INTRODUCTION

The CR87B is a precision instrument used to monitor and record temperature on a

6” circular paper chart. The CR87B may be carried as a portable instrument or

mounted in a fixed location.

The CR87B offers a variety of features to meet any temperature recording require-

ments. A combination of three temperature ranges and four chart speeds provide a

high degree of flexibility. In addition, the chart rotation may be set for single or

continuous turn operation as required by a particular application. To protect the data

being recorded the CR87B uses an automatic battery backup to maintain operation

during a power outage.

CHANGING PENS

BATTERY HOLDER

PLUG-IN AC

ADAPTER

FIG. 1

LATCH

TWO REAR KEYWAY SLOTS

FOR WALL MOUNTING

SIN

-40°/30°

-20°/50°

50°/120°

31 DAY

7 DAY

24 HOUR

6 HOUR

RANGE SPEED

PEN ADJ.

CHART ADJ.

CR87B

TEMP.

TEMPERATURE RECORDER

105

CR87B FEATURES AND CONTROLS

1. The 3 DIGIT TEMPERATURE DISPLAY shows temperature of the environment

being monitored. When the batteries are nearly discharged, the display will

alternate the display reading and “LO” to advise the operator that the batteries

are discharged and the CR87B will shortly cease operation.

NOTE: The battery backup feature of the CR87B is primarily intended for use in

situations where primary power is lost for short periods of up to 48 hours. The

CR87B is not intended to be used as a battery powered instrument. If the CR87B

is to be stored for an extended period, it is strongly advised to disconnect the

battery pack and remove the batteries to avoid damage to the instrument from

battery leakage.

2. The TEMPERATURE RANGE SELECTOR allows the user to choose the desired

temperature range for measurement and recording.

3. The CHART SPEED SELECTOR allows the user to select the time of one full

chart revolution. The corresponding chart has to be chosen according to the

desired chart speed. Chart part numbers are listed in this manual.

4. The PEN POSITION ADJUSTMENT KNOB allows the user to adjust the position

of the chart pen.

5. The CHART ADVANCE BUTTON allows the operator to set the chart to the

correct time. Press and hold the chart advance button until the desired time lines

up with the Time Pointer. The chart is rotated counterclockwise only. CAUTION:

Movement of the Chart Spindle (Item 9) by hand may cause permanent

damage to the chart mechanism.

5a.The TIME POINTER

6. TEMPERATURE ADJUSTMENT feature allows the user to adjust the reading of

the digital display during periodic calibration. The CR87B has been factory

calibrated and requires no adjustment to meet all published specifications.

7. The POWER ON/OFF / CONTINUOUS / SINGLE CHART SELECTOR allows the

user to apply power to the CR87B and to select Continuous or Single Turn for the

chart rotation. When power is first applied to the CR87B, the display will show

“888” to test each segment of the display, and the pen will move to the edge of

the chart. The pen will then move to the correct position on the chart. In the

Continuous switch position, the chart will rotate until power is removed. In the

Single Turn switch position, the chart will make one complete revolution and stop.

A blinking dot on the display (Item 1) will indicate that the chart has made one

complete revolution and stopped. To reset the chart for another revolution

place the switch in the Continuous switch position until the blinking dot goes out

and then slide the switch back to the Single Turn position. The chart will make

one complete revolution and stop.

DO NOT move the pen by hand or interrupt the pen movement. Failure to

observe this will cause the pen to read incorrectly and may result in damage to

the pen mechanism.

8. The RECORDING PEN contains special ink. The pen has a wrap-around arm

latch which makes the pen replacement “A SNAP!” To replace the pen, gently lift

up the PEN ARM, (do not over bend pen arm) release the pen latch by pushing it

down, and remove the pen; place a new pen on top of the pen arm, align the

notches on the pen arm with the notches on the pen latch and close the latch

by wrapping it around the pen holder until it is secured. Replace cap on the

pen tip when the CR87B is not used to insure long pen life. For pen installation

see Fig. 1.

9. The CHART SPINDLE holds and rotates the chart during the recording

operation. DO NOT ROTATE THE SPINDLE BY HAND AS IT MAY DAMAGE

THE INTERNAL MECHANISM.

10.The PAPER CHART is 6 inches in diameter. The replacement charts are

available from any of Sealed Unit Parts Co., Inc. authorized distributors in a

box of 60 charts each. The chart part numbers are listed on the following page.

TO INSTALL A NEW CHART disconnect power from the CR87B by selecting

OFF with the Power / Single/ Continuous Chart Selector. Place pen cap on

pen point. Gently lift the pen arm and while holding it remove the old chart.

Slide a new chart under the pen holder and the chart holding tabs. Align the

chart with the chart spindle. Apply power to the CR87B and rotate the chart by

depressing the chart advance button until the time pointer is aligned with the

line on the chart representing the right time or day. Remove the pen cap. If

desired, adjust the pen position according to the scale you wish to record.

11.The ROTATION POINTER indicates direction of chart rotation.

12.The HANDLE for carrying folds towards the back of the case to be out of the

way when CR87B is mounted on the panel or on the wall.

13.The KEYHOLE SLOTS located on the back of the case are provided for wall or

panel mounting.

14.The FRONT COMPARTMENT under chart was designed to store the battery

holder for battery backup as well as the connection for the adapter box.

15.The REMOTE TEMPERATURE SENSOR is interchangeable. The furnished 4"

stainless steel sensor has 15 feet of cable. The temperature sensor is an

electronic digital proprietary design for precision and very high interference

immunity. It utilizes the standard RCA connector. The sensor cable may be

extended with an extension cable available from Sealed Unit Parts Co., Inc. or

its distributors.

16. The BATTERY HOLDER is stored in the front compartment for backup batteries.

Use of 8 alkaline “AA” batteries is required for proper operation.

17.The 12VDC PLUG IN WALL ADAPTER provides primary power for the CR87B.

Alternate sources of 12 Volt power may also be used. This allows use of the CR87B

in automotive, marine or other mobile applications.

18.The POWER CONNECTOR is a connection point for the 12VDC wall adapter or

alternate source of 12VDC power.

19.Back Brace for counter top use.

CHARTS

Temperature Chart Speeds

Ranges 6 Hours 24 Hours 7 Days 31 Days

-40°F to +30°F CR87-4 CR87-1 CR87-7 CR87-19

-20°F to +50°F CR87-5 CR87-2 CR87-8 CR87-20

+50°F to +120°F CR87-6 CR87-3 CR87-9 CR87-21

-40°C to 0°C CR87-13 CR87-10 CR87-16 CR87-22

-30°C to +10°C CR87-14 CR87-11 CR87-17 CR87-23

+10°C to +50°C CR87-15 CR87-12 CR87-18 CR87-24

SPECIFICATIONS

Temperature Scale Selectable -40°F to +30°F, -20°F to +50°F,

(Fahrenheit Model) +50°F to +120°F

Temperature Scale Selectable -40°C to 0°C, -30°C to +10°C,

(Celsius Model) +10°C to +50°C

Chart Speed Selectable 6 Hours, 24 Hours, 7 Days, 31 Day

Chart Speed Accuracy +/-1%

Chart Diameter 6 Inches

Temperature Display 3 Digit LED 0.5"

Temperature Accuracy +/-2°F (+/-1°C)

Temperature Sensor Stainless steel tip submersible with 15 ft. of

cable

Recording Pen Ink Type

Power Supply 120 VAC, 50/60 Hz. or 220/240 VAC, 50Hz.

Battery Backup 8 Alkaline “AA” cells (Not included)

Battery Life 48 Hours

Operating Ambient

Temperature Range +32°F to +120°F (0°C to +49°C)

Relative Humidity 96% maximum

Dimensions 9 ¼” x 7 ¼” x 2 ¾”

Weight 4 lbs., 7 oz.

CAUTION: The Temperature Recorder should be placed outside the chamber being

monitored. DO NOT PLACE THE RECORDER DIRECTLY IN AREAS OF EXTREME

TEMPERATURES, HIGH HUMIDITY OR HEAVY CHEMICAL CONTENT.
