Takeway T-B03 Manuel utilisateur
Takeway® T-B03 Ballhead can be combining with Takeway® Clampod
or any tripod with 1/4" or 3/8" screw.
Parts name:
TEL: +886-4-2406 5031
www.takeway.tw/eng Before using the product for the first time, please
read through the user guide.
Please use this product correctly after fully
understanding the content of the user guide.
T-B03
Ballhead
T-B03
Ballhead
All information described in this manual is based
on the test standard of Takeway. Sorry for the
inconvenience caused if there are any printing
errors. The design and specifications of this
product are subject to change without notice.
Copyright: All Rights Reserved
Ballhead EN 2018/05
MANUAL
MANUAL
Quick
release
clip
Ballhead knob
Quick
release
knob
3/8"
Screw hole
3/8" » 1/4"
Screw adapter
T-BK02
T-RC01
T-RK01
T-SA23
1
2Combining with a tripod and make
sure it is firmly. Mount Quick release
clip with the camera on the Mounting
platform, and screw in Quick release
knob. Before shooting, please use
Ballhead knob to rotate the
camera freely in 360˚. Adjust the
camera to a proper position and you
can start shooting.
A
B
Release Quick release knob, and
remove Quick release clip.
Screw in Quick release clip on your
digital (SLR) camera with a coin
or a flathead screwdriver. Please
make sure that the quick release
clip is screwed in tightly so that the
camera does not loose from it.
A
B
C
360˚
T-B03
Ballhead
MANUAL
Size: 31 x 31 x 55mm
Weight: 78g
Materials: Aerospace-grade aluminium alloy, Nylon(T-BK02),
High-class stainless steel (T-SA23)
Quick release screw: 1/4"
Load capacity: 3kg
Screw hole : 3/8"
Screw adapter: 3/8" » 1/4"
D
Specifications:
C
D
