Sunload mVELO Mode d’emploi
1
Pedelec/e-Bike Charger mVELO
Manual and warranty.
Made in
Germany
2
The CE sign stands for Commanauté Europénne, i.e the Euro-
pean Community, meaning that all products coming with that
sign comply with all EU health and safety directives applicable
to the corresponding product category. This is the condition for
marketing of a product in European Union. The CE sign is the manufacture’s
declaration that the product meets the applicable EU directives and thus may
be safely operated. In addition, the SUNLOAD has the compliance with CE
regulations confirmed by an independent institute.
Pedelec/e-Bike Charger mVELO
The universal charger (110/230V AC power supply, 12/24V car, solar modules)
for Li-lon pedelec batteries with integrated measurement function (W, Wh, V).
The technology “made in Germany” is the highest level of product quality and safety.
It labels SUNLOAD products.
3
Dear Customer!
With your new Pedelec Charger mVELO you will experience a new
dimension of independence.
Charge comfortably and safely the Li-Ion battery of your e-Bike or LEV
(Light Electric Vehicle, e.g. even pedelec, e-scooter, e-wheelchair,...)
from the sun, car battery or main and stay mobile!
Let the sun work for you. You can extend the range with our light-
weight and foldable solar panels on your long trips or you can save
the solar power during a day on the permanently installed photovol-
taic system (carport, camper van, caravan) in a car- or solar-battery
and charge your pedelec in the night.
In one hour you can recharge max. 60 Wh, which corresponds to a
range of max. 10 km.
Follow with the unique energy meter the charging of your pedelec, so
you can easily check the consumption of the last tour and the battery
ageing.
Enjoy your new Pedelec Charger mVELO.
Your SUNLOAD Team
4
Table of contents
About this manual ............................................................................................ 5
Safety advice .................................................................................................... 6
Scope of supply and optional accessories ........................................................... 7
Which solar panel fits to mVELO? ....................................................................... 8
How to put the device into operation ................................................................ 9
Controls ............................................................................................... 9
Electrical connections......................................................................... 10
Display .............................................................................................. 11
Usage ............................................................................................................. 12
Input: how to charge from solar power ............................................... 12
Input: charge with a 12 V car adapter (CLA) ......................................... 13
Output: charge the pedelec battery .................................................... 13
How to check the battery status ......................................................... 14
Batteries compatibility ....................................................................... 15
The SUNLOAD energy management ................................................................. 16
Technical Data ................................................................................................. 16
Trouble shooting ............................................................................................. 17
Warranty ........................................................................................................ 17
Declaration of Conformity ............................................................................... 18
Cleaning ......................................................................................................... 19
Disposal .......................................................................................................... 19
SUNLOAD customer service - What can we do for you? ....................................... 19
5
About this manual
This mVELO comes with a multilevel safety system. Nevertheless we recom-
mend you to read this manual carefully. In order to avoid any risk or injuries
make sure to operate mVELO only as described in this manual. Please keep
this manual for reading it from time to time. When passing on the device,
make sure to hand over this manual as well.
Please note that we can have a revision of this manual on our homepage.
Symbols used in this manual:
This sign warns you of the risks of injury.
This sign warns you of the risk of explosion.
This sign warns you of potential damage.
6
The device can be used for charging of Li-lon batteries with a tting
acceptable voltage. There is a re danger by using of other types of
batteries or voltage (for example NiMH)!
Do not expose to open re, water, rain, snow or wet environment. Risk of
explosion or short circuit! Protect the device from getting wet (e.g. in case
of rain) and direct sunlight!
When transporting your mVELO in a bag, keep out any beverages or other
liquids, to prevent the electronic components from being damaged.
The temperature of the device may rise up to 60°C approximately, when in
use. Keep away any materials which are not suitable for that temperature!
Do not keep the device or its accessories within the reach of children or
animals! Keep away from children any small parts which might be
swallowed! If any object has been swallowed, immediately call a doctor!
Do not operate the device if the casing or a cable has been damaged.
Touching live parts may cause electric shock! Do not use the device for
operating life support or other medical equipment!
Safety advice
If the device does not work properly, please read the trouble-shooting section
before calling customer service.
Do not use other accessories than recommended by SUNLOAD!
7
Scope of supply and optional accessories
Scope of supply
SUNLOAD Pedelec Charger mVELO
12 V car adapter cable (CLA cable), 3 m
Operating manual
Recommended optional accessories (www.sunload-shop.com)
SUNLOAD foldable solar panel 30 Wp (0.9 kg)
SUNLOAD foldable solar panel 62 Wp (1.4 kg)
Solar modules 25 - 100 Wp (Uoc max. 30 V)
Power supply 100 V - 240 V AC to 24 V / 2.7 A DC
8
Which solar panel fits to mVELO?
The mVELO was specially designed to work highly efficiently with different
solar panels. The connector must be SAE plug or DC plug round hollow type
5.5 x 2.1mm (These are standard for solar panels of SUNLOAD).
Be careful when using connector cables from other manufacturers! The plugs may have
the inverse polarity! Double check it with the polarity symbol at the mVELO label.
The acceptable DC input voltage of the mVELO is limited to 30 V.
Please note that the open circuit voltage of the solar module must be lower than 30 V;
otherwise mVELO will be damaged!
As regards the size of the module, please note that the maximum power
the device may process amounts to 60 W. Above an input power of 60 W
the charge current will be automatically limited. Depending on the weather
conditions, we recommend to use solar panels with a peak power from 25 W
to 100 Watt. Higher panel power will not accelerate the charging process!
Please note that even a minor shadow on the solar panel surface considerably
reduces its power. When using a 62 Wp solar panel perfectly oriented towards
the sun – in Berlin, you will generate 45-50 Wh per hour. This amount of
energy correspondences a range of 5-8 km under realistic conditions
(www.Extraenergy.org).
9
How to put the device into operation
Controls
You may control the device with a push button.
Push button functions
Push and release Switch between display modes (see also “Display”)
Press and hold for
2 sec.
„WhOUT“ reset Wh to 0.0 Wh, only if you have „WhOUT“ in the display
Push button
Switch between
display modes
Display
Numeric display/
charge level
10
Electrical connections
Battery connector
for connection to Li-Ion batteries.
DC-input socket (5,5x2,1mm)
to connect solar panels,12 V-car batteries (by
adapter cable) or a power supply (100 V - 240 V).
Input: 10.5 V - 30 V DC, max. 2.5 A
