BM-U 4K High Definition Monitor
Model: BM-U175/245/275HDR
User Manual
Please read this user manual throughout before using
Ver：A
SWIT ELECTRONICS CO., LTD.
01
Preface
All internal technologies of this product are protected, including device, software and trademark.
Reproduction in whole or in part without written permission is prohibited.
All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative trademarks
in this user manual are the property of their respective owners.
Due to constant effort of product development, SWIT reserves the right to make changes and
improvements to the product described in this manual without prior notice.
The warranty period of this product is 2 years, and does not cover the following:
⑴ Physical damage to the surface of the products, including scratches, cracks or other damage
to the LCD screen or other externally exposed parts;
⑵ The LCD dot defects are not over three;
⑶ Any damage caused by using third-party power adaptors;
⑷ Any damage or breakdown caused by use, maintenance or storage not according to the user manual.
⑸ The product is disassembled by anyone other than an authorized service center.
⑹ Any damage or breakdown not caused by the product design, workmanship, or manufacturing
quality, etc.
＊ Any sales personnel have no rights to provide additional warranty.
For any suggestions and requirements on this product, please contact us through phone, fax,
Email, etc.
SWIT Electronics Co., Ltd.
Address: 10 Hengtong Road, Nanjing Economic and Technological Development Zone,
Nanjing 210038, P.R.China
Phone: +86-25-85805753
Fax: +86-25-85805296
Email: cont[email protected]
http://www.swit.cc
02
This manual is applicable to all models of BM-U (5 generation), and the schematic diagram is
taken as the appearance diagram of BM-U245. Any specification, appearance, this manual will
be additional text description.
※
Maintenance
Warning
1. In order to reduce the risk of fire and electrical shock, do not lay this product in rain or damp places.
2. Please keep away from the strong magnetic field; it may cause the noise of the video
and audio signals.
The power
1. Please use the power adapter provided or recommended by the manufacturer in order to
avoid damage.
2. For a third party power adapter, please make sure the voltage range, supplied power,
and polarity of power lead are fit.
3. Please disconnect the power cable under the following situations:
(A). If you do not operate this monitor for a period of time;
(B). If the power cable or power adaptor is damaged;
(C). If the monitor housing is broken.
The monitor
1. Please don't touch the screen with your fingers, which would probably deface the screen.
2. Please don't press the screen; the LCD is extremely exquisite and flimsy.
3. Please don't lay this product on unstable place.
Cleaning
1. Please clean the screen with dry and downy cloth or special LCD cleanser.
2. Please do not press hard when cleaning the screen.
3. Please do not use water or other chemical cleanser to clean the screen.
The chemical may damage the LCD.
03
Introduction
This series of monitors adopt TFT-LCD panel, the resolution is up to 3840×2160, H178° / V178°
ultra-wide viewing angle, supports 2 channels of 12G/6G/3G/HD/ SD-SDI, 2 channels of 3G/HD/
SD-SDI, and 1 channel of HDMI 2.0, and has 2 channels of 12G/6G/3G/HD/ SD-SDI ring out, and 2
channels of 3G/HD/ SD-SDI ring out, with earphone and speaker output.
Features:
3840X2160 Ultra HD
4K/UHD interface（2x12G-SDI&2x3G-SDI input,4xSDI output,1xHDMI 2.0 input）
16ch audio bar display, with any selected 2ch output
Support waveform selection display Y/Cb/Cr/R/G/B /RGB and single line selection mode
Vector scope, R/G/B/Y histogram, bi-color focus assist
3DLUT（17 x 17 x 17） accurate color correction
Dynamic UMD and TALLY(TSL3.1, 4.0) display
Composition ratio auxiliary line:4:3/13:9/14:9/15:9/16:9/1.85:1/2.35:1/2:1/Custom
Support USB firmware upgrade and import Log file.(USB file system supports FAT 32 format only)
Eco mode
Packing list
standard package
monitor
user manual
warrantee card
Battery plate（V-mount or Gold mount option ）
tabletop stand
power cord
details
X
1
X
1
X
1
X
1
X
2
X
1
No.
1
2
3
4
5
6
04
Contents
Preface.
Maintenance
Contents
Packing List
Introduction
Operation Introduction
Front panel
Rear panel
OSD
Main Menu
Size
Specification
Trouble-Shooting
2
3
4
4
4
5
5
7
8
11
25
26
29
※ Only BM-U175/BM-U245 are equipped with battery gusset plate.
05
Operation Instructions
·Front panel
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10)
(11)
(1) Speaker: For SDI/HDMI embedded audio. (Will not work if earphone is plugged in)
(2) Desktop Stand Feet
(3) U1~U4: User shortcut key, which can be used to quickly enter the set user mode.
Long press tosave user settings. Please see details in “9. System”
(4) INFO: Display setting item. Press "INFO" button to display or turn off relevant status information
and audio and video analysis function graph. When opening the menu, press "INFO" to
exit the menu with one click
(5) F1~F5 function keys: Customize shortcut function keys. Users can set the shortcut keys to
different functions according to their own requirements.
(6)
Brightness Contrast Saturation
Backlight Volume Source
1080P
1080I
1080PsF
4K
(SDI1 IN) (SDI2 IN)
(SDI3 IN) (SDI4 IN)
Source
SFP
SDI 1
SDI 2
SDI 3
SDI 4
2-SI
SQ
HDMI
Four-Screen
Brightness: Adjust the brightness. -100~100 adjustable, default value is 0.
Contrast: Adjust contrast. -100~100 adjustable, default value is 0.
Saturation: Adjust saturation. -100~100 adjustable, default value is 0.
Backlight: Adjust the backlight. 0~100 adjustable, default value is 16.
※ The default backlight value of BM-U245 is 35.
06
Press Brightness, Contrast, Saturation, Backlight, Volume five shortcut keys confirm to select
this option, and rotate Menu to adjust the corresponding item value directly. Press the button and
automatically cancel the selection without operation within five seconds, and the button light will
be off, long press to restore default values.
Volume: Adjust the volume.0~100 adjustable, the default value is 36.Long press the volume
button to mute.
Source: Select the input source signal format. As shown in the figure above, when Four-screen
is selected, the screen is divided into 4 frames, and 4 channels of SDI signals can be displayed
simultaneously. When Four-screen is opened, some menu functions are turned off or displayed in
grey.
(7) Menu/Enter：When no Menu is displayed, press the button directly to open the Main Menu;
Rotate the knob to select different settings or adjust parameter values, press the knob to set.
(8) LUT/Firmware: Update firmware or import LUT files.
(9) PHONE: 3.5mm headphone jack is used to monitor the embedded audio signals of SDI and HDMI.
(10) Power: Power switch.
(11) Tally lamp: You can select the color of the tally lamp from “Green”, “Red”, or “Yellow”
Brightness Contrast Saturation
Backlight Volume Source
1080P
1080I
1080PsF
4K
(SDI1 IN) (SDI2 IN)
(SDI3 IN) (SDI4 IN)
Source
SFP
SDI 1
SDI 2
SDI 3
SDI 4
2-SI
SQ
HDMI
Four-Screen
07
·Rear panel
（1） SFP IN: Optical fiber interface
12G/6G/3G/HD/SD-SDI video signal fiber input interface
● Fiber optic module is optional
（2） SDI OUT1/IN1,SDI OUT2/IN2:12G-SDI
（3） SDI OUT3/IN3,SDI OUT4/IN4:3G-SDI
（4） ETHERNET: Network interface
1000M high-speed RJ45 Ethernet port, for web server IP external control.
（5） HDMI 2.0 IN
● Will not display HDCP protected content.
（6） RS485: TSL UMD control port
（7） GPI: GPI control port
（8） Fan
（9） VESA bracket mounting area
（10）DC IN:12V~17V
（11）AC IN:100V~240V
（12）AC switch: Used to directly turn on or off AC power supply
※ BM-U175/BM-U245 supported DC, AC and battery powered three types of power supply.
BM-U275HDR AC power supply only.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8) (9)
(11)
(12)
(10)
⑴ Time Code（SDI）
Under SDI input, the monitor can display Time code information (LTC, VITC1&2). If no Time code info
is detected, it will display “TC UNLOCKED”. User can set function keys F1～F5 or GPI pins as “Time
Code” to turn on or off this function.
⑵ On screen TALLY
Display TALLY signal from GPI port.
⑶ Source ID/UMD
Display TSL 3.1/4.0 UMD or User input Source ID.
⑷ Color Checker
After auto calibration, the color gamut and chromatic aberration (△E) before and after the
color correction pop up. "Auxiliary focus" - "color check" and "automatic color calibration" -
"measurement" pops up the gamut value and color difference value (△E) of the previous
calibration and this measurement.
⑸ Lissajous
Lissajous diagram showing audio signal. Users can set the shortcut key (F1～F5) or GPI pin on the
front panel to “Lissajous” function and turn it on/off.
⑹ Audio VU/PPM meters
Display meters of SDI/HDMI embedded audio or analog audio. The audio meter display channels, on
screen positions, markers and background colors are adjustable. User can set function keys F1～F5
or GPI pins as “Audio Bar” to turn on or off this function.
⑺ Histogram
Parallel display R/G/B/Y histogram for SDI and HDMI video. User can set function keys F1～F5 or GPI
pins as “Histogram” to turn on or off this function.
⑻ Vector
Display vector scope with 100% and 75% markers for SDI and HDMI video. The vector scope pattern
display positions, colors, background are adjustable. User can set function keys F1～F5 or GPI pins
as “Vector” to turn on or off this function.
⑼ Waveform
The display waveform can be selected from Y/Cb/Cr/R/G/B/RGB types, and single line display
mode selectable. The waveform display positions, colors, background are adjustable. User can
set function keys F1～F5 or GPI pins as “Waveform” to turn on or off this function.
08
·OSD
TC 00:15:13:07
CAMERA 1
R
R75
Mg
Mg75
B
B75
Cy
Cy75
G
G75
YI
YI75
W
Delta = 1.0
R
R75
Mg
Mg75
B
B75
Cy
Cy75
G
G75
YI
YI75
W
Delta = 0.0
(1)
(6)
(5)
(4)
(3)
(2)
(7) (8) （9）
in phase
LR
09
·Status display
Press “Menu/Enter” button, the main menu will pop up from the left top of the screen.
The main menu displays the current working status of the monitor.
(1) Format
A format for displaying the current input signal, if there is no currently identifiable
signal input, display "No Signal". When Four-screen is selected for the current channel,
the input signal standard of SDI 1/2/3/4 channel is displayed in standard.
(2) Channel
Displays the currently selected channel
(3) Color Temp
Displays the currently set color temperature mode
(4) Scan mode
Displays the currently set scan mode
(5) F1~F5
Displays the function value set by the current function key
(6) Version
Displays the current software version number
Main Menu
Exit&Status
Input
Color Management
Scanning
Control
Assist
De-embed
Auto Calibration
System
Format
Channel
Color Temp
Scanning
F1
F2
F3
F4
F5
Version
Status
(1)
(6)
(5)
(4)
(3)
(2)
>
>
>
>
>
>
>
>
>
>
XXX
XX
XX
XXXX
XX
XX
XX
XX
XX
XXX
Key configuration.
10
Steps
1. Press “Menu/ Enter” button, the main menu will pop up from the left top of the screen. The selected
main menu highlights in yellow .
2. Revolve “Menu/ Enter” to select submenu, the selected submenu highlights in yellow, press “Menu/
Enter” to apply and enter into the selected submenu’s items.
3. Revolve “Menu/ Enter” to select the item which needed to adjust, press “Menu/ Enter”, the selected
item and its parameters will be highlighted in yellow
4. Revolve “Menu/ Enter” to change the selected item’s parameter, press “Menu/ Enter” to apply and
save the settings.
5. Revolve “Menu/ Enter” to select “Exit”, press “Menu/ Enter” to quit submenu. Select “Exit & Status”
under the Main Menu and press to quit Main Menu
※ Notice
＊ The items in gray cannot be set up
＊ If there is no operation under the set time, the menu will automatically save settings and quit.
＊ If the key inhabit function is turned on, except System menu, all other items are in grey. Please
turn off the key inhibit function to adjust the items.
Ce manuel convient aux modèles suivants
3
Table des matières
Autres manuels SWIT Electronics Moniteur
SWIT Electronics
SWIT Electronics FM-17 Manuel utilisateur
SWIT Electronics
SWIT Electronics ProHD DT-X21H Manuel utilisateur
SWIT Electronics
SWIT Electronics BM-U175HDR Manuel utilisateur
SWIT Electronics
SWIT Electronics S-1273F Manuel utilisateur
SWIT Electronics
SWIT Electronics FM-21HDR Manuel utilisateur
SWIT Electronics
SWIT Electronics S-1073F Manuel utilisateur
SWIT Electronics
SWIT Electronics M-1093F Manuel utilisateur
SWIT Electronics
SWIT Electronics S-1243H Manuel utilisateur
SWIT Electronics
SWIT Electronics BM-U243 Manuel utilisateur
SWIT Electronics
SWIT Electronics CM-55C Manuel utilisateur
