System air E 28 Manuel

Callender and temperature settings

LEDs and buttons – navigating the menus – (change parameters).................. 2

Operator's level - tree structure ..................................................................................... 3

Running mode – Auto/On/O........................................................................................ 3

Alarm – cancel, acknowledge......................................................................................... 4

Setting of temperature...................................................................................................... 5

Modication of outdoor compensated supply temperature.............................. 5

Setting of ows - Flow control........................................................................................ 6

Setting of ows - Pressure control .................................................................................7

Schedule settings................................................................................................................ 8

Calender settings (time, date, weekday)..................................................................... 8

Setting of holidays.............................................................................................................. 9

Setting of extended running........................................................................................... 9

Setting of min/max supply air temperature ...........................................................10

Restore Systemair factory settings or latest user parameters

and settings.........................................................................................................................11

Annex 1A7 for the User manual

Software versions 3.2 , 3.3, 3.4 and 3.6

Operator's Guide for Systemair E 28 Controller

in large air handling units type:

Geniox, DV, TIME, DV Compact

LEDs and buttons – navigating the menus – (change parameters)

UP:

Move to a higher menu line

(Increase value of the parameter)

The menus are organised in a horizontal tree structure – upper left corner is start

DOWN:

Move to a lower menu line

(Decrease value of the parameter)

RIGHT:

Move right to a lower menu level

(Move the curser to the right in the para-

meter)

LEFT:

Move left to a higher menu level.

(Move

the curser to the left in the parameter)

OK/ENTER: Open/activate a selected

menu/setting

(Conrm a parameter value)

ALARM: Press for alarm list

CLEAR: Abort a parameter setting and

restore the original value, if ”OK/EN-

TER”not yet has been pressed.

ALARM LED: Red light is ashing for

unacknowledged alarm. Permanent red

light for acknowledged alarm, but the

alarm is still active, because the reason is

not yet eliminated.

"WRITE ENABLE" LED: Yellow light – slow

ashing indicates that a parameter can be

selected for changes, when the OK/EN-

TER button is pressed.Yellow light – fast

ashing indicates that the parameter is

activated for changes. Permanent yellow

light indicates that the changes are going

on.

Hand terminal – Systemair Control Panel LED's and buttons

Start display

Unit

Date - running mode

Running mode Running mode

On / O / Auto

Temperature Code - Setpoint Selected functions

and actual values

Air control Code - Supply air m3/h or Pa

Possibly CO2-

control Code - Extract air m3/h or Pa

Time settings Set time and date

Scedules

Start / Stop

Extended running

Access rights Change level

Code - 1111

Operator's level - tree structure

Running mode – Auto/On/O

The display

shows

x 1

To select Auto, Manual Normal, Manual

Reduced or O

The display is lit up

Running mode

Actual running mode

Conrm selected value with OK. The

system will automatically return to the

start menu after some minutes.

To return to the start menu at once

– press and several times



x 2



Running mode

Auto

Manuel reduced run

Manuel normal run

O

Unit

Date, time

Syst: Running mode (Auto, Ma-

nual reduced, Man. norm., O)

Start menus

Follow the steps

below

Alarm – cancel, acknowledge

The display

shows

x 2

Conrm with OK. Class A alarm is always

triggered by the system, when the reason

for alarm is hazardous, and it is only pos-

sible to restart the unit, when the reason

for the alarm has been solved. The Class A

alarm can be triggered by the temperature

sensor inside the water heating coil if the

temperature falls below the set point value,

or the class A alarm can be triggered by the

re thermostats when the temperature rises

above the set point values, indicating risk of

re.

Press the alarm button twice to see

the alarms logged in the alarm list

Select – Cancel.

Never select Block, Block is only for test

purposes during maintenance work.





To return to the start menu at once

– press and several times

Conrm selected value with OK. The system

will automatically return to the start menu

after some minutes.

When the reason for the alarm has been

solved, pressing the OK button will activate

the menu - Conrm - and the unit starts.

The alarm indication disappears from the

display.

Example:

Low frost guard temp

Date, time, Class:A

Cancel

Example:

Low frost guard temp

Acknowledge

Block

Cancel

Example:

Low frost guard temp

Date, time, Class:A



Follow the steps

below

The display

shows

The display is lit up

Temperature

The system is congured to control a

certain temperature. The actual value and

set point for this temperature is shown.

Access code 1111 may be necessary.

Set point temperatures for outdoor tempe-

rature compensation are shown. The control

curve is dened with 8 node points. Only 2 or

3 node points are shown in the display, and

the remaining node points are displayed by

scrolling and .

Temperatur

To return to the start menu at once

– press and several times.

Select and conrm new set point tempera-

ture.

The system will automatically return to the

start menu after some minutes.



x 1

x 2

x 1

x 2

Setting of temperature

Value to be changed ashes.

Select one new set point temperature

for each outdoor temperature shown on

the curve and conrm selected value with

OK.The system will automatically return to

the start menu after some minutes.

Act: xx.x ˚C Setp

Setp: yy.y ˚C

Outdoor comp Setp.

xx ˚C = zz.z ˚C

yy ˚C = vv.v ˚C

Outdoor comp. Setp

xx ˚C = zz.z. ˚C

yy ˚C = vv.v ˚C

Unit

Date, time

Syst: Running mode (Auto, Ma-

nual reduced, Man. norm., O)

 



To return to the start menu at once

– press and several times.

Modication of outdoor compensated supply temperature



Follow the steps

below

The display

shows

x 1

x 2

x 1

x 3

10.

11.

12.

Value to be changed ashes.

Change of set point for normal ow (1/1)

and for reduced ow (1/2). Access code

1111 may be necessary.

The display is lit up

Air control

Selection of supply air fan (SAF)

or exhaust air fan (EAF).

Supply air fan selected as example.

Conrm change of the set point value

with OK. Value to change is ashing.

Conrm selected value with OK

Conrm change of the set point value

with OK. Value to change is ashing.

Outdoor compensation of the airow is

able to reduce the air ow when the out-

door temperature is low. Two node points

- outdoor temperature/airow denes the

reduction of airow by declining outdoor

temperature. The temperature compensa-

tion between the 2 node points is linear.

Select and conrm new value for normal air

ow (1/1) and for reduced air ow (1/2)

To return to the start menu at once

– press and several times.



Setting of ows - Flow control

SAF (SAF = Supply air fan)

EAF (EAF = Extract air fan)

Flow control SAF

Setp. 1/1: xx.xxx m³/h

Setp. 1/2: yy.yyy m³ /h

Setp. 1/1: x.xxx m³/h

Setp. 1/2: y.yyy m³/h

Setp. 1/1: xx.xxx

Setp. 1/2: yy.yyy

Outdoor comp. setp

aa ˚C = bb.bbb m3/h

cc ˚C = dd.ddd m3/h

Unit

Date, time

Syst: Running mode (Auto, Ma-

nual reduced, Man. norm., O)

Follow the steps

below

Flow control (control of the ow

through the fans)

The display

shows

x 1

x 2

x 1

x 3

10.

11.

12.

Value to be changed ashes.

Change of set point for normal ow (1/1)

and for reduced ow (1/2). Access code

1111 may be necessary.

The display is lit up

Air control

Selection of supply air fan (SAF)

or exhaust air fan (EAF).

Supply air fan selected as example.

Conrm change of the set point value

with OK. Value to change is ashing.

Conrm selected value with OK

Conrm change of the set point value

with OK. Value to change is ashing.

Outdoor compensation of the airow

is able to reduce the air ow when the

outdoor temperature is low. Two node

points - outdoor temperature/pressure

in ducts denes the reduction of airow

by declining outdoor temperature. The

temperature compensation between the 2

node points is linear.

Select and conrm new value for normal air

ow (1/1) and for reduced air ow (1/2)

To return to the start menu at once

– press and several times.



Setting of ows - Pressure control

Pressure control

SAF (SAF = supply air fan)

EAF (EAF = extract air fan)

Pressure control SAF

Setp. 1/1: xxx Pa

Setp. 1/2: yyy Pa

Setp. 1/1: xxx Pa

Setp. 1/2: yyy Pa

Setp. 1/1: xxx

Setp. 1/2: yyy

Outdoor comp. setp

aa ˚C = bbb Pa

cc ˚C = ddd Pa

Unit

Date, time

Syst: Running mode (Auto, Ma-

nual reduced, Man. norm., O)

Follow the steps

below

Pressure control

The display

shows

x 4

x 1

x 4

x 1

The display is lit up

Time settings

Select Timer Normal speed (example). (Do not

select Time/Date, because this is the Calendar

setting – time, date, weekday of the internal

clock in the controller)

Conrm selected value with OK.

Value to be changed ashes.

Return to menu to select: Timer Normal

Speed or Timer Reduced Speed and so on.

Conrm selected value with OK. The system

will automatically return to the start menu

after some minutes.

Select Time/Date (this menu permits the

setting of time and date in the internal

clock)

Time: aa:aa is activated for changes.

Value to be changed ashes

Conrm with OK when all values are OK. The

system will automatically return to the start

menu after some minutes..

To select the correct value.

Conrm with OK.

Schedule settings

Normal Speed

Monday

Per 1: 09:00 - 16:00 (Periode 1)

Per 2: 16:00 - 21:00 (Periode 2)

Monday

Per 1: 07:00 - 1700 (Periode 1)

Per 2: 17:00 - 07:00 (Periode 2)

Time: aa:aa

Date: bbbb-bb-bb

Weekday: Xxxxxxxxx

Unit

Date, time

Syst: Running mode (Auto, Ma-

nual reduced, Man. norm., O)

Unit

Date, time

Syst: Running mode (Auto, Ma-

nual reduced, Man. norm., O)

Time/Date

Timer Normal Speed

Timer Reduced Speed

Extended running

Holidays

Time/Date

Timer Normal Speed

Timer Reduced Speed

Extended running

Holidays

Calender settings (time, date, weekday)

 

To return to the start menu at once

– press and several times.

Follow the steps

below

The display

shows

The display is lit up

Time settings

Select Holidays (Do not select Time/Date,

because this is for setting the internal

clock)

Select Extended running (Do not select

Time/Date, because this is for setting the

internal clock)

Conrm selected value (example).

Value to be changed ashes.

Extended running is activated for changes.

Value to be changed ashes

To select the correct value

Conrm with OK.

Conrm with OK when all values are OK.

The system will automatically return to the

start menu after some minutes

Conrm with OK when all values are OK. The

system will automatically return to the start

menu after some minutes.

x 4

x 1

x 4

x 1

Setting of holidays

x 4

x 3

Holidays (MM:DD)

1: 01:01 - 01:03

2: 02:14 - 01:21

and so on - up to 24 holiday periods

Holidays (MM:TT)

1: 01:01 - 01:03

2: 02:14 - 02:21

and so on - up to 24 holiday periods

Unit

Date, time

Syst: Running mode (Auto, Ma-

nual reduced, Man. norm., O)

Unit

Date, time

Syst: Running mode (Auto, Ma-

nual reduced, Man. norm., O)

Time/Date

Timer Normal Speed

Timer Reduced Speed

Extended running

Holidays

Time/Date

Timer Normal Speed

Timer Reduced Speed

Extended running

Holidays

Extended running

xx min

Time in ext. Running: yy (minutes

already spent of the total exten-

ded running time)

Setting of extended running

 

To return to the start menu at once

– press and several times.

To return to the start menu at once

– press and several times.

x 1

Follow the steps

below

The system is now logged on at the Admin

level and unskilled persons could change

important parameters and settings to values

that will cause malfunction of the system.

Go to the start menu to return the system

immediatlely to the lowest access level –

Operator.

Digit to be changed ashes. Factory logged

password, exclusively for service partners.

The display

shows

10.

The display is lit up

Access rights

Select - Log on

Return to start menu

Temperature

If the system is congured for cascaded

room temperature control, this menu

with max/min supply air temperature is

displayed.

Value to be changed ashes. Conrm se-

lected value with OK

Access rights

Select - Log o and select the answer – Yes

System returns to the start menu and is now

logged on at the Operator-level.

Select and conrm new set point temperature.

11.

12.

x 5

x 1

x 6

x 2

x 6

Setting of min/max supply air temperature

x 2

13.

Unit

Date, time

Syst: Running mode (Auto, Ma-

nual reduced, Man. norm., O)

Log on

Log o

Change password

Log o?

Actual level: Admin

Log on

Enter password ****

Actual level:

Operator

Actual level:

Admin

With Caskaded control

max/min supply air setp

Max: xx ˚C

Min: yy ˚C

Running mode

Temperature

Air control

Time settings

Manuel/Auto

Settings

Conguration

Access Rights

Access to this menu requires log on at the high-authority level – ”Admin”.



Follow the steps

below

Table des matières

Autres manuels System air Contrôleurs

System air

System air PULSER Manuel utilisateur

System air

System air MTY Manuel utilisateur

System air

System air RE 1 Manuel utilisateur

System air

System air Topvex VAV Manuel utilisateur

System air

System air TControl EASY 3S Manuel

System air

System air fantech IPF05-1L Manuel utilisateur

System air

System air 145946 Manuel utilisateur

System air

System air RVAZ4-24A Manuel utilisateur

System air

System air REPT6 Manuel utilisateur

System air

System air SYSVRF AHU 5HP S Mode d'emploi

System air

System air MZ3-Touch Manuel utilisateur

System air

System air SAVE VTC 500 Manuel utilisateur

System air

System air REP 6 Manuel utilisateur

System air

System air CWR-86E Mode d'emploi

System air

System air ARGUS-RC-H Manuel utilisateur

System air

System air SYS WSC 86 Mode d'emploi

System air

System air PULSER-M Manuel utilisateur

System air

System air S-RVAZ4-24A Manuel utilisateur

System air

System air CORRIGO Manuel utilisateur

System air

System air NOTUS-R Manuel utilisateur

System air

System air WC 120G Instructions d'installation

System air

System air TControl POD glass EC Manuel

System air

System air RETP6 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
