SVS-Vistek CAMERA Link EoSens 3CL Manuel utilisateur

EoSens® 3CL

User Guide

Contents

1Before you start 5

1.1 About this manual 5

1.1.1 Tips, remarks, and notes 5

1.1.2 Registered trademarks 5

1.1.3 Conformity and use 5

1.1.4 Supplements 6

1.2 Warranty and non-warranty clause 7

1.3 Support 7

2Introduction 8

2.1 Intended use 8

2.2 Scope of delivery 8

2.3 Optional accessories 8

2.4 System requirements 9

3The camera 10

3.1 Camera description 10

3.2 Operating temperature 10

3.3 Additional cooling 11

3.4 Interfaces of the camera 11

3.5 Status LED 12

4First steps 13

4.1 Connecting power and I/O signals 13

4.2 Connecting camera and image processing system 14

4.3 Camera settings and profiles 15

4.4 Changing the pixel clock 16

4.5 Cleaning sensor and lens 17

5Technical data 18

5.1 Camera specifications 18

5.2 Sensor specifications 19

5.3 Connector pinning 19

5.3.1 CameraLink connector 19

5.3.2 Power connector 20

5.4 Sensor defect specifications 22

5.5 Camera dimensions 22

5.6 Timing diagrams 23

5.6.1 Free run with electronic shutter 23

5.6.2 External sync with internal timer 24

5.6.3 Pulse width mode 24

5.7 Spectral response 25

5.7.1 Monochrome and color with UV/IR Cut Filter 25

5.7.2 Monochrome and color without UV/IR Cut Filter 25

6Appendix 26

Declaration of Conformity 27

Figures

Fig.: 3-1: Interfaces of the camera EoSens® 3CL 11

Fig.: 4-1: Power connector pinning 13

Fig.: 4-2: Optocoupler 14

Fig.: 4-3: Connecting camera and image processing system 15

Fig.: 5-1: CameraLink connector, MDR-26 19

Fig.: 5-2: Power connector 21

Fig.: 5-3: Quantum Efficiency mono and color with UV/IR Cut Filter 25

Fig.: 5-4: Quantum Efficiency mono and color without UV/IR Cut Filter 25

1 Before you start

1.1 About this manual

This manual contains helpful information to install and operate the described cam-

era. It has been produced with care. Nevertheless, information might be erroneous or

incomplete. Mikrotron GmbH cannot be held responsible for any problems resulting

from incomplete or erroneous information.

In case you detect errors or need further information, please inform us via mail:

[email protected] or

Call +49- 89-7263-4200

We highly recommend to read this manual carefully.

NOTICE This manual is subject to change without notice.

It is intended for staff with technical qualifications who have been specially trained

and have the appropriate knowledge in the field of automation technology, electrical

and optical devices.

INFO Keep this manual for future use.

1.1.1 Tips, remarks, and notes

This manual contains tips and notes that help to avoid data loss or camera damage.

They are emphasized as follows:

INFO Provides information that may help to improve camera handling or avoid data loss.

NOTICE Provides information to avoid damage to the system.

1.1.2 Registered trademarks

In this manual the following registered trademarks may be used:

lMotionBLITZ®

lImageBLITZ®

lEoSens®

lGenICam®

lMicrosoft® and Windows®

lIntel®

Throughout the manual, these trademarks are not specifically marked as registered

trademarks. This in no way implies that these trademarks can be used in another con-

text without the trademark sign.

1.1.3 Conformity and use

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These requirements are

designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment.

1 Before you start 5

This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions given in this guide, may cause

harmful interference to radio communications. Operation of this equipment in a res-

idential area is likely to cause harmful interference in which case the user will have to

correct the interference at its own expense.

NOTICE You are herewith cautioned that any changes or modifications not expressly

approved in this description could void your authority to operate this equipment.

制造说明：

此设备的生产与测试依照FCC条例第15条条例，符合A类电子设备标准。产品提

供在商用使用环境中的合理保护，以防止使用过程中可能涉及到的损害。

此设备会产生、使用并可发射出无线电波，如果未按照本手册中所述安装和使

用，可能会对无线通信设备产生干扰。如本设备在居民区操作出现干扰等情

况，用户需要自费处理。

备注：请注意，如未按照此使用说明操作而自行更改设备，那么您将无权使用

本设备。

規制適合宣言とご使用について(米国FCC)

この機器は、FCC規則のパート15に定められたクラスAデジタル装置に関する規制

要件に基づいて所定の試験が実施され、その適合が認証されています。これらの

規制要件は、商業環境において機器を使用する際、有害な干渉に対する妥当

な保護を提供するために設けられています。この機器は、無線周波数エネルギー

を生成かつ利用するとともに、放射することもあります。このリファレンスガイドの指

示に従って設置および使用が行われない場合は、無線通信に有害な干渉を引き

起こす恐れがあります。この機器を住宅地で利用すると有害な干渉を起こすこと

もあり、その場合、使用者は自己負担において適切な対策を講じる必要がありま

す。

注意事項：このリファレンスガイドに明示的に承認していない変更や修正を行った

場合には、本製品を使用する権利が無効となることがあります。

1.1.4 Supplements

For customers in Canada

This apparatus complies with the Class A limits for radio noise emissions set out in

Radio Interference Regulations.

Pour les utilisateurs au Canada

Cet appareil est conforme aux normes Classe A pour bruits radioélectriques, spé-

cifiées dans le Règlement sur le brouillage radioélectrique.

1 Before you start 6

Life support applications

The products described in this manual are not designed for use in life support appli-

ances or devices and systems where malfunction of these products can reasonably be

expected to result in personal injury.

NOTICE Mikrotron customers using or selling these products for use in such applications do

so at their own risk and agree to fully indemnify Mikrotron for any damages res-

ulting from such improper use or sale.

1.2 Warranty and non-warranty clause

Warranty is described in §8 of our General Terms and Conditions which can be

downloaded on the Mikrotron web page (www.mikrotron.de/en/terms.html).

In addition, take the following non-warranty clauses into account.

NOTICE The camera does not contain serviceable parts. Do not open the body of the cam-

era. If the camera has been opened, the warranty will be void.

NOTICE The camera has to be used with a supply voltage according to the camera’s spe-

cification. Connecting a lower or higher supply voltage, AC voltage, reversal polar-

ity or using wrong pins of the power connector may damage the camera. Doing so

will void warranty.

Our warranty does not protect against accidental damage, loss, or acts of nature.

INFO Mikrotron cannot be held responsible for the loss of data. We recommend a backup

plan.

1.3 Support

1. In case of support or a warranty claim, make a note of the camera type and its

serial number (S/N). You find all necessary information on the identification

plate of the camera.

2. Contact us in one of the following ways:

oContact us via email: [email protected]. Our support team will guide

you through the process.

oOr visit our support website

www.mikrotron.de/en/services/support.html

and fill out the form. You will receive an automatic reply from our ticket sys-

tem.

1 Before you start 7

2 Introduction

2.1 Intended use

The camera EoSens® 3CL belongs to the product class of so-called high-speed

machine vision (MV) cameras that are integrated into test or measurement systems.

High-speed MV cameras are designed to capture images with high frame rate for

various purposes in an industrial or scientific environment to deliver image data for

further analysis. The images are transmitted to a frame grabber on a connected com-

puter where they can be evaluated with the help of a software.

Other uses

Any other use is regarded as unintended use and leads to the loss of guarantee and

liabilities. Contact the manufacturer for other uses.

These products are designed for industrial applications only. The cameras are not

designed for life support systems where malfunction of the products might result in

any risk of personal harm or injury.

2.2 Scope of delivery

The following components are part of delivery. Before installing the camera, check if

the delivery is complete:

lCamera as ordered

lF-mount or C-mount lens adapter as ordered

lUSB storage device with

oVCAM2 software

oGenICam XML file

oProduct documentation

NOTICE Check if the delivery is complete before installing the camera.

INFO The firmware can be updated remotely via a special updating software. For firmware

updates, inform Mikrotron via email: [email protected].

2.3 Optional accessories

Lenses

Only lenses for industrial purpose are suitable. To find lenses or other accessories,

visit www.mikrotron.de/en.

Cable

lKKRDCLSRxx: CameraLink cables with lengths from 0.5 to 8 m are available.

INFO If the cable length exceeds 8m, high-quality cables are required.

In order to use Full camera link, two cables for each camera are needed.

2 Introduction 8

Power supply

lNTCAM13xx: The 12V/2.5A power supply is available with 5 or 10 m cable.

lNTCAM13xxSTR with strobe connector: The 12V / 2.5 A power supply with

strobe connector is available with 5 or 10 m cable.

Adapter

lF-mount adapter

lC-mount adapter

2.4 System requirements

The PC or image processing system that is connected with the camera must be

equipped with:

lAn image processing system, e.g. PC and operating system according to the

requirements of the frame grabber

lA fully installed frame grabber with the most recent device driver and software

lA CameraLink cable (one cable for BASE mode or two cables for operating in

FULL mode)

lAn external power supply providing an output voltage between 8 and 24 V and

a current of at least 2 A (e.g. NTCAM13xx or NTCAM13xx10)

2 Introduction 9

3 The camera

3.1 Camera description

The CMOS 3.0 Megapixel CameraLink cameras offer a high photo sensitivity and

therefore make inspection in low light conditions possible. Both BASE and FULL mode

cameras are available as monochrome and color version.

Mikrotron CameraLink cameras comply with the CameraLink standard. The camera

link standard defines the following items:

lThree configuration types BASE, MEDIUM and FULL with different data transfer

speeds

lThe transfer protocol which is used by the frame grabber to communicate with

the camera.

For detailed information about the CameraLink standard, refer to the AIA web page:

www.visiononline.org.

The color and monochrome cameras are supplied with the following features:

l3D image smoothing

lAuto exposure

lFirmware updates on site possible

lFPN correction

lMultiple pixel exposure

lTest image

Bayer filter

The sensor of the EoSens color cameras is supplied with a Bayer color filter. In order

to get the color information, the imaging software has to decode the information of

each pixel into red, green, and blue (RGB) by using the values of its neighboring

pixels. Each red, green and blue filter element covers exactly one pixel on the sensor.

A matrix of 2x2 filter elements builds a filter element matrix. A Bayer pattern image

therefore must have an even number of pixels and an even number of lines. The

ordering of the RGB pixels for each sensor is provided in the section on technical

data.

UV/IR cut filter

In addition, color cameras are equipped with an UV/IR cut filter. Light with

wavelengths between 370nm and 670nm will be transmitted. As CMOS sensors are

susceptible to UV and IR rays outside the visible spectrum, UV/IR filter avoid blurred

images and therefore improve color images.

3.2 Operating temperature

Despite of its high performance, the fanless 3CL camera is compact and works

silently. If the camera is mounted on mechanical parts, the heat generated during

operation will be dissipated by the cooling fins at the rear of the camera and the

mechanical parts.

3 The camera 10

Table des matières

Autres manuels SVS-Vistek Système de vision industrielle

SVS-Vistek

SVS-Vistek EXO Series Manuel utilisateur

SVS-Vistek

SVS-Vistek GIGA VISION ECO 4I/O Manuel utilisateur

SVS-Vistek

SVS-Vistek EoSens Creation 2.0XGE Manuel utilisateur

SVS-Vistek

SVS-Vistek exo174 Manuel utilisateur

SVS-Vistek

SVS-Vistek CoaXPress fxo540 Manuel utilisateur

SVS-Vistek

SVS-Vistek shr 411 Manuel utilisateur

SVS-Vistek

SVS-Vistek SHR 10GigE Manuel utilisateur

SVS-Vistek

SVS-Vistek CoaXPress EoSens 4CXP Manuel utilisateur

SVS-Vistek

SVS-Vistek 10 GiGE FXO Series Manuel utilisateur

SVS-Vistek

SVS-Vistek exo174 U3 Series Manuel utilisateur

SVS-Vistek

SVS-Vistek CoaxPress EoSens Creation 1.1CXP2 Manuel utilisateur

SVS-Vistek

SVS-Vistek CoaXPress FXO Series Manuel utilisateur

SVS-Vistek

SVS-Vistek CoaXPress EoSens 21CXP2 Manuel utilisateur

SVS-Vistek

SVS-Vistek hr387 Series Manuel utilisateur

Manuels Système de vision industrielle populaires d'autres marques

Festo

Festo SBOC-M-R1B-H Manuel utilisateur

Banner

Banner VE200G1B Manuel utilisateur

Sony

Sony Vision Exchange PEQ-C100 Manuel utilisateur

Datalogic

Datalogic MX-U81 Instructions d'installation

Cognex

Cognex In-Sight D900 Series Manuel utilisateur

Spektrum

Spektrum SPMVR2520 Manuel utilisateur

Huaray

Huaray Movidius Series Manuel utilisateur

Daheng Imaging

Daheng Imaging MERCURY2 USB3 Manuel utilisateur

Teledyne

Teledyne e2v Eliixa+ Series Manuel utilisateur

Photron

Photron FASTCAM Mini CX Series Manuel utilisateur

National Instruments

National Instruments Vision CVS-1455 Manuel utilisateur

Omron

Omron FH-L550 Manuel utilisateur

iGen

iGen NV20/20 Manuel utilisateur

JAI

JAI GO-5100MP-USB Manuel utilisateur

Ark Vision Systems

Ark Vision Systems AVS-Monitor 7 FHD Manuel utilisateur

Cognex

Cognex In-Sight 9902L Manuel utilisateur

Feniex

Feniex C-5500 Manuel utilisateur

Advantech

Advantech AIIS-3411 Series Manuel d'installation et d'exploitation
