Swann SWDVK-840004F Manuel utilisateur

For more information on this product visit www.swann.com

Professional protection for your home or

business 24/7

• Swann’s latest TruBlue™ blue-lit D1 DVR with real time, full screen high resolution video recording

• Includes 4 x high resolution 600TVL cameras with powerful night vision to 65ft/20m for indoor /

outdoor use

• A comprehensive surveillance system that allows you to view & record up to 8 cameras and view live

with the free SwannView app

• Set & forget by recording continuously from 4 channels for 45 days+ onto a 1TB hard drive, even

longer with motion detection

• Save time & have peace of mind by easily locating incident video, then transfer to USB ﬂash drive

or USB HDD

• View live or playback in high resolution on your LCD screen via VGA connection or HDTV via HDMI

• Setting up remote viewing has never been easier with Swann’s ‘My DVR’ customizable network

conﬁguration

• Surveillance in the palm of your hand with live viewing on 3G/4G-enabled Smartphones & tablets

including iPhone, iPad, Android, BlackBerry and more*, and remote notiﬁcation via email

• A cutting-edge solution for any home or business wanting complete protection

Professional Security System

DVR8-4000™ TruBlue™ 8 Channel D1

Digital Video Recorder & 4 x PRO-530™ Cameras

SWDVK-840004F

Monitor and mobile phones not included, not all handsets supported

+45 days recording achieved using lower settings, default settings give 12 days recording

Larger, Clearer High Res–Video

SwannView App

Free Download

www.swann.com/swannview

Available on the

App Store

Backlit Display

TRUBLUE™

LClHihR

Vid

www.s

wann.

com/s

wannv

iew

Monitoring Kit

WEATHERPROOF IP67 CAMERA WITH CABLE

THREADED THROUGH STAND

EASILY CONNECT TO PLASMA/LCD TV, HDTV

OR LCD MONITOR

45 DAYS+CONTINUOUS RECORDING TO 1TB HDD

1TB

POWERFUL DAY & NIGHT VISION UP TO 65FT/20M

TRANSFER INCIDENT VIDEO TO FLASH DRIVE

DETER PREVENT CRIME, VANDALISM & MORE

ADD 4 MORE CAMERAS

CHANNELS

CONNECT TO HDTV, LCD & PLASMA TVs

CLEAR RESOLUTION 600 TV LINES

ðȫ³” SWANN TRUCOLOR VIDEO SENSOR

600TVL

REAL TIME, FULL SCREEN HIGH RES RECORDING

SET UP YOUR DVR FROM YOUR PC IN MINUTES

MY DVR

EASY

600TVL

2XU3URPLVH

Swann stands by its Lifetime Support promise to make

advanced security easy to use, install and maintain.

Everything is in the pack but if you need it, Swann’s help

desk is available with extended hours for the life

of the product.

Installation is easy

Do-it-Yourself

Installing this Swann product is simple. For instructions,

tips and videos see the operating instructions in this pack

or visit www.swann.com

Professional Installation

Need extra help?

We have an installer in your region!

For more visit

www.swann.com

For more information on this product visit

www.swann.com

Please note that the information contained within this document is subject to change without notiﬁcation.

All trademarks remain properties of their respective owners.

What’s in the box

• DVR8-4000™

• 1TB Hard Drive (installed)

• Remote Control (with Batteries)

• PRO-530™ Cameras x 4

• BNC Cables 60ft / 18m x 4

• Mouse

• Ethernet Cable

• Software CD

• Mounting Screws & Plugs

• Operating Instructions

• Theft Deterrent Stickers x 4

Speciﬁcations

DVR

Video

Video Signal Type NTSC or PAL

Video Inputs 8 Composite BNC Inputs

Video Outputs VGA, HDMI

Display Resolution 1024 x 768, 1280 x 1024, 1280 x 720, 1920 x 1080

Display Frame Rate NTSC: 30fps/channel, PAL: 25fps/channel

Audio

Audio Input 4 RCA Inputs

Audio Output 1 RCA Outputs

Recording

Compression Format H.264

Recording Resolution NTSC: D1 (704 x 480), CIF (352 x 240)

PAL: D1 (704 x 576), CIF (352 x 288)

Recording Frame Rate NTSC: 30fps D1 / PAL: 25fps D1

Recording Modes Manual / Motion / Schedule

HDD Interface / Type 1TB SATA HDD (installed)

Hard Drive Support Up to 2TB

Network

LAN Connection Yes

Network Interface RJ45

Network Protocol TCP/IP, DDNS, UPnP

Dynamic DNS Yes (swanndvr.net : DYN)

Remote Operation Yes

General

Operating Power DC 12V

Dimensions 11.81” x 8.46” x 1.97” / 300mm x 215mm x 50mm

Weight 3.5lbs / 1.6kg

Backup Method USB to Flash Drive / Network / eSATA

RC Battery Type x Qty AAA x 2 (included)

Camera

Video

Image Sensor 1/3” SwannTruColor (STC)

Video Quality 600 TV Lines

Resolution 728 x 488

Minimum Illumination 0 Lux (IR on)

Day / Night Mode Color during day / switches to B&W at night

White Balance Automatic

Signal / Noise Ratio 45dB

Gain Control Automatic

Backlight Compensation Yes

Lens 4.8mm

Viewing Angle 58 degrees

Night Vision

Night Vision Distance Up to 65ft / 20m

IR Cut Filter Yes

Number of Infra-red LEDs 24

Infra-red Wavelength 850nm

Infra-red LED Life 10,000 hours

General

Indoor / Outdoor Indoor / Outdoor

Operating Power DC 12V

Operating Temperature 14°F ~ 140°F / -10°C ~ 60°C

Body Construction Aluminum

Dimensions - Camera 2.0” x 2.0” x 2.8” / 50mm x 50mm x 70mm

Dimensions - Stand & Stand 2.5” x 2.5 ” x 5.7” / 65mm x 65mm x 145mm

Weight 0.56lbs / 253g

Codes

Swann Code SWDVK-840004F

UPC 815849013599

Professional Security System

DVR8-4000™ TruBlue™ 8 Channel D1

Digital Video Recorder &

4 x PRO-530™ Cameras

View camera live from

anywhere in the world!

iPad

SwannSmart™ app

USE WITH

DOWNLOAD FROM

DOWNLOAD

App Store®

www.swann.com/swannsmart

or use the disk in the pack

One of the great

features of this product

is its remote viewing

capabilities. You can

view your home or

business from anywhere

in the world via

broadband Internet

connection on PC or on

your Smartphone or

tablet* via the

SwannSmart™ app.

Android devices iPhone

Google™Play
