Sven FLAT Manuel utilisateur

www.sven.ﬁ

OPERATION

MANUAL

Portable Speaker System (NXT)

flat

ENG

Operation Manual

CONTENTS

1. INTRODUCTION .......................................................................

............

2. SAFETY PRECAUTIONS ............................................................................

3. PACKAGE CONTENTS ..............................................................................

4. SPECIAL FEATURES .................................................................................

5. LOCATING ................................................................................

............

6. DESCRIPTION OF CONSTRUCTION .........................................................

7. INSTALLATION AND OPERATION GUIDE .......................................................

8. TROUBLESHOOTING ....................................................................

..........

9. TECHNICAL SPECIFICATIONS .........................................................

..........

Technical support is on www.sven.ﬁ

Congratulations on your purchase of the Sven speaker system!

Please read this operation manual before using the unit and retain this operation manual in a safe

place for future reference.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this manual more exact, some discrepancies may occur. The

information in this manual is given on «as is» terms. The author and the publisher do not bear any

liability to a person or an organization for loss or damage which has arisen from the information

contained in this manual.

UNPACKING

Unpack the device carefully. Make sure there are no accessories left in the box. Check up the

device for damage; if the product was damaged during transportation, address the ﬁrm which

carried out the delivery; if the product functions incorrectly, address the dealer at once.

ATTENTION!

Do not switch on the speaker system immediately after you bring it into a room from environment

with negative temperature! After unpacking, the speaker system should be kept in conditions of

room temperature for at least 4 hours.

flat

ENG

1. INTRODUCTION

SVEN Flat is a speaker system (SS) produced under the NTX technology. This technology is based

on the physical principle of creating a ﬂat sound wave by means of a light emission surface driven

by a pair of independent powerful drivers. The large area of the emission surface helps provide

deeper bass, wide frequency range and directivity pattern with depth of only 18 mm.

2. SAFETY PRECAUTIONS

•Do not open the SS and do not perform repairs by yourself.

•Do not put foreign objects inside the holes of the SS. Make sure that needles, hair pins, coins,

insects etc. do not get inside.

•Protect the SS from high humidity, water and dust. Do not locate it in areas with high level of

humidity and dust.

•Protect the SS from heating: do not locate it near a heat source or expose to direct sunlight.

•Do not use gasoline, alcohol or other solvents when cleaning, since they may damage the

paint-coated surface of the SS. Clean it with dry soft cloth only.

•If the SS does not operate, unplug it and address your dealer.

3. PACKAGE CONTENTS

•Speaker — 1 pc

•ААА type batteries – 3 pcs

•3.5 mm mini-jack to mini-jack signal cable — 1 pc

• Operation manual — 1 pc

• Warranty card — 1 pc

4. SPECIAL FEATURES

•Compatible with MP3 players, mobile devices, PCs and notebooks

•Ultrathin design

•NXT technology

•Powered by primary or rechargeable AAA batteries

5. LOCATING

•To provide high-quality sound reproduction, place the speaker on a ﬁrm ﬂat surface.

Portable Speaker System (NXT)

ENG

Operation Manual

6. DESCRIPTION OF CONSTRUCTION

aIN: audio source connection jack

bON/OFF: power switch

cBattery compartment

dBatteries

eBattery compartment cover

7. CONNECTION AND OPERATION

GUIDE

• Before making any connections, be sure

that all the components are switched oﬀ.

• Connect the included mini-jack to mini-

jack signal cable to the IN ajack of the

speaker and to the output port of your

audio source (PC, laptop, audio player,

etc.), as shown in Fig. 2.

• Open the battery compartment c. Insert

3 AAA batteries d(included), matching their polarity. Close the battery compartment cover e.

• Switch on the power with the ON/OFF bbutton. The LED indicator on the speaker’s front panel

will light up.

• Switch on your audio source. Adjust the volume by means of the volume control of your sound

source.

• To switch the power oﬀ, press the ON/OFF button b.

Notes:

• Don’t mix different battery types, old and new batteries.

• If the SS is left unused for a long period of time (more than a week), remove all the

batteries from the battery compartment.

Fig. 1. Rear panel

Fig. 2. Connection diagram

flat

ENG

8. TROUBLESHOOTING

Value

80 – 20 000

120 × 100

2 × 20

155 × 125 × 18

0.225

Parameter, measurement unit

Output power, W (RMS)

Frequency response, Hz

Radiator dimensions, mm

Driver diameter, mm

Dimensions, mm

Weight, kg

9. TECHNICAL SPECIFICATIONS

Notes:

• Technical speciﬁcations given in this table are supplemental information and cannot give

occasion to claims.

• Technical speciﬁcations are subject to change without notice due to improvement of SVEN

production.

Problem

The LED is oﬀ.

No sound.

Low volume

level.

Sound distortion.

Cause

Incorrect batteries installation.

The sound source is not con-

nected.

Low level of the input signal.

The batteries are discharged.

High volume level.

Solution

Check if the batteries are properly

installed.

Check the connection of the sound

source.

Adjust the level of the output signal on

the source.

Replace the batteries with new ones.

Adjust the volume level.

If none of the above methods can solve the problem, please seek professional advice at your

nearest service center. Never attempt to repair the product yourself.

Portable Speaker System (NXT)

Модель:

FLAT

Импортер вРоссии: ООО «СКАНДИТРЕЛ»,

111024, РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии: ООО «РТ-Ф»,

105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите в

гарантийном талоне или на сайте www.sven.ﬁ

Гарантийный срок: 12 мес.

Срок службы: 5 лет.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Модель:

FLAT

Постачальник/імпортер вУкраїні: ТОВ «СВЕН Центр».

Київська область, м. Переяслав-Хмельницький,

вул. Героїв Дніпра, 31.

Призначення, споживчі властивості та відомості

про безпеку товару див. укерівництві зексплуатації.

Умови гарантійного обслуговування дивіться в

гарантійному талоні або на сайті www.sven.ﬁ

Гарантійний термін: 12 міс.

Строк служби: 5 років.

Товар сертифіковано/має гігієнічний висновок.

Шкідливих речовин не містить.

Зберігати всухому місці.

Виготовлено під контролем «Свен Скандинавія

Лімітед», 48310, Фінляндія, Котка, Котолахдентіє, 15.

Зроблено вКитаї.

Produced under the control of Oy Sven Scandinavia Ltd.

15, Kotolahdentie, KOTKA, Finland, 48310.

Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland. flat

Portable Speaker System (NXT)
