Systembuild Evolution 2566335COM Manuel utilisateur

2566335COM

36" STORAGE CABINET

B342566335COM0

THIS INSTRUCTION BOOKLET CONTAINS

IMPORTANT

SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

For the latest information on SystemBuild products

Tube

You

Date of Purchase ___ / ___ / ___

Lot Number:

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-866-452-4081 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.systembuild.com

Assembly Difficulty Meter

Easy Tough

Secure Your Furniture

Keep your home and family safe

with the wall anchor kit that is

included with the product.

Serious or fatal crushing injuries can

occur from tipping furniture.

WARNING: Manufacturer assumes no liability

for improper installation or excessive loads

placed on screws or bracket. This wall anchor

is not a substitute for proper adult supervision.

Helpful Hints

systembuild.com

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-866-452-4081

Monday-Friday

9am - 5pm CST

Visit systembuild.com to view the

limited warranty valid in the U.S. and Canada.

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a

(right) and

(left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

Tube

You

Tube

You

PEOPLE NEEDED FOR ASSEMBLY: 1-2

systembuild.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Tube

You

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

systembuild.com

Quick

Assembly

Tip

Before You Start

systembuild.com

Board Identification

Not actual size

Tube

You

Left Panel

37360335013

Right Panel

37360335023

Bottom

37363335042

Shelf (x2)

37363335051

Adjustable Shelf (x3)

37363335060

Door (x2)

32566335070 Back Panel

K736333501

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

systembuild.com

Board Identification

Not actual size

Tube

You

This piece is paperboard construction.

It is not made from wood, but is

required for the assembly of your unit.

systembuild.com

Part List

Not Actual Size

Tube

You

(x8)

#A22620

cam lock

(x8)

#A22610

cam bolt

(x4)

#A23030

confirmat

(x4)

#A17400

machine screw

(x5)

#A12930

1-1/8" screw

(x10)

#A12420

#8 x 5/8" screw

(x42)

#A21110

nail

(x12)

#A80250

shelf support

(x2)

#A89370

door bumper

(x2)

#A52680

pull

(x5)

#A44140

adjustable foot

12a

12b

12c

(x1)

#A84050

safety bracket kit

(x6)

#A65615

hinge

Actual Size

12d

systembuild.com

STEP1

Tube

You

(x8)

systembuild.com

STEP2

Tube

You

12a

(x1)

(x8)

12a

12c

Proper orientation of CAM LOCK

Tip

Assembly

Quick

12c

Do not tighten this screw.

systembuild.com

STEP3

Unscrew the two piece foot as shown. After top part of

foot is attached to bottom shelf, screw on bottom part of

foot. Be sure all four feet are level with each other.

(x5)

(x10)

Tube

You

(x5)
