User Manual – SMPK8858

IntroductionⅠ

Product features:

zDisplay: 2.8-inch touch TFT screens.

zOperation interface: Friendly operation interface, easy for operation.

zMemory: Built–in flash memory

zCard slot: Micro-SD card slot to expand memoryby2GBmax.

zSpeaker:A high quality speaker.

zInterface: USB2.0.

zLanguage: Multi-languages.

zAudio: MP3, WMA format files, etc.

zVideo: AVI format files.

zPhoto: JPEG format files.

Appearance and KeysⅡ

OperationsⅢ

1. Playing Music

Choose “Music” option on the main menu, and double click the corresponding icon to enter it.

Keys:

Click “ / ”previous song / next song

Click to play the music file and click “ ” key to return to the main menu while playing music

Functional Description：

⑴Adjust Volume

Click on speaker volume key “ / ”on the bottom of screen to adjust the volume.

⑵Play List

Click “ ” to enter the “Play List” and you can choose the song here. When playing music click “ ” to

directly return to main menu.

(4) Repeat mode

Click “ ” to choose once, repeat one, folder repeat, all once, all repeat, intro under repeat mode file.

(5) EQ Setup

Click “ ” to choose 8 EQ modes: NOR/3D/ROCK/POP/CLASS/BASS/JAZZ/USER EQ.

(6) A-B Repeat and Pause

Click “A-B” to mark the starting point of the “A-B Repeat” Mode, click “A-B” again to mark the end point.

Click “A-B” again to quit the “A-B Repeat” Mode. You can’t enter “A-B Repeat” mode when the music is in

pause.

When the player is under “A-” or “A-B” state, click “ /”to play the previous or next song, and then

“A-B Repeat” function will be ineffective.

Click “Play” on the screen to pause the music.

(7) Lyric Display

Naming lyric files as same as the music file and the player will directly display the lyric.

3. Playing Video

Click “Video” on the main menu.

Keys:

z“/ ”previous song / next video

zClick on the selected video file and play. And click “ ” to return to the main menu.

Functional Description：

(1) Forward/ Backward

While playing the video, click “ / ” to go forward or backward.

(2) Adjust Volume

Click the speaker volume key “ / ”on bottom of the screen to adjust the volume.

Notice: While playing the video, the menu bar will be hidden and it will be showed after pointing the screen

by pen.

4. Photo Browser

Choose “Photo” option on the main menu. Select and play image from the “picture list”.

Double click “M” key to return to the main menu

Click to play slideshow

Click to return to the picture list

Click to return to main menu.

Click to hide the menu bar

Click and to go forward and backward

Click to set the time interval of slideshow

5. Recording

Double click the “Recording” logo on the main menu.

Operations:

Recording:

“”: Start Recording

“”: Pause

“”: Save the file

“”: Return

Playing the file:

(1) Enter the music mode

(2) Press“ /” and select the file

(3) Press“ / ” to adjust the volume

6. Explorer

Double click the “Recording” logo on the main menu.

Note: An additional folder “SD card” will be shown after inserting the TF card.

File Manager

zPlay the file: Double click the file on the list

zDelete file: Select the file and Click “ ”. An alert message will be pop out for final

confirmation.

7. Setting

Double click “Setting” logo on the main menu.

1. Music

zRepeat Mode

a. Once Stop after playing all the songs in all directories

b. Repeat 1 The currently played song will be played repeatedly until this function is disabled.

c. Folder once All music in the selected folder would be played once until this function is disable.

d. All once The current folder will be played randomly

e. All repeat All music will be played from the beginning to the last one repeatedly

f. Intro All music will be played for 10 seconds from the beginning

zEQ Setup and User EQ

After entering the music option, click on “ ” and press “EQ Select” to choose the EQ mode

“Normal/3D/Rock/Pop/Classic/bass/Jazz/User EQ”. Or you can edit your favorite EQ mode in the “User EQ set”

option.

zPlay mode

You can choose “Order” or “Shuffle” in the “play mode” folder

Order: Choose “Order” mode to play songs in sequence

Shuffle: Choose “Shuffle” to play songs randomly

2. Record

Double click “Record” option and select “REC Quality” or “REC Volume”

zREC Quality: high quality, normal quality

zREC Volume: five options of volume level “+1, +2, +3, +4 and +5”

*The recorded voice file will be saved in “Music”

*If the player “Full Space”, it indicates that there is no space to save new file

3. Display Setup

①Backlight time: six options of 5 sec., 10 sec., 15 sec., 20 sec., 30 sec., and always on.

②Lum: five options of +1, +2, +3, +4 and +5, the higher level, the brighter.

③Backlight mode: Normal and Power save modes.

4. Auto play set

There are text and jpeg under this file: 1s, 2s, 3s, 4s, 5s.

5. System Setup

Four sub-options: Language, about, Upgrade and Default set.

①Languages: Simplified Chinese, Traditional Chinese, English, Korean, Japanese, and French

②About: Player information

③Touch Screen Calibration

Click the three "+" shown on screen consecutively to complete the touch screen calibration. You can press the

"power" to quit the calibration at anytime. It is recommended to set the touch screen calibration everytime when

you operate your player.

6. Power Off Time

There are six options of Power: Off, 10 min., 15 min., 30 min., 60 min. and 120 min.

7. Defaulted set

Click “yes” to format the player or click “no” to return to the main menu

*The recorded voice file will be saved in “Music”

*If the player “Full Space”, it indicates that there is no space to save new file

Firmware UpdateⅦ

The player can be upgraded or reset by the software program stored inside the installation CD.

1. Insert the installation CD. Open the file \Firmware Upgrade tool\ConsumerUpdate 3.1.2.0\setup.exe

2. Install and run the program.

3. Click “Open” and select the firmware file (.rfw)

4. Click Update to start the firmware upgrade process

Note: Firmware upgrade is to improve and optimize the performance of the player, but the normal operation

would not be affected without the firmware upgrade. However, an inappropriate upgrade may damage the

player.

ⅧAppendixes

1. Video File Format Conversion

The file format WMV, RM, AVI, VOB or DAT could be converted toAVI format by a software program

1. Insert the installation CD. Open the file \Firmware Upgrade tool\ConsumerUpdate 3.1.2.0\setup.exe

2. Install and run the program.

3. Click the "Add" button and a dialog will be pop out.

Resolution: 320 x 240 (set as default)

Source File: Select the source file

Target File Path: Select the folder for saving the converted file

Target File Name: Edit the file name

Setting – Quality: High / Medium / Low

Setting –Aspect Ratio: Full / 4:3 / 16:9

Scope: Enter the Starting time and duration

Click “Convert Now” to start the file conversion

2．FAQ

(1) Unable to turn on the player

·Check the battery level (by connecting to the power)

(2) The keys don’t work.

·Check the key lock status

(3) Messy code on the screen

·Check the language setting

3．Technical Specifications

Screen dot matrix（320*240）262K color

Dimension 96.9mm( length)×55mm（width）×12.6mm（height）

Connection Speed USB2.0 （HIGH SPEED）

Build-in Memory highspeed flash memory: 8GB

Power supply polymer lithium battery 700mAh

Sampling Frequency 8KHz/16KHz

Record Format WMA（32kbps，64 kbps）

Record Record Time 68 hours（1GB）

Earphone’s Max

Output （L）5mW＋（R）5mW（32Ohm）

MP3 Bit Rate 64K bps –320K bps

WMA Bit Rate 64K bps –384K bps

FR 20Hz~20KHz

SNR 83dB

Degree of Distortion 0.4%

Preservation No. 20

Earphone’s Max

Output （L）5mW＋（R）5mW（32Ohm）

MP3、WMA、

SNR 45dB

Music Format MP1、MP2、MP3、WMA、WAV、FLAC、APE

Service Temperature -5 ~40℃

System Requirement Windows98/SE/ME/2K/XP/Vista
