Systembuild Evolution 4419335COM Manuel utilisateur

4419335COM

TallCabinet

B344419335COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

ForthelatestinformationonSystemBuildproducts

followusatAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐866‐452‐4081(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.systembuild.com

AssemblyDifficultyMeter

Easy Tough

SecureYourFurniture

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

ContactUs!

HelpfulHints

2

systembuild.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐866‐452‐4081

Monday‐Friday

9am‐5pmCST

Visitsystembuild.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

systembuild.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You



Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.

PressCAMBOLTintohole.

PresspartstogethersoCAMBOLTinserts

intoedgehole.

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

PressCAMLOCKintohole.

Endhole

Arrowtopointtowardsend

holeinedgeofpart.

4

systembuild.com

BeforeYouStart

Quick

Tip

Assembly

Tube

You

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

systembuild.com

BoardIdentification

Notactualsize

Tube

You

LeftPanel

33915335010

RightPanel

33915335020

Bottom

33915335040

ABC

DEF

Door

34419335060

AdjustableShelf(x2)

33915335050

BackPanel

K391533500

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

Shelf(x2)

33915335030

6

systembuild.com

BoardIdentification

Notactualsize

Tube

You

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

7

systembuild.com

PartList

ActualSize

Tube

You

NotActualSize

(x8)

#A22710

cam bolt

(x8)

#A22700

cam lock

(x8)

#A21670

wood dowel

(x4)

#A23030

confirmat screw

(x8)

#A12420

5/8" screw

(x4)

#A12930

1-1/8" screw

(x36)

#A21110

nail

(x4)

#A44140

foot

(x2)

#A17400

7/8" bolt

(x1)

#A52680

handle

(x3)

#A65615

hinge

(x8)

#A80250

shelf support

(x1)

#A84050

safety bracket

(x2)

#A89370

door bumper

8

systembuild.com

STEP1

Tube

You

(x8)

9

systembuild.com

STEP2

Tube

You

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x8)

(x8) (x1)

Donotfullytightenscrew.

NOTE:

YouhavetwopartsC(shelf),on

oneofthemyouwillattachthe

safetybracket(5a).

10

systembuild.com

STEP3

Tube

You

finishededgesfaceup

UNLOCKLOCK
