We are very pleased that you have decided to

purchase this product from SWAROVSKI OPTIK.

If you have any questions, please consult your

specialist dealer or contact us directly at

WWW.SWAROVSKIOPTIK.COM.

Please find our current product accessories at WWW.SWAROVSKIOPTIK.COM.

1 Carrying strap

2 Eyepiece cover

Wrist strap

4 Twist-in eyecup

5 Focusing wheel

Dioptric compensation

7 Objective lens cover

For your safety!

WARNING!

Never look at the sun with

the binocular! This leads to

injury of your eyes!

Never look through the

binocular when walking!

You could encounter ob-

stacles!

General information

Please protect your bino-

culars from jolts and jars.

Repairs should be carried

out only by authorized

workshops.

DE ENEN

Fitting the carrying strap

Assembly with eyepiece cover attached on one

side (recommended).

Alternatively: with eyepiece cover attached on

both sides.

Fitting the wrist strap

Adjustment of the twist-in eye cups

Use without eyeglasses:

Turn both eye cups (coun-

ter-clockwise) until they

stop.

Use with eyeglasses:

Turn both eye cups clock-

wise until they stop.

Adjustment of interpupillary distance

To see a single round image, turn the two halves

of the binoculars until no irritating shadows can

be seen.

Operation

DE ENEN

Adjustment of focusing

It is possible to bring every

subject into focus from

the shortest adjustment

distance (see Technical

Data Sheet) to infinity by

turning the focusing wheel.

In the infinity position the little nose of the focusing

wheel is at the top.

Dioptric compensation

To achieve optimal image quality, the possibly

varying visual acuity between the left and right eye

must be corrected.

Use with equal acuity of both eyes:

The dioptric compensation

is set to “zero”.

Use with varying acuity of both eyes:

1. Look through the left ocular with your left eye

and turn the focusing wheel to focus sharply on

a selected object.

2. Now, using your right eye, look at the same

object through the right eyepiece and use the

dioptric compensation to set the optimal image

sharpness.

Assembly instructions for objective lens cover

2. 1.

Maintenance and care

Lens-cleaning cloth

You can clean high sensitive lens surfaces with

the enclosed special cloth made of micro-fibres. It

is suitable for objective lens, ocular lens and eye-

glasses.

Please keep the cloth clean, as dirt can damage

DE ENEN

the lens surface. If the cloth gets dirty, it can be

washed in luke-warm soapy water and air-dried.

Please use it exclusively for cleaning lens sur-

faces!

Cleaning

We have designed all elements and surfaces

to require little care. To ensure the long-lasting

optical brilliance of your binocular, you should

keep the glass surfaces free of dirt, oil and grease.

When cleaning the lenses, first remove larger par-

ticles with an optical lens brush. For the subse-

quent thorough cleaning we recommend breathing

onto the lens surface to form a coat of condensa-

tion and then cleaning it with a soft, moist cloth.

The housing is best cleansed with a soft, moist

cloth (don’t use the lens-cleaning cloth).

In the event of hard-to-remove dirt (e.g. sand)

the eye cups can be unscrewed and cleaned very

easily.

Storage

You should keep your binocular in its bag in a well-

ventilated, dry place.

If the instrument is wet,

it must be dried prior to

storage.

In tropical regions or re-

gions with a high degree of

humidity the best place to

store the instrument in is an air-tight receptacle

along with a moisture-absorbing agent (e.g. silica

gel).

6,*

(

All data are typical values.

We reserve the right to make changes regarding design and delivery.

We accept no liability for printing errors. BA-698-01, 07/2011
