Super Circuits DMR 1 Manuel utilisateur
Volume
1
DMR 1 & 1N,
DMR 9 & 9N
User Guide
SUPER/CIRCUITS
DMR1, DMR1N, DMR9, DMR9N, /
USER MANUAL
©SUPER/CIRCUITS
11000 NORTH MOPAC EXPRESSWAY
SUITE 300
Austin, TX 78759
Phone 800-335-9777 • Fax 866-2567-9777
Please read instructions thoroughly and keep for future reference
The product specifications and information are updated without notice.
2
RISK OF EL ECTRIC SHOCK. WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NON SERVICEABLE PARTS INSIDE PLEASE REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL
All the safety and operating instructions should be read. The improper
operation may cause permanent damage.
The triangle with the lightning flash arrowhead symbol is to alert users of the presents of
“dangerous voltage" within this enclosure and may cause an electric shock.
The exclamation point within an equilateral triangle is to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
•Use provided power adapter only.
•Handle equipment with care.
•Do not expose this equipment to open sunlight.
•Do not spill liquid on equipment. Do not use this equipment near water.
•Please power down the unit before unplugging.
•Do not Power on and off quickly (Give unit 15 to 30 seconds when powering off and on).
•Service and Installation by a qualified service technician only.
•For your safety, unplug the power before moving, installing, or replacing parts.
•Before operating make sure all the power cables and wires are properly installed.
•Avoid dramatic temperature changes, dust, and humidity.
•Operating temperature ranges are from 5C~40C. (41 to 104 degree Fahrenheit.)
•Keep this unit in a well-ventilated place and away from any heat-generating objects.
•Do not block the fan and vent areas.
•Please power down the unit before unplugging.
3
Table of Contents
PRODUCT OVERVIEW
•FEATURES …………………………………………………………………..………...…………6
•PACKAGE INCLUDES …………………………………………………………….…………...7
•FRONT PANEL……………………………………………………………………………………8
•BACK PANEL………………………………………………………………………..………..…14
.
GETTING STARTED
•INSTALLATION GUIDE………………………………………………………………………...15
BASIC MENU SETUP
•INTRODUCTION TO MENU………………………………………………………………..….19
OPERATIONS
•RECORDING OPTIONS……………………………………………………………………….30
oAlarm recording setup………………………………………………………………...31
oTimer……………………………………………………………………………………35
oManual record……………………………………………………………………….…35
oMotion detection………………………………………………………………….……35
VIDEO PLAYBACK CONTROLS
•PLAY………………………………………………………………………………………..….…39
•FASTFORWARD & FASTREWIND…………………………………………………….…..…39
•SLOW FORWARD & SLOW REWIND………………………………………………………..39
•PAUSE……………………………………………………………………………………………40
•STOP……………………………………………………………………………………………..40
•IMAGE JOG DIAL……………………………………………………………………………….40
•CAMERA SELECTION……………………………………………………………………...….40
MENU OPTIONS
•SYSTEM MENU…………………………………………………………………………………41
oAUDIO INPUT…………………………………………………………………………………….……..41
oINT AUDIBLE ALARM…………………………………………………………………………………41
oEXT AUDIBLE ALARM………………………………………………………………………….……..41
oMOTION AUDIBLE ALARM…………………………………………………………………….……41
oALARM DURATION………………………………………………………………………………..….42
oDWELL TIME…………………………………………………………………………………………….42
oMESSAGE LATCH……………………………………………………………………………………….42
oTITLE DISPLAY………………………………………………………………………………………….42
oTIME DISPLAY……………………………………………………………………………………….….42
oDATE & TIME………………………………………………………………………………………..….42
oNEW PASSWORD……………………………………………………………………………………….42
oCLEAR HDD………………………………………………………………………………………….…..42
oSYSTEM RESET………………………………………………………………………………………...42
•SEARCH…………………………………………………………………………………….……42
•TIMER…………………………………………………………………………………………….43
•RECORD…………………………………………………………………………………………45
•CAMERA…………………………………………………………………………………………46
•EVENT……………………………………………………………………………………………47
4
•NETWORK SETTINGS GUIDE………………………………………………………………..46
ADVANCE OPERATION OPTIONS…………………………………………….…..64
TROUBLE SHOOTING…………………………………………………………….…65
SPECIFICATIONS…………………………………………………………………….66
COMPATIBLE DISK BRANDS…………………………………………………..….67
APPENDIX 1 INSTALLING HARDDRIVE……………………………………….…67
APPENDIX 2 RACK MOUNT………………………………………………….…….69
5
Chapter
1
Product Overview
Features
•Remote control over the Internet
•Wavelet Compression Format replaces Time-Lapse VCR + Multiplexer
•4 Audio inputs / 2 Audio outputs
•On-screen Display and RTC (Real time clock) feature.
•Support for up to 16 video input channels
•Picture-In-Picture (PIP) is available in live and playback.
•Motion detection.
•Alarm pin connector for external control
•Video loss detection
•Record up to 160 events
•Power-loss memory feature
•Support for two Removable HDDs, IDE Type for DMR 1 only.
•Multiple Search by date and time, alarm, full list
•Security password protection
6
PACKAGE INCLUDES
DMR 1 & 1N DMR 9 & 9N
OR
Digital Multiplex Recorder (with HDD cartridge)
User’s Manual Accessories pack 2 Keys for Cartridge Power Adapter and Cord
DVR Software
NOTE: Please check the package to make sure that you receive all accessories.
RISK OF EL ECTRIC SHOCK, DO NOT OPEN WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NON SERVICEABLE PARTS
INSIDE PLEASE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
7
DMR1/1N FRONT PANEL
1. REMOVABLE HDD CARTRIDGE
Refer to page.46 Appendix #1.
2. MENU
Press MENU key to enter main menu.
3. ENTER
ENTER key.
4. ZOOM
Press ZOOM key to enlarge the picture area.
5.
PIP key for Picture in Picture screen.
6. SLOW
Slow down video playback.
7. SELECT
Press SELECT key to select camera (1~16) to display full screen.
8.
4 channel display
9.
7, 9, 10, 13 channel display
8
10.
16 channel display
11. LED LIGHT
The LED lights, light under the following conditions.
•HDD : HDD is activated
•HDD Full : HDD is full
•ALARM: to disable ALARM LED light, please refer to page.13. Set Camera / ALARM
OFF. (All camera alarms should be set to OFF.)
•TIMER : Timer is enabled
•PLAY : In Play
•REC : In Recording
12. CAMERA (1-16)
Press the Camera Select (1-16) to select camera.
13. REC
Press REC to start recording.
14. REW / LEFT
REWIND: at different speeds. Press REW again to adjust speed to 1, 2, 4, 8, 16, 32.
LEFT: Under setup use as a Left button.
15. PLAY
Play recorded video.
16. STOP / DOWN
•STOP: Stop action.
•DOWN: Down key.
•
17. PAUSE / UP
•Pause action.
•Up key.
18. FF / Right
•Forward at high-speed, press FF again to adjust speed to 1, 2, 4, 8, 16, 32.
•Right: Under setup, use as a right button.
19. POWER
Press Power to turn ON / OFF.
9
DMR1/1N REAR CONNECTIONS
1. POWER
Press Power to turn ON / OFF.
2. EXTERNAL I/O
•Control external devices.
•Alarm input, external I / O explanation.
3. 75Ω/ HI
When using Loop connector, switch to HI. When video inputs are disconnected set to 75 Ω.
4. VIDEO INPUT (1-16)
Connect to video source.
5. LOOP (1-16)
Video output for cameras (1~16).
6. AUDIO IN (1-4)
Connect to audio source. Use in microphone applications.
IPS set to 25A (for NTSC) or 18A (for PAL)
4 audio inputs, select only 1 during recording.
7. AUDIO OUT (R/L)
Connect to monitor audio in or speaker.
set IPS to 25A (for NTSC) or 18A (for PAL)
With 2 mono audio outputs from the same source.
8. MONITOR
Connect to Main monitor.
9. CALL
Connect CALL to the monitor to display each screen in sequence. To set the time duration
go to the SYSTEM > DWELL TIME menu. The CALL monitor is controlled by alarm trigger
settings.
10. LAN
