Supermicro Switch Quick Configuration CLI Guide

Switch Quick Configuration

CLI Guide for

SSE-G48-TG4

SSE-G24-TG4

SSE-X24S

SBM-GEM-X2C

SBM-GEM-X2C+

SBM-GEM-X3S+

SBM-XEM-X10SM

Release : 1.0b 2 / 19

Supermicro Switch Quick Configuration CLI Guide

The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility

for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this

manual, or to notify any person or organization of the updates. Please Note: For the most up-to-date version of this manual, please

see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual at any time and

without notice. This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only

under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, SPECULATIVE OR

CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING,

REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the State of California,

USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Super Micro's total

liability for all claims will not exceed the price paid for the hardware product.

Manual Revision 1.0b

Release Date: June 28, 2012

Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not copy any part of this document.

Printed in the United States of America

Release : 1.0b 3 / 19

Supermicro Switch Quick Configuration CLI Guide

Contents

1 Introduction................................................................................................................. 4

2 Basic Configurations................................................................................................... 5

2.1 Console Port........................................................................................................ 5

2.2 Management IP Address..................................................................................... 6

2.2.1 Changing Management IP Address ............................................................ 7

2.2.2 Default Gateway ......................................................................................... 7

2.3 User Accounts..................................................................................................... 8

2.4 Interface MTU and Jumbo Frames..................................................................... 9

2.5 Interface Description........................................................................................... 9

2.6 Configuring Interface Range............................................................................. 10

2.7 Stacking............................................................................................................. 11

2.8 Tracking Uplink Failure.................................................................................... 12

2.9 Saving Configurations ...................................................................................... 13

2.10 Upgrading Firmware......................................................................................... 14

2.11 Resetting to Factory Defaults............................................................................ 14

3 VLAN Configurations .............................................................................................. 15

3.1 VLAN Example................................................................................................ 16

4 Link Aggregation...................................................................................................... 18

4.1 Link Aggregation Example............................................................................... 19

Release : 1.0b 4 / 19

Supermicro Switch Quick Configuration CLI Guide

1 Introduction

This document is designed to provide Supermicro Switch users with the information required to

configure the basic functionalities on the switch through the Command Line Interface (CLI).

The Supermicro Switch command line interface is accessible through an RS232 console port, or

viaTelnet and SSH connections.

The Supermicro Switch CLI is designed to follow industry standard CLI commands. Standard

features including context sensitive “help” and auto-completion-on-tab-key are supported.

After logging in to the switch CLI, you are automatically in the user EXEC mode. This mode

supports “show” commands and minimal configuration commands.

To enter the configuration mode, use the command “configure terminal”. For example:

SMIS# configure terminal

SMIS(config)#

To exit to EXEC mode, use the command exit or end.

Note:

Most of the contents of this manual apply to all of these seven switch products:

SSE-G48-TG4,

SSE-G24-TG4,

SSE-X24S,

SBM-GEM-X2C,

SBM-GEM-X2C+

SBM-GEM-X3S+

SBM-XEM-X10SM.

In a few sections the contents differ for these products. In those specific places, the applicable

product is clearly identified. So if any particular product is not mentioned, you can assume that

the contents are valid for these seven products.

Release : 1.0b 5 / 19

Supermicro Switch Quick Configuration CLI Guide

2 Basic Configurations

2.1 Console Port

Switch Console Port

SSE-G24-TG4

SSE-G48-TG4

SSE-X24S

These switches have a DB9 RS232 console port. Use the serial

cable provided with the switch to connect the switch console port

to any computer COM port.

SBM-GEM-X2C

SBM-GEM-X2C+

SBM-GEM-X3S+

These switches have an RJ45 connector for the RS232 console

port. Connect a regular straight RJ45 Ethernet cable to the switch

console port, and connect the other end of the RJ45 Ethernet

cable to the console adapter provided with the switch.

The console adapter coverts the RJ45 to DB9 port. Connect the

DB9 end of the console adapter to any computer COM port.

SBM-XEM-X10SM This switch has a USB connector for the RS232 console port. Use

the USB to DB9 serial cable provided with the switch to connect

the USB console port to any computer COM port.

The computer COM port settings should be as follows:

Baudrate: 9600

Data: 8 bit

Parity: none

Stop: 1 bit

Flow Control: none

Release : 1.0b 6 / 19

Supermicro Switch Quick Configuration CLI Guide

2.2 Management IP Address

The default management IP address for all Supermicro switch products is: 192.168.100.102.

Switch Management IP Interface

SSE-G24-TG4

SSE-G48-TG4

The management IP is configured for VLAN 1. All front 1G ports

and back 10G ports are configured as untagged member ports

of VLAN 1 by default.

You can connect to any of the front panel 1G ports or back

panel 10G ports to manage the switch with management IP.

SSE-X24S The management IP is configured for a 1G management

Ethernet port. You can connect to this management Ethernet

port with the management IP.

If you prefer to manage through the 10G ports, then you can

assign the desired management IP address to VLAN 1.

Alternatively, you can create any layer 3 VLAN to manage the

switch through its 10G ports.

SBM-GEM-X2C

SBM-GEM-X2C+

SBM-GEM-X3S+

SBM-XEM-X10SM

For blade switches, you can manage with the default IP through

the CMM Ethernet connections. The internal management

Ethernet ports of the blade switches are connected with the

CMM Ethernet ports internally.

If you prefer to manage through the front panel Ethernet ports,

then you can assign the desired management IP address to

VLAN 1.

Alternatively, you can create any layer 3 VLAN and manage the

switch through its front Ethernet ports.

Release : 1.0b 7 / 19

Supermicro Switch Quick Configuration CLI Guide

2.2.1Changing Management IP Address

Function Command Syntax Example

Configure management

IP address ip address <ip addr> SMIS(config)# ip address

172.31.1.100

Remove management

IP address no ip address SMIS(config)# no ip address

Get management IP

through DHCP ip address dhcp SMIS(config)# ip address dhcp

View management IP

address show ip interface SMIS# show ip interface

2.2.2Default Gateway

The default gateway can be configured only for the SBM-GEM-X2C, SBM-GEM-X2C+, SBM-

GEM-X3S+, SBM-XEM-X10SM and SSE-X24S switches.

Use the command ip gateway <ip addr> to configure the gateway.

For example:

SMIS(config)# ip gateway 172.31.1.1

For other switches (SSE-G24-TG4 and SSE-G48-TG4) you can add the required route to access

the gateway for a desired network. The route can be added using the command ip route <prefix>

<mask> {<next hop> | vlan <id> | interface }.

For example:

SMIS(config)# ip route 10.0.0.0 255.0.0.0 172.31.0.1

Note:

For blade switches SBM-GEM-X2C, SBM-GEM-X2C+, SBM-GEM-X3S+ and SBM-XEM-X10SM

the management IP address and default gateway can also be configured from the CMM

management interface.

The management IP address and gateway of the switch are saved automatically into switch

NVRAM. So you do not need to do a save configuration command in order to save the

management IP and gateway.

Release : 1.0b 8 / 19

Supermicro Switch Quick Configuration CLI Guide

2.3 User Accounts

The default administrative user name for all Supermicro switches is ADMIN and the password for

all these switches is also ADMIN. The password for this ADMIN user can be changed using the

command username ADMIN password <new password>.

New users can be created with different privilege levels. Fifteen is the highest privilege – it equals

ADMIN user. One is the lowest privilege which only allows the user to view the configurations; the

user may not modify them. The default privilege is at least one.

Function Command Syntax Examples

Create New User username <name> [password

<password>] [privilege <level>] SMIS(config)# username abc

password abc privilege 15

SMIS(config)# username new1

password new1

Remove user no username <name> SMIS(config)# no username abc

Change

password username <name> [password

<password>] SMIS(config)# username abc

password aa12

View users list users SMIS# list users

Release : 1.0b 9 / 19

Supermicro Switch Quick Configuration CLI Guide

2.4 Interface MTU and Jumbo Frames

The interface MTU can be changed by using the mtu command in interface mode. The default

MTU is 1500 bytes. The maximum supported MTU for 1Gig ports is 9202. The maximum

supported MTU for 10Gig ports is 16338.

The Supermicro switch MTU refers only to the layer 2 payload size. Hence the MTU of 9202

means a total “in-wire” MTU of 9220 (14 bytes Ethernet Header plus 4 bytes FCS are added).

To configure the MTU for any interface, the interface must be administratively brought down using

the shutdown command.

Function Command Syntax Examples

Configure MTU mtu <frame size> Example to configure MTU for port gi 0/1

SMIS(config)# interface gi 0/1

SMIS(config-if)# shutdown

SMIS(config-if)# mtu 9000

SMIS(config-if)# no shutdown

View MTU show interface mtu SMIS# show interface mtu

To configure jumbo frame support just configure the MTU as 9200 bytes (or to any other jumbo

size preferred up to 9202 bytes).

2.5 Interface Description

Interfaces can be assigned with a description or name in text. This helps users to identify or

remember the interface connections with other components on the network.

Function Command Syntax Examples

Configure

interface

description

description <string> Example to configure description for gi 0/1

SMIS(config)# interface gi 0/1

SMIS(config-if)# description lab network

View

description show interface description SMIS# show interface description

Release : 1.0b 10 / 19

Supermicro Switch Quick Configuration CLI Guide

2.6 Configuring Interface Range

To configure the same parameters on multiple interfaces, the interface range command can be

useful. For example, to configure the MTU as 9000 for all gi 0/1 to gi 0/24 ports, using the range

command allows all to be configured in one sequence instead of requiring that they be configured

on the individual interfaces 24 times.

Function Command Syntax Examples

Interface

Range

Command

interface range <intf str> Example to configure mtu for 24 ports from gi 0/1 to

gi 0/24

SMIS(config)# interface range gi0/1-24

SMIS(config-if)# shut

SMIS(config-if)# mtu 9000

Example to configure description for 3 ports gi 0/1,

gi 0/5 and gi 0/10

SMIS(config)# int range gi0/1,gi0/5,gi0/10

SMIS(config-if)# description test network

Autres manuels pour SSE-G48-TG4

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Supermicro Changer

Supermicro

Supermicro SSE-G48-TG4 Manuel utilisateur

Supermicro

Supermicro SSE-G24-TG4 Manuel utilisateur

Supermicro

Supermicro SuperBlade Series Manuel utilisateur

Supermicro

Supermicro SSE-X3648S Manuel utilisateur

Supermicro

Supermicro L2 Manuel utilisateur

Supermicro

Supermicro SSE-G48-TG4 Manuel utilisateur

Supermicro

Supermicro SSE-G3748 Series Manuel utilisateur

Supermicro

Supermicro SuperBlade SBM-GEM-X2C+ Manuel utilisateur

Supermicro

Supermicro SSE-G3632S Manuel utilisateur

Supermicro

Supermicro MicroBlade MBM-GEM-004 Manuel utilisateur

Supermicro

Supermicro L2 Manuel utilisateur

Supermicro

Supermicro SSE-T7132 Series Manuel utilisateur

Supermicro

Supermicro SSE-G24-TG4 Manuel utilisateur

Supermicro

Supermicro L2 Manuel utilisateur

Supermicro

Supermicro SBM-25G-100 Manuel utilisateur

Supermicro

Supermicro SSE-G24-TG4 Manuel utilisateur

Supermicro

Supermicro SSE-G48-TG4 Manuel utilisateur

Supermicro

Supermicro SSE-G2252 Manuel utilisateur

Supermicro

Supermicro SSH-C48Q Manuel utilisateur

Supermicro

Supermicro SSH-C48Q Manuel utilisateur

Supermicro

Supermicro L2 Manuel utilisateur

Supermicro

Supermicro L2 Manuel utilisateur

Supermicro

Supermicro SSE-G24-TG4 Manuel utilisateur

Supermicro

Supermicro SSE-F3548S Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
