Syscom Video SSFL Manuel utilisateur
EQUIPOS PROFESIONALES DE COMUNICACIÓN S.A. DE C.V
Calle Méndez y 20 # 2001, Colonia Pacico,
Tel. (614) 4120126
C.P. 31030, Chihuahua, Chih, México
R.F.C.: EPC051025IN0
Read this user manual before using the equipment and
keep it for future reference
User Manual
SSFL-SSFM
Support for Solar Module
B
SOLAR MODULE
(NOT INCLUDED)
ARM
SCREW 3/8
FLAT WASHER 3/8
PRESSURE WASHER 3/8
HEX SCREW 3/8
SCREW 1/4
PRESSURE
WASHER 1/4
FLAT
WASHER 1/4
NUT
1/4
BASE
INCLINATION
ADJUSTMENT WITH
PERFORATIONS
SUPPORT
DETAIL B
Introducon
Thank you for selecng the SYSCOM SSFL-SSFM Support.
Theinformaon contained in this manual will help you in
the installaonof the product as well as finding all the
physical characteriscs, included parts and recommendaons
for use.
Included Parts
- 4 Hexagonal Screws 1/4"
-4 Hex Nut 1/4"
- 4 Pressure Washers 1/4"
- 4 Flat Washers 1/4"
- 6 Hex Screws 3/8"
- 6 Hex Nuts 3/8"
- 6 Flat Washer 3/8"
- 6 Pressure Washer 3/8"
- 2 ARMS
- 2 SUPPORTS
- 4 BASES
Physical Characteriscs
· Exterior Dimensions:
SSFL- 1350 mm supports of length.
SSFM- 950 mm supports of length.
· Weight:
SSFL - 5,7 Kg.
SSFM- 5,4 Kg.
· Color:
According to availability.
