OPERATION

MANUAL

Portable Multimedia USB

Speaker System 2.0

PS-35

ENG

Operation Manual PS-35

CONTENTS

1. MSS DESCRIPTION .................................................................................

2. SAFETY PRECAUTIONS ............................................................................

3. PACKAGE CONTENTS ..............................................................................

4. SPECIAL FEATURES .................................................................................

5. LOCATING .............................................................................................

6. AS CONSTRUCTION ................................................................................

7. CONNECTION AND OPERATION GUIDE .......................................................

8. TROUBLE SHOOTING .............................................................................

9. TECHNICAL SPECIFICATION .....................................................................

Technical support is on www.sven.ﬁ

Congratulations on your purchase of the Sven speaker system!

Please read this operation manual before using the unit and retain this operation manual in safe place

for future reference.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eﬀorts to make this manual more exact, some discrepancies may occur. The

information of this manual is given on «as is» terms. The author and the publisher do not bear any

liability to a person or an organization for loss or damages which have arisen from the information,

contained in the given manual.

UNPACKING

Unpack the device carefully. Make sure there are no accessories left in the box. Check up the

device for damages; if the product was damaged during transportation, address the ﬁrm which

carried out the delivery; if the product functions incorrectly, address the dealer at once.

ATTENTION!

Do not switch the acoustic system on immediately after you bring it into a room from environment

with negative temperature! After unpacking the acoustic system should be kept in conditions of

room temperature for at least 4 hours.

ENG

Portable Multimedia USB

Speaker System 2.0

1. MSS DESCRIPTION

SVEN PS-35 Portable Multimedia USB Speaker System 2.0 (MSS) is designed to play music, sound

games, etc. MSS is characterized with high volume and an unusual cubic shape. Transformation

mechanism (top panel cube rotation) lets you change dynamics angle and sound direction. MSS

power supply is possible by USB or by batteries (ААА type), due to which it can be connected to

virtually any audio source: a desktop computer, notebook, netbook, MP3 player or PSP. The

speaker with a control panel is named the active one.

2. SAFETY PRECAUTIONS

•Do not open the MSS and do not perform repairs by yourself.

•Do not put foreign objects inside the holes of the MSS. Make sure that needles, hair pins, coins,

insects etc. do not get inside.

•Protect the MSS from high humidity, water and dust. Do not locate it in areas with high level of

humidity and dust.

•Protect the MSS from heating: do not locate it near a heat source or expose to direct sunlight.

•Do not use gasoline, alcohol or other solvents when cleaning, since they may damage the

paint-coated surface of the MSS. Clean it with dry soft cloth only.

•If the MSS does not operate, unplug it and address your dealer.

3. PACKAGE CONTENTS

•Active speaker — 1 pc

•Passive speaker — 1 pc

•Signal cable — 1 pc

•Acoustic cable — 1 pc

•USB power cable — 1 pc

• Operation manual — 1 pc

• Warranty card — 1 pc

4. SPECIAL FEATURES

• Compact design

•Rotating transformation ability

•Easy connection to various audio devices

• Volume control

•USB power supply or 3 AAA batteries

5. SYSTEM REQUIREMENTS

•Notebook (netbook) or PC with USB port

•Any signal output with 3.5 mm jack

ENG

Operation Manual PS-35

Fig. 1. Аctive speaker

6. DESCRIPTION OF CONSTRUCTION

aVolume control wheel

bPower LED

cRotary mechanism

dUSB: USB port (power supply)

eAUX: Audio source input

fL OUT: Active speaker output

gPassive speaker input

hBattery compartment

iON/OFF: POWER switch

jBattery compartment cover

Fig. 2. Passive speaker

Fig. 3. Active speaker

bottom view

7. CONNECTION AND OPERATION GUIDE

SVEN PS-35 Multimedia Speaker System (MSS) can be connec-

ted to a USB-port on your computer or laptop (see Fig. 4).

• Connect the speakers to each other using the acoustic cable

as shown in Fig. 4.

• Insert the mini-jack of the signal cable (included) into active

speaker AUX f, and connect the opposite mini-jack of the

signal cable to LINE OUT port of the PC sound card or OUTPUT

of МР3/CD-player, as shown in Fig. 4.

• Plug the USB-cable to the USB-port on your computer or

laptop. (see. Fig. 4).

• MSS power supply is also possible by using batteries.

Batteries installation

• Open the battery compartment (see. Fig. 3).

• Put in batteries (3 AAA type batteries – not included).

• Close the battery compartment.

Notes:

• Never use both USB and batteries power supply together.

• Don’t rotate the mechanism of speaker transformation

more than 180°!

•Adjust volume level to its minimum by turning the volume

control wheel acounterclockwise until it stops.

• Shift the ON/OFF slide switch ion the active speaker bottom

panel. Power LED bwill illuminate.

• Switch on the audio source and adjust MSS volume level by

the volume control wheel aor by Windows tools at your

discretion. While turning the wheel clockwise a, volume level

increases, but while turning it counterclockwise, it reduces.

ENG

Notes:

• Place the speakers symmetrically to the listener.

• Connect the speakers to a USB port of your laptop or PC, otherwise please use active

USB-hub.

• After turning off the computer or laptop unplug the USB device.

8. TROUBLE SHOOTING

• If there is weak sound or there is no sound of the speakers, please make sure that the USB cable

is plugged to the Laptop or PC and it is powered on. If power is supplied by batteries, make sure

they are inserted into the battery compartment. If the batteries are discharged, replace them with

new ones.

• If the sound is produced by one of the speakers only, check the connection of the speakers.

Value

6 (2 × 3)

80 – 20 000

Ø 50

5DС/USB

75 × 70 × 65

0.372

Parameter, measurement unit

Output power (RMS), W

Frequency range, Hz

Speaker dimension, mm

Power supply, V

Dimensions (one satellite) (W × H × D), mm

Weight, kg

9. TECHNICAL SPECIFICATION

Notes:

• Technical speciﬁcation given in this table is supplemental information and can not give

occasion to claims.

• Technical speciﬁcation is subject to change without notice due to improvement of SVEN

production.

USB AUX L OUT

Signal cable mini-jack to

mini-jack (included)

Acoustic cable

(included)

USB power cable

(included)

MP3-player

Fig. 4. Connection diagram

Active speaker Passive speaker

Portable Multimedia USB

Speaker System 2.0

Модель: PS-35

Импортер вРоссии: ООО «СКАНДИТРЕЛ»,

111024, РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии: ООО «РТ-Ф»,

105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите в

гарантийном талоне или на сайте www.sven.ﬁ

Гарантийный срок: 12 мес.

Срок службы: 2 лет.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Модель: PS-35

Постачальник/імпортер вУкраїні: ТОВ «СВЕН Центр».

Київська область, м. Переяслав-Хмельницький,

вул. Героїв Дніпра, 31.

Призначення, споживчі властивості та відомості

про безпеку товару див. укерівництві зексплуатації.

Умови гарантійного обслуговування дивіться в

гарантійному талоні або на сайті www.sven.ﬁ

Гарантійний термін: 12 міс.

Строк служби: 2 років.

Товар сертифіковано/має гігієнічний висновок.

Шкідливих речовин не містить.

Зберігати всухому місці.

Виготовлено під контролем «Свен Скандинавія

Лімітед», 48310, Фінляндія, Котка, Котолахдентіє, 15.

Зроблено вКитаї.

Produced under the control of Oy Sven Scandinavia Ltd.

15, Kotolahdentie, KOTKA, Finland, 48310.

Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland. PS-35

Portable Multimedia USB

Speaker System 2.0
