USER’S MANUAL

Web Camera with Headset

ICH-7900

User’s Manual

ENG

ICH-7900

Thank you for choosing the SVEN unit!

Please read this operation manual before using the unit and retain this

operation manual in a safe place for future reference.

This manual and information contained in it are copyrighted. All rights

reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this manual more exact, some

discrepancies may occur. The information of this manual is given on «as is»

terms. The author and the publisher do not bear any liability to a person or an

organization for loss or damages which have arisen from the information

contained in the given manual.

CONTENTS

1. SAFETY PRECAUTIONS . . . ..................................

2. PACKAGE CONTENTS .. . ...................................

3. SPECIAL FEATURES ........................................

4. SYSTEM REQUIREMENTS ..................................

5. CONNECTION AND INSTALLATION .. . . . ....................

6. DESCRIPTION . . . ...........................................

7. TECHNICAL SPECIFICATION .. . .............................

Technical support: www.sven.ﬁ

ENG

Web Camera with Headset

1. SAFETY PRECAUSIONS

•Protect your web camera from high humidity, dust or high temperatures.

•Do not use gasoline, spirit or other dissolvents for cleaning. This may

cause damage of the surface. Clean the outside of the camera with soft

cloth.

•Do not attempt to disassemble or repair your device.

•Protect the device against powerful shocks and falls – they may damage

the internal electronics.

2. PACKAGE CONTENTS

•Web camera — 1 pc

•User’s manual — 1 pc

•Warranty card — 1 pc

3. SPECIAL FEATURES

•Headset

•Adjustable focal distance

•Photo capture by one touch of the snapshot button

•Comfortable mounting clip for camera ﬁxation

•Ball-type hinge for camera rotation

•Automatic face tracking*

•16 video eﬀects and 10 types of frames*

•Adjustable headband

•Flexible microphone holder

•Comfortable embouchures

4. SYSTEM REQUIREMENTS

•Windows 98SE/2000/XP/Vista/7 or up

•Pentium P4 1.4GHz or AMD Athlon 1GHz

•128 MB RAM

* To have more opportunities and functions of the web camera, please

download additional software from www.sven.ﬁ

ENG

ICH-7900

User’s Manual

•200 MB Free Hard Disk Space

•Video adapter 24-bit color

•Available USB 1.1 or 2.0 port (high-

speed USB 2.0 port is required for

higher resolution)

5. CONNECTION AND INSTALLATION

•Connect the web camera to an

available USB port.

•This web camera supports Plug and

Play technology. Installation of the

device is automatic after its connection

to USB port.

6. DESCRIPTION

aSnapshot button

bFocus

cLenses

dBall-type hinge

eMounting clip

fStand

gAdjustable headband

hМicrophone

iFlexible microphone holder

jEmbouchures

Fig. 1. Web Camera

Fig. 2. Headset

ENG

Web Camera with Headset

7. TECHNICAL SPECIFICATION

Parameter, unit

Sensor type

Resolution, pix

Frame rate, frames/sec

Focus distance, mm

Weight, g

Impedance, Ω

Sensitivity, dB/1 kHz

Frequency response, Hz

Max. output power, mW

Jack type, mm

Module dimensions, mm

Directional selectivity

Response level of microphone, dB/1 kHz

Frequency response of mic-phone, Hz

Cable length, m

Weight, g

Value

CMOS

640 x 480, maximum 3200 х2400

(enhanced by software)

up to 30 fps for 640 х480

3 to inﬁnity

190

20 — 20000

mini-jack Ø 3,5

6 × 5

omnidirectional (360°)

–36 ± 2

30 — 16000

2,2

105

Notes:

• Technical speciﬁcation given in this table is supplemental information and

can not give occasion to claims.

• Technical speciﬁcation is subject to change without notice due to

improvement of SVEN production.

Web Camera

Headset

ICH-7900

Модель:

ICH-7900

Импортер вРоссии: ООО «СКАНДИТРЕЛ»,

111024, РФ, г. Москва,

ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии:

ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха

Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите

вгарантийном талоне или на сайте www.sven.ﬁ

Гарантийный срок: 12 мес.

Срок службы: 2 года.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Модель:

ICH-7900

Постачальник/імпортер вУкраїні: ТОВ «СВЕН

Центр». Київська область, м. Переяслав-

Хмельницький, вул. Героїв Дніпра, 31.

Призначення, споживчі властивості та відомості

про безпеку товару див. укерівництві

користувача.

Умови гарантійного обслуговування дивіться в

гарантійному талоні або на сайті www.sven.ﬁ

Гарантійний термін: 12 міс.

Строк служби: 2 роки.

Товар сертифіковано/має гігієнічний висновок.

Шкідливих речовин не містить.

Зберігати всухому місці.

Виготовлено під контролем «Свен Скандинавія

Лімітед», 48310, Фінляндія, Котка, Котолахдентіє,

15. Зроблено вКитаї.

Produced under the control of Oy Sven Scandinavia

Ltd. 15, Kotolahdentie, KOTKA, Finland, 48310.

Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
