SWIT S-1051C Manuel utilisateur

Model:

S-1051C

5" Portable On-camera HDMI LCD Monitor

User Manual

Please read this User Manual

throughout before using

Preface

Congratulations on your purchase of this product Please read this user manual carefully

．

All internal technologies of this product are protected, including device, software and trademark

Reproduction in whole or in part without written permission is prohibited

．

All brands and trademarks of SWIT Electronics Co , Ltd are protected and other relative trademarks in this

user manual are the property of their respective owners

．

Due to constant effort of product development, SWIT reserves the right to make changes and

improvements to the product described in this manual without prior notice

．

This product is covered by 2 years conditional warranty, and misuse, abnormal handling, alterations or

modifications in design or construction will void this warranty It is considered normal that the LCD bright

dot defects are not to exceed three

．

For any suggestions and requirements on this product, please contact us through phone, fax, Email, etc

SWIT Electronics Co., Ltd.

Address: 10 Hengtong Road, Nanjing Economic and Technological Development Zone,

Nanjing 210038, P R China

Phone: +86-25-85805753

Fax: +86-25-85805296

Email: contact@swit cc

Website: http://www swit cc

Maintenance

 Monitor

1 Please keep the signal terminals and the cooling vent away from knife-edge, metal or liquid in order to avoid

short-circuit and damage

2 Please don't try to disassemble any parts of the monitor by yourself, which would probably damage the

monitor and do harm to human body, and it will cause the invalidation of product warranty

3 Please don't touch the screen with your fingers, which would probably deface the screen

4 Please don't press the screen; the LCD is extremely exquisite and flimsy

 The ower

Please use the provided power adapter or the battery recommended by the manufacturer in order to avoid

damage

If you use third party power adapter, please be sure that the DC voltage is between 6 5V-17V and the plug

should be: The monitor will not work if the polarities are reversed

Please never use the light connector (2- in, female) in right front of camera handle to ower the

monitor; otherwise it will damage the circuit of the monitor.

Please disconnect the power cable or take off the battery under the following situations:

1 If you do not operate this monitor for a period of time;

2 If the power cable or power adaptor is damaged;

3 If you operate this monitor by the methods different from this User Manual, and cause unknown problems;

4 If the monitor housing is broken

 Working Environment

1 Please don't lay this product on the unstable place

2 Please don't lay this product in hot, cold or wet location

 Cleaning

1 Please clean the screen with dry and downy cloth or special LCD cleanser

2 Please do not press hard when cleaning the screen

3 Please do not use water or other chemical cleanser to clean the screen The chemical may damage the

LCD

4 For first time use, please tear off the factory LCD film To protect the LCD screen, please post the LCD

protection film offered in the package

1. Features

◆

◆◆

◆

High resolution LCD Panel

1 2 Mega pixels 5” LCD, 800×480, wide viewing angle, 16:9/4:3 adjustable

◆

◆◆

◆

HDMI in ut

Accept multi-format HDMI input, compact and light weight

◆

◆◆

◆

Peaking focus assist

The Peaking focus assist function is to mark the sharpest edges of the image with purple color, for

cameramen to check if the subjects are focused

◆

◆◆

◆

False color

The false color is used to aid in the setting of camera exposure Under false color mode, the over exposed

subjects (above 101 IRE) on the monitor will display as RED, and the underexposed subjects will display as

BLUE For correct exposed subjects, it will display as green and pink

◆

◆◆

◆

DSLR scale zoom in

The Canon DSLR outputs the CMOS sensor ratio HDMI and this zoom in mode can make the effective

image scale full screen on the monitor

◆

◆◆

◆

User definable function keys

There are 2 function keys on the monitor front panel, which permit users to define shortcuts for the various

functions

◆

◆◆

◆

User editable video title

User can edit a video title for the current camera, and the title will display on the top of screen

◆

◆◆

◆

Quick interchangeable DV battery mount

The monitor supports various types of DV battery mounts, and the DV mounts can be easily taken off and

changed to another type

2. Panel Instruction

2.1 Front view

①

: Power on/off

Connect with power cable or mount battery, press the “ ” and the power indicator is turned on and

after 10 seconds, the monitor will be switched on and get into normal working status Press the “ ”

again, the indicator is turned off and monitor is switched off

Remark: Disconnect with power cable or take off the battery if the monitor will not be used for a period of

time

②

F1: User definable function key 1

③

F2: User definable function key 2

④

FOCUS: Peaking focus assist switch on/off

Press “FOCUS” once, it will display the current peaking on/off status Press “FOCUS” again to switch

on/off the focus assist line

⑤

F.COLOR: False color switch on/off

Press “F COLOR” once, it will display the current false color on/off status Press “F COLOR” again to

switch on/off the false color mode

⑥

DISPLAY: Display current settings

Press “Display” to display safety mark, title and the current input signal information

⑦

MENU: Press to enter Menu

⑧

OK: Under menu system, revolve “OK” to adjust settings and press to apply; and out of menu system,

directly revolve “OK” to adjust volume

2.2 Rear view

①

PHONE: Earphone jack, for HDMI audio

②

Battery mount connector:

Connect with SWIT S-7001 series quick release DV mounts, and then mount corresponding DV batteries

See details in “Optional Battery Mount”

③

DC 12V IN: Connect with DC12V power adapter Please mind the polarity as:

④

HDMI: HDMI input

3. In ut Formats

Input Supported formats

480i / 576i / 480p / 576p

1080i (60 / 59 94 / 50)

720p (60 / 59 94 / 50)

HDMI

1080p (60 / 59 94 / 50)

4. Menu O eration

Press “MENU” and it will display menu system

 Revolve “OK” to select an item The selected item will be highlighted display

 Press “OK” to enter the selected item

 Under menu system, press “MENU” to back to previous menu

 The menu will automatically save and quit if it remains idle



5. Picture Settings Submenu

The Picture Settings Submenu includes:

(1) CONTRAST: 0-100 value adjustment

(2) BRIGHTNESS: 0-100 value adjustment

(3) HUE: (not available on this model)

(4) SATURATION: 0-100 value adjustment

(5) SHARPNESS: 0-100 value adjustment

(6) CLR. TEMP.: Color temperature selection, Normal

(6500K), Warm (4500K), Cool (9300K)

(7) PIC.MODE: User defined and preset picture modes:

standard, soft and vivid selection

6. System Config Submenu

The System Config Submenu includes:

(1) BACKLIGHT: LCD backlight brightness adjustment, value 0-100

(2) RATIO: Select “16:9” or “4:3” to adjust the aspect ratio

(3) SCAN: “UNDERSCAN” and “OVERSCAN” selection

(4) ZOOM: “OFF”, “ZOOM1” and “ZOOM2” selection

ZOOM1: Canon DSLR scale zoom-in (1 2 times),

ZOOM2: 1 5 times zoom-in

(5) MARKER: Select and set the safety mark scale from

80%, 85%, 90% and 95%

(6) RESET: Revolve “OK” to RESET and press to reset all

to factory setting

7. Dis lay Settings Submenu

The DISPLAY settings submenu is to select the items to

be displayed on screen when ‘DISPLAY” button is pressed

Revolve "OK" to turn on/off the items:

(1) INFO: Including HDMI format, aspect ratio,

underscan/overscan, zoom status and peaking status

(2) MARKER: Safety mark

(3) TITLE: User edited title

8. Title Settings Submenu

Revolve "OK" button to select the letters, and press

"OK" to input Select SPACE to input space and DEL to

delete the left letter Max 10 letters are supported

After setting, press "MENU", the system will save data to

current user and quit menu The menu will automatically

save and quit if it remains idle

9. OSD Settings Submenu

The OSD Settings Submenu include

(1) LANGUAGE: Menu language English / Chinese selection

(2) H-POSITION: Menu horizontal position (0-100)

adjustment, real-time preview and default value: 50,

center

(3) V-POSITION: Menu vertical position (0-100)

adjustment, real-time preview and default value: 50,

center

(4) DURATION: Menu timeout setting

Set a time (in seconds) in which the menu will

automatically quit if remains idle Default: 10 seconds;

Range: 5 seconds to 60 seconds

(5) HALFTONE: Set a transparency value (0-100) of menu display Real-time preview supported

10. FUN.KEY Settings Submenu

The FUN KEY Settings Submenu is to define Function Key F1 and F2 The available function items are:

1-PATTERN: Color-bar test signal switch

2-RATIO: Aspect ratio switch

3-SCAN: Underscan / Overscan switch

4-ZOOM: Picture Zoom-in

5-CLR.TEMP: Color-temperature switch

6-PIC MODE: Preset picture mode switch

7-B/W: Color / Black & white switch

11. Cold Shoe Bracket

The provided monitor bracket support both cold shoe and screw mount for camera connection

1 For cold shoe: anticlockwise screw the knob to draw the bolt back, slide the cold shoe mount into camera,

and then clockwise adjust the knob to fasten

2 For screw mount: clockwise screw the knob to draw the bolt directly into the screw thread of camera till

fastened

3 Screw the ball head knob into monitors, and lock the ball head

12. O tional Battery Mount

12.1 S-7001 series DV battery mount

S-1051C monitor can use DV batteries by connecting with SWIT S-7001 series mount There’re following types

of S-7001 for choice:

Model Com atible battery ty e Recommended SWIT battery

S-7001F SONY L series NP-F770/970 S-8972, S-8970, S-8770

S-7001P Panasonic CGA series D54S/D28S S-8D62, S-8D54, S-8D28

S-7001J JVC BN-V428U S-8428

S-7001C Canon BP series BP-930/945 S-8945, S-8845

S-7001U SONY BP-U series U60/30 S-8U62

S-7001E Canon DSLR, LP-E6 S-8PE6

S-7001B

Panasonic VW-VBG6 S-8BG6

S-7001V JVC BN-VF823 S-8823

①

Lock

②

Knob

③

Cold shoe mount

④

Screw bolt

12.2 Installation of S-7001 mount

S-7001 Rear View Installation

S-7001 DV mount is quick releasable Please follow the instructions:

(1) Please make sure the power terminals are clean and in well condition before use

(2) Align the S-7001 slots to the bolts of the monitor rear panel, and press tightly in

(3) Slide the S-7001 mount down to the bottom

(4) If necessary, fix the S-7001 mount by screws on the top side

(5) Mount the battery to S-7001 to power the monitor

Slot

Terminal

Screw hole

Battery release
