST

10.0 WARRANTY

©Copyright Task Force Tips, Inc. 2017 LIU-050 December 4, 2017 Rev00

1.0 MEANING OF SAFETY SIGNAL WORDS

A safety related message is identied by a safety alert symbol and a signal word to indicate the level of risk involved with a particular

hazard. Per ANSI standard Z535.6-2006, the denitions of the four signal words are as follows:

DANGER

DANGER indicates a hazardous situation which, if not avoided, will result in death or serious

injury.

WARNING

WARNING indicates a hazardous situation which, if not avoided, could result in death or serious

injury.

CAUTION

CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor

or moderate injury.

NOTICE

NOTICE is used to address practices not related to personal injury.

2.0 SAFETY

This portable decontamination system can be used in potentially dangerous situations. The following must be observed at all times:

WARNING

Avoid directing agent onto the faces of yourself and other personnel. Improper use of agent

could result in death or serious injury, including damage to the eyes. To reduce the chance of

injury, have yourself and other personnel wear eye protection at all times.

WARNING

Make sure that the agent concentrate in the tank is the right type for the situation. (Refer to

agent concentrate manufacturer’s recommendations for proper agent choice.)

WARNING

Agent concentrates can be ine󰀨ective if not used at the correct percentage. Make sure that the

Percentage Knob is set to the correct concentration for the type of agent being used.

CAUTION

Make sure the Flow Control Valve is o󰀨 and the correct nozzle and Outlet Hose are securely

attached to the Control Block before the hose line is charged.

©Copyright Task Force Tips, Inc. 2017 LIU-050 December 4, 2017 Rev00

3.0 GENERAL INFORMATION

The DECON/pak Portable Decontamination System is a self-contained agent proportioning and rinse application system developed

specically for gross decontamination of reghting personnel and equipment. Injecting a variety of approved personal protective

clothing gross decontamination agents from 0.1% to 0.5%, the rugged green polypropylene 2.5 gallon concentrate tank and is

supplied by a pressurized 1” or 1.5” hoseline. The unit includes an integrated twist shut-o󰀨 valve, selective injection metering knob,

and is easily disassembled for cleaning. The pressure vacuum seal on the lid and inlet debris screen assures that the approved

decontamination agent chosen can be stored ready for immediate use. A detachable fan spray nozzle is attached to a 12’ discharge

hose for ease of use during agent application or rinsing operations.

The DECON/pak is not intended to be used for Class A , Class B, or any other type of foam concentrate. If you intend to use the

DECON/pak for liquids other than decontamination agents and water, we urge you to contact Task Force Tips Service Department

at 800-854-6864. The use of other liquids may void the warranty and subject the user to hazards not addressed in this manual. The

user assumes all risks for non intended uses.

FLOW (GPM)

DECON/pak FLOW CHARACTERISTICS

(with valve fully open)

INLET PRESSURE (PSI)

20182 6 1614

104 24 26228

150

350

250

450

100

300

200

400

500 MAXIMUM OPERATING

PRESSURE = 500 PSI

MINIMUM OPERATING

PRESSURE = 40 PSI

MINUTES TO USE 2½ GALLONS

OF CONCENTRATE AT 12 GPM

PERCENT MINUTES

0.1 208

0.2 104

0.3 69

0.4 52

0.5 42

FLOW (L/MIN)

10 6020 70 80

100

DECON/pak FLOW CHARACTERISTICS

(with valve fully open)

MAXIMUM OPERATING PRESSURE = 40 BAR

MINIMUM OPERATING PRESSURE = 3 BAR

INLET PRESSURE (BAR)

100

MINUTES TO USE 10 LITERS

OF CONCENTRATE AT 45 l/min

PERCENT MINUTES

0.1 208

0.2 104

0.3 69

0.4 52

0.5 42

©Copyright Task Force Tips, Inc. 2017 LIU-050 December 4, 2017 Rev00

3.1 PART IDENTIFICATION

OUTLET HOSE

12' HOSE

(3.6 m)

TWIST GRIP

FLOW CONTROL

PULL PIN

TANK

FAN NOZZLE

PERCENTAGE KNOB

(TURN)

3.2 LEFT or RIGHT HAND OPERATION

The Control Block and Valve Assembly can be mounted on the Tank for right or left hand operation. To switch hands, remove the

Shoulder Strap from the Pull Pins. Remove the Circle Cotters from the Pull Pins and remove the Pull Pins themselves. Pull the

Control Assembly straight up and out of the tank. Turn the Control Unit around and reinstall the Pull Pins, the Circle Cotters, and the

Shoulder Strap.

4.0 AGENT SELECTION

In any eductor type system the accuracy of the agent concentrate to water ratio will depend upon the viscosity (thickness) of the agent

concentrate. The more viscous, or thick, the agent concentrate, the greater the amount of energy required to draw the concentrate

into the eductor. The viscosity of most agent concentrates changes with temperature, some thickening to a gel at temperatures of

40º F (4º C).

The DECON/pak percentage knob was calibrated with ZepPowerPlex® Heavy-Duty Laundry Detergent. Actual agent concentrations

vary with changes in water ow, agent concentrate temperature and viscosity. The user must verify that the concentrate’s performance

is suitable for use in their application. In all cases, the manufacturer’s recommendations must be followed.

4.1 AGENT COMPATIBILITY

DANGER

Do not mix di󰀨erent types of agent concentrates or agents of the same type from di󰀨erent

manufacturers. Mixing of agent concentrates can cause the contents of the agent tank to gel and

produce unpredictable results. Clean tank and agent passages thoroughly when changing agent

types. Check with your PPE manufacturer for recommendations.

©Copyright Task Force Tips, Inc. 2017 LIU-050 December 4, 2017 Rev00

5.0 OPERATION

DECON/pak

PATENTED

UL502-D

PORTABLE DECONTAMINATION SYSTEM

Valparaiso,IN 46383-9327

+1 219 462-6161 • 800 348-2686 • MADE IN U.S.A.

www.tft.com

TASK FORCE TIPS

UL521

Read manual before use.

WARNING

Pat#5,810,089

PUSH & TURN

TO ATTACH

CONTROL

FLOW

FILL

2.5 GAL

CONNECT

SUPPLY

ADJUST %

START UP PROCEDURE

To Make Agent - Connect water supply. Attach the nozzle to the

Quick-Connect. Turn the Percentage Knob to the desired percentage.

Twist the Valve Handle to start water flow.

5.1 HOSE CONNECTION

Attach inlet re hose to the coupling on the inlet end of the DECON/pak. Larger hoses may be used with an adapter. For maximum

maneuverability, we recommend attaching 1” hose into the DECON/pak itself.

5.2 FILLING TANK

Unscrew the ll port lid by turning counterclockwise. Fill tank to bottom of ll port. Agent may seep out the vents if over lled. Close

the ll port lid by turning clockwise.

5.3 CONNECT DISCHARGE HOSE AND NOZZLE

1. The nozzle may be attached directly to the quick-connect tting on the control block or to the end of the outlet hose which is then

attached to the control block. Align the marks on the quick-connect male tting with the marks on the female tting and push the

two pieces together. Twist the nozzle or hose one quarter turn to the right to latch the quick-connect tting.

2. To remove fan nozzle, remove set screw.

3. Hose lengths available. TFT part U-HS6, U-HS, and U-HS25.

CAUTION

The DECON/pak’s eductor will not work if the backpressure from the outlet hose or nozzle is too

high. The 25’ (7.5m) U-HS25 optional hose is the maximum length that will work with the DECON/

pak. Adding additional hose, or using other hose assemblies and nozzles, may cause the DECON/

pak to not function properly.

CAUTION

There is no check valve in the DECON/pak eductor system. Do not install a shut o󰀨 valve between

the DECON/pak and the fan nozzle. This can cause the agent tank to ll with water and dilute the

agent concentrate.

5.4 SETTING AGENT CONCENTRATION

Turn the knob to the desired concentrate percentage. The percentage knob may be turned to the RINSE position for water only use.

Be sure to use the agent manufacturer’s recommended concentrate ratio.

5.5 CONTROLLING FLOW

Pressurize the hose line. Turn the ow control valve to start water owing through the DECON/pak. Flow may be reduced by partially

closing the control valve.

©Copyright Task Force Tips, Inc. 2017 LIU-050 December 4, 2017 Rev00

5.6 AGENT QUALITY

INSTALL CAP

ROTATE

OPEN SLIGHTLY

TO CLEAN OUT IF PLUGGED

Remove screw #2, spring #3, and knob #4. Inspect the

underside of the knob. Make sure the agent passages are

clear. Do not scratch the at face of the knob. Inspect the 2

holes in the top of the Control Block #5. If they are plugged,

pull pins #1, remove Block Assembly and clean out Pickup

Tube and holes.

TO SHUT DOWN

To prevent concentrate from drying in the agent passages the following

is recommended. While still connected to water supply, remove Circle

Cotters and Pull Pins. Remove Control Unit from tank. Attach the Cap

directly to the Quick-Connect on the Control Block. Turn the valve half

way on till the discharge is agent free. This will back ush a small

amount of water through the agent passage. Rotate the Percentage

Knob back and forth to make sure all agent passages are ushed.

PULL

CLEAN

UNSCREW

5.7 SHUT DOWN AFTER USE (FLUSHING)

DECON/pak should be ushed with water after each use to prevent agent concentrate from drying out inside of the Control Block

and Percentage Knob.

1) Reduce pump pressure to 100 psi or less.

2) Remove the nozzle and/or hose from the quick-connect on the front of the Control Block.

3) Remove the Circle Cotters and pull out the two Pull Pins that hold the Control Unit to the tank.

4) Pull straight up to remove the Control Unit and Pickup Tube from the tank.

5) Make sure the Percentage Knob is NOT in the RINSE position.

6) Install the Cap on the outlet of the Control Block.

7) Turn the Flow Control valve until a trickle of clean water is owing out the end of the Pickup Tube.

8) Turn the Percentage Knob back and forth to make sure all agent passages are ushed.

9) Shut o󰀨 water and reinstall the Control Unit on the tank and insert the Pull Pins and circle cotters.

10) Remove the Cap.

The exterior of the DECON/pak can be washed o󰀨 with the hose with the percentage knob in the RINSE position.

5.8 STORAGE

The DECON/pak can be stored with agent concentrate in it.

Make sure the control block and valve assembly is mounted

on the tank and the ll port is securely closed to prevent

evaporation. Storage in the upright position is recommended

to avoid agent leaking when the DECON/pak is not in use.

(See gure 6.8) DECON/pak

PATENTED

UL502-D

PORTABLE DECONTAMINATION SYSTEM

Figure 6.8

DECON/pak shown placed in a U-B mounting bracket in an upright position.

©Copyright Task Force Tips, Inc. 2017 LIU-050 December 4, 2017 Rev00

6.0 TROUBLE-SHOOTING

SYMPTOM POSSIBLE CAUSE REMEDY

DECON/pak will

not make agent

Out Of Agent Rell Tank

Percentage Knob is in RINSE Select desired percentage

Percentage Knob is plugged Remove screw on Percentage Knob, inspect and clean

holes in top of control block and agent passages in

bottom of Percentage Knob

Non-standard outlet hose being used which is too long or

too small in diameter

Order other hose option TFT part U-HS, U-HS6 or

U-HS25

Agent tank is nearly empty Rell tank

Agent is

Intermittent

DECON/pak tilted Keep Twist Grip Horizontal

Air vents are plugged Make sure that the small black rubber valve on the

inside of the agent tank lid is not stuck down with dried

agent concentrate

Poor Quality

Agent

Debris in nozzle Inspect nozzle, look for plugged holes

Debris under knob Unscrew Knob, inspect and clean

Agent solution velocity too high Partially close Flow Control

Agent gets thick when cold Select Another Agent

7.0 CLEAN UP AND MAINTENANCE

Turn the percentage knob to the RINSE position. Use the hose, or

hose and nozzle, to rinse o󰀨 the DECON/pak. Reset percentage

knob to proper percentage when nished.

For years of service, periodically inspect your DECON/pak. Make

sure the hose and fan nozzle are in place. Look for debris in the

bottom of the tank and ush if necessary.

DRILL 7/16" HOLE

TAP 1/4" NPT

LEFT FRONT ONLY!

7.1 DRAIN HOLE

If the DECON/pak is often used for di󰀨erent agent concentrates,

it may be helpful to install a drain to aid in emptying the tank. Drill

and tap the left front ear of the tank and install a ¼” NPT Pipe

plug. Plastic or Brass preferred.

8.0 SPECIFICATIONS

U.S. Units Metric Units

Tank Capacity (to bottom of ll port) 2.5 U.S. gallons 9.5 liters

Nominal ow (all nozzles) 12 gpm at 100 psi 45 l/min at 6.8 bar

Weight Empty 11.5 lb 5.2 kg

Weight Full 30.1 lb 13.6 kg

Length x Width x Height 13.5 x 10.75 x 17 in 345 x 275 x 430 mm

Operating Pressure Max/Min 500/40 psi 34.5/3 bar

9.0 DRAWINGS & PARTS LIST

# DESCRIPTION QTY PART #

1 Pull Pin 2 U180

3 3/16 SS Balls 21 V2120

4 1/4-28 x 1/2 Set Screw 1 VT25-28SS500

5 1.0 Hose Gasket 1 V3040

6 1.0 Coupling* 1 U260*

7 1.5 Hose Gasket 1 V3130

8 Angled Swivel 1 U265

9 Quad Seal 1 VOQ-4316

10 Rear Block 1 U270

11 Circle Cotter 4 U182

12 024 O-Ring 1 VO-024

13 Handle 1 U240

14 Flow Label 1 UL500

15 022 O-Ring 1 VO-022

16 Handle Plug 1 U241

17 Valve 1 U250

18 Valve Pointer Label 1 UL504

19 124 O-Ring 3 VO-124

20 1/4-20x3/4 Stud 1 U223

# DESCRIPTION QTY PART #

21 Knob Nut 1 U221

22 Knob Spring 1 U222

23 Percent Knob Label - Decon 1 UL505-D

24 Percentage Knob - Decon 1 U232

25 Vinyl Cap 1 VM1030

26 Spirol Pin 1 V1900

27 Rear Venturi Insert 1 U214

28 Dog Point Screw 4 H515

29 120 O-Ring 1 VO-120

30 Venturi Cap 1 U213

31 Cable Assembly 1VM1020

32 Cup Seal 1 U212

33 Front Venturi Insert 1 U210

34 Control Block 1 U200

35 Agent Pick Up Tube - Polyethylene 1 U201

36 Follower 2 U251

37 1.5 Coupling * 1 F10097*

38 Port Plug 1 B770

39 3/16 SS Balls 34 V2120

Table des matières

Autres manuels Task Force Tips Pistolet à peinture

Task Force Tips

Task Force Tips Ultimatic Guide rapide

Task Force Tips

Task Force Tips HURRICANE RC Manuel de programmation

Task Force Tips

Task Force Tips PROTECTOR Guide rapide

Task Force Tips

Task Force Tips G-Force Guide rapide

Task Force Tips

Task Force Tips IN-LINE GAUGE WITH VALVE Manuel utilisateur

Task Force Tips

Task Force Tips Twister Manuel de programmation

Task Force Tips

Task Force Tips Ultimatic Manuel de programmation

Task Force Tips

Task Force Tips MASTER Guide rapide

Task Force Tips

Task Force Tips Ultimatic Manuel utilisateur

Task Force Tips

Task Force Tips BLITZFIRE Series Guide rapide

Task Force Tips

Task Force Tips VIT Manuel de programmation

Task Force Tips

Task Force Tips METRO 1 Series Guide rapide

Task Force Tips

Task Force Tips PRO/pak Guide rapide

Task Force Tips

Task Force Tips Chimney Snuffer Guide rapide

Task Force Tips

Task Force Tips G-Force Series Guide rapide

Task Force Tips

Task Force Tips Mid-Force Guide rapide

Task Force Tips

Task Force Tips Master Foam Series Guide rapide

Task Force Tips

Task Force Tips Masterstream Series Manuel de programmation

Task Force Tips

Task Force Tips TRANSFORMER Guide rapide

Task Force Tips

Task Force Tips LDH GATED WYE Manuel utilisateur

Task Force Tips

Task Force Tips Masterstream Series Manuel de programmation

Manuels Pistolet à peinture populaires d'autres marques

SNOWJOE

SNOWJOE Sunjoe 24V-GS-LTW-RM Manuel utilisateur

Graco

Graco 246737 Manuel d'utilisation et d'entretien

Binks

Binks SV100 Manuel utilisateur

Fimco

Fimco LG-4-3-1 Manuel utilisateur

AG SPRAY

AG SPRAY FS-ATV-25BL Manuel utilisateur

Nordson

Nordson MicroMax 2 Manuel utilisateur

Bonide

Bonide 051 Manuel d'utilisation

zogics

zogics Z-DAS Manuel utilisateur

KISANKRAFT

KISANKRAFT KK-KBS-165 Manuel utilisateur

Matrix

Matrix SG 650 Manuel utilisateur

Anest Iwata

Anest Iwata SGA-3 Guide de démarrage rapide

paasche

paasche VV Fiche technique

Carlisle

Carlisle DeVilbiss JGA-510 Manuel utilisateur

Gardena

Gardena 11120 Manuel utilisateur

Conrad

Conrad Hobby Airbrush K3 Manuel utilisateur

wiwa

wiwa 14025 R/F Manuel utilisateur

Graco

Graco EM 390 Manuel d'utilisation

DeVilbiss

DeVilbiss LUNA2i Manuel utilisateur
