Swann DVR4-SecuraNet Manuel utilisateur

Product Code: SW242-4MB

www.swannsecurity.com Monitoring Kits & Recording

• Monitor & record up to 4 cameras simultaneously 24/7

• High compression MPEG4 – high resolution & less hard drive space needed with faster streaming than MJPEG models

• Motion detection records activity to pre-installed 160GB hard drive

• Protect your loved ones, home & business

MONITORING

Warranty

month

DVR4-SecuraNet™

4 Channel Digital Video Recorder with

Networking

Perfect for business, retail, large homes, law enforcement,

schools & more

to PC

via USB

Easy to

connect

Remote

viewing

over the web

or network

High Compression

MPEG 4

Video

160

www.swannsecurity.com

™

MONITORING

DVR Specifications

• Compression: MPEG4

• Video I/O: BNC 4-channel inputs / 1-channel output

• Audio I/O: RCA 1-channel input / 1-channel output

• Display Resolution: NTSC: 720x480 PAL: 720x576

• Display Frame Rate: NTSC: 100fps PAL: 100fps

• Record Resolution: NTSC: 720x240 PAL: 720x288

• Record Frame Rate: NTSC: 60fps PAL: 50fps

• HDD Interface: PATA or SATA

• Record Modes: Continuous, Motion Detection,

Sensor Triggered, Time Schedule

• Record Picture Quality: Low, Normal, High, Highest

• Network Interface: RJ45, TCP/IP

• USB Interface: USB2.0

• VGA Output: YES

• Remote Control: IR remote control

• Power Supply: DC 12V (adapter included)

• Dimensions (DxWxH): 13.6” x 9.45” x 2.17”

(345mm x 240mm x 55mm)

• MPEG4 compression

• SOC single chip, high stability

• Linux operating system

• Full-D1 live monitoring, each or quad display

• Multiple record modes: continuous, motion

detection, sensor triggered, time schedule

• Motion detection: settable window & sensitivity

• Variable record frame rate & quality level

• Support hiding & switching channels

• System self-recovery after power reconnected

• Video loss alarm function

• IR Remote control

• Audio I/O

• VGA output

• USB2.0

• Network monitoring: Web browser

DVR Features:

Package Contents

• DVR4-SecuraNet™

• 160GB Hard Drive

• Power Adapter & Cable

• Remote Control

• BNC to RCA Video Cable 3ft (1m)

• BNC to RCA Adapters x 9

• Manual and Installation CD

• Ethernet Cable

• Theft Deterrent Stickers x 4

DVR4-SecuraNet™

4 Channel Digital Video Recorder with Networking

Perfect for business, retail, large homes, law enforcement, schools & more

Note: For best results slowly guide hard drive tray into position

Navigation Playback Controls

Lockable Hard

Drive Tray

Channels (1-4) /

Quad Selection

HDD LED Activity

IR Remote

Control

Receiver

Selection

Video Output

Audio

Output

LAN

Camera Inputs (1-4) DC Input

VGA Output

Power LED

USB Connector

Quad Selection

Please note that the information contained within this document is subject to change without notification.
