ES3000 Ethernet Switch - Quick Install Guide
2
To the Installer
This guide is intended for the technician responsible for installing the Symbol ES3000 Ethernet
Switch. It is also assumed that the technician is familiar with Ethernet LAN-based networking
concepts. The Symbol ES3000 Ethernet Switch is available in the following models:
•ES3000-PWR (supporting PoE)- Part Number ES-3000-PWR-10-WW
•ES3000 (non PoE)- Part Number ES-3000-10-WW
The purpose of this document is to provide specifications, features and guidelines for the installer to
use during installation. This document does not give site-specific installation instructions. Refer to
www.symbol.com for accessing the ES3000 User Guide (for general device configuration information)
and the ES3000 Advanced Concept Guide (for advanced configuration information unique to the ES3000).
Document Conventions
Before working on any equipment, be aware of the hazards associated with its installation and use.
Also, become familiar with standard practices for preventing accidents.
Indicates tips, hints and special requirements.
Care is required. Disregarding cautions can cause data loss or equipment damage.
Indicates a potentially dangerous condition or procedure that only Symbol-trained
personnel should attempt to correct or perform.
3
Power Cord Set
Only use a power cord approvedfor its intended countryof operation:
U.S.A. and Canada The cord set must be UL-approved and CSA certified.
The minimum specification for the flexible cord is:
No. 18AWG
Type SV or SJ
3-conductor
The cord set must have a rated current capacity of at least 15A.
The attachment plug must be an earth-grounding type with a NEMA
5-15P (15A, 125V) or NEMA 6-15P (15A, 250V) configuration.
Denmark The supply plug must comply with section 107-2-D1, standard
DK2-1a or DK2-5a.
Switzerland The supply plug must comply with SEV/ASE 1011.
Others The power cord shall meet local regulation requirement, if any.
The appliance coupler (the connector to the unit and not the wall plug) must have a configuration for
mating with an EN60320/IEC320 appliance inlet.
ES3000 Ethernet Switch - Quick Install Guide
4
Warnings
• Only trained and qualified personnel are allowed to install this equipment.
• Remove any jewelry (rings, watches, necklaces, etc.) while installing this equipment.
• Install this equipment in racks with appropriate dimensions and weight allowances. Verify
racks are anchored and do not install in a way that can cause the equipment to tip and break.
Damage to the device or bodily injury can occur from equipment not appropriately mounted
and secured.
• Verify the unit and any device connected to it is properly wired and grounded.
• Attach only approved power cords to the device. Verify connecting power circuits have
appropriate overload protection.
• Verify the power connector is accessible at all times during the operation of the equipment.
• Do not work with equipment power circuits in dimly lit spaces.
• Do not install this equipment or work with its power circuits during thunderstorms or
weather conditions where power surges can exist.
• Verify adequate ventilation around the device, and that ambient temperatures meet
equipment operation specifications.
• For plugable equipment, the socket-outlet shall be installed near the equipment and shall be
easily accessible.
5
Introduction
The Symbol ES3000 Ethernet Switch provides centralized management of network components
across the wired network infrastructure. The Ethernet Switch connects directly to distributed LAN
resources (network switch or managed hubs). The rack-mountable design allows easy installation
with other network components.
The Ethernet Switch provides several features to assist in an efficient system installation:
• LED Indicators-indicate status for power and the condition of the Ethernet ports.
• Front-Mounted Ethernet Ports-allows easy access to Ethernet cabling.
• Serial Console Port - allows installers and administrators to connect directly to the device’s
command line interface (CLI).
Specifications
Width 482.6 mm with mounting brackets
440 mm without mounting brackets
Height 44 mm (1RU)
Depth 256 mm
Weight PoE version 8.95 lbs. (with rack brackets)
PoE version 8.80 lbs. (without rack brackets)
Non PoE version 7.90 lbs. (with rack brackets)
Non PoE version 7.75 lbs. (without rack brackets)
Max Power Consumption 100VAC - 240VAC, 50Hz/60Hz, 3.5A (PoE)
100VAC - 240VAC, 50Hz/60Hz, 1.5A (non PoE)
Operating Temperature 0º to 40ºC
Operating Humidity 10% to 85% (without condensation)
MTBFES-3000-PWR-10-WW 140,000 hours @ 25C
ES-3000-10-WW 355,000 hours@25 C
FIBER-3000-1S-WW 1,250,000hours@ 25 C
ES3000 Ethernet Switch - Quick Install Guide
6
Installation
Preparing for Site Installation
Site preparation for the ES3000 Ethernet Switch installation begins with a site survey and network
analysis. Review the site survey reports to determine specific equipment placement, site-specific port
capacity and power drops. Ensure the installation area is free of dust and dirt.
Review the following guidelines for site preparation:
• Assign installation responsibility to appropriate personnel.
• Identify where all installed components are located.
• Verify appropriate rack mounting requirements.
• Arrange for a sufficient number of power drops to support the equipment installation.
• Verify adequate ventilation to all installed equipment.
• Identify and prepare Ethernet and TCP/IP and serial port connections.
• Verify cable lengths are within maximum allowable distances for optimal signal
transmission.
Package Contents
Inspect the package contents and report any missing or damaged items to the Symbol sales
representative. The package (for both the PoE and non-PoE Ethernet Switch models) should contain
the following:
• ES3000 Ethernet Switch
• Quick Installation Guide
• Rack-mounting brackets
•Power cord (optional)
• Null-modem serial cable.
ES3000 Ethernet Switch - Quick Install Guide
8
Parity: None
Stop bits: 1
Flow control: None
3. Hit the return key <Enter> to display the ES3000 logon screen.
4. Enter a user name of admin and password of symbol. Press Enter.
5. Select System Admin from the main menu. Press Enter.
6. Select Access from the System Admin menu. Press Enter.
7. Select IP Config from the Access menu. Press Enter.
The System IP Configuration Menu displays.
To use the ES3000 Web Management interface to configure the device:
A network connection is required between the device and the host to use the Web
Management interface to configure the device.
1. Access the Web interface (using a Web browser) by entering the switch IP address into the
address bar. Press Enter.
9
Internet Explorer 5.0 or later or Netscape Navigator 6.0 or later is required.
2. Enter a user name of admin and password of symbol. Press OK.
The Web interface General Information page displays.
ES3000 Ethernet Switch - Quick Install Guide
10
Once the ES3000 user interface has been accessed using either the menu, CLI or Web
interfaces, refer to the ES3000 User Manual for advanced device configuration
information. Go to http://www.symbol.com/services/downloads to access the guide.
Installing a SFP Fiber Transceiver
The ES3000 Ethernet Switch supports a SFP (small form factor pluggable) fiber channel transceiver
used in fiber channel cable installations.
To install the SFP Fiber Transceiver:
1. Remove the rubber plug protecting the optics on the transceiver.
2. Insert the transceiver into the fiber transceiver cage available on ports 25 or 26 on the
ES3000 Ethernet Switch.
3. Ensure one of the following two cable types is used when connecting fiber cable to the
ES3000 Ethernet Switch:
• LC 62.5um/125um multimode fiber optic cable
• LC 50um/125um multimode fiber optic cable
4. Consult the system administrator for cable length and installation specifications unique to
the installation environement.
If removing the SFP transceiver, disengage locking mechanism on SFP transceiver
carefully before removing the transceiver from the ES3000 Ethernet Switch.
