Swann 4-4350 Manuel
1
The Setup Wizard
Before starting the Setup Wizard, please make
sure you’ve done the following -
1. Completed the DVR Quick Start Guide (the
blue coloured guide).
2. Able to easily access your router.
3. Your DVR is connected to your TV and both are
turned on and visible.
4. Access to a computer to create a new email
account.
QW_484350140416E | © Swann 2016
READ ME
SECOND!
2
System Language: Select a language you would like the system menu
to be displayed in. Select from English, Russian, French and Spanish.
• Click “Apply” to continue.
• Click “Exit” to exit the Setup Wizard.
Welcome to the Setup Wiz-
ard! The Setup Wizard au-
tomatically runs the first
time you start your DVR and
will guide you through all
the important steps to get
you up and running. Please
be patient as it can take a
moment for the Setup Wiz-
ard to appear after turning
on your DVR.
Step One - System Language
3
By default, the Setup Wizard will display each time the DVR starts or is
re-booted. As the Setup Wizard is only required the first time you turn on
the DVR, click the checkbox to disable this.
• Click “Next” to continue.
• Click “Exit” to exit the Setup Wizard.
Step Two - Disable the Setup Wizard
4
This step is pretty straight forward, you just have to give your DVR a new
password.
Admin Password: The default password is “12345”. Click the dialogue box
and enter this password.
New Admin Password: Click the checkbox to enable a new password.
New Password: Enter a new password. The password can be up to 16 char-
acters in length.
Confirm: Enter your new password again to confirm.
• Click “Previous” to go back to the previous screen.
• Click “Next” to continue.
• Click “Exit” to exit the Setup Wizard.
Use the on-screen keyboard to
input text, numbers and spe-
cial characters.
Step Three - Create a new Password
5
Time Zone: Select a time zone relevant to your region or city.
Date Format: Select a preferred display format.
System Date: If the date is not correct, click the calendar icon to select
the correct date.
System Time: If the time is not correct, click the clock icon to select the
correct time. The time is displayed in 24-hour time.
Live View Mode: 3 x 3 is the default mode and will display up to 8 video
channels on-screen. Selecting 1 x 1 will display the first video channel
full-screen. Other views available are 2 x 2, 1 + 5 and 1 + 7.
Resolution: Select a resolution that is suitable for your TV. 1920 x 1080
(1080p) resolution will give you the best quality. Make sure your TV sup-
ports the resolution selected. When you complete the Setup Wizard, the
resolution will change.
• Click “Previous” to go back to the previous screen.
• Click “Next” to continue.
• Click “Exit” to exit the Setup Wizard.
Step Four - General Configuration
6
The DST function allows you to configure your DVR to automatically ad-
just its time for Daylight Savings in your time zone. You can set when
daylight saving time starts and ends.
Enable DST: Click the checkbox if you would like the DVR to adjust the
time when Daylight Savings time begins.
From/To: Here you can define when Daylight Savings applies to your
location, so you’ll need to tell the DVR when it applies to you.
DST Bias: This refers to the difference in minutes, between Coordinated
Universal Time (UTC) and the local time. Select the time that DST has
increased by in your time zone.
The NTP (Network Time Protocol) function allows the DVR to automat-
ically sync its clock with an on-line server, which gives it the ability to
constantly have an accurate time setting. Obviously this is very impor-
tant for a security system and is enabled by default. We don’t recom-
mend changing any of the default settings.
• Click “Previous” to go back to the previous screen.
• Click “Next” to continue.
• Click “Exit” to exit the Setup Wizard.
Step Five - Daylight Savings & Internet Time
7
Enable Server Authentication: Click the checkbox to enable.
User Name: Enter the user name for the account you created.
Password: Enter the email password for the account you created.
SMTP Server: Gmail enter (smtp.gmail.com). Outlook enter (smtp.live.
com). Yahoo enter (smtp.mail.yahoo.com). See example above.
SMTP Port: Gmail enter 465. Outlook enter 587. Yahoo enter 465.
Enable SSL: Click the checkbox to enable (must be enabled).
Sender: Enter the sender’s name. See example above.
Sender’s Address: Enter the email address for the account you created.
Select Receivers: Only one receiver is required to send alerts to, howev-
er you can send alerts to an additional two receivers.
Receiver: Enter the receiver’s name.
Receiver’s Address: Enter the receiver’s email address.
Test: Click to verify the information is correct. A message will appear
on-screen stating if the test has been successful. Click “OK” to continue.
If the test failed, try the suggestions above (top right).
Send UID: Click this to email your DVR’s UID. You can use this to access
your DVR from SwannView Plus on your mobile device or computer.
Click “OK” to complete the Setup Wizard.
Step Six - Email Configuration
We recommend that you
create a new email account
that is dedicated to your
DVR. Three email provid-
ers are supported – Gmail
(gmail.com), Outlook (out-
look.com) and Yahoo (ya-
hoo.com). Select your pre-
ferred provider then on
your computer, go to the
relevant website to create
an account. When finished,
input those details here.
Email not working, please try
the following -
1. Check that your email and
password are correct.
2. Located at the front of your
DVR, the network LED (NET)
should be flashing. If you don’t
see this, disconnect then recon-
nect the Ethernet cable or try a
different port on your router.
3. Search “less secure apps” at
(support.swann.com).
8
Live View Mode
Live View mode is the default display for your DVR. Each camera connected will be displayed (multiple view modes available). You can check the
operation of your DVR by using the status icons on the Live View screen. The date and time as well as the name for each camera is also displayed.
26-02-2016 Fri 09:30:15
Camera 01
26-02-2016 Fri 09:30:15
Camera 02
26-02-2016 Fri 09:30:15
Camera 03
26-02-2016 Fri 09:30:15
Camera 04
Menu Bar
Status IconsDate & Time
Camera Toolbar
Double-click a live
video channel to
view full screen.
Click & drag a live
video channel to
reposition it.
To gain access to the Menu, right-click the
mouse on the Live View screen to display the
Menu Bar (see page 9 for more information).
Notification Camera Name
9
Live View Icons & Controls
Menu Bar
1. Click this to access the Menu.
2. Click this to display a full-screen video channel.
3. Click this to select from one of the multi-screen view-
ing modes available.
4. Click this to display the previous channel(s).
5. Click this to display the next channel(s).
6. Click this to automatically switch between channels at
specific intervals (known as “Dwell Time” in the Menu).
7. Click this to select either “Continuous Record” mode
or “Motion Detection Record” mode. This will bypass the
current recording schedule.
8. Click this to change the display contrast level to one of
the pre-sets available.
9. Click this to enter “Playback” mode to play your re-
corded videos.
10. Click this to access the PTZ controls.
11. Click this to disable the internal buzzer when events
or errors occur. Click “Yes” or “No” to confirm.
For more information about the various functions
available, download the instruction manual from
our support center (support.swann.com). Search
for - DVR 4350 Manual.
You’re now ready to download the SwannView Link
app for your Android or iOS mobile device. Follow
the instructions provided in the SwannView Link
Quick Start Guide (the green coloured guide).
The alarm icon indicates
that an event such as mo-
tion, video loss or tampering
has occurred.
The recording icon indicates
that the camera is currently
recording (either manually
or when detecting motion).
Indicates the video
channel has lost
its signal from the
camera.
This icon will appear on-
screen when there is a no-
tification or error. Click the
icon to view the message. Clicking a live video channel re-
veals the Camera Toolbar. This
provides quick access to manual
recording, video playback, audio
monitoring, PTZ controls and the
ability to change image settings.
1
2
3
4
5
6
7
8
9
10
11
