Talkpool OY1110 Manuel utilisateur
OY1110
LoRaWAN Temperature and humidity sensor
User manual
Version 1.0
January 2019
OY1110 LoRaWAN Temperature and humidity sensor, User manual, Version 1.0
2
Table of Contents
1
Disclaimer .............................................................................................................................. 3
1.1 Technical support ...................................................................................................................... 3
1.2 EU Declaration of conformity .................................................................................................... 3
2
Warnings ............................................................................................................................... 4
3
Environmental ....................................................................................................................... 5
4
Product Description .............................................................................................................. 6
5
Installation and activation ..................................................................................................... 7
5.1 LoRaWAN Configuration ............................................................................................................ 8
5.2 Sensor states and state check .................................................................................................... 8
5.2.1 Re-join functionality .............................................................................................................. 9
6
Specification ........................................................................................................................ 10
7
Product life length ............................................................................................................... 12
8
Security ................................................................................................................................ 12
9
Protocol ............................................................................................................................... 12
9.1 LoRaWAN standard commands ............................................................................................... 12
9.2 Unsolicited uplink status commands ....................................................................................... 13
9.3 Periodic measurement reports ................................................................................................ 13
9.3.1 Periodic single measurement report .................................................................................... 13
9.3.2 Periodic grouped measurement report ............................................................................... 13
9.3.3 Measurement value ............................................................................................................. 14
9.3.4 Grouping header .................................................................................................................. 15
9.3.5 Example: Single measurement report ................................................................................. 15
9.3.6 Example: Grouped measurement report ............................................................................. 15
9.4 Downlink commands and queries ........................................................................................... 16
9.5 Commands ............................................................................................................................... 17
9.5.1 Measurement interval ......................................................................................................... 18
9.5.2 TX group size ........................................................................................................................ 18
9.5.3 Reset device ......................................................................................................................... 18
9.6 Uplink query response ............................................................................................................. 19
9.6.1 Uplink status report ............................................................................................................. 19
OY1110 LoRaWAN Temperature and humidity sensor, User manual, Version 1.0
3
1 Disclaimer
This document represents information on products at the time of publication and is subject to
change without prior notice due to product improvements or other reasons. Talkpool makes
no warranties based on the accuracy or completeness of the contents of this document and
reserves the right to make changes to specifications and product descriptions at any time
without notice. Talkpool reserves all rights to this document and the information contained
herein.
1.1 Technical support
1.2 EU Declaration of conformity
EC DECLARATION OF CONFORMITY
certify that the design and manufacturing of this product
WIRELESS TEMPERATURE SENSOR /
FUNK-TEMPERATURSENSOR /
TRÅDLÖS TEMPERATUR SENSOR /
TRÅDØS TEMPERATUR SENSOR /
DRAADLOZE TEMPERATUURSENSOR
OY1110 EU868
conforms to the following directives and standards
The Radio Equipment Directive (2014/53/EU),
EN 300 220-1 V2.4.1, EN 300220-2 V2.4.1,
EN 301 489-1 V1.9.2, EN 301 489-3 V1.6.1,
EN 60950-1:2006+A11+A1+A12+A2
RoHS Directive 2011/65/EU
This product was CE marked in year -18
2018-12-01 ___________________
Managing Director Stefan Lindgren
OY1110 LoRaWAN Temperature and humidity sensor, User manual, Version 1.0
4
2 Warnings
The following safety precautions must be observed during all phases of the operation, usage,
service or repair of this Talkpool product.
• Read the product manual.
• Do not modify the product.
• The product should not be exposed to extreme heat or open flame.
• The device must not be exposed to harsh chemical agents or solvents.
• The labelling of the product may not be changed, removed or made unrecognizable.
OY1110 LoRaWAN Temperature and humidity sensor, User manual, Version 1.0
5
3 Environmental
This symbol on the product or on its packaging indicates that this product must not be
disposed of with your other household waste. Instead, it is your responsibility to dispose of
your waste by taking it to a collection point designated for the recycling of electrical and
electronic appliances. Separate collection and recycling of your waste at the time of disposal
will contribute to conserving natural resources and guarantee recycling that respects the
environment and human health. For further information concerning your nearest recycling
center, please contact your nearest local authority/town hall offices, your household waste
collection company or the shop where you bought the product.
OY1110 LoRaWAN Temperature and humidity sensor, User manual, Version 1.0
6
4 Product Description
Figure 1: OY1110 Temperature and humidity sensor
The OY1110 LoRaWAN Temperature and humidity sensor is designed to measure
temperature and humidity in indoor environments. The sensor is intended for climate control,
energy optimization, and damage preventions in attics and basements. It is optimized for
reliable and secure measurements with more than 10 years life length.
The standard measurement and reporting interval is 15 minutes, other reporting intervals can
be configured over the air.
OY1110 LoRaWAN Temperature and humidity sensor, User manual, Version 1.0
7
5 Installation and activation
The sensor consists of a bottom piece, to be mounted on the wall, and a top piece with the
active parts.
Figure 2: Mounting information
The bottom piece is mounted on the wall with the “UP” arrow upwards. It can be mounted
either with screws or adhesive tape.
Figure 3: Push button and LED
The top piece contains all active components. The unit is shipped in sleep mode, i.e. with all
functions, including radio, deactivated. The sensor is activated by pressing the push button for
3 seconds until the red LED makes two short flashes, make sure to not hold longer than 5
seconds. When the device has successfully joined the LoRaWAN network there will be a long
(2s) flash.
Note “UP”
OY1110 LoRaWAN Temperature and humidity sensor, User manual, Version 1.0
8
5.1 LoRaWAN Configuration
Configuration on the network server is done with
AppEUI: 70-B3-D5-D7-2F-F8-16-00 (a.k.a. JoinEUI)
It is possible to order a batch of devices configured with a customer unique AppEUI from the
Talkpool OUI range.
The device is configured with device unique DevEUI and AppKey
The device is default configured for OTA provisioning. Contact the Talkpool team for ABP
configuration. The device follows the LoRaWAN standard related Join configuration
parameters, such as RX1 and RX2 windows, RX2 downlink frequency etc.
The default setting is ADR enabled.
5.2 Sensor states and state check
The sensor has four states: Initial, Joining, Configure and Operational state.
Figure 4: Device states
OY1110 LoRaWAN Temperature and humidity sensor, User manual, Version 1.0
9
To check the device state, press the button and hold it pressed until the red LED starts
flashing after 0.5s.
State
Description
LED response
Initial
Low power state during transport. Radio not active.
1 short flash (0.5 sec)
Joining
Trying to join a LoRaWAN network. The device
will remain in this state until successfully joined a
LoRaWAN network
2 short flash (0.5 sec)
Configure
Enables quick over-the-air configuration, by polling
server after configuration commands during 2
minutes. This is done by sending uplink status
command (0x20).
1 long flash (2 sec)
Operational
Joined to a LoRaWAN network, measures
temperature and humidity periodically, and sends
measurement reports toward a LoRAWAN network.
1 long flash (2 sec)
5.2.1 Re-join functionality
The device supervises its connectivity to the network, by monitoring that periodic downlink
messages are received.
The device tries to re-join the network if it has not heard anything from the network for 288
uplinks (3 days @ 15-minute message interval). The device requests and normally gets a
downlink ever 64th uplink due to the ADRAckReq functionality.
OY1110 LoRaWAN Temperature and humidity sensor, User manual, Version 1.0
10
6 Specification
Accuracy and range
Temperature accuracy ± 0,2 °C (conditions 0 °C to +50 °C)
Temperature range -20 °C to +60 °C
Humidity accuracy ± 2% (conditions 10-90% RH)
Humidity range 0% to 100% non-condensing
Accuracy of ± 0,1 °C and ± 1,5% humidity available upon request
Connectivity
Network LoRaWAN
Frequency bands 868 MHz
Provisioning Over the air & personalization
Security
Algorithms AES-128
Hardware Cryptographic co-processor
Features Secure boot
Secure firmware upgrade
Hardware based ultra-secure key storage
Battery life
Battery life length 10 years (at 5-minute intervals, SF7)
Primary cell Lithium-thionyl 3.6V
Capacity 3.6 Ah
Size & Weight
Size 65 x 75 x 28 mm
Weight 75g
Configuration
Measurement intervals 1 minute – 1 week*
Transmission intervals 1 minute – 12 weeks*
*Default 15 minutes, configurable over the air
