RIDER'S HANDBOOK
Model HCXT Supplement
EXCELSIOR-HENDERSON
MOTORCYCLE MANUFACTURING COMPANY
All text, photographs, and illustrations in this handbook are based on the most
current product information available at the time of publication. Product
improvements or other changes may result in differences between this handbook
and the motorcycle. Excelsior-Henderson reserves the right to make production
changes at any time, without notice and without incurring any obligation to make
the same or similar changes to motorcycles previously built.
EXCELSIOR-HENDERSON MOTORCYCLE MANUFACTURING COMPANY
805 HANLON DRIVE • BELLE PLAINE, MINNESOTA 56011 • TELE: 612.873.7000/FAX: 612.873.7030
Copyright©1999 Excelsior-Henderson Motorcycle Manufacturing Company. All rights reserved. Super X and X-Twin are
registered trademarks, and Excelsior-Henderson, the X & Bar logo, the Super X Logo, Rider’s Handbook, and Road
Crew are trademarks of Excelsior-Henderson Motorcycle Manufacturing Company.
Dunlop is a registered trademark of Dunlop Tire Corporation.
Features of the Super X motorcycle are covered by U.S. Patent Nos. D406088, D408565, D409539, D409774,
D409964, D412139, with additional patents pending.
i
Introduction....................................................................1
Read the Model HCXT Supplement....................................1
Hazard Symbol and Terms in the Supplement .....................2
Safety Information ..........................................................3
Gross Vehicle Weight Rating ..............................................4
Loading............................................................................5
Highway Bar.....................................................................6
Safety and Vehicle Information Labels.................................7
Product Description ......................................................11
Vehicle Components .......................................................11
Instruments and Controls ..............................................13
Location.........................................................................13
Windshield......................................................................14
Driving Lamps ................................................................14
Pre-Operation Check .....................................................15
Tires ..............................................................................16
Tire Pressure .............................................................16
Tire Condition ...........................................................16
Tread Depth ..............................................................17
Contents
ii Contents
Electrical Equipment........................................................ 17
Driving Lamps........................................................... 17
Maintenance ................................................................. 19
Saddle ........................................................................... 20
Electrical Equipment........................................................ 20
Check Driving Lamps................................................. 20
Adjust Driving Lamps ................................................. 21
Replace Driving Lamp Bulb ........................................ 22
Windshield ..................................................................... 22
Adjust Windshield Height and Tilt................................ 22
Adjust Windshield Air Gap.......................................... 24
Tires.............................................................................. 24
Check Tire Pressure................................................... 24
Check Tire Surface Condition ..................................... 25
Tread Depth.............................................................. 25
Cleaning and Storage .................................................... 27
Cleaning ........................................................................ 27
Windshield Care ............................................................. 28
Saddlebag Care .............................................................. 28
Specifications ............................................................... 31
1
Introduction
Read the Model HCXT Supplement
The Model HCXT Supplement is designed to be used in conjunction with the
Super X Riders Handbook. The HCXT Supplement contains information that is
specific to the Super XModel HCXT motorcycle. Read the Rider’s Handbook
and the Model HCXT Supplement thoroughly before you ride. The information
found in both documents is essential to safe riding and proper maintenance of
your motorcycle.
2Introduction
Hazard Symbol and Terms in the Supplement
The hazard symbol indicates a potential hazard to you, others, or your
motorcycle. Pay special attention to information in the Model HXCT
Supplement that begins with this symbol.
The following terms have special meaning in the Model HCXT Supplement. Be
certain you understand the meaning of each term, as the terms communicate
important information about the motorcycle and its operation and maintenance.
WARNING
Indicates a potential hazard that could injure you or others.
Caution
Indicates a potential hazard that could damage the motorcycle.
Notice
Emphasizes important information that might otherwise be overlooked.
!
3
Safety Information
This section contains information to help you operate your Super XModel
HCXT motorcycle safely and enjoyably while minimizing risk to you, your
passenger, and others. Your ability to safely operate the motorcycle depends on
your judgment and use of safe riding techniques. Motorcycling has inherent risks.
You can minimize those risks, but you can’t eliminate them completely.
We want to keep you riding. Take the time to read and understand the following
information to help minimize risk and maximize pleasure when operating the
motorcycle. Even if you are an experienced rider, read this section and the rest of
the Model HCXT Supplement before riding the motorcycle.
• Read, understand, and use the information contained in this section. This
section contains safety information specific to the Super X Model HXCT, as
well as information about general motorcycle safety.
4Safety Information
Gross Vehicle Weight Rating
Gross vehicle weight is the total weight of the motorcycle, the rider, and the
passenger.
• The weight of the motorcycle includes: the motorcycle and all its fluids; any
accessories and their contents; and any additional cargo on the motorcycle.
• The weight of the rider or passenger includes: body weight, all apparel, and
objects in or on apparel.
WARNING
Do not exceed the motorcycle’s gross vehicle weight rating. Exceeding the
weight rating can lessen stability and handling and could cause you to lose
control of the motorcycle.
The gross vehicle weight rating of the Super X Model HCXT is 1140 lb. The total
weight of the Super X Model HXCT is approximately 780 lb with a full capacity of
all fluids, and without any cargo. The combined weight of the rider, passenger, and
cargo cannot exceed 360 lb. The following example shows how to stay within the
gross vehicle weight rating.
5Safety Information
Loading
WARNING
Adding additional weight to the motorcycle can affect its stability, handling
characteristics, and safe operating speed.
Use the following guidelines when attaching cargo to the motorcycle.
• Keep cargo weight to a minimum, and keep it as close to the motorcycle as
possible, to minimize a change in the motorcycle’s center of gravity. Changing
the center of gravity can lessen stability and handling and could cause you to
lose control of the motorcycle.
• Distribute weight evenly on both sides of the motorcycle. Maintain even weight
distribution by checking cargo to make sure they are securely attached to the
motorcycle before riding and whenever you take a break while riding. Uneven
Super X Model HCXT with cargo
Item Weight
Super X with full capacity of all fluids 780 lb
Attached cargo 30 lb
Rider - dressed and ready to ride 205 lb
Passenger - dressed and ready to ride 125 lb
Total gross vehicle weight 1140 lb
6Safety Information
weight distribution, or cargo that shifts suddenly while you are riding, can make
the motorcycle hard to handle and cause you to lose control of the motorcycle.
• Do not attach large or heavy cargo such as sleeping bags, duffle bags, or tents
to the handlebars, front fork area, or front fender. Cargo placed in any of these
areas can cause instability due to improper weight distribution or aerodynamic
changes, and can cause you to lose control of the motorcycle. Such items can
also block air flow to the engine and could cause overheating that can damage
the engine.
• With the exception of highway pegs, do not attach additional weight to the
highway bar.
• Do not exceed the maximum cargo weight limit of the saddlebags (15 lbs. each)
or luggage carrier (5 lbs.), and do not attach cargo to a component not designed
for that purpose, as either of these could result in an equipment failure that
could cause you to lose control of the motorcycle.
Highway Bar
WARNING
The highway bar will not protect you from injury.
