SunSynk SSCLK3.1 Manuel utilisateur
Rev. 1 (03/10/21)
Power-Maker Battery
SSCLK3.1
SSCLK5.6
Global Tech China Ltd, 3 Floor, Wai Yip Industrial Building.171 Wai Yip Street,
Kwun Tong, Kowloon, Hong Kong.
Tel: +852 2884 4318 Fax: +8522884 4816
www.sunsynk.com / [email protected] / www.globaltechhk.com
INDEX
1. INTRODUCTION ........................................................................................................................ 3
2. ANC BATTERY CELLS .................................................................................................................. 4
3. SAFETY ..................................................................................................................................... 6
4. BATTERY TESTING EQUIPMENT AND CONDITIONS .................................................................... 7
4.1. APPEARANCE ............................................................................................................................ 7
4.2. MEASUREMENT APPARATUS ........................................................................................................ 7
4.3. STANDARD TEST CONDITION ........................................................................................................ 7
4.4. REST PERIOD ............................................................................................................................. 7
5. BATTERY MANAGEMENT SYSTEM ............................................................................................. 9
6. CASE STRUCTURE .................................................................................................................... 11
7. PACKAGING ............................................................................................................................ 12
8. APPROVALS AND CERTIFICATES .............................................................................................. 13
9. APPROVALS AND CERTIFICATES .............................................................................................. 14
9.1. LONG TIME STORAGE ................................................................................................................ 14
9.2. OTHERS ................................................................................................................................. 14
10. WARRANTY .......................................................................................................................... 14
10.1. WARRANTOR ........................................................................................................................ 14
10.2. PRODUCTS ............................................................................................................................ 14
10.3. PRODUCT WARRANTY ............................................................................................................. 14
10.4. PERFORMANCE WARRANTY ...................................................................................................... 15
10.5. WARRANTY OBLIGATIONS ........................................................................................................ 15
10.6. PRODUCT SUITABILITY ............................................................................................................. 16
10.7. WARRANTY TERM .................................................................................................................. 16
10.8. PERSONS ENTITLED TO MAKE WARRANTY CLAIMS ........................................................................ 17
10.9. CLAIM NOTICE ....................................................................................................................... 17
10.10. WARRANTY LIMITATIONS ....................................................................................................... 17
10.10.1 EXCLUDED WARRANTY CLAIMS ................................................................................................... 17
10.10.2 INTERNET CONNECTIVITY ........................................................................................................... 18
10.11. GENERAL ............................................................................................................................ 18
3
1. INTRODUCTION
The Sunsynk Power-Maker Battery has a revolutionary design that allows it to be both
wall or rack mounted. It does not require additional components as it comes complete
with all accessories.
Featured on the front of the Power-Maker Battery is a blue strip which glows indicating
that the component is working correctly. Included within the unit are cells produced by
China’s top cell manufacturers, ANC.
Parameter SSCLK3.1 SSCLK5.63 Remark
Rated Capacity Typical 62Ah 115Ah Standard discharge (0.2C5A) after the
standard voltage
Minimum 60Ah 110Ah
Cell Voltage Nominal
Voltage 3.2V 3.2V Mean Operation Voltage
Internal Impedance ≤0.65mΩ ≤0.65mΩ
Internal resistance measured at AC 1kHz
after the battery has 50% charge.
(This measurement requires new batteries
and is conducted within one week of shipment
with less than 5 cycles)
Dimension
Depth 24.5mm 24.5mm
Initial dimension. Width 140.5mm 140.5mm
Height 160.5mm 160.5mm
Rapid charge
based on cell
voltages
Constant
Current 110A 110A
Charge time: Approx. 1.5h@≥10°C Constant
Voltage 3.65V 3.65V
Cut Off 0.01C5A 0.01C5A
Standard
discharge per cell
Constant
Current 12A
0.2C
Cut Off
Voltage 5V
Volumetric Specific Energy 295Wh/L Approximately
Gravimetric Specific Energy 139Wh/kg Approximately
Combination Method 110Ah 110Ah
Factory Voltage per Battery
Pack 51V (40%-60%) Mean Operation Voltage
Cut Off Voltage per Battery
Pack 42V
Charging Voltage per Battery
Pack 54.75V
Internal Impedance per Battery
Pack ≤40mΩ
Internal resistance measured at AC 1kHz
after 50% charge. The measure must use the
new batteries within one week after shipment
and cycles less than 5 times.
Standard Charge
Constant
Current 20A 20A
Charge Time: Approx. 6h Constant
Voltage See Above
Cut Off 0.02CA
Maximum Continuous Charge
Current 60A 110A When 0°C>T ≥-10°C
4
Maximum Continuous
Discharge Current 60A 110A
Operation
Temperature
Range
Charge 0~45°C
60±25%R.H. Bare Cell
Discharge -20~55°C
Storage Temperature Range
Less than 12 months: -
10~45ºC
60±25%R.H. at the shipment state
Less than 3 months: -
10~45ºC
Less than 7 days: -
10~45ºC
Dimensions 442 x 520 x 132mm Case Included
Weight 28.5kg
2. ANC BATTERY CELLS
ANC was found in May, Shangrao economic development zone. Jiangxi province, the area is
30 acres. We focus on R&D, production and sales of power batteries; provide effective security
solutions to clean energy storage and conversion. We collaborate with top experts, partner
with domestic and foreign well-known research institutions to achieve a continuous innovation
target. Embracing the belief of "excellent brand, innovative technology, trustworthy quality and
win-win concept", we pursuit the leading position in the battery industry
5
6
3. SAFETY
When installing or operating the battery, please consider the following safety instructions:
Do not immerse the battery in water or allow it to get wet.
Do not use or store the battery near sources of heat such as a fire or heater.
Do not use any chargers other than those recommended by Sunsynk.
Do not reverse the positive(+) and negative(-) terminals. Do not connect the battery directly
to wall outlets.
Do not put the battery into a fire or apply direct heat to it.
Do not short-circuit the battery by connecting wires or other metal objects to the positive(+)
and negative(-) terminals.
Do not pierce the battery casing with a nail or other sharp object.
Do not try to open it with a hammer or step on it.
Do not strike, throw or subject the battery to severe physical shock. Do not directly solder
the battery terminals.
Do not attempt to disassemble or modify the battery in any way.
Do not use the battery if it gives off an odour, generates heat, becomes discoloured or
deformed, or appears abnormal in any way. If the battery is in use or being recharged,
remove it from the device or charger immediately and discontinue use.
Do not use or store the battery where it is exposed to extreme heat or direct sunlight. This
can also reduce battery performance and/or shorten service life.
If the battery leaks and electrolyte solution get into your eyes, do not rub them. Instead,
rinse them with clean running water and immediately seek medical attention. If left as is, the
electrolyte can cause eye injury.
7
4. BATTERY TESTING EQUIPMENT AND CONDITIONS
4.1. Appearance
There shall be no such defect as scratch, bur and other mechanical scratches, and the
connector should be no rust dirt. For the structure and dimensions, see the attached drawing
of the battery.
4.2. Measurement Apparatus
1. Dimension Measuring Instrument
The dimension measurement shall be implemented by instruments with an equal or more
precision scale of 0.01mm.
2. Voltmeter
The standard class specified in the national standard or more sensitive class has inner
impedance less than 10 KΩ/V.
3. Ammeter
Standard class specified in the national standard or more sensitive class. Total external
resistance, including ammeter and wire, is less than 0.01Ω.
4. Impedance Meter
Impedance shall be measured by a sinusoidal alternating current method(AC 1kHz LCR
meter).
4.3. Standard Test Condition
The test should be conducted with new batteries within one month after shipment from our
factory, and the cells shall not be cycled more than five times before the test. Unless otherwise
defined, test and measurement shall be done under a temperature of 23±2℃ and relative
humidity of less 75%, air 86Kpa~106Kpa.
4.4. Rest Period
Unless otherwise defined, 30min, rest period after charge, 30min, rest period after discharge.
8
Figure: Capacity retention curve of cell with 1C charge/discharge rate at room temperature
Experimental and fitted (fitting based on the steady decrease range, 2000-2800 cycles)
capacity retention curve.
The cycling test is time-consuming. Therefore, we predicted the cycling life based on the fitted
curve. The predicted cycling life is over 5000 cycles and is for reference only. The cycling test
of the cell is still running.
9
5. BATTERY MANAGEMENT SYSTEM
1) The BMS is designed for 15/16 series lithium battery.
2) The BMS have all functions, which are:
Overcharge detection function;
Over-discharge detection function overcurrent detection function short detection function;
Temperature detection function balance function communicate function Alarm function;
Total capacity function;
Storage history function;
Polarity Reverse Connection Protection Function.
Cell overcharge protection
Overcharge detection voltage 3.65±0.025V
Overcharge detection delay time
Typical:1.0s
Overcharge release voltage 3.38±0.02V
Cell over-discharge
protection
Over-discharge detection
voltage 2.5±0.02V
Over-discharge detection delay
time
Typical:1.0s
Over-discharge release voltage 2.9±0.02V or charge release
Over-current protection
Discharge Over-current
protection current1 130±10A
Discharge Over-current
detection delay time 1
1S
Discharge Over-current
protection current2 150±10A
Discharge Over-current
detection delay time2
≤100m±50ms
Charge OC protection current 130±10A
Overcharge detection voltage 3.65±0.025V
10
Short protection
Short protection current 350±10A
Protection condition Load short
Detection delay time ≤300us
Protection release condition Charging release
Temperature(T)
protection
Charge high T protection
55±3
℃
Charge high T recover
50±5
℃
Discharge high T protection
65±5
℃
Discharge high T recover
60±5
℃
Charge low T protection
-5±5
℃
Charge low T recover
0±5
℃
Discharge low T protection
-20±5
℃
Discharge low T recover
-15±5
℃
Balance Balance threshold voltage 3.45V
Communication
It has RS232 and RS485 standard communication interface, it can
real-time monitoring the capacity of battery bank, the voltage,
current, environment temperature, and charging/discharging
current.
Alarm It has over-temperature, over charge, under-voltage, over- current,
short circuit alarm function.
