[PRODUCT NO. & NAME] Issue: A Page 1 of 9
SERVICE MANUAL
EM0480
Coffee Burr Grinder
ISSUE: A
DATE: 7 April 2005
[PRODUCT NO. & NAME] Issue: A Page 2 of 9
SPARE PARTS LIST
Note: Not all parts are available as spare parts. Please check price list.
Item
Description
No. of
Parts
Supplier’s
Code
Sunbeam
Part No.
1
Hopper Lid
1
C3-1008
EM0480101
2
Hopper
1
C3 -1005
EM0480102
Hopper
assembly
3
Blade
2
C3 -2106
4
Spring
2
38 -5092
5
Hopper Base
1
C3 -2006
6
Hopper Small Cover
1
C3 -2004
8
Dial
1
C23-1131
9
Dial Insert
1
C3 -2015
10
Safety Switch Bracket
1
C3 -2005
11
Dial Base
1
C3 -2004
12
Dial Spring
4
38-5094
13
Screw
4
31-3004-SS
14
Screw
4
31-1006
7
Screw
2
31-5006-SS
EM0480110
–Upper &
lower burr
ass’y
15
Top - Burr
1
C3-1004
16
Top Burr Base
1
C23-8060
20
Burr Blade
1
C23-1150
17
Coffee Cover
1
C3-2003
18
Cap Nut
1
C23-1145
19
Inter Washer
1
34-7028
21
Bottom Burr
1
C213-8059
22
Safety Switch Spring
1
38-5093-2
23
Micro Switch
1
089-8024-
01
24
Safety Switch Rod
1
C3-1012
25
Paddle Rod
1
C23-2215
26
Paddle
1
C3-9024
EM0480113
27
Paddle Plate
1
C23-2212
28
Bearing Washer
2
C23-2226
29
Thrust Bearing Plate
1
C3-2007
30
Ball 040613
6
C23-8064
31
Coffee Chute
1
C3-2002
32
Coffee Outlet
1
C3-1007
33
Lock Button
1
C3-1007
34
Lock Spring
1
38-5093-1
35
Screw
3
31-1067
36
Main Housing
1
C23-1130
37
Push Switch Bracket
1
C3-2001
38
Push Switch Spring
2
38-5095
39
Micro Switch
1
089-82014-
02
40
Push Switch Leaf
1
C3-2000
[PRODUCT NO. & NAME] Issue: A Page 3 of 9
Item
Description
No. of
Parts
Supplier’s
Code
Sunbeam
Part No.
41
Group handle locator small
1
C3-1003
EM0480106
42
Group handle locator large
1
C3-1010
EM0480107
43
T Piece
1
C3-1002
44
Push Switch Rod
1
C23-1143-
SS
45
Screw
2
31-1006
46
Screw
2
31-1100
47
NBR Seal
1
45-6196
48
Gear Box
1
18-8100
49
Screw
4
31-1020
50
Motor Group
1
50-2043
51
Screw - 1
4
31-1064
52
Gasket
4
34-2014
53
Rubber Cushion
4
45-6194
54
Motor Bracket
1
C23-2209
55
Toggle Switch Bracket
1
C3-9025
56
Toggle Switch
1
50-1060
57
Blade
1
20-2035
58
Screw- 1
3
31-1141
59
Storage container lid
1
C3-1009
EM0480103
60
Storage container
1
C3-1006
EM0480104
61
Rubber mat
1
C3-6003
EM0480105
62
Base Casting
1
C23-1132
63
Screw - 1
9
31-1076
64
Base Cover
1
C3-5000
65
Feet Rubber
4
45-6195
66
Screw - 1
8
31-1339
67
Power Cord
1
17-33002-
1B
68
Cable Clamp
1
C3-2112
69
Screw - 3
6
31-1005
70
Location Pin
1
C23-2216-
SS
Burr cleaning brush
EM0480108
Spacer
EM0480109
Silicone Spout
75-054
EM0480112
[PRODUCT NO. & NAME] Issue: A Page 4 of 9
EXPLODED VIEW DRAWING
[PRODUCT NO. & NAME] Issue: A Page 5 of 9
[PRODUCT NO. & NAME] Issue: A Page 6 of 9
[PRODUCT NO. & NAME] Issue: A Page 7 of 9
[PRODUCT NO. & NAME] Issue: A Page 8 of 9
[PRODUCT NO. & NAME] Issue: A Page 9 of 9
CIRCUIT DIAGRAM
