Swann NHD-819 Manuel utilisateur

HD Dome

Security Camera

For use with Swann 7300 and 7400 Series HD NVRs

EN INSTRUCTION MANUAL

This guide has been designed to help you connect

the cables and install your HD Dome camera at

your desired location. To set up and configure

the camera so you can view it on your Swann

NVR-7300 or NVR-7400 please use the guides

that came with your NVR or search for them at

http://support.swann.com/ and follow the steps

for adding cameras using the on-screen menu.

Important note - All jurisdictions have specific

laws and regulations relating to the use of cam-

eras. Before using any camera for any purpose,

it is the buyer’s responsibility to be aware of all

applicable laws and regulations that prohibit or

limit the use of cameras.

Important safety instructions

1) Make sure the camera is fixed correctly and

stable if fastened in place.

2) Do not operate if wires and terminals are ex-

posed.

3) This camera can only be used in combination

with Swann’s NVR-7300 and NVR-7400 HD net-

work video recorders.

4) The reset button is used to perform a factory

reset. Disconnect the Ethernet cable, hold down

the reset button then connect the Ethernet cable.

Keep holding the reset button for 20 seconds then

release. The NVR will take a short time to detect

and display the camera after it has been reset.

Warning - Modifications not approved by the party

responsible for compliance could void user’s au-

thority to operate the equipment.

Introduction

Choosing a location for your Camera

Some things to consider when choosing a location -

1) What you want to monitor and where you’ll get the

best view of it.

2) How you’re going to connect the camera to your

monitoring system; remember that cables and

connections should be kept out of the weather.

3) It’s recommended to mount your camera at an

elevated position to minimise harm.

4) Place your camera as close to the area of interest

as practicable. The best position is from about 4m

(13ft) above looking slightly down, keeping in mind

the details you are looking for.

5) Although the sky looks nice when you look at the

live view from your camera, it is an unlikely direction

for an offender to approach, make sure your camera

has minimal sky in it as the light in daylight can make

the foreground of the image darker.

6) Think about the most likely way a potential offender

may approach your home, use your cameras to give

you the best coverage of these areas.

7) The camera’s casing is resistant to water, different

weather conditions and tampering. It would take

an overwhelming event of this kind to damage the

housing of the camera. However, the cable and

connector are vulnerable and require protection.

8) Even though the camera is weather and water-

resistant, the cable and connectors are not always

as easy to protect. We recommend you cover the

connectors and the end of the cable with some

waterproof tape or similar for best results.

9) Avoid bending your cables at sharp angles.

10) Don’t put your cable near live electrical wiring.

AC electricity generates radio “noise” which can

interfere with the signal from your camera.

Connecting your Camera

To connect your camera to the NVR, simply connect the supplied Ethernet cable to the LAN connection on the

camera then plug the other end of the cable (1) into one of the IP camera inputs on the back of the NVR.

DC Power Reset

LAN

Microphone

AUDIO

OUT

eSATA

LAN

VGA

HDMI

DC 48V USB

1 3 5 7

2 4 6 8

It doesn’t really matter which input you use as they are quite versatile and will be configured in a later step.

The Ethernet cable is the same at both ends so it doesn’t matter which end plugs into the camera or NVR.

Note: The DC Power connector is provided as an alternative power option if required. The NVR will provide PoE

power over the network cable when connected as described above and in this case the DC Power is not needed.

Mounting your Camera

The camera can be mounted onto a flat vertical or horizontal surface and

must be of sufficient strength to hold the camera. To mount the camera -

• Using a Phillips head screwdriver, remove the screw (1) from the

mounting clip. Press down on the mounting clip and carefully remove

the dome cover lifting from the front edge first.

• You’re now free to remove the camera to gain access to the mounting

bracket (2). There are four mounting holes available.

• Position the camera in the location you want to mount to then mark

the mounting holes on the surface to position the screws. Using the

appropriate screws for the surface you are mounting to, screw the

camera into place. Place the camera back onto the mounting bracket.

• To reinstall the dome cover, there are two dome clips located on the

mounting base. Place the dome cover into the dome clips first then

press down on the cover until it locks into place. Place the screw back

onto the mounting clip and tighten.

• The dome cover can be rotated left or right and the camera can be

aimed in almost any direction from wherever you choose to mount it.

Dome Clips

Limited Warranty - Terms & Conditions

Swann Communications warrants this product

against defects in workmanship and material for

a period of one (1) year from its original purchase

date. You must present your receipt as proof of

purchase for warranty validation. Any unit which

proves defective during the stated period will

be repaired without charge for parts or labour

or replaced at the sole discretion of Swann. The

end user is responsible for all freight charges in-

curred to send the product to Swann’s repair cen-

tres. The end user is responsible for all shipping

costs incurred when shipping from and to any

country other than the country of origin.

The warranty does not cover any incidental, ac-

cidental or consequential damages arising from

the use of or the inability to use this product. Any

costs associated with the fitting or removal of this

product by a tradesman or other person or any

other costs associated with its use are the re-

sponsibility of the end user. This warranty applies

to the original purchaser of the product only and

is not transferable to any third party. Unauthor-

ized end user or third party modifications to any

component will render all warranties void. By law

some countries do not allow limitations on certain

exclusions in this warranty. Where applicable by

local laws, regulations and legal rights will take

precedence.

For Australia: Our goods come with guarantees

which cannot be excluded under Australian Con-

sumer Law. You are entitled to a replacement

or refund for a major failure and for compensa-

tion for any other reasonably foreseeable loss or

damage. You are also entitled to have the goods

repaired or replaced if the goods fail to be of ac-

ceptable quality.

FCC Verification

This equipment has been tested and found to comply with the limits for Class B digital device, pursu-

ant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and the receiver

• Connect the equipment into an outlet on a circuit different from that to which the receiver is con-

nected

• Consult the dealer or an experienced radio/TV technician for help

These devices comply with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) These devices may not cause harmful interference.

(2) These devices must accept any interference received, including interference that may cause unde-

sired operation.

M81XCAM120516E | © Swann 2016

Helpdesk/Technical Support

Technical Support E-mail: [email protected]om

Telephone Helpdesk

USA Toll Free 1-800-627-2799

USA Parts & Warranty 1-800-627-2799

(M-F, 9am-5pm US PT)

AUSTRALIA 1800 788 210

NEW ZEALAND Toll Free 0800 479 266

UK 0808 168 9031

For more information on this product visit www.swann.com

See every detail in rich, super HD

• State-of-the-art security camera with outstanding 4 Megapixel Super HD video image clarity from 75%

more pixels than 1080p & enhanced digital zoom providing close-up detail that has to be seen to be

believed

• Camera features a built-in microphone so you can see & hear what’s happening^

• See everything during the day & night with wide 80° viewing angle & the latest infrared cut filter for

amazing night vision to 100ft/30m

• Built to suit any conditions with weather resistant rating of IP66 for indoor & outdoor use

• This camera can only be used in combination with Swann’s Super HD Network Video Recorders including

NVR4-7400™, NVR8-7400™ & NVR16-7400™ for cutting-edge IP surveillance

• Professional surveillance camera gives you the peace of mind from being able to see the detail you need

including license plates, faces, clothing colors & more, all in stunning 4 Megapixels

SWNHD-819CAM

Super HD Security Camera

4 Megapixel Dome Cameras for HD NVRs

SUPER HIGH DEFINITION

4MP

NIGHT VISION

EASY INSTALLATION

WEATHER PROOF

POWER OVER ETHERNET

AUDIO MONITORING

PoE

4MP

PLATINUM DIGITAL HD

Security Made Smarter

^Requires purchase of Swann NVR

For more information on this product visit

www.swann.com

Our Promise

Swann stands by its promise of Lifetime Support

to make advanced security easy to use, install and

maintain. Everything is in the pack but if you need

it Swann’s help desk is available 24 hours a day,

7 days a week for the life of the product.

Installation is easy

Do-it-Yourself

Installing this Swann product is simple. For

instructions, tips and videos see the operating

instructions in this pack or visit www.swann.com

Professional Installation

Need extra help? We have an installer in your

region! For more visit www.swann.com

What’s in the box?

All installation accessories included

• NHD-819™ Dome Camera

• Ethernet Cable 60ft / 18m

• Mounting Screws & Plugs

• Operating Instructions

• Theft Deterrent Stickers

See the difference

Specifications

NHD-819™ CAMERA

Video

Video Quality Up to 4MP

Backlight Compensation Yes

Wide Dynamic Range Yes

Viewing Angle 80°

Audio

Microphone Yes

Audio Range Up to 16ft/5m

Night Vision

Night Vision Distance Up to 100ft / 30m

IR cut Filter Yes

General

Indoor / Outdoor Indoor / Outdoor, IP66 rated

Operating Power DC 12V - PoE

Operating Temperature -4°F ~ 122°F / -20°C ~ 50°C

Body Construction Aluminum

Dimensions - Camera 4.7” x 4.2” x 3” /

120mm x 108mm x 78mm

Weight - Camera 10.1lbs/460g

Code

Swann Code SWNHD-819CAM

Take a closer look

Weather resistant

aluminum casing

80° Viewing angle

Easy mount base screws

into a flat surface

Color video

image sensor

Super HD Security Camera

4 Megapixel Dome Cameras for HD NVRs

Know what’s happening

with zoom 75% more

powerful than 1080p

Perfect for close up detail

such as license plates,

facial detail, clothing

colors & more

75%

BETTER

RESOLUTION

1920 pixels

1080 pixels

1080P HD

2560 pixels

1440 pixels

4MP Super HD

VIEW

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Swann Caméra de sécurité

Swann

Swann SW231-SCK Manuel utilisateur

Swann

Swann IP-3G ConnectCam 1000 Manuel utilisateur

Swann

Swann SWA31-C4 Manuel utilisateur

Swann

Swann SWNHD-811CAM Manuel utilisateur

Swann

Swann DIY Security Cams SW216-2DS Manuel utilisateur

Swann

Swann pro 842 Manuel utilisateur

Swann

Swann SW-P-HSK Manuel utilisateur

Swann

Swann DVR16-8600 Combo Guide de démarrage rapide

Swann

Swann DVR4-1000 Guide de démarrage rapide

Swann

Swann SwannEye HD Manuel utilisateur

Swann

Swann Night Hawk Camera Pack Manuel utilisateur

Swann

Swann PNP-155 Manuel utilisateur

Swann

Swann SW-C-MDNC Manuel utilisateur

Swann

Swann PRO-750 Manuel utilisateur

Swann

Swann nightwatch Manuel utilisateur

Swann

Swann SW211-DTX Manuel utilisateur

Swann

Swann SWPRO-A852PTZ Manuel utilisateur

Swann

Swann PRO-536 Manuel utilisateur

Swann

Swann Wireless OutdoorCam SW231-WCX Manuel utilisateur

Swann

Swann SWWHD-PTCAM Manuel utilisateur

Swann

Swann ADW-300 Manuel utilisateur

Swann

Swann DIY Security Cam SW211-DSC Manuel utilisateur

Swann

Swann Imitation Security Camera Manuel utilisateur

Swann

Swann OutdoorCam SW244-AUO Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
